Hyperkernel: Push-Button Verification of an OS Kernel Luke Nelson, Helgi Sigurbjarnarson , Kaiyuan Zhang, Dylan Johnson, James Bornholt, Emina Torlak, and Xi Wang The OS Kernel is a critical component Essential for application correctness and

slide-1

SLIDE 1

Hyperkernel: Push-Button Verification of an OS Kernel

Luke Nelson, Helgi Sigurbjarnarson, Kaiyuan Zhang, Dylan Johnson, James Bornholt, Emina Torlak, and Xi Wang

slide-2

SLIDE 2

The OS Kernel is a critical component

Essential for application correctness and security
Kernel bugs can compromise the entire system

Kernel App App App

slide-3

SLIDE 3

slide-4

SLIDE 4

slide-5

SLIDE 5

Formal verification: high correctness assurance

Write a spec of expected behavior
Prove that implementation matches the spec
Goal: How much can we minimize the proof burden

IronClad

slide-6

SLIDE 6

Formal verification: high correctness assurance

Write a spec of expected behavior
Prove that implementation matches the spec
Goal: How much can we minimize the proof burden

IronClad

Proof effort: 11 person years

slide-7

SLIDE 7

Our result: Hyperkernel

Unix-like OS kernel: based on xv6
Fully automated verification using the Z3 solver
Functional correctness of system calls
Crosscutting properties (e.g., process isolation)
Limitations:
Uniprocessor
Initialization & glue code unverified

slide-8

SLIDE 8

Designing Hyperkernel for proof automation

Xv6

Syscall semantics are loop-y and

require writing loop invariants

Kernel pointers difficult to

reason about

C is difficult to model

Hyperkernel

Finite interface
Separate user and kernel spaces &

identity mapping for the kernel

Verify LLVM intermediate

representation (IR)

slide-9

SLIDE 9

Designing Hyperkernel for proof automation

Xv6

Syscall semantics are loop-y and

require writing loop invariants

Kernel pointers difficult to

reason about

C is difficult to model

Hyperkernel

Finite interface
Separate user and kernel spaces &

identity mapping for the kernel

Verify LLVM intermediate

representation (IR)

slide-10

SLIDE 10

Designing Hyperkernel for proof automation

Xv6

Syscall semantics are loop-y and

require writing loop invariants

Kernel pointers difficult to

reason about

C is difficult to model

Hyperkernel

Finite interface
Separate user/kernel spaces and

use identity mapping for kernel

Verify LLVM intermediate

representation (IR)

slide-11

SLIDE 11

Designing Hyperkernel for proof automation

Xv6

Syscall semantics are loop-y and

require writing loop invariants

Kernel pointers difficult to

reason about

C is difficult to model

Hyperkernel

Finite interface
Separate user/kernel spaces and

use identity mapping for kernel

Verify LLVM intermediate

representation (IR)

slide-12

SLIDE 12

Designing Hyperkernel for proof automation

Xv6

Syscall semantics are loop-y and

require writing loop invariants

Kernel pointers difficult to

reason about

C is difficult to model

Hyperkernel

Finite interface
Separate user/kernel spaces and

use identity mapping for kernel

Verify LLVM intermediate

representation (IR)

slide-13

SLIDE 13

Outline

Verification workflow
Finite interface design
Demo
Evaluation & lessons learned

slide-14

SLIDE 14

Outline

Verification workflow
Finite interface design
Demo
Evaluation & lessons learned

slide-15

SLIDE 15

Overview of verification workflow

Syscall Implementation

slide-16

SLIDE 16

Overview of verification workflow

Syscall Implementation State Machine Specification pre new

ld

slide-17

SLIDE 17

Overview of verification workflow

Syscall Implementation State Machine Specification pre new

ld

slide-18

SLIDE 18

Overview of verification workflow

Syscall Implementation State Machine Specification pre new

ld

slide-19

SLIDE 19

Overview of verification workflow

Syscall Implementation State Machine Specification pre new

ld

slide-20

SLIDE 20

Overview of verification workflow

Syscall Implementation State Machine Specification pre new

ld

slide-21

SLIDE 21

Overview of verification workflow

Syscall Implementation State Machine Specification Verifier LLVM pre new

ld

slide-22

SLIDE 22

Overview of verification workflow

Syscall Implementation State Machine Specification Verifier Bug Counterexample

ld

LLVM pre new

ld

slide-23

SLIDE 23

Syscall Implementation Verifier Bug Counterexample

ld

Declarative Specification

P

LLVM State Machine Specification pre new

ld

slide-24

SLIDE 24

Syscall Implementation State Machine Specification Verifier Bug Counterexample

ld

Declarative Specification

P

LLVM pre new

ld

slide-25

SLIDE 25

Syscall Implementation Verifier Counterexample

ld

LLVM State Machine Specification pre new

ld

Bug Declarative Specification

P

Cross-cutting properties:

Correctness of reference counters
Scheduler safety property
Process Isolation

slide-26

SLIDE 26

Syscall Implementation Verifier Counterexample

ld

LLVM State Machine Specification pre new

ld

Bug

Cross-cutting properties:

Correctness of reference counters
Scheduler safety property
Process Isolation

For any virtual address in a process p, if the virtual address maps to a page the page must be exclusively owned by p.

Declarative Specification

P

slide-27

SLIDE 27

Syscall Implementation Verifier Counterexample

ld

LLVM State Machine Specification pre new

ld

Bug

Cross-cutting properties:

Correctness of reference counters
Scheduler safety property
Process Isolation

For any virtual address in a process p, if the virtual address maps to a page the page must be exclusively owned by p.

Declarative Specification

P

slide-28

SLIDE 28

Syscall Implementation State Machine Specification Verifier Bug Counterexample

ld

Declarative Specification

P

LLVM pre new

ld

slide-29

SLIDE 29

Syscall Implementation State Machine Specification Verifier LLVM Bug Counterexample

ld

Declarative Specification

P

OK Kernel Image pre new

ld

slide-30

SLIDE 30

Outline

Verification workflow
Finite interface design
Demo
Evaluation & lessons learned

slide-31

SLIDE 31

Verification through symbolic execution

Goal: Minimize proof burden
No manual proofs or code annotations
Symbolic execution
Fully automated technique, used in bug-finding
Full functional verification if program is free of loops and state is finite
Feasible when units of work sufficiently small for solving
Hyperkernel approach: Finite interface design

slide-32

SLIDE 32

Overview of techniques

Safely push loops into user space
Explicit resource management
Decompose complex syscalls
Validate linked data structures
Smart SMT encodings

slide-33

SLIDE 33

Overview of techniques

Safely push loops into user space
Explicit resource management
Decompose complex syscalls
Validate linked data structures
Smart SMT encodings

slide-34

SLIDE 34

The sbrk() system call

User space virtual address space

brk

void *sbrk(intptr_t increment)

slide-35

SLIDE 35

The sbrk() system call

increments the programs data space by increment bytes

User space virtual address space

brk

void *sbrk(intptr_t increment)

increment

slide-36

SLIDE 36

The sbrk() system call

User space virtual address space

brk

void *sbrk(intptr_t increment) increments the programs data space by increment bytes

slide-37

SLIDE 37

The sbrk() system call

Goal: Redesign sbrk(); ensuring process isolation.

User space virtual address space

brk

void *sbrk(intptr_t increment) increments the programs data space by increment bytes

slide-38

SLIDE 38

The sbrk() system call: Dealing with loops

void *sbrk(intptr_t increment)

slide-39

SLIDE 39

The sbrk() system call: Dealing with loops

void *sbrk(intptr_t increment)

slide-40

SLIDE 40

The sbrk() system call: Dealing with loops

void *sbrk(intptr_t increment)

page table root

entry

4K page

slide-41

SLIDE 41

The sbrk() system call: Dealing with loops

void *sbrk(intptr_t increment) void *sbrk_one_page()

page table root

entry

4K page

slide-42

SLIDE 42

The sbrk() system call: Decomposition

page table root

entry

4K page

void *sbrk_one_page()

slide-43

SLIDE 43

The sbrk() system call: Decomposition

PML4 table

entry

4K page page directory page table

entry

page directory

entry

page table

entry

void *sbrk_one_page()

slide-44

SLIDE 44

The sbrk() system call: Decomposition

PML4 table

entry

4K page page directory page table

entry

page directory

entry

page table

entry

alloc_pdpt(…) alloc_pd(…) alloc_pt(…) alloc_frame(…) void *sbrk_one_page()

slide-45

SLIDE 45

The sbrk() system call: Decomposition

PML4 table

entry

4K page page directory page table

entry

page directory

entry

page table

entry

alloc_pdpt(…) alloc_pd(…) alloc_pt(…) alloc_frame(…) void *sbrk_one_page()

slide-46

SLIDE 46

The sbrk() system call: Decomposition

int alloc_pdpt(int pml4, size_t index) int alloc_pd(int pdpt, size_t index) int alloc_pt(int pd, size_t index) int alloc_frame(int pt, size_t index)

slide-47

SLIDE 47

The sbrk() system call: Explicit allocation

App Kernel

Search for free page

alloc page#

1 2 3

slide-48

SLIDE 48

The sbrk() system call: Explicit allocation

App Kernel

alloc, page# success/fail

Kernel keeps track of per-page metadata: owner/type
User space searches for free page; kernel validates

slide-49

SLIDE 49

The sbrk() system call: Finite Interface

Any composition of these system calls maintains isolation

int alloc_pdpt(int pml4, size_t index, int free_pn) int alloc_pd(int pdpt, size_t index, int free_pn) int alloc_pt(int pd, size_t index, int free_pn) int alloc_frame(int pt, size_t index, int free_pn)

For any virtual address in a process p, if the virtual address maps to a page the page must be exclusively owned by p.

slide-50

SLIDE 50

Implementation

Component Lines Languages Kernel implementation 7,616 C, assembly State-machine specification 804 Python Declarative specification 263 Python Verifier 2,878 C++, Python User-space implementation 10,025 C, assembly

slide-51

SLIDE 51

Outline

Verification workflow
Finite interface design
Demo
Evaluation & lessons learned

slide-52

SLIDE 52

Demo

Hyperkernel in action
Catching a low-level bug

producing a stack trace

Catching a process isolation bug

producing a visualized counterexample

slide-53

SLIDE 53

Outline

Verification workflow
Finite interface design
Demo
Evaluation & lessons learned

slide-54

SLIDE 54

What was the development effort?

Write a state machine specification
Relate LLVM data structures to

abstract specification state

Write checks for the representation

invariants if needed.

slide-55

SLIDE 55

What was the development effort?

Adding and verifying a system call usually takes < 1 hour
Write a state machine specification
Relate LLVM data structures to

abstract specification state

Write checks for the representation

invariants if needed.

slide-56

SLIDE 56

Is the design effective for scalable verification?

45 minutes on a single core machine
15 minutes on an 8-core Intel i7
Not sensitive to system parameters (e.g., number of pages)
Design is effective for scalable verification

slide-57

SLIDE 57

Conclusion

Feasible to verify simple Unix-like OS kernel
Automatic verification through symbolic execution
Make interface finite
Decompose complex system calls to scale verification
Verifiability as a first-class system design concern
http://locore.cs.washington.edu/hyperkernel
