Circadian Release of Propionate for Antihypertensive Therapy HUST-CHINA BACKGROUND A Novel Method Antihypertensive Drug Engineered Bacteria Interacts with Olfr78, a GPCR expressed in smooth muscle cells of Propionate small blood
SLIDE 2
SLIDE 3
Engineered Bacteria Antihypertensive Drug
A Novel Method
SLIDE 4
Jennifer L. Pluznick, et al. PNAS, 2012, 11, 4410–4415
Propionate
Interacts with Olfr78, a GPCR
expressed in smooth muscle cells of small blood vessels
Induce vasodilatation and
hypotension
SLIDE 5
A Novel Method
Engineered Machine
Propionate Oscillator
SLIDE 6
Our Progresses
SLIDE 7
Background
Wood-Werkman Reaction
Haller T, Buckel T, Rétey J et al. Biochemistry, 2000, 39(16): 4622-46229.
SLIDE 8
Plasmids Construction
- Insert four genes into
pET-28a(+) plasmids
- Transform them into
BL21 E.coli strains
SLIDE 9
Protein Expression
Marker sbm ygfD ygfG ygfH Control Successfully validate the expression of sbm, ygfD, ygfG, and ygfH. 170 130 100 70 55 40 35 25 15 (KDa)
SLIDE 10
22787.7 23810.4 24051.3 24986.3 25765.1 20000 21000 22000 23000 24000 25000 26000 27000
4.49% 9.41% 9.65% 13.07%
**
Concentration of propionate (mg/L)
n.s. n.s. n.s.
P<0.01
Control ygfH ygfG sbm ygfD
HPLC analysis of wild-type BL21 and recombinant BL21 with four genes (4hrs after IPTG induction)
Production Increasement
Propionate's output can be increased over 10% with ygfD
SLIDE 11
Question How can we make ygfD expressed periodically?
OSCILLATOR !
SLIDE 12
Our Progresses
SLIDE 13
Hybrid Promoter
Activation
from araBAD promoter
Repression
from lacZYA promoter
+Arabinose +AraC
- IPTG
+LacI Hybrid Promoter
SLIDE 14
+Arabinose +IPTG
lacl
Hybrid Promoter
araC
Hybrid Promoter
Oscillator
- IPTG
SLIDE 15
Issues
SLIDE 16
The Single-Cell Level
Delay Differential Equations (DDEs) AraC’s oscillation, τ = 30min, T = 11 hours
τ ~N(30.0,1.02)min T1 = 644.8min, T2 = 639.2min, T3 = 654.1min, T4 = 642.6min, T5 = 645.1min
Random Period
SLIDE 17
The Multi-Cell Level
A group of genetic oscillating cells can oscillate as well as a single one does.
SLIDE 18
Adjusting Period
The period range is limited to 44min – 50min when altering Arabinose and IPTG, with τ = 2 min.
Not Satisfying
SLIDE 19
Period increases linearly and unlimitedly when delay τ increases.
Adjusting Period
SLIDE 20
Achieve rapid protein degradation Reporter pET-28a(+) +Arabinose +IPTG
Oscillator Construction
LAA
lacl
Hybrid Promoter LAA
araC
Hybrid Promoter LAA
mRFP pACYCDuet-1
SLIDE 21
Immobilized cell with oscillator expresses RFP periodically
LAA
araC mRFP
Hybrid Promoter LAA
Validation of constructed pET-28a(+)
Validation of Oscillator
SLIDE 22
Validation of Oscillator
Fluorescence density of multi- cells changes in an
- scillating way
SLIDE 23
Wet-Lab & Modeling
Wet-lab work and modeling results consistent with each
- ther well.
SLIDE 24
Our Progresses
SLIDE 25
Future Plan
Circadian release of high-level propionate Replace mRFP with ygfD
LAA
araC mRFP Hybrid Promoter
LAA LAA
araC mRFP Hybrid Promoter
LAA
SLIDE 26
- Regulating the period of propionate release under the direction of modeling
- Mathematically simulate the “in vivo” environment
Modeling
Future Plan
SLIDE 27
Transfer the engineered machine into Bifidobacterium Bifidobacter dobacteriu ium E.col coli
Future Plan
SLIDE 28
Human Practice
A Lecture In The High School Collaborations Crosswords Game
SLIDE 29
Human Practice
A Talk to The Public Questionnaire
SLIDE 30
Accomplishments
I. Subcloned sbm, ygfG, ygfH and ygfD, constructed and documented the expression vectors of the four genes II. Constructed the oscillator with mRFP and LAA tags
- III. Found the gene that can realize the
highest production of propionate
- IV. Achieved the periodical fluorescence
intensity simulated working process of the oscillator V. Analyzed the sensitivity and the robustness of the oscillator, providing ways to adjust for a wanted period
- VI. Verified that oscillators in multi cells
can oscillate as well as in a single one
- VII. A new application in hypertension
treatment VIII.Shared information with WHU & HZAU, and help HZAU complete a biobrick
SLIDE 31
Acknowledgement
Guangdong Shang Jingnan Lu Jeff Hasty Roya Mahmoudi
