Human-level control through deep reinforcement

Liia Butler

But first... A quote

"The question of whether machines can think... is about as relevant as the question of whether submarines can swim" Edsger W. Dijkstra

Overview

• 1. Introduction
• 2. Reinforcement Learning
• 3. Deep neural networks
• 4. Markov Decision Process
• 5. Algorithm Breakdown
• 6. Evaluation and conclusions

Introduction

Deep Q-network (DQN)

• The agent
• Reinforcement learning plus
• Deep neural networks
• Goal: General artificial intelligence
• How little do we have to know to be intelligent? Can we solve a wide range of challenging

tasks?

• Pixels and game score as input

Reinforcement Learning

• Theory of how software agents may optimize their control of the environment
• Inspired by the psychological and neuroscientific perspectives on animal

behavior

• One of the three types of machine learning

http://en.proft.me/media/science/ml_types.png

Space Invaders

Deep Neural Networks

• An architecture in deep learning, type of artificial neural network
• Artificial neural network: a network of nodes representing processing elements that are highly

connected, working together towards specific problems, like in biological nervous system

• Multiple layers of nodes with increasing abstraction of the data
• Extract high-level representations from raw data
• DQN uses "deep convolutional network"
• 84 x 4 x 4 image produced by preprocessing map
• three convolutional layers
• Two fully connected layers
• http://www.nature.com/nature/journal/v518/n7540/carousel/nature14236-f1.jpg

http://www.nature.com/nature/journal/v5 18/n7540/images/nature14236-f4.jpg

• State
• Action
• Reward

Markov Decision Process

http://cse-wiki.unl.edu/wiki/images/5/58/ReinforJpeg.jpg

What these mean for DQN

• State - What is going on?
• The goal was to be universal so it's represented by screen pixels
• Action - What can we do?
• Ex. moving, direction, buttons
• Reward - What's our motivation?
• Points, lives, etc.

http://www.retrogamer.net/wp-content/uploads/2014/07/Top-10-Atari-Jaguar-Games-616x410.png

How is DQN going to do this?

• Preprocessing - Reduce input dimensionality, max value for pixel color,

remove flickering

• ε-greedy policy - choosing the action
• Bellman equation - optimal control of environment, action-value function
• Using a function approximator to estimate the action-value function
• Loss function and Q-learning gradient
• Experience replay - building a data set from agent's experience

Algorithm Breakdown

Key D = Memory, or data set N = Number of experience tuples in replay memory Q = "quality" function Θ = The weight M = Number of episodes s = sequence x = observation/image Φ =preprocessing sequence T = time-step at which game terminates ε = probability in ε-greedy policy a = action s = state y = target r = reward ν = reward discount factor C = Number of updates to Q

Algorithm Breakdown

Key D = Memory, or data set N = Number of experience tuples in replay memory Q = "quality" function Θ = The weight M = Number of episodes s = sequence x = observation/image T = time-step at which game terminates ε = probability in ε-greedy policy a = action Φ =preprocessing sequence s = state y = target r = reward ν = reward discount factor C = Number of updates to Q

ε-greedy policy

ε-greedy policy

• Exploration, random
• Exploitation, best one according to the Q value

How to choose the action 'a' at time 't'

Algorithm Breakdown

Key D = Memory, or data set N = Number of experience tuples in replay memory Q = "quality" function Θ = The weight M = Number of episodes s = sequence x = observation/image T = time-step at which game terminates ε = probability in ε-greedy policy a = action Φ =preprocessing function s = state y = target r = reward ν = reward discount factor C = Number of updates to Q

Experience Replay

Experience Replay

1. Take action 2. Store transition in memory 3. Sample random minibatch of transitions from D 4. Optimize using gradient descent on target 'y' and Q-network

Optimizing the Q-Network

• Bellman Equation:
• The loss function we have:
• From this:
• Gives us the Q-learning gradient:

Algorithm Breakdown

Key D = Memory, or data set N = Number of experience tuples in replay memory Q = "quality" function Θ = The weight for approximator M = Number of episodes s = sequence x = observation/image T = time-step at which game terminates ε = probability in ε-greedy policy a = action Φ =preprocessing sequence s = state y = target r = reward ν = reward discount factor C = Number of updates to Q

Breakout!

Evaluation and Conclusions

• Agents vs. Pro gamers
• Action at 10 Hz (an action every 0.1 seconds), every 6th frame
• At 60 Hz (every 0.017 seconds), every frame, only 6 games > 5% better performance
• Controlled human conditions
• Out of the 49 games
• 29 at human or above
• 20 below

http://www.nature.com/nature/journal/v518/n7540/images_article/nature14236-f2.jpg

http://www.nature.com/nature/journal/v518/n7540/images_ article/nature14236-f3.jpg

29 out of 49 20 out of 49

Questions and Discussion

• What do you think are some non-gaming applications of deep reinforcement

learning?

• Do you think that comparing with the "professional human game tester" is a

sufficient enough of an evaluation? Is there a better way?

• Should we even have a general AI, or are we better off with domain specific

AIs?

• Are there other consequences besides a computer beating your high score?

(Have we doomed society?)
