Multiple 5G slices concurrently operated on the same infrastructure – with different distribution of control and user plane

• 2. Dedicated Functions at Cloud

Edge Requires security, latency and reliability. (distributed control and user plane)

• 1. Centralized + Distributed

Fully fledged functions distributed across network.

Ref: NGMN 5G White Paper

• 3. Basic centralized CP, distributed

UP Basic control plane and user plane capabilities, no mobility. (central control and distributed user plane)

HUAWEI TECHNOLOGIES CO., LTD., Proprietary Page 5

Personalized applications in cloudlet require low latency (<10 ms), high reliability, mobility support:

• Cognitive assistance (e.g., wearable cognitive devices for healthcare, Google glass, Olympus mobile eye trek)

Ref: The case for VM-based Cloudlets in Mobile Computing, IEEE Pervasive Computing.

• V2V (Vehicle-to-vehicle) and V2I (Vehicle-to-infrastructure)

USER DRIVEN

HUAWEI TECHNOLOGIES CO., LTD., Proprietary Page 6

Flatter (tier 2 and 3) Internet Peering

Lower Transit cost (#1 for Tier 2 ISP) End user experience, latency (#1 for content providers) Control over routing, redundancy (#1 for Yahoo, NetFlix)

Consolidated fixed-mobile Data Centers

Orange NG-POP plans to have common data centers for Fixed and mobile networks. Session continuity between fixed/mobile sessions.

Operator requirements for DC consolidation, and flatter peering by ISPs.

NETWORK DRIVEN

HUAWEI TECHNOLOGIES CO., LTD., Proprietary Page 7

[Ref: 4G Americas Recommendations on 5G Requirements and Solutions] Flexible mobility means that there may be a range of options based on device type, application, application context or statically configured. Flexible mobility consists of managing mobility and tracking/reachability to save power. Examples with Idle mode mobility on a per-device basis, and active mode mobility on a per-application basis is shown below:

HUAWEI TECHNOLOGIES CO., LTD., Proprietary Page 8 Signaling, data traffic

Signaling and data traffic is growing exponentially. Variety of applications including those with low delay bound, high bandwidth in future. In the future, OTT players will form symbiotic relationship with carriers via dynamic SLA offerings

Future core Network should design for massive signaling, low latency and data demand.

2 4 6 8 10 12 14 2012 2013 2014 2015 2016 Traffic (Exabytes) Signaling (100 Trillion msg)

References: Cisco VNC – Data traffic Growth Oracle – LTE Signaling Traffic Growth

Revenue growth will come from exposing network analytics to OTT players

Signaling will growth faster

HUAWEI TECHNOLOGIES CO., LTD., Proprietary Page 9

IT Cloud Carrier Cloud

HUAWEI TECHNOLOGIES CO., LTD., Proprietary Page 10

DB

AAA PCRF

IP Network

Mobile Core Data Svc Diameter Network Data Center Data center Regional Network

Charging Analytics

DB

HSS Mobile Core - CP Mobile Core - UP

MM/SM Auth API SDN-C

Mobile Core Data Service

DB

Mobile Core Data Service

DB

Mobile Core - CP Mobile Core - UP

MM/SM Auth

• SDN-C

Dense Radio Network: Macro/small cells

Flexible Mobile Core Distribution: clustered, elastic sites with NFV/SDN

• 1. centralized + distributed (UP/CP)
• 2. dedicated functions at cloud edge (UP/CP)
• 3. Centralized CP, distributed UP.

Mobile core Data Service (MDS): Data tier that is loosely coupled to mobile core functions and to network services/apps like billing, analytics. SDN based Transport Plane: white box traffic forwarding, stateful function are handled with in-switch autonomous functions and flexible service chaining Next Gen Session and Mobility Management: support for varying levels of mobility and state transfers, transactions, QoS, low latency, high reliability.

SDN Network

SORC SORC SORC

SWITCH SWITCH

APP APP

HUAWEI TECHNOLOGIES CO., LTD., Proprietary Page 11

DB

AAA PCRF

IP Network

Mobile Core Data Service Diameter Network

Charging Analytics

DB

HSS Mobile Core - CP Mobile Core - UP

MM/SM Auth API SDN-C

Mobile Core Data Service

DB

Mobile Core Data Service

DB

Mobile Core - CP Mobile Core - UP

MM/SM Auth

• SDN-C

SDN Network

SORC SORC SORC

REGION METROPLEX LOCALITY

SWITCH SWITCH

Multiple 5G slices operating concurrently A) Central CP, Central UP

• NGMN Slice 1: smartphone

B) Edge CP, Edge UP

• NGMN Slice 1: smartphone, Slice 2: V2V

C) Central CP, Edge UP

• NGMN Slice 3: IoT

APP APP

HUAWEI TECHNOLOGIES CO., LTD., Proprietary Page 12

DB

AAA PCRF

IP Network

Mobile Core Data Service Diameter Network

Charging Analytics

DB

HSS Mobile Core - CP Mobile Core - UP

MM/SM Auth API SDN-C

Mobile Core Data Service

DB

Mobile Core Data Service

DB

Mobile Core - CP Mobile Core - UP

MM/SM Auth

• SDN-C

SORC

REGION METROPLEX LOCALITY

SWITCH SWITCH

APP APP

Radio + Mobile Core in a DC Support for a combined mobile /radio site while also supporting mobile core slice that is centralized.

DC Network

Mobile Core Data Service

DB

Mobile Core - CP Mobile Core - UP

MM/SM Auth API SDN-C

SORC

SWITCH

DC Network

HUAWEI TECHNOLOGIES CO., LTD., Proprietary Page 13

PGW SGW SGW MME

Backhaul network

eNB eNB eNB eNB

DB

AAA PCRF

IP Network

Mobile Core Data Service

Charging Analytics

DB

HSS Mobile Core - CP Mobile Core - UP

MM/SM Auth API SDN-C

Mobile Core Data Service

DB

Mobile Core Data Service

DB

Mobile Core - CP Mobile Core - UP

MM/SM Auth

• SDN-C

SDN Network

SORC SORC SORC

SWITCH SWITCH

APP

HUAWEI TECHNOLOGIES CO., LTD., Proprietary Page 14

DB

AAA PCRF

IP Network

Mobile Core Data Svc Diameter Network Data Center Data center Regional Network

Charging Analytics

DB

HSS Mobile Core - CP Mobile Core - UP

Auth SDN-C

Mobile Core Data Service

DB

Mobile Core Data Service

DB

Mobile Core - CP Mobile Core - UP

MM/SM Auth

• SDN-C

Dense Radio Network: Macro/small cells SDN Network

SORC SORC SORC

SWITCH SWITCH

Data synchronization in Mobile Core:

– Subscriber data: (read heavy) relatively infrequent updates. Use mobile core signaling to resolve stale/out-of-sync data – MM/SM context data: (write heavy) frequent updates and routing depends on it. May require locking for maintaining consistency. – Accounting /charging data: (write heavy) high volume of data. Out-of-sync data can resolved by application (without locking).

Why do we need a distributed data layer ?

– Distributed data service layer that can be evolved, scaled and deployed independently of control. – Decoupled operation: need to operate in the presence of intermittent wide area network/server failures. – Latency of accessing remote database is avoided. – Capability to expose network services

MM/SM MM/SM

Subscriber Data Acct/Charging Data MM/SM Data

HUAWEI TECHNOLOGIES CO., LTD., Proprietary Page 15

MME GW PCRF SDN-C MME PCRF SDN-C GW GW GW mgmt DNS SDN-C DB-H IoT

SWITCH(GW)

DB-H SDN-C

MM/SM

Auth SDN-C MDS

MM/SM

mgmt MDS DB-H DNS coord MME GW PCRF SDN-C MME PCRF SDN-C GW GW GW mgmt DNS

IP Network SDN Backhaul

DB-H SDN-C

MM/SM

Auth SDN-C MDS

MM/SM

mgmt MDS DB-H DNS coord

IP Network Backhaul/ S1

SWITCH(GW) SWITCH(GW)

Realize “gateway” functionality with distributed resources:

• Multiple controllers in peered and/or hierarchical mode
• Forwarding elements that host stateful functions
• Service chaining and in-switch autonomous functions
• Core forwarding plane fns buffering, paging, mobility management, metering, charging.
• Dynamic local measurement services, state monitoring and data aggregation

Support for computing services at the Edge (e.g., MEC):

• Containerization, pooling of edge cloud resources
• Dynamic provisioning across core and edge cloud resources
• Few networking abstractions
• limited to “ports”.
• limited support for geographic distribution of net

functions

• sub-optimal routing path for network flows
• low throughput and high latency.

IT to CARRIER

Carrier Cloudlets

SDN-C DB-H IoT

SWITCH(GW)

Carrier Cloud DCs IT Cloud DCs

Fast path support for low latency and/or high throughput applications.

HUAWEI TECHNOLOGIES CO., LTD., Proprietary Page 16

ARNO (June ’15) Brahmaputra (Feb. ’16) Release C Release D

• L2/L3 VPN with multi-

tenancy

• Resource scheduling,

reservation

• SLA provisioning
• Fault management
• Service assurance
• Multi-site support
• Simple SFC/VNFFG
• ONOS integration with

ONOSFW SBI/NBI

• Basic policy support
• Dynamic SFC/VNFFG
• Edge computing
• Edge storage
• Policy based slicing
• Containerization
• Advanced resource

scheduling, reservation

• Fault management, high

availability, service assurance

• IPv6 for flattening

networks

OpenStack + ODL Fixed Network Config. Build & CI for OPNFV release OpenStack + ODL + ONOS + OC Cluster Level Config. Lab Ready Dynamic Policy VM + Container Support Fixed Network Ready

• Control and data plane

function hosting on forwarding elements

• MANO for Edge Cloud,

Cloud, Inter and Intra Cloud/Edge Cloud

• Distributed Data Services
• Mobile network

abstractions

• Dynamic policy mapping

based on context & state

• SON support
• Control delegation

Low Latency + High Throughput Hosting Mobile Network Ready IoT/MTC Ready

Light Blue text = work not yet started in OPNFV
