GTC 2016 - San Jose

HPC Application Porting to CUDA at BSC

Pau Farré, Marc Jordà www.bsc.es

• WARIS-Transport

○ Atmospheric volcanic ash transport simulation ○ Computer Applications department

Agenda

2

• PELE

○ Protein-drug interaction simulation ○ Life Sciences department

WARIS-Transport Volcano ash dispersion simulation

Motivation

4

• VAAC: Volcanic Ash Advisory centers

○ Controlling volcano eruptions ○ Help airliners → Redirect flights

• Forecast of atmospheric

transport and deposition of volcanic ash

○ Meteorological models

• Eyajfajallajökull eruption (Iceland, 2010)

○ 48% cancelled flights in europe during a week (107.000 flights) ○ Over €1.3 billions in losses

• Puyehue-Cordon Caullé eruption (Chile, 2011)

○ Multiple flights cancelled in ■ Chile ■ Argentina ■ South-Africa ■ Australia

Eruptions

5

Ash extension map Airspace shutdown Ash extension map

Rectangular Cartesian Grid (x,y,z) Factors controlling atmospheric transport:

• Wind advection
• Turbulent diffusion
• Gravitational settling of particles

General Advection-Diffusion-Reaction Eq. ⇒ Custom Jacobi Stencil

Description

6

stencil

• utput

• Finite difference method: Iterative process
• Main computation

– Advection-Diffusion-Reaction

Algorithm

7

• 1. Advection-Diffusion-Reaction Kernel

○ ~80% CPU execution time

CUDA Implementation (I)

8

• 1. Advection-Diffusion-Reaction Kernel
• 2. Compute Terminal Velocity

○ Meteorological computations

CUDA Implementation (II)

9

• 1. Advection-Diffusion-Reaction Kernel
• 2. Compute Terminal Velocity
• 3. Implement all non-IO computations in GPU

○ Minimize CPU ⇔ GPU copies

CUDA Implementation (III)

10

• 1. Advection-Diffusion-Reaction Kernel
• 2. Compute Terminal Velocity
• 3. Implement all non-IO computations in GPU
• 4. Different particles sizes are launched in different streams

CUDA Implementation (IV)

11

Kernel Overlap

12

• Some datasets are too small to fully occupy all SMs with only one

kernel

• Parallel kernel execution to fully occupy all SMs

Chile-2011 dataset 0.25º (grid size 121x121x64) Chile-2011 dataset 0.05º (grid size 601x601x64)

Results

13

4 GPU runs as fast as 8 Marenostrum3 nodes (128 cores) Implementations:

• MPI + AVX
• MPI + OpenMP + AVX
• MIC (MPI+OpenMP+AVX)
• MPI + CUDA (1 GPU/rank)
• Chile 2011 dataset 0.05º
• Marenostrum supercomputer

○ 16x cores/node ○ 2x Intel MIC

• GPU Server:

○ 4x Nvidia Tesla K40

PELE: Protein Energy Landscape Exploration

Interactive Drug Design with Monte Carlo Simulations

PELE Vision

15

• Drug design is a costly process
• Design through Interactive biomolecular

simulations ○ Statistical approach → Faster simulations ○ Visual analysis

• Computational power + human intuition

PELE-GUI

Monte Carlo approach where each trial does:

• Perturbation

○ Protein shape + ligand position

• Relaxation

○ Further refinement to a more stable position (energy minimization)

• Acceptance test

○ If accepted, used as inital conformation for future trials

PELE: Protein Energy Landscape Exploration

16

Relaxation Perturbation

PELE Demo

17

• Exec. time cost of energy terms
• Bond Energy: 1.27%
• Angle Energy: 0.93%
• Dihedral Energy: 2.13%
• Non-bonding Interactions

○ Electrostatic ○ Lennard Jones ○ Solvent Energy ○ Total: 37,58 %

• Update alphas: 27.96%

PELE Energy Formula

18

Initial profiling → Energy computation was the most time consuming task

• Exec. time cost of energy terms
• Bond Energy: 1.27%
• Angle Energy: 0.93%
• Dihedral Energy: 2.13%
• Non-bonding Interactions

○ Electrostatic ○ Lennard Jones ○ Solvent Energy ○ Total: 37.58 %

• Update alphas: 27.96%

PELE Energy Formula

19

Initial profiling → Energy computation was the most time consuming task

CUDA Implementation

20

• CUDA implementation

○ New data structure for interactions list in GPU ○ With atomics ■ Profiling showed high overheads

• Lack of DP atomics?
• High contention due to list order?

○ Without atomics ■ Main kernel + custom reduction to aggregate results ■ ~3x faster than 1st approach Update Alphas (27.96%)

• All to all atom interactions
• No major issues

Non-bonding Terms (37.58%)

• List of interactions (atom pairs)

○ Several cut-offs to reduce the number of interactions

• Energy computations are performed

multiple times in different parts of PELE

• Maintain data coherent between CPU and

GPU

• High code complexity

○ Porting everything inbetween involves a major refactoring

CUDA Implementation (II)

21

PELE call graph Energy computations in time

Automatic CPU ⇔ GPU copies

• CUDA Unified Virtual Memory (UVM)
• Unified CPU & GPU data structures

○ Allocation pointers can be used both in the CPU and GPU ○ CUDA runtime manages the copies internally

• Custom std::allocator for std::vectors

CPU/GPU data coherence

22

Explicit CPU ⇔ GPU copies

• Code is harder to follow and maintain
• Complex application:

○ Difficult to track which CPU code uses GPU results ○ Usage may depend on many conditions

• Programmers tend to be conservative

○ Always copy GPU results to host after the kernel ■ If not used, performance cost for no reason

• 4KB copies are not large enough to get maximum PCIe bandwidth
• Also, some unnecessary copies

○ The runtime has to be conservative because it doesn’t always know what’s input or output ○ Our use of streams and allocations attached to them was not optimal

UVM profiling

23

After the kernel launch

• Call owner_CPU(...) to notify the memory manager
• As said, copies are done lazily when needed

Before launching a kernel

• Call owner_GPU(void* host_ptr, access_type)

○ Access types

■ Read, Write, ReadWrite, FullWrite

○ Returns gpu_ptr

Semi-automatic memory manager

24

UVM style

• It maintains pairs of allocations (CPU & GPU)
• DtoH copies are only performed when data is really needed in the CPU

○ A page-fault handler detects CPU accesses

• Copies all the allocation at once

○ Better bandwidth

Performance comparison

25

UVM Semi-automatic memory manager

• Semi-automatic memory manager has better performance

○ Mainly because of better PCIe bandwidth

Results (I)

26

55x 5.29x 15.09x

Results (II)

27

2.4x 2x

Upper bound 2.9x (Amdahl’s law) PELE acceleration is still ongoing

• Non-bonding list generation
• Computations in perturbation

step

• Etc.

Conclusions

Acceleration of existing applications

• Some parts are accelerated while others are kept in the CPU
• Maintain data coherence between CPU & GPU is complex
• We showed two examples:

○ WARIS-Transport ■ Simple enough to port most of the computations to GPU and keep data there ○ PELE ■ Complex app → use a manager to handle the copies ■ UVM is a great tool to automatize the copies ■ We implemented a Semi-automatic memory manager to improve the performance Atomics might have a large performance impact

• Store partial results and apply a reduction step after the kernel
• Libraries can help with reductions

○ CUB, Modern GPU, etc.

Conclusions

29

Thank you!

For further information please contact pau.farre@bsc.es marc.jorda@bsc.es

www.bsc.es
