slide-1
SLIDE 1

How to Network in Online Social Network

Giovanni Neglia, Xiuhui Ye (Politecnico di Torino), Maksym Gabielkov, Arnaud Legout (Inria)

Maestro Team 16 January 2014

slide-2
SLIDE 2

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 2

Outline

  • 1. Influence maximization problem (Kempe, Kleinberg and

Tardös in 2003)

  • 2. How the problem changes for a user in an online social

network

  • 3. Simulation results on Twitter’s complete graph (2012)
slide-3
SLIDE 3

Influence propagation

Recruited node Influenced node p p p p p

16 January 2014 - 3

t=0

  • G. Neglia – How to Network in Online Social Networks
slide-4
SLIDE 4

Influence propagation

Recruited node Influenced node p p p p p

16 January 2014 - 4

t=1

  • G. Neglia – How to Network in Online Social Networks
slide-5
SLIDE 5

Influence propagation

Recruited node Influenced node p p p p p

16 January 2014 - 5

t=2

  • G. Neglia – How to Network in Online Social Networks
slide-6
SLIDE 6

Influence maximization

Recruit a set A of K nodes to maximize the expected number of influenced nodes (σ(A)=E[|φ(A)|])

Recruited node Influenced node

16 January 2014 - 6

  • G. Neglia – How to Network in Online Social Networks
slide-7
SLIDE 7

Kempe et al 2003

  • 1. Decreasing cascade model:

q pv(u,S) = prob. that u can influence v, given that nodes in S have already tried to influence v q pv(u,S) ≥ pv(u,T) if

16 January 2014 - 7

v u

t=2

  • G. Neglia – How to Network in Online Social Networks

S ⊂ T

slide-8
SLIDE 8

Kempe et al 2003

  • 2. Linear Threshold Model

q Node v has a threshold θv sampled from a uniform random variable in [0,1] and link (i,j) has a weight bij q Node v is influenced if Σ biv 1(i is influenced) > θn

v s u

16 January 2014 - 8

t=2

  • G. Neglia – How to Network in Online Social Networks

buv bsv

slide-9
SLIDE 9

Kempe et al 2003

  • 2. General Threshold Model

q Node v has a threshold θv sampled from a uniform random variable in [0,1] q Node v has a monotone activation function fv:2V->[0,1] and is influenced at t if fv(S) > θv, where S is the set of influenced nodes at t

16 January 2014 - 9

  • G. Neglia – How to Network in Online Social Networks
slide-10
SLIDE 10

Kempe et al 2003

Their results:

I. Decreasing cascade model & General threshold model are equivalent

q For each {pv(u,S)}, it is possible to find {fv(S)} such that the probability distribution of φ(A) is the same

16 January 2014 - 10

  • G. Neglia – How to Network in Online Social Networks
slide-11
SLIDE 11

Kempe et al 2003

Their results:

I. Decreasing cascade model & General threshold model are equivalent

q For each {pv(u,S)}, it is possible to find {wij} such that the probability distribution of φ(A) is the same

  • II. The greedy algorithm achieves a (1-1/e)

approximation ratio

q This follows from a general result proven by Nemhauser, Wolsey, Fisher in '78 for non-negative, monotone, submodular functions

16 January 2014 - 11

  • G. Neglia – How to Network in Online Social Networks
slide-12
SLIDE 12

Monotonicity of σ(A)

q σ(A1)≤σ(A2) if

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 12

A

1 ⊂ A2

slide-13
SLIDE 13

Submodularity of σ(A)

q σ(A1U {v}) - σ(A1) ≥ σ(A2U {v}) - σ(A2) if

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 13

v

A

1 ⊂ A2

v

slide-14
SLIDE 14

The greedy algorithm

1: start with A={} 2: for i =1 to K 3: let vi be the node maximizing the marginal gain σ(A U {v}) - σ(A) 4: set A:=A U {vi} Question: how to calculate σ(A U {v}) - σ(A)?

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 14
slide-15
SLIDE 15

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 15
  • 2. How the problem changes in OSN

v u Tweeting node Retweeting node p p p p p

v follows u’s tweet v is a follower of u u is a following of v

slide-16
SLIDE 16

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 16
  • 2. How the problem changes in OSN

Assumption: a user can only influence people through Twitter itself

v u Tweeting node Retweeting node p p p p p

v follows u’s tweet v is a follower of u u is a following of v

slide-17
SLIDE 17

The user can only select its followers (up to K=2000)…

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 17
  • 2. How the problem changes in OSN

v u p p p p p

v follows u’s tweet v is a follower of u u is a following of v

slide-18
SLIDE 18

The user can only select its followers (up to K=2000)… And hope that they follow back

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 18
  • 2. How the problem changes in OSN

v u p p p p p

v follows u’s tweet v is a follower of u u is a following of v

slide-19
SLIDE 19

Our problem

Let the reciprocation probability rv be known How should the user select the set of followers A in

  • rder to maximize σ(A)=E[|φ(A)|]? (all the choices at t=0)

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 19

v u p p p p p

slide-20
SLIDE 20

Map the new problem to the old one

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 20

u2 u3 u1 p p p u4 p Select K followers u2 u3 u1 p p p u4 p

slide-21
SLIDE 21

Map the new problem to the old one

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 21

u2 u3 u1 p p p u4 p Select K followers u2 u3 u1 p p p u4 p u'1 u’2 u'3 u'4 p r p r p r p r Recruit K nodes in V’ equivalent to

slide-22
SLIDE 22

Map the new problem to the old one

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 22

Select K followers u2 u3 u1 p p p u4 p u2 u3 u1 p p p u4 p u'1 u’2 u'3 u'4 p r p r p r p r Recruit K nodes in V’ equivalent to

Greedy algorithm has the same approximation ratio

slide-23
SLIDE 23

A 2nd twist: dynamic policies

q Following users is not expensive q Idea: replace non-reciprocating users q How to operate:

  • follow one user
  • if the user does not reciprocate by T
  • unfollow it and follow someone else

q It is now possible to follow over time more than K users, but only K at a given time instant

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 23
slide-24
SLIDE 24

An ideal policy

q Imagine to know who is going to reciprocate by T q The greedy algorithm with such knowledge would achieve an (1-1/e) approximation ratio

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 24

u2 u3 u1 p p p u4 p u2 u3 u1 p p p u4 p u'3 u'4 p p

slide-25
SLIDE 25

A practical greedy policy

1: start with A={}, D={} i=0 2: while i ≤ K 3: let vi be the node in V-D maximizing the marginal gain σ(A U {v}) - σ(A), given that it reciprocates 5: follow vi 6: if vi reciprocates by T: 7: A:=A U {vi}, i=i+1 5: else: 6: D:=D U {vi}

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 25
slide-26
SLIDE 26

A practical greedy policy

1: start with A={}, D={} i=0 2: while i ≤ K 3: let vi be the node in V-D maximizing the marginal gain σ(A U {v}) - σ(A), given that it reciprocates 5: follow vi 6: if vi reciprocates by T: 7: A:=A U {vi}, i=i+1 5: else: 6: D:=D U {vi} practical greedy = ideal greedy

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 26
slide-27
SLIDE 27

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 27

#Readers vs #Retwitters (3rd twist)

v u Retweeting (and reading) node p p p p p Reading (non- retweeting) node

What if we consider as performance metric #readers?

slide-28
SLIDE 28

Map the new problem to the old one

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 28

u2 u3 u1 p p p u4 p w(u''2)=1 u2 u3 u1 p p p u4 p u''1 u''2 u''3 u''4 1 1 1 1 1 1 1 1 w(u''1)=1 w(u''4)=1 w(u''3)=1 w(u1)=0 w(u4)=0 w(u3)=0 w(u2)=0

Select K nodes to maximize E[Σ w(ui) 1(ui is active)]

slide-29
SLIDE 29

An ideal policy

q Is E[Σ w(ui) 1(ui is active)] submodular?

  • Yes it is (need to go carefully through the steps of

Kempe et al)

q then greedy is a (1-1/e) approximation algorithm

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 29
slide-30
SLIDE 30

Wrap up

q The point of view of a user in an OSN introduces new twists, but does not change fundamentally the problem

  • In particular the greedy algorithm guarantees a

(1-1/e) approximation ratio

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 30
slide-31
SLIDE 31

Wrap up

q The point of view of a user in an OSN introduces new twists, but does not change fundamentally the problem

  • In particular the greedy algorithm guarantees a

(1-1/e) approximation ratio

q Limits:

  • need to know the whole topology, pv(u,S), rv
  • How to calculate the marginal gain? Montecarlo

simulations…

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 31
slide-32
SLIDE 32

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 32

Outline

  • 1. Influence maximization problem (Kempe, Kleinberg

and Tardös in 2003)

  • 2. How the problem changes for a user in an online

social network

  • 3. Simulation results on Twitter’s complete graph (2012)
slide-33
SLIDE 33

Know your enemy q Crawl of the whole Twitter in June 2012 q 500 million of nodes q 23 billion of arcs q 417GB as an edgelist

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 33
slide-34
SLIDE 34

Montecarlo simulations q Naive implementation

  • O(NKS) simulations,
  • where S is #simulations to achieve the

required confidence

  • ≈100GB to store the graph in RAM

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 34
slide-35
SLIDE 35

Trade RAM for Storage

  • Influenced node of a cascade = reachable

nodes in the pruned graph

  • Need to store S * p * 417GB
  • RAM still a problem for p≥1%

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 35

u2 u3 u1 p p p u4 p

u2 u3 u1 u4 u2 u3 u1 u4 u2 u3 u1 u4 u2 u3 u1 u4

…

prune

slide-36
SLIDE 36

Useful preprocessing

  • Reachability can also be calculated on the

SCCs’ graph

  • For larger p we save memory, storage and

computation

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 36

u2 u3 u1 u4 u5 S1 S2

Pruned graph SCCs’ graph u1, u2, u3 u4, u5 Calculation of the Strongly Connected Components

slide-37
SLIDE 37

How many samples? q We tried to estimate it analytically

  • Random configuration model
  • Subcritical branching process for small p
  • All-or-nothing supercritical branching process

for large p

q S≤100 for all the values of p

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 37
slide-38
SLIDE 38

Different algorithms

  • 1. Greedy
  • Know topology, probabilities
  • 2. Highest degree
  • Know nodes’ degrees
  • 3. Random
  • Know nodes’ ids

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 38
slide-39
SLIDE 39

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 39

1 20 40 60 80 100 120 140 160 180 200 0.5 1 1.5 2 2.5 3 3.5 4 4.5x 10

6

initial set size #retweets p = 0.001 greedy high−degree random 1 20 40 60 80 100 120 140 160 180 200 2 4 6 8 10 12x 10

4

initial set size #retweets p = 0.0001 greedy high−degree random

<d>p≈4*10-3 <d>p≈4*10-2

slide-40
SLIDE 40

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 40

1 20 40 60 80 100 120 140 160 180 200 0.5 1 1.5 2 2.5x 10

8

initial set size #retweets p = 0.1 greedy high−degree random 1 20 40 60 80 100 120 140 160 180 200 1 2 3 4 5 6 7x 10

7

initial set size #retweets p = 0.01 greedy high−degree random

<d>p≈0.4 <d>p≈4

High variability

slide-41
SLIDE 41

The effect of reciprocity

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 41

1 10 20 30 40 50 60 70 80 90 100 110 1 2 3 4 5 6 7x 10

7

initial set size #retweets p = 0.01 greedy high−degree random 1 20 40 60 80 100 6.145 6.15 6.155x 10

7

r = min # followings # followers +100,1 ! " # $ % &

slide-42
SLIDE 42

#Readers vs #Retwitters

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 42

1 5 10 15 20 25 30 35 40 0.5 1 1.5 2 2.5 3 3.5 x 10

8

initial set size #retweets or #readers p = 0.01 greedy retweets high−degree retweets random retweets greedy readers high−degree readers random readers

slide-43
SLIDE 43

Take Home Lesson q For sparse graphs, highest degree (1-hop ahead) works as well as greedy q For dense graphs, any strategy, even random, works as well as greedy q Only in the middle, greedy can outperform highest degree…

  • Remarks in Habiba and Berger-Wolf, 2011

q … but we do not observe it

16 January 2014

  • G. Neglia – How to Network in Online Social Networks
  • 43
slide-44
SLIDE 44

Thank you! Questions?
