How to get from A to E: using networks to unravel the past, present, and future Rebecca Cotton-Barratt Admissions Coordinator and Schools Liaison Officer Mathematical Institute University of Oxford 24 June 2014 1 How to get from A to E 24

slide-1
SLIDE 1

How to get from A to E 24 June 2014

How to get from A to E:

using networks to unravel the past, present, and future

Rebecca Cotton-Barratt Admissions Coordinator and Schools Liaison Officer Mathematical Institute University of Oxford 24 June 2014

1

slide-2
SLIDE 2

How to get from A to E 24 June 2014

What is a graph?

2

slide-3
SLIDE 3

How to get from A to E 24 June 2014

What is a graph?

  • Set of vertices v and

edges e

  • Can be complete,

directed, weighted, simple and/or connected

3

slide-4
SLIDE 4

How to get from A to E 24 June 2014

Bridges of Königsberg

4

slide-5
SLIDE 5

How to get from A to E 24 June 2014

Handshaking Lemma

Every finite undirected graph has an even number

  • f vertices of odd degree

5

slide-6
SLIDE 6

How to get from A to E 24 June 2014

Eulerian Circuits and Paths

6

  • Circuit: every vertex must

have an even degree

  • Path: at most two

vertices can have an odd degree

slide-7
SLIDE 7

How to get from A to E 24 June 2014

Utilities Problem

Is it possible to connect three houses to three utility supplies without the supply pipes crossing?

7

slide-8
SLIDE 8

How to get from A to E 24 June 2014

Euler’s Formula

8

F + V – E = 2 2E = F1 + 2F2 + 3F3 + 4F4 + …

slide-9
SLIDE 9

How to get from A to E 24 June 2014

Bipartite Graphs

9

F + V – E = 2 2E = 4F4 + 6F6 + 8F8 + …

slide-10
SLIDE 10

How to get from A to E 24 June 2014

Utilities Problem

F = 2 + E – V F = 2 + 9 – 6 F = 5

10

slide-11
SLIDE 11

How to get from A to E 24 June 2014

Utilities Problem

F = 2 + E – V F = 2 + 9 – 6 F = 5 2E = 4F4 + 6F6 + 8F8 + … 18 = 4F4 + ... > 20

11

slide-12
SLIDE 12

How to get from A to E 24 June 2014

Theorem on Friends and Strangers

12

Can you find a group of 5 people of whom no 3 are mutual acquaintances or mutual strangers?

slide-13
SLIDE 13

How to get from A to E 24 June 2014

Theorem on Friends and Strangers

13

slide-14
SLIDE 14

How to get from A to E 24 June 2014

World War I

“The enemy of my enemy is my friend.”

14

Unbalanced triangles.

slide-15
SLIDE 15

How to get from A to E 24 June 2014

World War I

15

slide-16
SLIDE 16

How to get from A to E 24 June 2014

World War I

16

slide-17
SLIDE 17

How to get from A to E 24 June 2014

World War I

17

slide-18
SLIDE 18

How to get from A to E 24 June 2014

World War I

18

slide-19
SLIDE 19

How to get from A to E 24 June 2014

World War I

19

slide-20
SLIDE 20

How to get from A to E 24 June 2014

World War I

20

slide-21
SLIDE 21

How to get from A to E 24 June 2014

Rock, Paper, Scissors

  • Chinese Han dynasty

game

  • Exported to Japan as

Frog, Snake, Snail.

21

slide-22
SLIDE 22

How to get from A to E 24 June 2014

Rock, Paper, Scissors

  • Chinese Han dynasty

game

  • Exported to Japan as

Frog, Snake, Snail.

22

slide-23
SLIDE 23

How to get from A to E 24 June 2014

Variations: Changing Arrows

  • 3 move game
  • Good old rock, nothing

beats rock. ~ Bart Simpson

23

slide-24
SLIDE 24

How to get from A to E 24 June 2014

Variations: Adding a Move

24

slide-25
SLIDE 25

How to get from A to E 24 June 2014

Variations: Adding More Moves

General Properties

  • There is one winner

between every pair of moves

  • Ties are not allowed

25

slide-26
SLIDE 26

How to get from A to E 24 June 2014

General Games

Possible Question

  • Is there always a move

that beats everything else?

26

slide-27
SLIDE 27

How to get from A to E 24 June 2014

General Games

27

Possible Question

  • Is there always a move

that beats everything else?

  • No!
slide-28
SLIDE 28

How to get from A to E 24 June 2014

Threatening Behaviour

Definition

  • A move a threatens

another move b if a beats another move c which beats b.

28

slide-29
SLIDE 29

How to get from A to E 24 June 2014

Threatening Behaviour

New Question

  • Is there always a move

which beats or threatens every other move?

29

slide-30
SLIDE 30

How to get from A to E 24 June 2014

Proof: Is There Always a Move Which Beats

  • r Threatens Every Other Move?
  • 1. Take the move which

beats the most other moves.

(Note: We don’t need to know what beats what exactly.)

30

slide-31
SLIDE 31

How to get from A to E 24 June 2014

Proof: Is There Always a Move Which Beats

  • r Threatens Every Other Move?
  • 2. Does T. rex threaten

every red?

(Hint: What does it mean for T. rex to threaten every red?)

31

slide-32
SLIDE 32

How to get from A to E 24 June 2014

Proof: Is There Always a Move Which Beats

  • r Threatens Every Other Move?
  • 3. What happens if some

red beats every blue?

32

slide-33
SLIDE 33

How to get from A to E 24 June 2014

Proof: Is There Always a Move Which Beats

  • r Threatens Every Other Move?
  • 4. Then that move beats more moves than T. rex

33

slide-34
SLIDE 34

How to get from A to E 24 June 2014

Proof: Is There Always a Move Which Beats

  • r Threatens Every Other Move?
  • 1. Take the move which

beats the most other moves.

(Note: We don’t need to know what beats what exactly.)

34

slide-35
SLIDE 35

How to get from A to E 24 June 2014

King Chicken Theorem

  • The King Chicken

theorem states that in a flock of chickens there is always a chicken which pecks or threatens every

  • ther chicken.

35

slide-36
SLIDE 36

How to get from A to E 24 June 2014

Further Questions

  • If a chicken is pecked by

another chicken, is one

  • f the chickens that

pecks that chicken a king?

  • Can there be precisely

two king chickens in a flock?

36

slide-37
SLIDE 37

How to get from A to E 24 June 2014

Big Brother Surveillance

37

slide-38
SLIDE 38

How to get from A to E 24 June 2014

Networks in the News

38

slide-39
SLIDE 39

How to get from A to E 24 June 2014

Travelling Salesman Problem

39

slide-40
SLIDE 40

How to get from A to E 24 June 2014

Travelling Salesman Problem

40

slide-41
SLIDE 41

How to get from A to E 24 June 2014

Google Page Rank

41

slide-42
SLIDE 42

How to get from A to E 24 June 2014

University Mathematics

Statistics

Probability Optimization Mathematical Genetics

42

Pure Mathematics

Logic Set Theory Algebra (e.g. groups) Analysis (e.g. calculus) Geometry Topology Number Theory

Applied Mathematics

Differential Equations Numerical Analysis Classical Mechanics Fluid Dynamics Mathematical Physics Information Theory Cryptography Mathematical Biology

slide-43
SLIDE 43

How to get from A to E 24 June 2014

Joint Degrees

  • Mathematics and

Philosophy (3/4 years)

  • Logic/set theory from

natural bridge

  • Philosophy options (e.g.

epistemology or language) relate well with maths

43

  • Mathematics and

Statistics (3/4 years)

  • Same first year as Maths
  • Then greater range of

Stats options

  • Mathematics and

CompSci (3/4 years)

  • Pure Maths options and

CompSci from a flexible mathematical viewpoint

slide-44
SLIDE 44

How to get from A to E 24 June 2014

Thanks for Listening!

Any Questions? Visit us at: www.maths.ox.ac.uk

44
