SLIDE 1

SLIDE 2

Hot Dog Stand USA, 1871 President Khrushchev trying a Hot Dog USA, 1959 First model of Vitrum Group Hot Dog Stand Latvia, 1995

SLIDE 3

Our production

Darbs ¡ ¡ar ¡ ¡metālu

SLIDE 4

Hot Dog Stand - The basics

Tempered curved glass for protection (Straight glass can also be installed) Made out of stainless steal metal Light box for advertisement Refrigerated section for salads and sauces Sausage boiler Refrigerated draws with gastra trays Easy to clean Draws with gastro trays Handy pull-out cutting board for bread Grill surface Rolling grill Contacts press grill

SLIDE 5

Hot Dog Stand 1150

Climate class facilities in accordance with EN441

3; +25°C

RH = 60% Temperature class of the product M2; -1...+7°C Rated Voltage 3~380V, 50Hz Degree of protection of electrical equipment from electric shock 1 Power consumption, kW (total) 5,95kW Among them: Refrigeration unit 0,38kW (6A) Frontal lighting 0,02kW (6A) Contact Grill TL5270 * 1,60kW (10A) Roller Grill GL6R65T * 0,950kW (10A) Sausage boiler CL-A1D * 1,0kW (10A) Grill surface GL9520 * 2,0kW (16A) Type of refrigerant R134a The mass of refrigerant for the embedded unit 0.25kg Net capacity city load: dm ³ For the refrigerated unit 136 Non refrigerated 180

Possible specifications: 1.Rolling grill with Teflon surface GL6R65T 1100 x 256 x170 1piece 2.Contact press grill TL5270 280 x375 x 170 1piece 3.Sausage boiler. CL-A1D 320 x 335 x 300 1piece 4.Grill surface GL9520 460 x 375 x120 1piece 5.Gastro accessories 1piece

SLIDE 6

Hot Dog Stand 1550

Possible specifications: 1.Rolling grill with Teflon surface GL6R65T 1100 x 256 x170 1piece 2.Contact press grill TL5270 280 x375 x 170 2piece 3.Sausage boiler. CL-A1D 320 x 335 x 300 1piece 4.Grill surface GL9520 460 x 375 x120 1piece 5.Gastro accessories 1piece

Climate class facilities in accordance with EN441

3; +25°C

RH = 60% Temperature class of the product M2; -1...+7°C Rated Voltage 3~380V, 50Hz Degree of protection of electrical equipment from electric shock 1 Power consumption, kW (total) 5,89kW Among them: Refrigeration unit 0,38kW (6A) Frontal lighting 0,02kW (6A) Contact Grill TL5270 * 1,60kW (10A) Roller Grill GL6R65T * 0,950kW (10A) Sausage boiler CL-A1D * 1,0kW (10A) Grill surface GL9520 * 2,0kW (16A) Type of refrigerant R134a The mass of refrigerant for the embedded unit 0.25kg Net capacity city load: dm ³ For the refrigerated unit 128 Non refrigerated 136

SLIDE 7

Tempered straight glass for protection

Hot Dog Stand - “Silver”

Paper napkin holder Light box with LED lighting Stainless steal Refrigerated draws with gastra trays Draws with gastro trays Grill surface Rolling grill Contacts press grill Trays- Refrigerated or non refrigerated for sauces etc

SLIDE 8

Hot Dog Stand Silver 1200

Possible specifications: 1.Rolling grill with Teflon surface GL6R65T 1100 x 256 x170 1piece 2.Contact press grill TL5270 280 x375 x 170 2piece 3.Sausage boiler. CL-A1D 320 x 335 x 300 1piece 4.Grill surface GL9520 460 x 375 x120 1piece 5.Gastro accessories 1piece

Climate class facilities in accordance with EN441

3; +25°C

RH = 60% Temperature class of the product M2; -1...+7°C Rated Voltage 3~380V, 50Hz Degree of protection of electrical equipment from electric shock 1 Power consumption, kW (total) 5,95kW Among them: Refrigeration unit 0,38kW (6A) Frontal lighting 0,02kW (6A) Contact Grill TL5270 * 1,60kW (10A) Roller Grill GL6R65T * 0,950kW (10A) Sausage boiler CL-A1D * 1,0kW (10A) Grill surface GL9520 * 2,0kW (16A) Type of refrigerant R134a The mass of refrigerant for the embedded unit 0.25kg Net capacity city load: dm ³ For the refrigerated unit 136 Non refrigerated 180

SLIDE 9

Hot Dog Stand Silver 1600

Possible specifications: 1.Rolling grill with Teflon surface GL6R65T 1100 x 256 x170 1piece 2.Contact press grill TL5270 280 x375 x 170 2piece 3.Sausage boiler. CL-A1D 320 x 335 x 300 1piece 4.Grill surface GL9520 460 x 375 x120 1piece 5.Gastro accessories 1piece

Climate class facilities in accordance with EN441

3; +25°C

RH = 60% Temperature class of the product M2; -1...+7°C Rated Voltage 3~380V, 50Hz Degree of protection of electrical equipment from electric shock 1 Power consumption, kW (total) 5,95kW Among them: Refrigeration unit 0,38kW (6A) Frontal lighting 0,02kW (6A) Contact Grill TL5270 * 1,60kW (10A) Roller Grill GL6R65T * 0,950kW (10A) Sausage boiler CL-A1D * 1,0kW (10A) Grill surface GL9520 * 2,0kW (16A) Type of refrigerant R134a The mass of refrigerant for the embedded unit 0.18kg Net capacity city load: dm ³ For the refrigerated unit -removable 213 For the refrigerated unit 128 Non refrigerated 136

SLIDE 10

Hot Dog Stand - Modified

Chip wood Stainless steal Rolling grill Contacts press grill

SLIDE 11

Examples of installed Hot Dog Stands

SLIDE 12

SLIDE 13

SLIDE 14

SLIDE 15

SLIDE 16

Thank you for getting to know our Hot Dog stands

We look forward to working with you. Please do not forget to visit our websites: www.vitrum.lv www.gastrovitrum.lv www.logivitru.lv You can also find us on Facebook at

www.facebook.com/vitrumgroup

and Twitter. Our address: G.Astras 3a, Riga, Lv 1084 Latvia Phone: (+371) 67802384 Email: info@vitrum.lv
