Ken O’Brien, Nicholas Fraser, Michaela Blott 27th March 2019

Heterogeneous Compute Architectures For Deep Learning In The Cloud

Outline

˃Why FPGAs? ˃Deep Learning: Challenges & Solutions ˃FINN ˃FPGAs to ACAPs

Mega-Trend:

Explosion of Data

˃ Astronomically growing amounts of data

More sensors More users More use cases: Genomics (DNA) “Genomical”

>> 3

Stephens, Zachary D., et al. "Big data: astronomical or genomical?."

1 0.1 2 21 5 10 15 20 25 Astronomy Twitter YouTube Genomics Storage ExaBytes/year

Data Acquisition in 2025

We need significantly more compute resources to process and extract patterns / insights from this data!

Technology:

End of Moore’s Law & Dennard Scaling

Economics become questionable Power dissipation becomes problematic

Technology Trends

Era of Heterogeneous Compute using Accelerators

Page 5

˃ Diversification of increasingly heterogenous devices and system

Moving away from standard van Neumann architectures

˃ True Architectural innovation & Unconventional Computing Systems

Deep Learning

• customized precision arithmetic

Cat? Input Image

What’s the Challenge? Example: Convolutional Neural Networks

Forward Pass (Inference)

Neural Network Neural Network For ResNet50: 70 Layers 7.7 Billion operations 25.5 millions of weights

>> 7

Basic arithmetic, incredible parallel but Huge Compute and Memory Requirements

Compute and Memory for Inference

Inference (1 input) GOPS average Inference (1 input) MBytes average Spectrum of Neural Networks

MLP ImageNet Classification CNNs Object Detection Semantic Segmentation OCR Speech Recognition

*architecture independent **1 image forward *** batch = 1 **** int8

Huge Compute and Memory Requirements & Variations

>> 8

0.00 10.00 20.00 30.00 40.00 50.00 60.00 06/07/2009 18/11/2010 01/04/2012 14/08/2013 27/12/2014 10/05/2016 22/09/2017 04/02/2019 Error (%) Publication Date

ImageNet Classification Top-5 Error Over Time (ImageNet)

BNN CNN Reduced Precision Internal

Floating Point to Reduced Precision Neural Networks

Deliver Competitive Accuracy

Float point improvements are slowing down Reduced precision competitive accuracy

Reducing Precision

Scales Performance & Reduces Memory

˃ Reducing precision shrinks LUT cost

Instantiate 100x more compute within the same fabric

˃ Potential to reduce memory footprint

NN model can stay on-chip => no memory bottlenecks Precision Modelsize [MB] (ResNet50) 1b 3.2 8b 25.5 32b 102.5 C= size of accumulator * size of weight * size of activation

Reducing Precision Inherently Saves Power

Source: Bill Dally (Stanford), Cadence Embedded Neural Network Summit, February 1, 2017 Target Device ZU7EV ● Ambient temperature: 25 °C ● 12.5% of toggle rate ● 0.5 of Static Probability ● Power reported for PL accelerated block only 2/2 0.500 0.700 0.900 1.100 1.300 1.500 1.700 1.900 2.100 8 10 12 14 16 18 20 Estimated Power Consumption [W] Test error [%]

LSTM - Test Error vs Power(W)

Bits (W/A) Pareto Optimal >> 11 Rybalkin, V., Pappalardo, A., Ghaffar, M.M., Gambardella, G., Wehn, N. and Blott, M. "FINN-L: Library Extensions and Design Trade-

• ff Analysis for Variable Precision LSTM Networks on FPGAs."

FPGA: ASIC:

2/3 3/4 2/4 2/8 4/4 3/8 8/8 3/3 4/8

1.0 10.0 100.0 1000.0 10000.0 100000.0 1000000.0 10000000.0 100000000.0 1000000000.0 0.00 5.00 10.00 15.00 20.00 25.00 30.00 COMPUTE COST (LUTS + 100*DSPS)

• VAL. ERROR (%)

IMAGENET CLASSIFICATION TOP5% VS COMPUTE COST F(LUT,DSP)

1b weights 2b weights 5bit weights 8bit weights FP weights minifloat ResNet-50 Syq

Design Space Trade-Offs

Resnet18 8b/8b Compute Cost 286 Error 10.68% Resnet50 2b/8b Compute Cost 127 Error 9.86%

Reduced Precision can

• reduce cost / resources
• save power
• scale performance

Pareto-optimal solutions

Scaling with FINN

>> 13

˃ Design Flow Tool for Quantized Neural Networks

Rapid access to network structure and compute/memory footprint statistics Performance prediction for target device Automatic architecture scaling and generation for target device

˃ Multi-stage tool-flow

Frontend Design Space Exploration Backend

˃ Binary Network Release Available

https://github.com/Xilinx/FINN

Page 14

FINN –Tool for Exploration of NNs of FPGAs

HW Architecture – Dataflow

Layer 0

…

Input image

Weight buffer Weight buffer Weight buffer

Inference output

Layer 1 Layer X-1

HW Architecture – Dataflow

Layer 0

…

Input image

Weight buffer Weight buffer Weight buffer

Inference output

Layer 1 Layer X-1

Weight buffering in on-chip memory

• High operational intensity for

inference Small intermediate buffer for feature maps

• No data reordering between layers
• Multi-line buffering for convolutions
• Low latency, high throughput

HW Architecture – Dataflow

Layer 0 DSP

…

Input image

Weight buffer Weight buffer Weight buffer

Inference output

Layer 1 LUT-MAC Layer X-1

1 Compute engine per layer

• Ad-hoc arithmetic according to layer

quantization

HW Architecture – Dataflow

Layer 0 DSP

…

Input image

Weight buffer Weight buffer Weight buffer

Inference output

Layer 1 LUT-MAC Layer X-1

1 Compute engine per each layer

• Adjust parallelism with compute

requirements

PE PE PE PE PE PE PE PE PE PE PE PE PE PE PE PE

Per layer operations Topology summary

19

Frontend Stage – Import and Network Statistics

Neural Network Description (Prototxt) FINN

Device Specification File Folding Factor Calculation Performance Prediction

20

Design Space Exploration Stage: Balanced Dataflow

Neural Network Description FINN

Page 21

Convolutional Layer – Folding

Height Width Channels . . . . SIMD PE PE SIMD Input Feature Map Output Feature Map Weights

Folding Factor Calculation Performance Prediction Device Specification File

22

Design Space Exploration Stage: Balanced Dataflow

Neural Network Description FINN 1: Given a target FPS, what resources are required? 2: Given total resources, what FPS can be achieved?

Page 23

Vivado HLS – QNN Library

Layer-specific configuration values

– Support to multiple padding, in this case same

Implementation-specific parallelism values

– Folding factors

Precision configuration values

– Independent precision for input/output activations and weights and signed/unsigned math

Device Specification File Hardware Generation

24

Backend Stage - Hardware/ Runtime Generation

Neural Network Description FINN FINN QNN Library Optimal Folding Factors

˃ top.cpp

Sequence of layers, 1:1 with network topology

˃ config.h

Finn-generated configuration, with network configuration values + parallelism-specific values

˃ (possible) params.h

Finn-generated weights values to be hardcoded in the bitstream

Page 25

Hardware Generation – Network Dataflow Example

Page 26

Scaling Parallelism

For each layer, set all SIMD, PE to 1

– Single MAC

Until hardware no longer fits on device or FPS target reached

– Find slowest layer

• Increase SIMD to next factor of IFM_CHANS or
• Increase PE to next factor of OFM_CHANS

Goal: Calculate folding factors such that layers produce balanced dataflow

FINN

Performance Results

˃ Up to 50TOPS measured performance for BNNs

Network Platform Precision (W/A) Performance (TOPS) MLP AWS-F1 1/1 50.8 CNV AWS-F1 1/1 12.1 Tincy-YOLO AWS-F1 1/3 5.3 DoReFa-Net/PF AWS-F1 1/2 11.4

˃ Multiple precision types supported

8-bit in DSPs, reduced precision in LUTs

Blott, M., et al. "FINN-R: An End-to-End Deep-Learning Framework for Fast Exploration of Quantized Neural Networks"

From FPGAs to ACAPs

>> 28

New Heterogeneous Devices

>> 29

NOC

Programmable Logic Processing System I/O

(GT, AMS)

AI Engines

SW PE SW PE SW PE SW PE SW PE SW PE LUT BRAM DSP URAM Application Processor Real-Time Processor Transceivers PCIe DDR HBM AMS

˃ From the Xilinx World: Evolution of FPGAs to ACAPs

Up to ~147 TOPS of Int8 performance!

Conclusions

˃ As Moore’s law has ended, heterogeneous accelerated systems have emerged ˃ High computational demand of machine learning applications is driving hardware development ˃ Customized dataflow architectures and memory subsystems, custom precisions

• Dramatic performance scaling and energy efficiency benefits
• Target Datacenter or Embedded devices
• Enabling new exciting trade-offs within the design space

˃ New ACAP devices with AI engines

30

Adaptable. Intelligent.

>> 31

Thanks!
