Hardware and JVM Design Trends? Those Dont Affect Me! Or Do They? Dan Heidinga Eclipse OpenJ9 Project Lead Interpreter Lead, IBM Runtimes @danheidinga DanHeidinga Important disclaimers THE INFORMATION CONTAINED IN THIS PRESENTATION IS

slide-1
SLIDE 1

Hardware and JVM Design Trends? Those Don’t Affect Me! Or Do They?

Dan Heidinga Eclipse OpenJ9 Project Lead Interpreter Lead, IBM Runtimes @danheidinga DanHeidinga

slide-2
SLIDE 2

Important disclaimers

§ THE INFORMATION CONTAINED IN THIS PRESENTATION IS PROVIDED FOR INFORMATIONAL PURPOSES ONLY. § WHILST EFFORTS WERE MADE TO VERIFY THE COMPLETENESS AND ACCURACY OF THE INFORMATION

CONTAINED IN THIS PRESENTATION, IT IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED.

§ ALL PERFORMANCE DATA INCLUDED IN THIS PRESENTATION HAVE BEEN GATHERED IN A CONTROLLED

  • ENVIRONMENT. YOUR OWN TEST RESULTS MAY VARY BASED ON HARDWARE, SOFTWARE OR

INFRASTRUCTURE DIFFERENCES.

§ ALL DATA INCLUDED IN THIS PRESENTATION ARE MEANT TO BE USED ONLY AS A GUIDE. § IN ADDITION, THE INFORMATION CONTAINED IN THIS PRESENTATION IS BASED ON IBM’S CURRENT

PRODUCT PLANS AND STRATEGY, WHICH ARE SUBJECT TO CHANGE BY IBM, WITHOUT NOTICE.

§ IBM AND ITS AFFILIATED COMPANIES SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES ARISING OUT

OF THE USE OF, OR OTHERWISE RELATED TO, THIS PRESENTATION OR ANY OTHER DOCUMENTATION.

§ NOTHING CONTAINED IN THIS PRESENTATION IS INTENDED TO, OR SHALL HAVE THE EFFECT OF: – CREATING ANY WARRANT OR REPRESENTATION FROM IBM, ITS AFFILIATED COMPANIES OR ITS

OR THEIR SUPPLIERS AND/OR LICENSORS

2

slide-3
SLIDE 3

Who am I?

§ One of the Project Leads for the Eclipse OpenJ9 JVM. § I've been involved with virtual machine development at IBM

since 2007 and lead IBM’s Interpreter team working on OpenJ9.

§ I've represented IBM on both the JSR 292 ('invokedynamic')

and JSR 335 ('lambda') expert groups and lead J9's implementation of both JSRs. And am now involved in Project Valhalla and Panama.

§ I’ve also maintain the bytecode verifier and deal with various

  • ther parts of the runtime.

3

slide-4
SLIDE 4

§ Moore’s law and singled threaded performance § The multicore explosion § Multi-tenant: bare metal, virtualization & containers § The deployment strategy shift § Spectre: Caught passing bad checks § Cloud as an opportunity

4

Trends

slide-5
SLIDE 5

§ Moore’s law and singled threaded performance § The multicore explosion § Multi-tenant: bare metal, virtualization & containers § The deployment strategy shift § Spectre: Caught passing bad checks § Cloud as an opportunity

5

Trends

slide-6
SLIDE 6

Moore’s Law

6

https://commons.wikimedia.org/wiki/File:Moore%27s_Law_Transistor_Count_1971-2016.png

§ The number of transistors doubles

every two years

§ Amazing single threaded

performance improvements

slide-7
SLIDE 7

Benchmark wars: Peak performance is #1

7

§ Cooperative suspend (1999) § Adaptive compilation (1999) § Escape analysis and stack allocating

  • bjects (2001)

§ Real Time Specification for Java (2005 -

2011)

§ Dynamic Ahead of Time compiled code

in production (2006)

§ Hot code replacement (2007) § Compressed references (2007) § Metronome soft real-time GC (2008)

Resource sharing? Not so much!

slide-8
SLIDE 8

Long lead times affect JVM design

Time between ordering and racking a server? Often 6+ months Buy the biggest server you can afford

9

slide-9
SLIDE 9

Long lead times affect JVM design

Time between ordering and racking a server? Often 6+ months Buy the biggest server you can afford

10

The JVM better use all of it!

slide-10
SLIDE 10

§ Moore’s law and singled threaded performance § The multicore explosion § Multi-tenant: bare metal, virtualization & containers § The deployment strategy shift § Spectre: Caught passing bad checks § Cloud as an opportunity

11

Trends

slide-11
SLIDE 11

Welcome to the multicore revolution

12

§ ~2006 RIP Moore’s Law? § Singled threaded performance no

longer growing by leaps and bounds

§ Welcome to the multicore

revolution

https://commons.wikimedia.org/wiki/File:Moore%27s_Law_Transistor_Count_1971-2016.png

slide-12
SLIDE 12

java.util.concurrent brings ForkJoin to the masses

13

§ ForkJoinPool brought the concept of work stealing to user code in Java 7 – The same technique that Java’s GC’s used to parallelize garbage

collection

§ Java 8 continued the trend towards parallelism with the introduction of

Lambda, ParallelStreams and Spliterators

§ The focus still on peak performance – but now it’s up to you (and the platform) to write good multithread code

slide-13
SLIDE 13

Common Characteristics

Deployments: infrequent Startup: Small fraction of up time Focus on peak performance

14

slide-14
SLIDE 14

Aside: Development and Debugging

15

https://xkcd.com/303/

slide-15
SLIDE 15

Trade peak performance for faster startup

  • Xquickstart (OpenJ9)
  • client (Hotspot)

16

slide-16
SLIDE 16

Adaptive JIT Compilation

17

§ Methods start out running bytecode form directly § After many invocations (or via sampling) code get compiled at ‘cold’ or ‘warm’ level § Low overhead sampling thread is used to identify hot methods § Methods may get recompiled at ‘hot’ or ‘scorching’ levels (for more

  • ptimizations)

§ Transition to ‘scorching’ goes through a temporary profiling step

cold hot scorching profiling interpreter warm

slide-17
SLIDE 17

§ Moore’s law and singled threaded performance § The multicore explosion § Multi-tenant: bare metal, virtualization & containers § The deployment strategy shift § Spectre: Caught passing bad checks § Cloud as an opportunity

18

Trends

slide-18
SLIDE 18

19

http://www.fanpop.com/clubs/home-improvement-tv-show/images/33144922/title/wilson-wallpaper

slide-19
SLIDE 19

Footprint and Startup

SharedClasses cache

20

slide-20
SLIDE 20

Footprint and Startup

21

Classfile ROMClass J9RAMClass

slide-21
SLIDE 21

ShareClasses: ROM pays off

22

JVM 1 JVM 2 JVM 3

slide-22
SLIDE 22

ShareClasses: ROM pays off

23

JVM 1 JVM 2 JVM 3

slide-23
SLIDE 23

ShareClasses: ROM pays off

24

JVM 1 JVM 2 JVM 3

Shared Classes Cache

Faster startup, Smaller footprint

slide-24
SLIDE 24

Balloon drivers

slide-25
SLIDE 25

–XX:+IdleTuningGcOnIdle -XX:+IdleTuningCompactOnIdle

https://developer.ibm.com/javasdk/2017/09/25/still-paying-unused-memory-java-app-idle/

“…around 30 percent of data center servers have not delivered information or computing services in the last six months.”

slide-26
SLIDE 26

Container Support

§ Container detection mechanism (-XX:+UseContainerSupport) – This allows JVM to tune itself based on limits imposed by the container. § Increase default heap size when running in container – JVM is typically the only application in the container – Reserve a larger chunk of container memory for heap § Better utilization of memory available to the container § -XX:MaxRAMPercentage and -XX:InitialRAMPercentage – Existing options for adjusting heap -Xmx/-Xms accept absolute values. – Cumbersome to adjust –Xmx/-Xms when container memory limit can vary – Adjust the heap based on percentage of the physical memory rather than an

absolute value.

§ Adjust Runtime.availableProcessors() based on cgroup limits § Add container limits to the Javacore file

slide-27
SLIDE 27

OpenJ9 JIT memory auto-scaling based on container limits

  • Docker container without swap space configured -> Exceed limit? Kaboom!
  • Docker container with swap space configured -> Exceed limit? Swap! Performance cost
  • JIT must be aware of container memory limits to avoid causing performance or functional

instability!

  • JIT compiler scratch memory usage is auto-scaled based on container memory limit
  • Reduce number of compilation threads as container limit is approached
  • Lower optimization level of compiled methods as container limit is approached
  • Different sized containers running same application on OpenJ9 could behave differently
  • Ramp up to peak throughput could be slower in smaller containers
  • Peak memory usage could be lower in smaller containers
slide-28
SLIDE 28

29

Trends

§ Moore’s law and singled threaded performance § The multicore explosion § Multi-tenant: bare metal, virtualization & containers § The deployment strategy shift § Spectre: Caught passing bad checks § Cloud as an opportunity

slide-29
SLIDE 29

The new world

30

slide-30
SLIDE 30

Continuous integration

31

slide-31
SLIDE 31

Continuous deployment

32

Checkout Compile Test Deploy

slide-32
SLIDE 32

Key idea of cloud

Making it faster and cheaper to get ideas into production with less risk

33

slide-33
SLIDE 33

Cloud: horizontal scaling

34

slide-34
SLIDE 34

Microservices

35

slide-35
SLIDE 35

Serverless / Function as a Service

https://github.com/apache/incubator-openwhisk/blob/master/docs/images/OpenWhisk.png

36

slide-36
SLIDE 36

New World Characteristics

Deployments: frequent, multiple times a day Startup: Larger fraction of uptime Lots of “first” runs: fewer opportunities to reuse work from previous runs

37

slide-37
SLIDE 37

The JVM needs to change

38

slide-38
SLIDE 38

“Dynamic” AOT through ShareClasses

39

Shared Classes Cache AOT ROM Classes

$ java –Xshareclasses ...

slide-39
SLIDE 39

Shared cache enablement

  • Enabled with –Xshareclasses
  • Population of the cache happens naturally & transparently at runtime
  • Applicable to boot, extension, & application loaders

& all URLClassloader-subclasses

  • Helper APIs to enable non-URLClassloaders (manual)
  • Disclaim the JIT and meta data after startup
  • Reduce footprint further
  • Debug data is only paged in as needed
slide-40
SLIDE 40

New AOT ramp up and throughput on Liberty Daytrader7

OpenJ9 default JIT vs –Xtune:virtualized with old AOT vs –Xtune:virtualized with new AOT

  • New AOT ramps up faster than the old AOT and stabilizes at higher throughput
  • New AOT cuts AOT vs JIT compiled code throughput delta roughly in half
slide-41
SLIDE 41

Jprofiling: Ramp up faster

§Improved mechanism for profiling compiled code. –Careful placement of counters –Conditionally patch code to enable / disable §Reduces the dependency on interpreter profiling. àGets into compiled code faster àDon’t sacrifice profiling quality

42

S I A C D B E F G H X

https://github.com/eclipse/openj9/blob/master/doc/compiler/JProfiling.md

slide-42
SLIDE 42

§ Moore’s law and singled threaded performance § The multicore explosion § Virtualization enters the arena § The deployment strategy shift § Spectre: Caught passing bad checks § Cloud as an opportunity

43

Trends

slide-43
SLIDE 43

Spectre & related security issues

44

https://upload.wikimedia.org/wikipedia/commons/thumb/2/25/Spectre_with_text.svg/702px-Spectre_with_text.svg.png

slide-44
SLIDE 44

§ Moore’s law and singled threaded performance § The multicore explosion § Virtualization enters the arena § The deployment strategy shift § Spectre: Caught passing bad checks § Cloud as an opportunity

45

Trends

slide-45
SLIDE 45

The JVM needs to keep changing

46

slide-46
SLIDE 46

JIT as a Service

47

App JIT App JIT App JIT App JIT

slide-47
SLIDE 47

JIT as a Service

48

App App App App JIT

slide-48
SLIDE 48

Take aways

§ The application life cycle has changed – no longer dominated by uptime. – Frequent restarts are the new reality. – Startup is now critical to your application! § The JVM is becoming a good neighbor – Intelligent resource usage matters… including giving them back § The free lunch is over – Expect to spend more and more time looking at resource usage, performance

and footprint.

49

slide-49
SLIDE 49

https://adoptopenjdk.net/releases.html?variant=openjdk11&jvmVariant=openj9 https://adoptopenjdk.net/releases.html?variant=openjdk8&jvmVariant=openj9 https://github.com/eclipse/openj9 https://openj9.slack.com/

50

slide-50
SLIDE 50

Questions?

51

Dan Heidinga Eclipse OpenJ9 Project Lead Interpreter Lead, IBM Runtimes @danheidinga DanHeidinga
