Hamilton Works Hamilton Works Community Liaison Committee Meeting Community Liaison Committee Meeting 06 February 2019 K. Chan Agenda Agenda 1. Welcome and Safety Contact 2. Review and Approval of Agenda 3. Review and Approval of

slide-1
SLIDE 1

Hamilton Works Hamilton Works Community Liaison Committee Meeting Community Liaison Committee Meeting

06 February 2019

  • K. Chan
slide-2
SLIDE 2

Agenda Agenda

1. Welcome and Safety Contact 2. Review and Approval of Agenda 3. Review and Approval of Minutes of 17 October 2018 4. Performance under O.Reg . 419/05 Site Specific Standard Order – Particulates 5. Cokemaking Update 6. Benzene Monitoring Program 7. Community Concerns 8. Adjournment

slide-3
SLIDE 3

Know Your Know Your Emergency Exits Emergency Exits

Review Evacuation Routes of the room you are located in

slide-4
SLIDE 4

Agenda Agenda

1. Welcome and Safety Contact 2. Review and Approval of Agenda 3. Review and Approval of Minutes of 17 October 2018 4. Performance under O.Reg . 419/05 Site Specific Standard Order – Particulates 5. Cokemaking Update 6. Benzene Monitoring Program 7. Community Concerns 8. Adjournment

slide-5
SLIDE 5

Agenda Agenda

1. Welcome and Safety Contact 2. Review and Approval of Agenda 3. Review and Approval of Minutes of 17 October 2018 4. Performance under O.Reg . 419/05 Site Specific Standard Order – Particulates 5. Cokemaking Update 6. Benzene Monitoring Program 7. Community Concerns 8. Adjournment

slide-6
SLIDE 6

Agenda Agenda

1. Welcome and Safety Contact 2. Review and Approval of Agenda 3. Review and Approval of Minutes of 17 October 2018 4. Performance under O.Reg . 419/05 Site Specific Standard Order – Particulates 5. Cokemaking Update 6. Benzene Monitoring Program 7. Community Concerns 8. Adjournment

slide-7
SLIDE 7

Site Site-Specific Standard Order (Particulates): Specific Standard Order (Particulates): Performance Review Performance Review – Daily Daily

Date Date Doors Doors (% Leaks) (% Leaks) Lids Lids (% Leaks) (% Leaks) Off Off-takes takes (% Leaks) (% Leaks) 2015 Limits (July 2 start) 54% 2% NA 2016 Limits 32% 2% NA 2017 2017-2019 Limits 2019 Limits 10% 10% 2% 2% 5% 5% 2020 Limits 5% 1% 4% Oct 1 Oct 1 – Dec 31, 2018 Dec 31, 2018 Range ange (Average) (Average) 0 – 2.47% 2.47% (0.2%) (0.2%) 0 – 0.78% 0.78% (0.04%) (0.04%) 0 – 6.58% 6.58% (0.46%) (0.46%)

Daily Measurements Performed YTD

  • All weekdays, except for holidays
  • 10 Saturdays
  • 10 Sundays

Oct 1 – Dec 31, 2018 Operational Adjustments

  • Offtakes - The Battery was still stabilizing its
  • perations after resuming from scheduled 16 -

hour maintenance downturn on October 10th. Leak was repaired.

slide-8
SLIDE 8

Site Site-Specific Standard Order (Particulates): Specific Standard Order (Particulates): Performance Review Performance Review – 30 Day Rolling Averages 30 Day Rolling Averages

Oct 1 – Dec 31, 2018 Performance

  • In compliance with 2018 limits

Date Date Doors Doors (% Leaks) (% Leaks) Lids Lids (% Leaks) (% Leaks) Off Off-takes takes (% Leaks) (% Leaks) Charging Charging (sec) (sec) (log avg) (log avg) 2015 Limits (July 2 start) 38% 0.8% 25% 12 sec 2016 Limits 22.5% 0.8% 15% 12 s 2017 2017-2019 Limits 2019 Limits 7% 7% 0.8% 0.8% 4.2% 4.2% 12 s 12 s 2020 Limits 4% 0.4% 2.5% 12 s Oct 1 Oct 1 – Dec 31, 2018 Dec 31, 2018 Range Range (Average) (Average) 0.1 0.1 – 0.39% 0.39% (0.24%) (0.24%) 0.02 0.02 – 0.12 0.12% (0.053%) (0.053%) 0.17 0.17 – 1.16 1.16% (0.55%) (0.55%) 5.94 5.94 – 7.88 s 7.88 s (6.82 s) (6.82 s)

slide-9
SLIDE 9

Site Site-Specific Standard Order (Particulates): Specific Standard Order (Particulates): Performance Review Performance Review – Daily Observations Daily Observations – Pushing Emissions Pushing Emissions

Oct 1 – Dec 31, 2018 Operational Adjustments

  • Cleaned plugged risers and orifices (2)
  • Reduced coking schedule

Date Date Pushing Emission Pushing Emission (opacity %) (opacity %) 2015 Limit (July 2 start) ≥ 50% 2016 2016 – 2018 2018 ≥ 50% 2019 ≥ 40% 2020 ≥ 30% Oct 1 Oct 1 – Dec 31, 2018 Dec 31, 2018 Range Range (Average) (Average) 0 – 58.3% 58.3% (13.4%) (13.4%)

slide-10
SLIDE 10

Site Site-Specific Standard Order (Particulates): Specific Standard Order (Particulates): Performance Review Performance Review – Additional Items Additional Items

  • There were no community complaints for the period of

October – December 2018

  • MECP will provide verbal comments
slide-11
SLIDE 11

Agenda Agenda

1. Welcome and Safety Contact 2. Review and Approval of Agenda 3. Review and Approval of Minutes of 17 October 2018 4. Performance under O.Reg . 419/05 Site Specific Standard Order – Particulates 5. Cokemaking Update 6. Benzene Monitoring Program 7. Community Concerns 8. Adjournment

slide-12
SLIDE 12

Hamilton Works Hamilton Works Cokemaking Cokemaking Update Update

February 2019 Pete Schiestel

slide-13
SLIDE 13

Stelco Stelco Cokemaking Cokemaking Overview Overview

  • Video presentation
slide-14
SLIDE 14

Coke Battery Overview Coke Battery Overview

slide-15
SLIDE 15

HW Battery HW Battery

Future Standards: Future Standards: Minimizing or eliminating battery operating delays will lower coke ovens emissions. The Stelco Hamilton Works coke ovens department has a broadened preventive maintenance and upgrade plan to meet all future standards.

slide-16
SLIDE 16

Upgrades Upgrades

  • Rebuilding #3 primary cooler

aiding in improving gas quality.

  • Extending the battery decking

to increase coal bunker usage.

  • Rebuilding #3 tar decanter to

remove more tar.

  • Adding another oxygen sensor

into the rich gas stream to control under firing usage.

  • Designing a one spot quench

car to assist the coke shed pushing emission control.

  • Engineering study to resurrect

the #5 & #6 boosters to eliminate the need for #1 coke

  • ven gas flare.
slide-17
SLIDE 17

Thank You. Thank You.

stelcocanada.com

slide-18
SLIDE 18

Agenda Agenda

1. Welcome and Safety Contact 2. Review and Approval of Agenda 3. Review and Approval of Minutes of 17 October 2018 4. Performance under O.Reg . 419/05 Site Specific Standard Order – Particulates 5. Cokemaking Update 6. Benzene Monitoring Program 7. Community Concerns 8. Adjournment

slide-19
SLIDE 19

Benzene Monitoring Program Benzene Monitoring Program

  • Monitor – Hand-held with Photoionization Detector for VOCs (specific

for benzene)

  • Most of the sources at the Coke Ovens and By-Products are well

controlled

  • Sources with opportunities for improvement include:
  • Group 1

Group 1 – Manage with procedures and operating practice

  • Fugitive Battery emissions – charging, doors (minimize visible

leaks)

  • Light Oil Loading hose – (upon completion of loading, cap off hose)
  • Keep hatch closed– Dissolved Air Clarifier; Excess Ammonia Liquor

Storage Tank – (work practice – reinforce operators to close hatches and maintain seals)

  • Group 2

Group 2 – Emission control equipment

  • Process Water Decanter Tank

– (emission control to be incorporated at top vent on the tank)

  • Next steps: Implementation of identified opportunities for improvement
slide-20
SLIDE 20

Agenda Agenda

1. Welcome and Safety Contact 2. Review and Approval of Agenda 3. Review and Approval of Minutes of 17 October 2018 4. Performance under O.Reg . 419/05 Site Specific Standard Order – Particulates 5. Cokemaking Update 6. Benzene Monitoring Program 7. Community Concerns 8. Adjournment

slide-21
SLIDE 21

Agenda Agenda

1. Welcome and Safety Contact 2. Review and Approval of Agenda 3. Review and Approval of Minutes of 17 October 2018 4. Performance under O.Reg . 419/05 Site Specific Standard Order – Particulates 5. Cokemaking Update 6. Benzene Monitoring Program 7. Community Concerns 8. Adjournment

slide-22
SLIDE 22

Supplementary (March 21, 2019) Supplementary (March 21, 2019)

slide-23
SLIDE 23

Site Site-Specific Standard Order (Particulates): Specific Standard Order (Particulates): Performance Review Performance Review – Daily Daily

Date Date Doors Doors (% Leaks) (% Leaks) Lids Lids (% Leaks) (% Leaks) Off Off-takes takes (% Leaks) (% Leaks) 2015 Limits (July 2 start) 54% 2% NA 2016 Limits 32% 2% NA 2017 2017-2019 Limits 2019 Limits 10% 10% 2% 2% 5% 5% 2020 Limits 5% 1% 4% Jan 1 Jan 1 – Feb 28, 2019 Feb 28, 2019 Range ange (Average) (Average) 0 – 0.26% 0.26% (0.11%) (0.11%) 0 – 0.26% 0.26% (0.01%) (0.01%) 0 – 2.6% 2.6% (0.47%) (0.47%)

Daily Measurements Performed YTD

  • All weekdays, except for holidays
  • 3 Saturdays
  • 2 Sundays

Jan 1- Feb 28, 2019 Operational Adjustments

  • In compliance with 2019 limits
slide-24
SLIDE 24

Site Site-Specific Standard Order (Particulates): Specific Standard Order (Particulates): Performance Review Performance Review – 30 Day Rolling Averages 30 Day Rolling Averages

Jan 1 – Feb 28, 2019 Performance

  • In compliance with 2019 limits

Date Date Doors Doors (% Leaks) (% Leaks) Lids Lids (% Leaks) (% Leaks) Off Off-takes takes (% Leaks) (% Leaks) Charging Charging (sec) (sec) (log avg) (log avg) 2015 Limits (July 2 start) 38% 0.8% 25% 12 sec 2016 Limits 22.5% 0.8% 15% 12 s 2017 2017-2019 Limits 2019 Limits 7% 7% 0.8% 0.8% 4.2% 4.2% 12 s 12 s 2020 Limits 4% 0.4% 2.5% 12 s Jan 1 Jan 1 – Feb 28, 2019 Feb 28, 2019 Range Range (Average) (Average) 0.04 0.04 – 0.17% 0.17% (0.13%) (0.13%) 0 – 0.03 0.03% (0.011%) (0.011%) 0.34 0.34 – 0.64 0.64% (0.48%) (0.48%) 5.01 5.01 – 9.31s 9.31s (7.43 s) (7.43 s)

slide-25
SLIDE 25

Site Site-Specific Standard Order (Particulates): Specific Standard Order (Particulates): Performance Review Performance Review – Daily Observations Daily Observations – Pushing Emissions Pushing Emissions

Jan 1 – Feb 28, 2019 Operational Adjustments

  • Increased coking time; increased coke oven gas supply

to underfiring; decrease coal moisture

Date Date Pushing Emission Pushing Emission (opacity %) (opacity %) 2015 Limit (July 2 start) ≥ 50% 2016 – 2018 ≥ 50% 2019 2019 ≥ 40% 2020 ≥ 30% Jan 1 Jan 1 – Feb 28, 2019 Feb 28, 2019 Range Range (Average) (Average) 0 – 40% 40% (6.55%) (6.55%)

slide-26
SLIDE 26

Emission Observation (March 12, 2019) Emission Observation (March 12, 2019)

Conclusion:

  • Pushing emission

Probable Cause:

  • Low oven temperature due to water washing of the

underfiring system to remove deposits in the piping

  • The gas to the oven being water washed is shut off as the

washing is being done Resolution:

  • The Battery heating was supplemented by natural gas
slide-27
SLIDE 27

Batch Anneal Batch Anneal

  • Upgrade existing #3 Batch Anneal facility
  • 12 bell anneal workbases (6 for heating; 6 for cooling)
  • Anneal steel coils in nitrogen atmosphere
  • Expected annual production of approximately 540,000 tonnes of

annealed steel coils

  • Stelco has applied for a new Environmental Compliance Approval for

non-contact cooling water system

  • Existing baywater supply network to control temperature of cooling

bell inner cores

  • Non-contact cooling water to be discharged through an existing

industrial sewer to Hamilton Harbour via MISA control point

  • Water from existing baywater supply network to a closed loop

cooling water skid

  • Effluent water quality should be equivalent to influent
  • Effluent temperature to be monitored by thermocouple; if required,

would be regulated prior to industrial sewer outfall

slide-28
SLIDE 28

Proposed 2019 CLC Meeting Dates Proposed 2019 CLC Meeting Dates

  • Thurs. March 21
  • Wed. June 12
  • Wed. Sept. 18
  • Wed. Dec. 11
slide-29
SLIDE 29

Thank You. Thank You.

stelcocanada.com
