The Solution to Air Compliance LA DEQ GREEN CONFERENCE 1 DISCUSSION OVERVIEW VAPOR POINT MISSION THE VAPOR POINT TECHNOLOGY SUCCESSFULLY ENGINEERED APPLICATIONS FIELD DATA = DEMONSTRATED SUCCESS CASE HISOTRY COST

slide-1
SLIDE 1

1

LA DEQ GREEN CONFERENCE

The Solution to Air Compliance

slide-2
SLIDE 2

DISCUSSION OVERVIEW

  • VAPOR POINT MISSION
  • THE VAPOR POINT TECHNOLOGY
  • SUCCESSFULLY ENGINEERED APPLICATIONS
  • FIELD DATA = DEMONSTRATED SUCCESS
  • CASE HISOTRY – COST ADVANTAGES
  • VAPOR POINT ADVANTAGES

2

slide-3
SLIDE 3

VAPOR POINT MISSION

– Create GREEN TECHNOLOGY– No NOx/CO Emission – Answer to industries’ emission compliance issues when Carbon, Thermal Combustion and Flaring are not viable

  • perationally and/or economically

– Provide Turn-Key Solution for Emission Compliance

  • Fugitive VOC Emissions
  • H2S and other hazardous compounds
  • Air Monitoring and Data Logging

3

slide-4
SLIDE 4
  • Keys to Effectiveness

– Reaction Chamber Design – creating “Hydraulic Amalgamation” between vapor and recovery chemistry

  • NOT a Traditional Scrubber
  • PATENTED PROCESS FOR VAPOR RECOVERY

– Proprietary Chemistry (Modified based on Application)

  • Dynamic capability [absorptive, adsorptive, solubility]
  • Recyclable Chemistry
  • Recoverable and Reusable Contaminate Gas

– Operational Effectiveness

  • No Power Requirements (In positive pressure applications)
  • No Heat Generation or Reactivity
  • Ease of Mobility
  • Ease of Adaptability
  • No Waste Generated or Left Behind
  • Can achieve 100% regulatory compliance

Vapor Point _ Vapor Lock

4

slide-5
SLIDE 5

Vapor Lock Process

5

DIRTY AIR CHEMICAL CONTACT CLEAN AIR Contaminated Vapor delivered to Vapor Lock, flow stream requires a minimum of 5 inches water column, plus back pressure resulting from liquid level height. *VAPOR LOCK TECHNOLOGY HAS BEEN ACCEPTED BY TCEQ AND EPA AS A SOLUTION FOR MANAGING AIR COMPLIANCE CONCERNS*

slide-6
SLIDE 6

Vapor Lock

Hydraulic Amalgamation Units

6

slide-7
SLIDE 7

Current Focus

  • Industrial Applications
  • Vacuum Trucks/Air Movers
  • Process Sumps/API Separators
  • Process Unit Blow Downs
  • Storage Tank Vents/Bladders
  • Pipeline Maintenance
  • Mobile Frac Tanks
  • Large Degassing Operations
  • Upstream Oil & Gas Tanks
  • Barges & Tankers

7

Su Succes cessfu sfully lly Devel velop

  • ped

ed Cur urren rently tly In R&D Pipe

(Expect to Come to Mkt within 12 mths)

slide-8
SLIDE 8

Vapor Point Applications

8 Applications Vapor Lock Packed Column Sparger Scrubber Thermal Oxidation Carbon Absorption Flares Vacuum Trucks

  • Air Movers
  • Sumps and Pits
  • API Tanks/Seperators
  • Above Ground Storage Tank
  • Temporary Storage Tanks
  • Pipeline Maintenance Applications
  • Process Unit Maintenance
  • Oilfield Rig Operations/Gas Busters
  • Paint Booth Off Gas
  • Contaminates

BETX ≥ 1000 PPM

  • BETX ≤ 1000 PPM
  • Total VOCs (≥C4) ≥ 1000 PPM
  • Total VOCs (≥C4) ≤ 1000 PPM
  • Total VOCs (≤C3)
  • H2S
  • Ammonia
  • Mercaptans
slide-9
SLIDE 9

Application Review

9

slide-10
SLIDE 10

Vacuum Truck/Air Movers

Field Applications

10

1 10 100 1,000 10,000 100,000 1,000,000

15:38 15:39 15:40 15:41 15:41 15:42 15:43 15:44 15:45 15:46 15:46 15:47 15:48 15:49 15:50 15:51 15:51 15:52 15:53 15:54 15:55 15:56 15:56 15:57

586,194

Cat-Gas Vacuum Test

Vacuum Truck Exhaust Vapor Lock Outlet

1.00 100.00 10,000.00 1,000,000.00

11:30 11:31 11:31 11:32 11:33 11:34 11:35 11:36 11:37 11:37 11:38 11:39 11:40 11:41 11:44 11:45 11:45 11:46 11:47

Raffinate Tank Water Draw

Vacuum Truck Exhaust Vapor Lock Outlet 1 10 100 1,000 10,000 100,000

12:28 12:30 12:57 13:33 13:40 13:46 13:50 14:19 14:22 14:27 14:52 14:55 15:00 15:03 15:08 15:31 15:35 15:38 15:41 16:08 16:12 16:15 16:20 16:24 16:35

100,000 VOC PPM - Log. Distribution

Air - Mover : Water Draw Slop Sludge

Vacuum Truck Exhaust #2 Vapor Lock Outlet 1 10 100 1000 10000 100000 9:44 10:15 10:40 3:05 3:22 3:35 3:50 4:15

80000 7400 71000 10000 27000 4500 16000 11000

VOC PPM - Log. Distribution

Naptha Line Break

Vacuum Truck Exhaust Vapor Lock #1 Outlet Vapor Lock #2 Outlet

slide-11
SLIDE 11

Cost Comparison _ Crude Sump

Old Solution Activated Carbon

  • $287,000 annual cost
  • Significant soft cost
  • Significant carbon

disposal/reactivation volumes

Vapor Point Solution

  • Saved client $70,000
  • Reduced carbon footprint
  • Vapor Sorb recycled by plant

and sold as fuels

11

Requirement – NESHAP/BWON requirement to control Benzene waste from refinery sump

slide-12
SLIDE 12

12

slide-13
SLIDE 13

Cost Comparison _ Benzene Tank

Old Solution Activated Carbon

  • $416,000 per year annual cost
  • Soft dollar savings associated

with management of changeouts (estimated at $125K)

  • Significant carbon

disposal/reactivation volumes

Vapor Point Solution

  • Saved client $169,000
  • Reduced soft dollar cost
  • Reduced carbon footprint

– Reduced Carbon System Size

  • Vapor Sorb recycled by plant

as saleable product

13

Requirement – Fence line monitors frequently showing benzene releases

slide-14
SLIDE 14

14

slide-15
SLIDE 15

Vapor Point Advantages

 Versatility in controlling Hazardous Emission Sources

 Maintenance of Safe Working Atmospheres

 Regulatory Compliance

 Effective Control of VOC Emissions

 Elimination of Regulated Pollutants

 If used appropriate 100% emission recovery

 Safe Effective Operations

 No heating issues  No outside energy sources needed

 Economically Efficient

 Recovered product yields high value fuel  Conserves Carbon Usage

 Turn-Key Solutions for Complete Fugitive Emission Compliance

15

slide-16
SLIDE 16

Thank you!
