GraFBoost:

Using accelerated flash storage for external graph analytics

Sang-Woo Jun, Andy Wright, Sizhuo Zhang, Shuotao Xu and Arvind

MIT CSAIL

1

Funded by:

Large Graphs are Found Everywhere in Nature

2

Human neural network

1) Connectomics graph of the brain - Source: “Connectomics and Graph Theory” Jon Clayden, UCL 2) (Part of) the internet - Source: Criteo Engineering Blog 3) The Graph of a Social Network – Source: Griff’s Graphs

Structure of the internet Social networks

TB to 100s of TB in size!

Storage for Graph Analytics

3

Terabytes in size Irregular structure Extremely sparse DRAM TB of DRAM

$$$ $

Our goal: $8000/TB, 200W $500/TB, 10W

Access Granularity: 8192 Bytes 128 Bytes

Random Access Challenge in Flash Storage

4

Flash DRAM Using 8 bytes in a 8192 Byte page uses 1/1024 of bandwidth! Wastes performance by not using most of fetched page Bandwidth: 3.6 GB/s ~100 GB/s

Two Pillars for Flash in GraFBoost

5

Hardware Acceleration Sort-Reduce Algorithm Flash Storage

Sequentialize Random Access Reduce Overhead of Sort-Reduce

• System resources
• Power consumption
• Performance

Vertex-Centric Programming Model

6

“Vertex program” only sees neighbors 3 Algorithm executed in terms of disjoint iterations Popular model for efficient parallism and distribution Vertex program is executed on one or more “Active Vertices” 1 ∞ ∞ 2 1 9 ∞ 4 1 Active Vertices 5 10 2 5 4 2 5 4 1 5

𝑤𝑒𝑡𝑢. 𝑜𝑓𝑦𝑢_𝑤𝑏𝑚 = 𝐰𝐟𝐬𝐮𝐟𝐲_𝐯𝐪𝐞𝐛𝐮𝐟(𝑤𝑒𝑡𝑢. 𝑜𝑓𝑦𝑢_𝑤𝑏𝑚, 𝑓𝑤) 𝑓𝑤 = 𝐟𝐞𝐡𝐟_𝐪𝐬𝐩𝐡𝐬𝐛𝐧 (𝑤𝑡𝑠𝑑, . 𝑤𝑏𝑚, 𝑓. 𝑥𝑓𝑗𝑕ℎ𝑢)

Algorithmic Representation of a Vertex Program Iteration

7

Random read-modify update into vertex data

Sort-reduce algorithm solves this issue

𝐠𝐩𝐬 𝐟𝐛𝐝𝐢 𝑤𝑡𝑠𝑑 𝐣𝐨 𝐵𝑑𝑢𝑗𝑤𝑓𝑀𝑗𝑡𝑢 𝐞𝐩 𝐠𝐩𝐬 𝐟𝐛𝐝𝐢 𝑓(𝑤𝑡𝑠𝑑, 𝑤𝑒𝑡𝑢) 𝐣𝐨 G 𝐞𝐩 𝐟𝐨𝐞 𝐠𝐩𝐬 𝐟𝐨𝐞 𝐠𝐩𝐬

General Problem of Irregular Array Updates

8

𝑮𝒑𝒔 𝒇𝒃𝒅𝒊 < 𝑗𝑒𝑦, 𝑏𝑠𝑕 > 𝒋𝒐 𝑦𝑡: xs f Random Updates X 𝑦 𝑗𝑒𝑦 = 𝒈(𝑦 𝑗𝑒𝑦 , 𝑏𝑠𝑕) Updating an array x with a stream of update requests xs and update function f

Solution Part One - Sort

9

Sorted xs Sequential Updates Sort xs according to index

Sort

Much better than naïve random updates Significant sorting overhead Terabyte graphs can generate terabyte logs X xs

xs

Solution Part Two - Reduce

10

3 7 1 3 1 1 8 3 5 2 8 3 9 1 2 3 3 1 1 8 3 9 1 2 10 1 3 5 2 8 3 7 19 1 3 8 3 7 Associative update function f can be interleaved with sort e.g., (A + B) + C = A + (B + C) Reduced Overhead merge merge

Big Benefits from Interleaving Reduction

11

Ratio of data copied at each sort phase 0.2 0.4 0.6 0.8 1 1 2 3 Normalized size of update stream Merge Iteration Kron32 0.2 0.4 0.6 0.8 1 1 2 3 Normalized size of update stream Merge Iteration Kron32 WDC 90% 0.2 0.4 0.6 0.8 1 1 2 3 Normalized size of update stream Merge Iteration Kron32 WDC Kron30 Twitter

Accelerated GraFBoost Architecture

12

Host (Server/PC/Laptop) Vertex Data Edge Data Active Vertices Partially Sort- Reduced Files

FPGA Flash Software

Accelerator-Aware Flash Management Multirate 16-to-1 Merge-Sorter Multirate Aggregator Wire-Speed On-chip Sorter In-storage accelerator reduces data movement and cost

Accelerated GraFBoost Architecture

13

Host (Server/PC/Laptop) Vertex Data Edge Data Active Vertices Partially Sort- Reduced Files

FPGA Flash Software

Edge Property Vertex Value

Edge Program

Update Log (xs)

Sort-Reduce Accelerator 1GB DRAM In-storage accelerator reduces data movement and cost

Evaluated Graph Analytic Systems

14

In-memory External Semi-External GraphLab (IN) FlashGraph (SE1) X-Stream (SE2) GraphChi (EX) GraFSoft GraFBoost GraFBoost2 Projected system with 2x memory bandwidth

“Distributed GraphLab: a framework for machine learning and data mining in the cloud,” VLDB 2012 “FlashGraph: Processing billion-node graphs on an array of commodity SSDs,” FAST 2015 “X-Stream: edge-centric graph processing using streaming partitions,“ SOSP 2013 “GraphChi: Large-scale graph computation on just a PC,“ USENIX 2012

Evaluation Environment

15

32-core Xeon 128 GB RAM 5x 0.5TB PCIe Flash 4-core i5 4 GB RAM Virtex 7 FPGA 1TB custom flash 1GB on-board RAM

+ +

$8000 $400 $??? $1000 All software experiments

Evaluation Result Overview

16

Large graphs: Medium graphs: GraFBoost has very low resource requirement Memory, CPU, Power In-memory External Semi-External GraFBoost

Fail Fail Slow Fast

Small graphs:

Fast Fail Fast Slow Slow Fast Fast Fast

1 2 3 PR BFS BC Normalized Performance

SE1 SE2 GraFBoost GraFBoost2

Results with a Large Graph: Synthetic Scale 32 Kronecker Graph

17

0.5 TB in text, 4 Billion vertices GraphLab (IN) out of memory GraphChi (EX) did not finish 1.7x 2.8x 10x GraFSoft

Results with a Large Graph: Web Data Commons Web Crawl

1 2 3 4 PR BFS BC Normalized Performance

SE1 SE2 GraFBoost GraFBoost2

18

2 TB in text, 3 Billion vertices GraphLab (IN) out of memory GraphChi (EX) did not finish GraFSoft

Results with a Large Graph: Web Data Commons Web Crawl

1 2 3 4 PR BFS BC Normalized Performance

SE1 SE2 GraFBoost GraFBoost2

19

2 TB in text, 3 Billion vertices GraphLab (IN) out of memory GraphChi (EX) did not finish GraFSoft

Only GraFBoost succeeds in both graphs GraFBoost can run still larger graphs!

Results with Smaller Graphs: Breadth-First Search

20

1 2 3 4 5 twitter kron28 kron30

Normalized Performance IN SE1 SE2 EX GraFBoost GraFBoost2

Fastest! Slowest Slowest Slowest GraFSoft

0.3 TB 1 Billion 0.09 TB 0.3 Billion 0.03 TB 0.04 Billion

Results with a Medium Graph: Against an In-Memory Cluster

21

1 2 3 4 5 6 PR BFS

Normalized Performance 5xIN SE1 SE2 EX GraFBoost

0.09 TB in text, 0.3 Billion vertices Synthesized Kronecker Scale 28

GraFSoft

GraFBoost Reduces Resource Requirements

22

80

20 40 60 80 100

GB

Conventional GraFBoost

32 2

5 10 15 20 25 30 35

Threads

Conventional GraFBoost

410

200 400 600 800

Watts

Conventional GraFBoost

2 40 External analytics Hardware Acceleration External Analytics + Hardware Acceleration

Future Work

23

Open-source GraFBoost Cleaning up code for users! Acceleration using Amazon F1 Commercial accelerated storage Collaborating with Samsung More applications using sort-reduce Bioinformatics collaboration with Barcelona Supercomputering Center

Thank You

24

Hardware Acceleration Sort-Reduce Algorithm Flash Storage

25

BlueDBM Cluster Architecture

26 Host Server (24-Core) FPGA (VC707) minFlash minFlash Host Server (24-Core) FPGA (VC707) minFlash minFlash Host Server (24-Core) FPGA (VC707) minFlash minFlash

…

PCIe 4GB/s FMC Ethernet 10Gbps network ×8 1 TB

1GB RAM Uniform latency of 100 µs!

The BlueDBM Cluster

27

BlueDBM Storage Device
