GPU Panel for Medicine at UMD Measurement Science Based on Full Coverage Microscopic Measurements Peter Bajcsy Information Technology Laboratory National Institute of Standards and Technology (NIST) Gaithersburg, MD, USA Measurement Problem

slide-1
SLIDE 1

GPU Panel for Medicine at UMD Measurement Science Based on Full Coverage Microscopic Measurements

Peter Bajcsy Information Technology Laboratory National Institute of Standards and Technology (NIST) Gaithersburg, MD, USA

slide-2
SLIDE 2

Measurement Problem

Current measurement science Full coverage measurement science

SPECIMEN SPECIMEN SPECIMEN MEASUREMENT

DECISION

Measurement

TECHNICAL MERIT: QUANTITATIVE MEASUREMENTS AT MULTIPLE LENGTH SCALES DATA (access, preservation, dissemination) and QUALITY (decision, scientific discovery) SMALL COVERAGE FULL COVERAGE

  • IMAGE COMPARISON
  • LIMITED ACCESS
  • RESTRICTED SCIENCE
  • SPECIMEN COMPARISON
  • WEB ACCESS
  • COMMUNITY SCIENCE
slide-3
SLIDE 3

Measurement Challenges

Measurement Science Impact: Interactive quantitative measurements at multiple length scales will enable:

  • To guarantee everyday function and safety of products by full coverage measurements
  • To increase reproducibility of scientific results
  • To understand phenomena statistically at macro scale while observed at micro scale and

hence prevent catastrophic events

slide-4
SLIDE 4

~.15 cm x .15 cm (~1 MB) Bottom of a 10 cm dish = 58 cm 2 (0.034% sampled) Bottom of 6-well dish = 9.5 cm 2 (0.2% sampled)

The way we observe and measure today…

Wanted: “The Truman Microscopic Show”

1 sample ≅ 18×14 images × 2 color channels × 24*4 images per day × 5 days of imaging = 241,920 images @ 2.8 MB/image = 0.677TB (17% sampled)

3 replicas ≅2.032TB

The way we might observe and measure tomorrow…

CELL BIOLOGY

Interactive measurements: 11 info layers ~14 million files in 0.5 million folders

Movie Player Frame Slider Intensity Information Information Layer Sub-setting Modes Scale Bar

3D Volume Dimensions: 22,912 x 20,775 x 161

Overview

slide-5
SLIDE 5

ANNOTATIONS PREDICTIONS GFP CHANNEL IMAGE TILES Corrections Stitching Segmentation PC CHANNEL IMAGE TILES Feature Extraction Conversion to 8bpp & Pyramid Building OFF-LINE PRE-PROCESSING Tracking Re-Projection IMAGE FEATURES A SET OF PYRAMIDS INPUT NETWORK Prediction Modeling

Computational Goal: Enable Interactive Measurements in a Browser

BROWSER INTERACTIVE MEASUREMENTS IMAGE UI FEATURE UI LINEAGE UI

slide-6
SLIDE 6

Enable Science From Big Image Data https://isg.nist.gov

Intensity Measurements Distance to Spectral Peaks

One TB-sized XYλ Cube One TB-sized XYT Cube Thousands of MB-sized XYZ Cubes

HOMOGENEOUS HETEROGENEOUS DARK Shape Measurements Heterogeneity Measurements

Thousands of MB-sized XYT Cubes
