GEOTECHNICAL ASSET MANAGEMENT MIDWEST GEOTECHNICAL CONF., 9/17/2019 GEOTECHNICAL ASSET MANAGEMENT Steve Taliaferro ODOT Office of Geotechnical Engineering 2 | 2019 Midwest Geotechnical Conference NCHRP RESEARCH REPORT 903 3 | 2019 Midwest

SLIDE 1

GEOTECHNICAL ASSET MANAGEMENT

MIDWEST GEOTECHNICAL CONF., 9/17/2019

SLIDE 2

2 |

GEOTECHNICAL ASSET MANAGEMENT

Steve Taliaferro ODOT Office of Geotechnical Engineering

2019 Midwest Geotechnical Conference

SLIDE 3

3 |

NCHRP RESEARCH REPORT 903

2019 Midwest Geotechnical Conference

SLIDE 4

4 |

REPORT 903

Research Overview (Vol. 1)
GAM Types
Implementation Manual (Vol. 2)
“Why” of GAM
Starting GAM Implementation
Understanding the GAM Process

2019 Midwest Geotechnical Conference

SLIDE 5

5 |

GAM TYPES

Embankments
Slopes
Soil and/or Rock
Retaining Walls
Subgrades
Ground Improvements
AUM and Karst (performance risk)
Unimproved/natural hazard

2019 Midwest Geotechnical Conference

SLIDE 6

6 |

“WHY” OF GAM

Financial Responsibility
Managing Risk
Decision Support

2019 Midwest Geotechnical Conference

SLIDE 7

7 |

IMPLEMENTATION

Step 1: Identify & Locate

(Inventory)

Step 2: Record Asset

Operations and Maintenance (O&M) Conditions

Step 3: Assess Asset

Performance Consequences

2019 Midwest Geotechnical Conference

SLIDE 8

8 |

IMPLEMENTATION

Step 4: Review Treatment

Recommendations

Step 5: Analyze the Impacts of

Differing Investment Levels

Step 6: Communicate Results

2019 Midwest Geotechnical Conference

SLIDE 9

9 |

MIDWEST STATE GAM SURVEY

1. As the asset is defined in the NCHRP

Research Report 903 (Geotechnical Asset Management for Transportation Agencies), does your state inventory:

Embankments
Slopes
Subgrades
Retaining Walls
Landslides (Not an asset in Report 903)
Other (describe here)

2019 Midwest Geotechnical Conference

SLIDE 10

10 |

MIDWEST STATE GAM SURVEY

2. As the asset is defined in the NCHRP

Research Report 903 (Geotechnical Asset Management for Transportation Agencies), does your state rate:

Embankments
Slopes
Subgrades
Retaining Walls
Landslides (Not an asset in Report 903)
Other (describe here)

2019 Midwest Geotechnical Conference

SLIDE 11

11 |

MIDWEST STATE GAM SURVEY

3. If you answered yes to any of the

above, please respond to the following:

Briefly describe how your GAM system came

about

How is it accessed (by the public, internally,

etc.)?

Who populates it?
How do you use the data?
Do you program projects using the data?

2019 Midwest Geotechnical Conference

SLIDE 12

12 |

MIDWEST STATE GAM SURVEY RESULTS

Inventory:

No states are inventorying

embankments, slopes, and subgrades as specifically defined in Rpt 903

7 of 9 states are either actively

inventorying retaining walls or have development underway with such an inventory “under discussion” in an additional state

2019 Midwest Geotechnical Conference

SLIDE 13

13 |

MIDWEST STATE GAM SURVEY RESULTS

Inventory:

5 of 9 states are actively inventorying

landslides on either a statewide (2 states) or limited (3 states) basis

2019 Midwest Geotechnical Conference

SLIDE 14

14 |

MIDWEST STATE GAM SURVEY RESULTS

Rating:

2 of 9 states are rating

retaining walls

2019 Midwest Geotechnical Conference

SLIDE 15

15 |

MIDWEST STATE GAM SURVEY RESULTS

GAM Systems:

Active retaining wall inventories are

being collected by consultants and internal forces

In-house developed databases and

University research contributions common

ArcGIS Collector used by 2 states
Asset Management Legislation

2019 Midwest Geotechnical Conference

SLIDE 16

16 |

OHIO’S GAM

2019 Midwest Geotechnical Conference

Retaining Walls

3 year initial population

underway

10 year re-inspection cycle
Inventory Fields vs. Inspection

Fields

SLIDE 17

17 |

OHIO’S GAM

2019 Midwest Geotechnical Conference

SLIDE 18

18 |

OHIO’S GAM

2019 Midwest Geotechnical Conference

SLIDE 19

19 |

OHIO’S GAM

2019 Midwest Geotechnical Conference

Geohazards

Landslide
Rockfall
Abandoned Underground Mines
Re-inspection cycles based on

severity/risk rating

SLIDE 20

20 |

OHIO’S GAM

2019 Midwest Geotechnical Conference

SLIDE 21

21 |

OHIO’S GAM

2019 Midwest Geotechnical Conference

SLIDE 22

22 |

OHIO’S GAM

2019 Midwest Geotechnical Conference

! ! ! ! !!

! ! ! ! ! ! ! ! ! ! ! ! ! ! !! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! ! !!

! ! ! ! ! ! ! ! ! ! ! ! ! ! !! ! ! !

! !

! ! ! !

! ! ! ! ! ! ! ! !

! !

! ! ! ! I

8 O U T E R B E L T MEDINA WILLOW I-271 N O R T H W E S T L A K E L A N D E U C L I D S P U R I-77 I-71 SADIE RIVER I-90 I

8 I-90 Source: Esri, DigitalGlobe, GeoEye, Earthstar Geographics, CNES/Airbus DS, USDA, USGS, AeroGRID, IGN, and the GIS User Community

Legend

SO4 (ppm)

0-3000

3000-5000

5000-8000

8000+ Chemical_Stabilization Full_Depth New_Pavement_Projects

DISTRICT 12 - SULFATE MAP

SLIDE 23

23 |

OHIO’S GAM

2019 Midwest Geotechnical Conference

Historic geotechnical

information/data is an asset

DIGGS compatible data now

required in Ohio

SLIDE 24

24 |

OHIO’S GAM

2019 Midwest Geotechnical Conference

SLIDE 25

25 |

OHIO’S GAM

2019 Midwest Geotechnical Conference

SLIDE 26

26 |

QUESTIONS/DISCUSSION

Last updated 9/24/2019

2019 Midwest Geotechnical Conference
