EGSR 2008 Geometry-Aware Framebuffer Level of Detail Lei Yang Pedro V. Sander Hong Kong University of Science and Technology Jason Lawrence University of Virginia Motivation Expensive procedural shading effects Heavy pixel shader

slide-1
SLIDE 1

Geometry-Aware Framebuffer Level of Detail

Lei Yang Pedro V. Sander

Hong Kong University of Science and Technology

Jason Lawrence

University of Virginia

EGSR 2008

slide-2
SLIDE 2

Motivation

  • Expensive procedural shading effects

– Heavy pixel shader workload – Examples

  • Soft shadows

27fps

  • Ambient Occlusion

3.2fps

  • Procedural noise texture

120fps

  • …

2 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

slide-3
SLIDE 3

Motivation

  • A method for reducing pixel workload

– General – Lightweight – No preprocessing – Smoothly adjustable tradeoff between speed/quality

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 3

1x 2x 3x 5.6x 9x 11x Tradeoff Tradeoff

slide-4
SLIDE 4

Dynamic Resizing

  • Render scene to low-res buffer (1st pass), then

upsample to target resolution (2nd pass). [Montrym97] – # of original pixel shader invocation is reduced (∝ 1/r2) – Blurs geometric discontinuities

1st pass Original shader 2nd pass Upsample

4 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

slide-5
SLIDE 5

Geometry-Aware?

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 5

+ =

depth normal

slide-6
SLIDE 6

Related Work

  • Interleaved sampling [Segovia06, Laine07]
  • Image-based proxy accumulation [Sloan07]

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 6

slide-7
SLIDE 7

Related Work

  • Edge-and-Point render cache

[Bala03, Velázquez-Armendáriz06]

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 7

slide-8
SLIDE 8

Overview

  • Geometry-Aware Resizing
  • Fine-Grained Resizing
  • Automatic Framerate Control
  • Results and Demo
  • Discussions and Conclusion

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 8

slide-9
SLIDE 9

Our Approach

  • Geometry-Aware Resizing

– Upsample according to geometric similarities between lo-res and hi-res buffers – Two-pass technique

  • 1st pass: Render geometry with the original pixel

shader on low-res buffer, store geometric info (normal & depth) + color

  • 2nd pass: Render geometry at full resolution and

use geometry-aware kernel to reconstruct the shading from the lo-res buffer

9 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

slide-10
SLIDE 10

Geometry-Aware Resizing

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 10

upsample color z n (z) depth (n) normal (z) depth (n) normal

1st pass 2nd pass

Vertex/ Geometry processing Pixel processing

slide-11
SLIDE 11

Geometry-Aware Reconstruction

Weight samples based on geometric similarity

1 1 1 1 0.1 0.9 0.9 0.9

Bilinear Bilateral

11 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

slide-12
SLIDE 12

Color sample j from the low-res buffer Filter weight of sample j Color sample j from the low-res buffer Filter weight of sample j

Joint Bilateral Filter

12 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

slide-13
SLIDE 13

Color sample j from the low-res buffer Spatial filter: bilinear / biquadratic / bicubic / Gaussian Color sample j from the low-res buffer Spatial filter: bilinear / biquadratic / bicubic / Gaussian

Joint Bilateral Filter

13 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

slide-14
SLIDE 14

Color sample j from the low-res buffer Range filter 1: Gaussian of the normal distance Color sample j from the low-res buffer Range filter 1: Gaussian of the normal distance

Joint Bilateral Filter

14 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

slide-15
SLIDE 15

Color sample j from the low-res buffer Range filter 2: Gaussian of the depth distance Color sample j from the low-res buffer Range filter 2: Gaussian of the depth distance

Joint Bilateral Filter

15 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

slide-16
SLIDE 16

Joint Bilateral Filter

16 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

slide-17
SLIDE 17

Joint Bilateral Filter

17 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

slide-18
SLIDE 18

Overview

  • Geometry-Aware Resizing
  • Fine-Grained Resizing
  • Automatic Framerate Control
  • Results and Demo
  • Discussions and Conclusion

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 18

slide-19
SLIDE 19

Fine-Grained Resizing

  • Resize only expensive & spatially smooth

computations

  • Break up the original shader

– Expensive & spatially smooth computation: 1st pass (at low-res) – Inexpensive / spatially high-freq computation: 2nd pass (at full-res)

19 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

slide-20
SLIDE 20

Fine-Grained Resizing

+ =

1st pass 2nd pass

20 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

slide-21
SLIDE 21

Comparison: Bilinear vs. Bilateral

  • Fine-grained resizing + Bilinear upsample?

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 21

slide-22
SLIDE 22

Overview

  • Geometry-Aware Resizing
  • Fine-Grained Resizing
  • Automatic Framerate Control
  • Results and Demo
  • Discussions and Conclusion

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 22

slide-23
SLIDE 23

Automatic Framerate Control

  • Dynamically select resizing factor r to

maintain a constant framerate

  • Use a feedback control mechanism
  • Input: previous frame-time
  • Output: r
  • Integral controller

23 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

Integral controller Reference frame-time 1st pass Original Shader 2nd pass Geometry-Aware Upsampler r Actual frame-time

slide-24
SLIDE 24

Controller Formulation

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 24

  • 1. Pixel processing

time ∝ # of pixels

  • 2. Pixel-bound

Constant screen coverage

slide-25
SLIDE 25

AFC implementation

  • Limit the range of Δt, Δr and r
  • Experimentally determine K’ with the

maximum screen coverage

25 Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence

slide-26
SLIDE 26

Overview

  • Geometry-Aware Resizing
  • Fine-Grained Resizing
  • Automatic Framerate Control
  • Results and Demos
  • Discussions and Conclusion

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 26

slide-27
SLIDE 27

Results – Car

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 27

slide-28
SLIDE 28

Results – Car (con’t)

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 28

slide-29
SLIDE 29

Results – Chess

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 29

slide-30
SLIDE 30

Results – Chess (con’t)

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 30

slide-31
SLIDE 31

Results – Dragon

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 31

slide-32
SLIDE 32

Results – Dragon (con’t)

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 32

slide-33
SLIDE 33

AFC results

  • Experimental data:

– Over 1000 frames – Various outside disturbances

  • View changes
  • Screen coverage changes
  • Shader workload changes

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 33

slide-34
SLIDE 34

Overview

  • Geometry-Aware Resizing
  • Fine-Grained Resizing
  • Automatic Framerate Control
  • Results and Demo
  • Discussions and Conclusion

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 34

slide-35
SLIDE 35

Limitations

  • Resizing high frequency signal

– Popping and flickering artifacts (aliasing)

  • Undersampled fine geometry

– Missing details around regions with high depth/normal complexities – Recompute missing samples in a 3rd pass?

  • Added geometry processing overhead

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 35

slide-36
SLIDE 36

Practical Advantages

  • Multiple shader / objects

– Sharing the same resized buffer – Sharing the reconstruction pass – Allow unified AFC

  • Easy to apply

– Mainly an added reconstruction pass

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 36

slide-37
SLIDE 37

Conclusion

  • A general approach for reducing shading

costs

  • Respect geometric discontinuities better

than conventional resizing

  • Allow continuous adjustment of

error/performance tradeoff

  • Automatic framerate control
  • Straightforward to incorporate into

existing systems

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 37

slide-38
SLIDE 38

Future Work

  • Multi-resolution resizing
  • Automated selection of resized elements
  • Resize for super-sample anti-aliasing
  • Obtain a Bosnia-Herzegovina visa ☺

Geometry-Aware Framebuffer LOD -- L. Yang, P. V. Sander, J. Lawrence 38

slide-39
SLIDE 39

Questions?

10 r 1
