Generating Low-Overhead Dynamic Binary Translators Mathias Payer and Thomas R. Gross Department of Computer Science ETH Z rich Motivation Binary Translation (BT) well known technique for late transformations Extend or add

slide-1
SLIDE 1

Generating Low-Overhead Dynamic Binary Translators

Mathias Payer and Thomas R. Gross Department of Computer Science ETH Z rich ü

slide-2
SLIDE 2

2 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Motivation

  • Binary Translation (BT) well known technique for late

“ ” transformations

  • Extend or add features on the fly
  • Flexibility of dynamic software BT incurs runtime overhead
  • Complexity of transformations can be a challenge
  • Offer a high-level interface at compile time, compile into effective

translation tables

slide-3
SLIDE 3

3 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Outline

  • Introduction
  • Design and Implementation
  • Table generation
  • Translator
  • Optimization
  • Conclusion
slide-4
SLIDE 4

4 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Binary Translation in a Nutshell

Static translation

1 2 3 4 Original program 0' 1' 2' 3' 4' Instrumented program What about:

  • Self modifying code?
  • Shared libraries?
  • Obfuscated Code?

?

slide-5
SLIDE 5

5 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Binary Translation in a Nutshell

Dynamic translation

1 2 3 4 Original program

...

0' 1' 2' 3' Instrumented program

... ...

Features:

  • Translates all executed

code

  • Captures all indirect

control flow transfers

  • Just in time translation
slide-6
SLIDE 6

6 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Binary Translation in a Nutshell

Translator

Gen.

  • pcode

table

1' 2' 3' Code cache 1 2 3 4 Original program

...

Table generator

supplies generated

  • pcode tables

at compile time

slide-7
SLIDE 7

7 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Binary Translation in a Nutshell

Translator

Gen.

  • pcode

table

1' 2' 3'

Trampoline to translate 4

Code cache 1 2 3 4 Original program 3 3' 1 1' 2 2' Mapping

...

slide-8
SLIDE 8

8 ETH Z rich / LST / Mathias Payer ü 2010-05-26

fastBT

  • Prototype for a dynamic BT system
  • Machine-independent, OS-independent
  • Focus of this talk: IA32, Linux
slide-9
SLIDE 9

9 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Table Generation

  • Translation tables describe individual instructions and are

used to select the correct adapter functions

  • Manual table construction is hard & cumbersome
  • Many instructions, write machine-code tables by hand
  • Use automation and high level description!
  • Information about opcodes, possible encodings, and properties
  • Specify default translation actions

Intel IA32

  • pcode

tables

  • High level interface
  • Adapter functions

Optimized translator table

Table generator

slide-10
SLIDE 10

10 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Table Generation

  • Use table generator to offer high-level interface
  • Transforming opcode tables into runtime translation tables
  • Add analysis functions to control the table generation
  • Memory access?
  • What are src, dst, aux parameters?
  • FPU usage?
  • What kind of opcode?
  • What opcode class (load, store, arithmetic, control flow, ...)?
  • Immediate value as pointer?
  • etc.
slide-11
SLIDE 11

11 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Translator implementation

  • Translator uses an iterator based approach and per-

instruction actions

  • Fundamentals to master low overhead:
  • Code cache
  • Inlining
  • Master (indirect) control transfers
slide-12
SLIDE 12

12 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Optimization

  • Indirect control flow transfers are expensive
  • Runtime lookup and patching required
  • Indirect control transfer replaced by software trap
  • Optimizations in fastBT:
  • Local branch prediction
  • Inlining a fast lookup into the code cache
  • Building on-the-fly shadow jump tables
slide-13
SLIDE 13

13 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Optimization: Branch prediction

  • Cache the last one or two targets
  • If there is a cache hit
  • No lookup is needed
  • Results in 3 to 5 instructions
  • If there is a cache miss
  • Lookup the target and cache it for future use
  • Updating the cache costs additional instructions
slide-14
SLIDE 14

14 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Optimization: Fast lookup

  • Emit an inlined fast lookup into the code cache
  • Uses the mapping table to translate the target
  • Optimized for direct hit in the mapping table
  • Results in 13 or 14 instructions
slide-15
SLIDE 15

15 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Optimization: Shadow jump table

  • Build a shadow jump table, iff the original indirect control

transfer uses a jump table

  • Initialize all entries with catch-all function
  • Lazy lookup and write-back in catch-all
  • Results in 5 instructions if the target is translated
slide-16
SLIDE 16

16 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Optimization: Problem

  • Each optimization is only effective for some program

locations and a specific program behavior

  • Low number of targets, few changes
  • Use a cache
  • High number of targets, many changes
  • Use fast lookup
  • Location has many different targets, all close to each other
  • Use a shadow jump-table
  • An adaptive runtime optimization can select the best
  • ptimization for each indirect control transfer
slide-17
SLIDE 17

17 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Adaptive Optimization

  • fastBT offers an adaptive optimization for indirect control

transfers

  • Start with a prediction for 1 or 2 locations, count misses
  • Recover to a fast lookup, if count exceeds threshold
  • Construct a shadow jump-table, if the control transfer uses a jump

table

  • Adaptive optimizations bring competitive performance!
slide-18
SLIDE 18

18 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Benchmarks: Setup

  • Used null-transformation to show translation overhead
  • Used SPEC CPU2006 benchmarks to evaluate

performance

  • We use the Test dataset for short running programs and the Ref

dataset for long running programs

  • Machine: E6850 Intel Core2Duo @ 3.00GHz
slide-19
SLIDE 19

19 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Related work

  • HDTrans
  • S. Sridhar et al. HDTrans: a low-overhead dynamic translator.

SIGARCH'07

  • Table based dynamic BT, no high level interface
  • DynamoRIO
  • D. Bruening et al. Design and implementation of a dynamic
  • ptimization framework for windows. In ACM Workshop Feedback-

directed Dyn. Opt. (FDDO-4) (2001).

  • IR based optimizing BT, does not export a translation interface
  • PIN
  • C.-K. Luk et al. Pin: building customized program analysis tools with

dynamic instrumentation. In PLDI'05

  • High overhead, offers high level interface
slide-20
SLIDE 20

20 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Benchmarks: Ref dataset

400.perlbench 445.gobmk 483.xalancbmk 447.dealII Average 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100% 126%

fastBT HDTrans PIN dynamoRIO Overhead

slide-21
SLIDE 21

21 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Benchmarks: Ref dataset

Benchmark Function calls 1) inlined Indirect jumps 1) jmptbl pred Indirect calls 1) pred 400.perlbench 25'814 8.1% 21'930 93.7% 6.3% 3'903 7.4% 445.gobmk 18'001 1.3% 93 1.0% 99.0% 185 4.1% 483.xalancbmk 28'888 10.6% 2'627 27.0% 63.6% 9'161 96.1% 447.dealII 52'756 54.5% 21'147 1.7% 98.3% 540 98.4%

1) All numbers are *106

slide-22
SLIDE 22

22 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Benchmarks: Test dataset

400.perlbench 445.gobmk 483.xalancbmk 447.dealII Average 0% 20% 40% 60% 80% 100% 120% 140%

fastBT HDTrans PIN dynamoRIO Overhead

1415% 308% 3481% 745%

slide-23
SLIDE 23

23 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Benchmarks: Ref vs. Test Dataset

Ref dataset Test dataset Benchmark no BT [s] fastBT no BT[s] fastBT 400.perlbench 486 56% 4 29% 445.gobmk 611 18% 21 18% 483.xalancbmk 371 24% <1 56% 447.dealII 552 44% 25 36% Average 839 6% 8 10%

slide-24
SLIDE 24

24 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Benchmarks: Summary

  • High overhead:
  • Many indirect control transfers
  • Function calls incur high overhead, even with optimizations
  • Indirect control transfers without caches or jump tables add overhead
  • High collision rate in mapping table
  • Expensive recoveries, try different rescheduling strategies
  • Low overhead:
  • Few indirect control transfers
  • Cost of indirect control transfers is reduced through optimizations
slide-25
SLIDE 25

25 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Conclusion

  • fastBT shows that it is possible to combine ease of use

with efficient binary translation

  • Adaptive optimizations select best optimization for

individual locations

  • Adaptive optimizations are necessary for low overhead in

table based binary translators

slide-26
SLIDE 26

26 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Thanks for your attention!

  • fastBT project page: http://nebelwelt.net/fastBT
  • Contact: mathias.payer@inf.ethz.ch
  • Kudos to:
  • Marcel Wirth, Peter Suter, Stephan Classen, and Antonio Barresi for

code contributions

  • My colleagues for endless comments and reviews

?

slide-27
SLIDE 27

27 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Table Generation: Analysis Function

bool isMemOp (const unsigned char* opcode, const instr& disInf, std::string& action) { bool res; /* check for memory access in instr. */ res = mayOpAccessMem(disInf.dstFlags); res |= mayOpAccessMem(disInf.srcFlags); res |= mayOpAccessMem(disInf.auxFlags); /* change the default action */ if (res) { action = "handleMemOp"; } return res; } // in main function: addAnalysFunction(isMemOp);

slide-28
SLIDE 28

28 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Optimization: Efficient Code

  • Static ind. call: call *(fixed_location)

pushl src_addr (1) cmpl $cached_target, *xx(i_trgt) (2) je $trans_target pushl *xx(ind_target) (3) pushl $tld pushl $addr_of_cached_target call fix_ind_call_predict pushl src_addr jmp *xx(ind_target)

  • 1. Push original src IP
  • 3. Recover if there is a misprediction
  • 2. Compare actual target w/ cached target & branch if prediction ok
slide-29
SLIDE 29

29 ETH Z rich / LST / Mathias Payer ü 2010-05-26

Optimization: Efficient Code

  • Dynamic ind. call: call *(reg)

pushl src_addr, *(reg), %ebx, %ecx movl 12(%esp), %ebx # load target movl %ebx, %ecx # duplicate ip andl HASH_PATTERN, %ebx # hash fct cmpl hashtlb(0, %ebx, 8), %ecx # check jne nohit movl hashtlb+4(0, %ebx, 8), %ebx # load trgt movl %ebx, (tld->ind_jmp_targt) popl %ecx, %ebx # epilogue leal 4(%esp), %esp # readjust stack jmp *(tld->ind_jmp_targt) # jmp to trans.trgt nohit: use ind_jump to recover

pushl src_addr jmp *(reg)
