The powerPerfector IQ is Born Secure your most Valuable asset

• Your Electricity Supply

Generate high savings and a 30% and higher ROI Essential in the 21st century Take control of your power for the first time

• Designed from the bottom up to improve power quality
• 100% safety and reliability record
• 6,000 units installed in Great Britain -100,000+ worldwide
• FT.com: “The Green Holy Grail”
• 15 year warranty and a 100 year lifecycle
• Average savings across all sites – 6 - 15 per cent

powerPerfector IQ – Optimiser fundamentals

• Networks - Old Architecture challenged by New “Renewable” Technology
• Unidirectional supply change to Multi-directional supply
• Wind/solar/battery/micro-generation, demand and frequency response
• Increased switching and transients
• Higher Voltage levels (Voltage stacking from Grid supply competition)
• Increased Voltage volatility (from intermittent renewable supply)
• Reduced inertia due to switch from Carbon Generation to Renewables
• Power Conditioning from powerPerfector becomes essential to mitigate risk

Universal Grid Challenges from Renewables

• At-source Intelligent Power Optimisation
• Guarantees electrical equipment runs efficiently

powerPerfector IQ – downstream of your supply

Precise, stable and balanced supply of your electricity supply for the first time

• Single integrated unit
• Handmade Peak efficiency: 99.94%
• No moving parts
• No bypass needed
• No forced cooling or temperature monitoring
• Precise Voltage setting from the iQ
• No maintenance required
• 15 year warranty
• No failures in 20yrs and 150,000 units
• Power Quality improvement by design
• 25% improved savings with iQ electronics

Standard VPO that the iQ now controls

Reactive power reduction of 25% - 50%

• Improved Power Factor – reduces KVA charges
• Increases the amount of available power to run equipment
• Results in more efficient use of power and increases room on your breaker

Power Factor improvement 8% - 20%

• Reduces risk of harmonic damage to sensitive electronic equipment and computer chips
• Extends the life of all electrically powered equipment and their control systems.

Harmonic Distortion reduced by 10% - 20%

• Transients damage and disrupt calibration of electronic controls and automated systems

“We were suffering from voltage spikes (transients) which on numerous occasions damaged the lift controls causing them to stop operating. In the 1.5 years following the powerPerfector installation there has been no repeat of the issue.” Kim Pivett, Ofgem

Common Transients from Renewables supressed

Key benefits of VPO

• 1. Reduce magnitude to optimum level
• 2. Protect against transients
• 3. Filter harmonics
• 4. Improve balance
• 5. Single inductive interaction
• 6. Installed at source
• 7. No need for continuous monitoring
• 8. No maintenance

Unique powerPerfector Optimiser schematic

• Primary winding connected in series with on-site load
• Primary winding carries 100% of load current
• Very few turns on the primary winding, turns ratio
• Very low impedance with negligible impact on existing electrical circuit – Risk mitigation
• Industry leading 99.94% efficiency at peak loading – Highest energy savings
• High efficiency and minimal heat output
• Neutral connection not required due to internal floating Neutral

Technology - Why we are different

Failure Proof

Why powerPerfector Optimiser is different

Risk pPIQ Function Benefits of pPIQ over standard powerPerfector

Increasing voltage instability of supply from multiple renewable energy feeds into the medium 11,000V and 20,000V grids

Dynamic Voltage Control

Eliminates input voltage instability electronically by controlling VPO output voltage at a constant pre-determined voltage level (+/- 0.5V or 99.998% accuracy). This ensures that a site’s equipment receives a highly stable voltage at a pre-set level. Local brownouts result in the site’s supply being too low for equipment to operate due to grid supply & demand constraints

Boosts incoming supply voltage by 10%+ below set point or 15% -25%

Custom build in 2017

Protects the site against network voltage sags due to diminishing power quality and from rapid longer term voltage reduction (brownouts) caused by grid

• verloading. If input voltages sag to 185V the pPIQ will boost the voltage back

to above 207V. Boosting lower voltage sags by 15%, 20% or 25% is achievable with custom units - increasing site resilience. The incoming supply voltage fluctuates rapidly or becomes erratic due to grid issues from variable renewable generation

Ultra Fast Response

Autonomous very fast response time of <0.25secs - qualifying it for enhanced frequency response and demand response for an unlimited amount of time and does not impact site operation/equipment usage Unbalance three phase supply due to Grid issues or single phase overloads reducing 3 phase equipment efficiency, operation and lifespan Increased transients and harmonics from degraded power quality due to multi-directional Grid and uncontrolled renewable feed into the Grid.

Actively controlled 3 phase voltage balancing to within 0.1% Standard Voltage Power Optimiser function

Actively corrects phase to phase voltage imbalance by correcting phase voltages to within 99.9% of each other, improving equipment operational efficiency and life span. Reducing kWh consumption. Suppresses harmonics and common transients. Reduces KVAr (c40%) and improves power Factor (8-20%)

After 4 years of R&D the powerPerfector IQ is born

pPIQ maintaining the output voltage with highly volatile input voltage and load change. Phase balancing is NOT engaged for this test.

Dotted Black Line – pPIQ Input Voltage / Colour Lines – pPIQ Lines 3 phase output

pP IQ Precise Voltage Control eliminates instability

The graph below shows the pPIQ Output Voltage control with a nominal fluctuating input voltage of 230V, this graph demonstrates the pPIQs unit ability to boost voltage - the GVC target voltage was altered at 1V increments from 216V to 253V for 1 minute durations. (3 phase balancing not engaged for test)

Dotted Black Line – pPIQ Input Voltage / Colour Lines – pPIQ 3 phase voltages

pP IQ operational results

powerPerfector technologies

powerPerfector powerPerfector plus The Future is Now The powerPerfector IQ

The graphs shows the 3 phase imbalanced voltage and the balanced voltage output after pPIQ activation. 3 phase imbalance input 3 Phase balanced output

pP IQ 3 phase individually balanced output to 0.1%

pPIQ multiple benefits

• 1. Protects from volatile voltage, diminishing power quality and common transients
• 2. Protects sites from common brownouts (Voltage Sags) during grid energy gaps
• 3. Gives you clean power for greatest operational efficiency - Future proof.
• 4. Provides security and control of your electricity supply for the first time
• 5. Highest possible energy saving due to balanced and precise fixed voltage output
• 6. Extends the life of all electrical equipment as it operates at optimal efficiency
• 7. Reduces the maintenance time and replacement costs of electrical assets
• 8. Improves Power Factor and reduces KVA charges
• 9. Future revenue potential from Demand and Frequency Response

Now you can take control of your Electricity Supply

Pre and post installation kWh

Time kWh per half hour

kWh, Cost and CO2 savings average 6% - 14%

Highest Security for the single most critical point

• f failure in your site or

business Future Income generation High Cost and Carbon Savings

The Life benefits of the powerPerfector IQ

The Bottom Line

• The average return on Investment on all our installations is 30%
• Annual savings go direct to bottom line profits
• Any saving from Energy Efficiency can be multiplied by the company’s Price Earnings Ratio
• £100,000 savings gives shareholders £1 million of value on a 10PE
• Your saving – protection – goes on for 100 years
• What other Risk Mitigation pays for itself ?

The pPIQ is designed to secure your site and give you control of your most valuable

• asset – Your Electricity Supply - for the first time.

Installed at more than…

• 300+ private companies,

including:

• Retail
• Hospitality
• Financial services
• Manufacturing
• Offices and data centres
• Many others
• 178 councils
• 98 HE / FE facilities

(all types)

• 28 government agencies

Our Customers…

Tesco – 1600 Units and 12 other Supermarket Groups
