GCT634@KAIST Invited lecture: Sound Source Separation

7 June 2018 Keunwoo Choi at QMUL.uk, Spotify.us, groovo.io

Sound Source Separation

• “Cocktail party effects”


..as if we’re simulating human brain (as if we know what’s going on there)

Let’s isolate the “target” audio signal!

Sound Source Separation

Input Target Noise Speech, Ambience Speech Noise Mixture of speech Speaker i all j != i Music ((Vocal, Drum, Guitar, Bass + ..) Instrument i all j != i

problem = f(assumptions} assumptions = {environments: {dry, wet, ..}, signal = {ch: {mono, stereo, ..}, content: {speech, music}}, target: {...}}

SSS Applications

• KA-RA-O-KE!
• Transcription
• DJing/Mixing
• Many other MIR tasks
• Once we called it a “Chicken-and-egg”;


Solving SSS would make many tasks extremely easier

BIG ASSUMPTION
 FOR A LONG WHILE

• with |STFT| (or CQT)
• 1 time-frequency bin, 1 instrument -- aka “W-disjoint”
• Phase doesn’t matter much
• It used to apply to (almost) every research

Problem config 1 -
 mixing matrix A

• There was a mixing matrix A that we’ll estimate its inverse.

s : source (instruments) a_xx : amplitude mixing coeffs x : stereo signal input ! w : estimated mixing coeffs ; y : estimated source (instruments)

ICA

• Independent Component Analysis (ICASSP ’98)
• Based on some stats -- independency, (non-)Gaussianity
• Not directly about audio but a general technique
• Example: http://www.kecl.ntt.co.jp/icl/signal/sawada/

demo/bss2to4/index.html

Further study: https://www.cs.helsinki.fi/u/ahyvarin/papers/NN00new.pdf

ADRESS

• Azimuth Discrimination and Resynthesis (DAFx 2004)
• 1-dim clustering; for stereo sound source separation

Problem config 2 -
 mixing matrix and delay

• Sources are at different angles and distances


→Mixing matrix A is also about time delay

DUET

• Location = {angle, distance}
• Each location, each 2D cluster, each instrument
• DOA (Direction Of Arrival) estimation
• Something similar is in your phone (with 2+ microphones)

to suppress non-speech sounds (but perhaps not in your earphones/headphones)

Problem config 3 - music - spectra of instruments

http://www.physics.usyd.edu.au/teach_res/hsp/sp/mod31/m31_strings.htm

NMF

• Assumptions of using NMF for SSS:
• The spectral shapes of musical instruments are known.
• NMF would separate each note (aka basis)!
• Many applications for drum separation (it works)

https://www.slideshare.net/DaichiKitamura/robust-music-signal-separation-based-on- supervised-nonnegative-matrix-factorization-with-prevention-of-basis-sharing

Problem config 4 - music - repeats

• “Instrumental parts repeat!” (↔ vocal)
• “Drums/beats repeat!” (↔ harmonic instruments)
• A valid assumption for modern popular music
• E.g., REPET (IEEE 2013), KAM (D. Fano Yela, ICASSP

2017), ...

Problem config 5 - music - some musical cases

• “Central” (~= vocal) source separation
• Because - main vocals are almost always

at the centre (and we all love karaoke)

• Harmonic/percussive source separation
• Because - they are (almost) completely

different in spectral/temporal axes

• Median filtering for drum separation (D.

Fitzgerald, DAFx)

“Gaussian mixture model for singing voice separation from stereophonic music”, M Kim et al, 2011

Problem config 6 - music - ‘informed’ source separation

• Exploiting the score as side information

“Score-Informed Source Separation for Musical Audio Recordings”, S Ewert et al., 2013

History so far...

less generality stronger assumptions

as time goes by

DEEP! LEARNING!!

DL and SSS

• Less assumptions (let’s think further papers!)
• Data-related; trained models do NOT extrapolate.


E.g., A model with speech probably wouldn’t work with music.

• Model-related; E.g., frame-based? context-free? Does

it estimate the phase? Stereo-input?

Frame-based DL-SS

• Because vocals are distinguishable in a frame (or frames)

“Deep Learning For Monaural Speech Separation”, Po-sen Huang et al, 2014

U-Net and SS

• Because vocals are distinguishable in the |STFT| image

“Singing Voice Separation With Deep U-Net Convolutional Networks”, A Jansson et al., ismir 2017 “U-Net: Convolutional Networks for Biomedical Image Segmentation”, O Ronneberger et al., 2015

A practical limitation

• Supervised learning requires a *paired*

dataset

• for such a system;


x: [mixtures]
 y: [instrumental mixtures; vocal tracks]

• → not sustainable

Inst Vocal 1 Inst Vocal 2 Inst Vocal 3

paired dataset

GANs and SS

• Weakly labelled dataset:


{many instrumental tracks}
 (aka Real)
 +
 {many voc + instrumental tracks}
 (input of aka Fake)

• We alternate to show a GAN-based model


{real instrumental / vocal-separated (fake) instrumental}
 and let the model learns


• i) to classify real/fake

• ii) to fake an instrumental track = to remove vocal


simultaneously.

Inst tracks mix tracks

unpaired dataset

Inst Vocal 1 Inst Vocal 2 Inst Vocal 3

paired dataset

“Adversarial Semi-Supervised Audio Source Separation applied to Singing Voice Extraction”, D Stoller, 2018 ICASSP

Further study

• A great SS tutorial: http://ismir2010.ismir.net/

proceedings/tutorial_1_Vincent-Ono.pdf
