CONICA Functional Flooring Presentation CONICA AG TRADITIONAL SWISS COMPANY WITH GLOBAL MARKET APPROACH Production in Schaffhausen since 1977 Targeted research and development in close connection with market requirements

slide-1
SLIDE 1

CONICA

Functional Flooring

Presentation

slide-2
SLIDE 2

2

  • Certified by international organizations
  • Products and systems meet international norms and test requirements
  • Comprehensive expertise in the area of polyurethane, polyurea,

epoxy resin and prepolymer

  • Production in Schaffhausen since 1977
  • Targeted research and development in close connection with market requirements

CONICA AG

TRADITIONAL SWISS COMPANY WITH GLOBAL MARKET APPROACH

slide-3
SLIDE 3

3

CONIPAVE

Functional Flooring

B2B SPORTS FLOORING

CONICA AG

SEGMENT STRUCTURE

Permeable Pavings

  • Footpaths and

bicycle paths in urban and rural areas

  • Permeable

(meets the requirements for „Sustainable Urban Drainage Solutions“)

  • Residential

properties, public buildings

  • Comfort, high

level of health and safety, noise reduction, variety of colours

  • Industrial areas,

residential spaces

  • Heavy resilience,

long life, quick and easy installation

  • Parking decks,

multi-storey car parks

  • Mechanical,

physical and chemical protection, slip resistant

  • Flat roofs, civil

engineering

  • Protection

against penetrating moisture, crack-bridging, elastic, fast hardening

Waterproofing Parking Industrial Decorative

slide-4
SLIDE 4

4

Flooring systems are required to meet a range of specifications, depending on whether it is to be used in public spaces such as schools, libraries and hospitals, or in private residential space. In addition to being robust and durable, the surface must in particular offer a high level of comfort, noise reduction and a wide range of colours. On top of this, particular importance is attached to health and safety aspects.

CONIFLOOR LPC

CONIFLOOR LPC+ CONIFLOOR LPC+ fl

CONIFLOOR UPD

CONIFLOOR UPD+

Solutions:

DECORATIVE

slide-5
SLIDE 5

5

CONIFLOOR LPC

  • Sealing lacquer

CONIFLOOR 540 CW

  • Coating

CONIFLOOR 440

  • Pore sealer

CONIFLOOR 310

  • Elastic layer

Thickness: 4 and 6 mm

  • Adhesive

CONIFLOOR 210

  • Base coat

CONIFLOOR 110

(cement substrate)

Low-emission, elastic floor coating based on polyurethane resin for indoor use.

DECORATIVE

SYSTEMES

  • CONIFLOOR LPC+

The use of an additional elastic layer (granulate mat) provides for a highly elastic and more comfortable effect.

  • CONIFLOOR LPC+ fl

The use of an flame-retardant layer provides for a higher flame resistance.

System Options:

slide-6
SLIDE 6

6

Highlights Application areas

 Odorless  High flexibility and elasticity  High chemical resistance  Seamless  High quality and safety  Noise reduction  Long life  Perfect combination of optic and comfort  Almost all colours & gloss intensity possible  UV resistant Residential properties, exhibition areas, offices, hospitals Certificates and test reports  Emission test acc. to AgBB  Fire classification acc. to DIN EN 13501

CONIFLOOR LPC

DECORATIVE

SYSTEMES

slide-7
SLIDE 7

7

Aliphatic, low-emission and elastic floor coating based on polyurethane resin for indoor use.

  • Sealing lacquer

CONIFLOOR 540 W

  • Coating

CONIFLOOR 450

  • Pore sealer

CONIFLOOR 310

  • Elastic layer

Thickness: 4 and 6 mm

  • Adhesive

CONIFLOOR 210

  • Base coat

CONIFLOOR 110

(cement substrate)

CONIFLOOR UPD

DECORATIVE

SYSTEMES

  • CONIFLOOR UPD+

The use of an additional elastic layer with the corresponding sealing of the pores provides for for a highly elastic and more comfortable effect.

System options

slide-8
SLIDE 8

8

Highlights Application areas

Schools, hospitals, libraries, canteens Certificates and test reports

 Emission test acc. to AgBB  Fire classification acc. to DIN EN 13501

 Odorless  High flexibility and elasticity  High chemical resistance  Seamless  High quality and safety  Noise reduction  Long life  Perfect combination of optic and comfort  Almost all colours & gloss intensity possible  UV resistant

CONIFLOOR UPD

DECORATIVE

SYSTEMES

slide-9
SLIDE 9

9

ZHAW, Winterthur / Switzerland ZHdK, Zurich / Switzerland Lascentrum Welding & Cutting, Alblasserdam / Holland Lascentrum Welding & Cutting, Alblasserdam / Holland

DECORATIVE

REFERENCES

slide-10
SLIDE 10

10

Resistant and resilient flooring systems are in high demand in the industrial sector. CONICA

  • ffers high quality system solutions that distinguish themselves far beyond the competition

through their high durability and ease of processing.

CONIFLOOR IPS

CONIFLOOR IPS as

CONIFLOOR IES

CONIFLOOR IES sr

Solutions:

INDUSTRIAL

slide-11
SLIDE 11

11

Three-layer, low-emission, hard polyurethane flooring system for indoor use.

  • Sealing lacquer

CONIFLOOR 520 CW

  • Coating

CONIFLOOR 420

  • Intermediate layer

CONIFLOOR 420

  • Primer

CONIFLOOR 110

  • Concrete

CONIFLOOR IPS

INDUSTRIAL

SYSTEMS

  • CONIFLOOR IPS as

Possesses additional antistatic properties.

System Options

slide-12
SLIDE 12

12

Highlights Application areas

 Easy to install  High mechanical resistance  Robust  Seamless  Slip resistant  Crack-bridging  Antistatic option possible  Easy to clean  Long life  High quality and safety Production halls, warehouses

Certificates and test reports  Emission test acc. to AgBB

 Fire classification acc. to DIN EN 13501  Friction coefficient test  Determination of crack bridging properties

CONIFLOOR IPS

INDUSTRIAL

SYSTEMS

slide-13
SLIDE 13

13

Three-layer, low-emission, industrial flooring system based on epoxy resin for indoor use.

  • Sealing lacquer

CONIFLOOR 520 CW

  • Coating

CONIFLOOR 430

  • Scratch coat

CONIFLOOR 110

  • Primer

CONIFLOOR 110

  • Concrete

CONIFLOOR IES

INDUSTRIAL

SYSTEMS

  • CONIFLOOR IES sr

Possesses additional sanded, slip resistant surface.

System Options

slide-14
SLIDE 14

14

Highlights Application areas

 Easy to install  High mechanical resistance  Robust  Seamless  Slip resistant (enhancement of slip resistancy possible due to additional sanded coating)  Easy to clean  Long life  High quality and safety Production areas, warehouses

Certificates and test reports  Fire classification acc. to DIN EN 13501-1

 Friction coefficient test

CONIFLOOR IES

INDUSTRIAL

SYSTEMS

slide-15
SLIDE 15

15

Sell Plastics, Nijkerk / Holland Warehouse Magazzini Raccordat, Cesena / Italy CK Industries Factory, Johannesburg / South Africa Tu Plast Warehouse, Debrecen / Hungary

INDUSTRIAL

REFERENCES

slide-16
SLIDE 16

16

Surfaces for parking decks and in multi-storey car parks must be able to both resist mechanical strain and withstand physical and chemical influences.

CONIPROOF PE CONIPROOF PP sl CONIPROOF PP dl

Solutions:

PARKING

slide-17
SLIDE 17

17

Rigid parking-deck coating based on epoxy resin.

  • Top coat

CONIPROOF 590 / 591

  • Scratch coat
  • Scratch coat

CONIPROOF 190 / 191

  • Primer

CONIPROOF 190 / 191

  • Concrete

CONIPROOF PE

PARKING

SYSTEMS

slide-18
SLIDE 18

18

Highlights Application areas

 Easy to install  High mechanical resistance  Abrasion-resistant  Slip resistant  Seamless  Long life  High quality and safety Underground parkings

Certificates and test reports

Test reports acc. to OS8 der Rili SIB des DAfSt

  • resp. to EN 1504-2

CONIPROOF PE

PARKING

SYSTEMS

slide-19
SLIDE 19

19

Crack-bridging parking-deck coating based on polyurethane.

  • Top coat

CONIPROOF 590 / 591

  • Wear coat

CONIPROOF 490

  • Scratch coat
  • Primer

CONIPROOF 190 / 191

  • Concrete

CONIPROOF PP sl

PARKING

SYSTEMS

slide-20
SLIDE 20

20

Highlights Application areas

 High surface protection  Easy to install  High mechanical resistance  Abrasion-resistant  Slip resistant  Crack-bridging  Seamless  Long life  High quality and safety Underground parkings, intermediate decks Tested as surface protection system acc. to OS11b der Rili SIB des DAfSt resp. to EN 1504-2

Certificates and test reports

CONIPROOF PP sl

PARKING

SYSTEMS

slide-21
SLIDE 21

21

Crack-bridging parking-deck coating based on polyurethane.

  • Top coat

CONIPROOF 590 / 591

  • Wear coat

CONIPROOF 491

  • Floating layer

CONIPROOF 490

  • Scratch coat
  • Primer

CONIPROOF 190 / 191

  • Concrete

CONIPROOF PP dl

PARKING

SYSTEMS

slide-22
SLIDE 22

22

Highlights Application areas

Intermediate decks and exposed top-floor parking decks

Certificates and test reports

Tested as surface protection system acc. to OS11b der Rili SIB des DAfSt resp. to EN 1504-2  High surface protection  Easy to install  High mechanical resistance  Abrasion-resistant  Slip resistant  Crack-bridging  Seamless  Long life  High quality and safety

CONIPROOF PP dl

PARKING

SYSTEMS

slide-23
SLIDE 23

23

Glatten, Germany Glatten, Germany

PARKING

REFERENCES

slide-24
SLIDE 24

24

Waterproofing systems are used above all wherever protection against penetrating moisture is required, as is the case in residential space, particularly on flat roofs and balconies, and in civil engineering (e.g. tunnels).

CONIPROOF SP CONIPROOF SU

Solutions:

WATERPROOFING

slide-25
SLIDE 25

25

Two-component, solvent-free and elastic polyurethane spray coating.

  • Top coat

CONIPROOF 510 C

  • Polyurethane-

spray coating

CONIPROOF 410

  • Scratch coat

sanded with quartz sand 0.3-0.8 mm

  • Concrete

CONIPROOF SP

WATERPROOFING

SYSTEMS

slide-26
SLIDE 26

26

Highlights Application areas

 Can be applied on walls, ceilings and concrete upstands  Very fast hardening  Elastic  Impermeable Civil engineering, roofs, bridges

CONIPROOF SP

WATERPROOFING

SYSTEMS

slide-27
SLIDE 27

27

Two-component, solvent-free and highly elastic polyurea spray coating.

  • Top Coat

CONIPROOF 510 C

  • Polyurea –

spray coating

CONIPROOF 401

  • Primer

sanded with quartz sand 0.3-0.8 mm

  • Concrete

CONIPROOF SU

WATERPROOFING

SYSTEMS

slide-28
SLIDE 28

28

Highlights Application areas

 For heavy duty surfaces  Very fast hardening  Elastic (more elastic than CONIPROOF SP)  Impermeable  High crack-bridging Structural und civil engineering

CONIPROOF SU

WATERPROOFING

SYSTEMS

slide-29
SLIDE 29

29

Verein Grazer Turnerschaft, Graz / Austria

WATERPROOFING

REFERENCES

slide-30
SLIDE 30

30

In addition to durability and slip resistance, these systems offer particularly high water permeability, which enables them to meet a wide range of urban requirements. This makes them ideally suited for all urban applications, including footpaths and bicycle paths, parks and house driveways.

CONIPAVE RA

Solution:

PERMEABLE PAVINGS

slide-31
SLIDE 31

31

Water-permeable flooring system composed of a mixture of decorative natural stones and recycled rubber granules.

  • Mixture of decorative natural

stones and recycled rubber granules

CONIPAVE RA

RED aggregate YELLOW aggregate SILVER aggregate Available blends:

PERMEABLE PAVINGS

SYSTEMS

slide-32
SLIDE 32

32

Highlights Application areas

 Environment friendly and sustainable due to usage of natural elements  Long life  Slip resistant  Permeable Footpaths, bicycle paths and roads, golf courses, playgrounds, parks and tree-base protections

Certificates and test reports

Meets requirements for „Sustainable Urban Drainage Solutions“

CONIPAVE RA

PERMEABLE PAVINGS

SYSTEMS

slide-33
SLIDE 33

33

Baia Mare, Romania Baia Mare, Romania

PERMEABLE PAVINGS

REFERENCES
