Andrea Marin From Systems to Components: Constructive Methods for Product-Form Solutions: other product-forms Andrea Marin 1 Maria Grazia Vigliotti 2 1 Dipartimento di Informatica Universit Ca Foscari di Venezia 2 Department of Computing


slide-1
SLIDE 1

Andrea Marin

From Systems to Components: Constructive Methods for Product-Form Solutions: other product-forms

Andrea Marin 1 Maria Grazia Vigliotti2

1Dipartimento di Informatica

Università Ca’ Foscari di Venezia

2Department of Computing

Imperial College London

Andrea Marin University of Venice

slide-2
SLIDE 2

Andrea Marin

Second part: sketch

1 Multiple application of (G)RCAT A class of

non-pairwise cooperations are considered. We show how multiple applications of (G)RCAT can still derive the product-form solution when it exists. Case studies: finite capacity queues with skipping [Pittel ’79, Balsamo et al. ’10], G-networks with signals [Harrison ’04b].

2 Extended Reversed Compound Agent Theorem

(ERCAT). The Extended Reversed Compound Agent Theorem [Harrison ’04a] is introduced. Applications for cooperations of pairs of automata which do not yield structural conditions of RCAT are shown.

Andrea Marin University of Venice

slide-3
SLIDE 3

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Part I Multiple applications of RCAT

Andrea Marin University of Venice

slide-4
SLIDE 4

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Outline

1 A mild introduction 2 Finite capacity queues with skipping: the RCAT solution 3 Product-form solution for G-networks with positive

Andrea Marin University of Venice

slide-5
SLIDE 5

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Preliminary

... . . . . . . . . . . . .

N0 N1 N2 λ1 λ1 λ1 λN λN λN µ1 µ1 µ1 (a, µi) (a, µi) (a, µi) µM µM µM

  • Value Ka may be interpreted as the sum of the reversed

rates of the active transitions labelled by a incoming into each state

  • In case of Birth and Death processes this may be easily

computed, i.e.: Ka = N

j=1 λj

M

j=1 µj

µi

Andrea Marin University of Venice

slide-6
SLIDE 6

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

RCAT or GRCAT?

  • The Reversed Compound Agent Theorem (RCAT)

[Harrison ’03] requires each state to have one incoming active transition for each synchronising label. Value Ka may be interpreted as the (constant) reversed rate of this unique transition.

  • The Generalisation (GRCAT) proposed in

[Marin et al. ’10] requires each state to have at least

  • ne incoming active transition for each synchronising
  • label. Value Ka may be interpreted as the (constant)

sum of the reversed rates of these transitions.

Andrea Marin University of Venice

slide-7
SLIDE 7

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Skipping mechanism for queues with finite capacity

  • Consider a tandem of exponential queues, Q1 and Q2
  • Q1 has a finite capacity B1 > 0
  • Customers arrive according to a homogeneous Poisson

process at Q1

  • If at the arrival epoch Q1 is saturated, the customer

immediately enters in Q2

  • After service completion in Q1 customers go to Q2

Q1 Q2 λ µ1 µ2

Andrea Marin University of Venice

slide-8
SLIDE 8

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Standard RCAT analysis

  • Processes:

Q1 Q2 λ λ λ (a, λ) (a, µ1) (a, µ1) (a, µ1) (a, xa) (a, xa) (a, xa) µ2 µ2 µ2 1 1 2 2 B1

  • Clearly, the reversed rates of a-transitions are constant,

hence Ka = λ

  • Structural (G)RCAT conditions are satisfied
  • Steady-state distribution:

π(n1, n2) ∝ λ µ1 n1 λ µ2 n2 with 0 ≤ n1 ≤ B1, n2 ≥ 0

Andrea Marin University of Venice

slide-9
SLIDE 9

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Standard RCAT analysis

  • Processes:

Q1 Q2 λ λ λ (a, λ) (a, µ1) (a, µ1) (a, µ1) (a, xa) (a, xa) (a, xa) µ2 µ2 µ2 1 1 2 2 B1

  • Clearly, the reversed rates of a-transitions are constant,

hence Ka = λ

  • Structural (G)RCAT conditions are satisfied
  • Steady-state distribution:

π(n1, n2) ∝ λ µ1 n1 λ µ2 n2 with 0 ≤ n1 ≤ B1, n2 ≥ 0

Andrea Marin University of Venice

slide-10
SLIDE 10

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Standard RCAT analysis

  • Processes:

Q1 Q2 λ λ λ (a, λ) (a, µ1) (a, µ1) (a, µ1) (a, xa) (a, xa) (a, xa) µ2 µ2 µ2 1 1 2 2 B1

  • Clearly, the reversed rates of a-transitions are constant,

hence Ka = λ

  • Structural (G)RCAT conditions are satisfied
  • Steady-state distribution:

π(n1, n2) ∝ λ µ1 n1 λ µ2 n2 with 0 ≤ n1 ≤ B1, n2 ≥ 0

Andrea Marin University of Venice

slide-11
SLIDE 11

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Standard RCAT analysis

  • Processes:

Q1 Q2 λ λ λ (a, λ) (a, µ1) (a, µ1) (a, µ1) (a, xa) (a, xa) (a, xa) µ2 µ2 µ2 1 1 2 2 B1

  • Clearly, the reversed rates of a-transitions are constant,

hence Ka = λ

  • Structural (G)RCAT conditions are satisfied
  • Steady-state distribution:

π(n1, n2) ∝ λ µ1 n1 λ µ2 n2 with 0 ≤ n1 ≤ B1, n2 ≥ 0

Andrea Marin University of Venice

slide-12
SLIDE 12

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Possible generalisation?

  • Consider a sequence of N exponential stations

Q1, . . . , QN with finite capacities B1, . . . , BN

  • Customers arrive at Qi according to a homogeneous

Poisson process with rate λi, 1 ≤ i ≤ N

  • At a job completion at queue Qi, the customer tries to

enter queue Qi+1, 1 ≤ i < N

  • A customer is allowed to enter Qi if this is not saturated,
  • r must try to enter Qi+1 otherwise, 1 ≤ i < N
  • After a job completion at queue QN or if this is

saturated, customers leave the system

  • Note the system in unconditionally stable

Andrea Marin University of Venice

slide-13
SLIDE 13

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Are these pairwise cooperations?

Q1 Q2 Q3 QN λ1 λ2 λ3 λN µ1 µ2 µ3 µN

  • Each transition in the system may change the state of
  • nly two components but. . .
  • Consider the cooperation between Q1 and Q3: an

arrival or a job completion at Q1 may generate an arrival at Q3 depending on the state of Q2!

  • The cooperation cannot be described only in terms of

pairs of queues in isolation

  • These cases may still be studied by RCAT with multiple

applications

Andrea Marin University of Venice

slide-14
SLIDE 14

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Outline

1 A mild introduction 2 Finite capacity queues with skipping: the RCAT solution 3 Product-form solution for G-networks with positive

Andrea Marin University of Venice

slide-15
SLIDE 15

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Cooperating processes

Q1 Q2 Q3 QN λ1 λ1 λ2 λ2 λ3 λ3 λN λN λN (a12, µ1) (a12, µ1) (a12, λ1) (a12, x12) (a12, x12) (a12, x12) (a23, K12) (a23, µ2) (a23, µ2) (a23, λ2) (a23, x23) (a23, x23) (a23, x23) (a34, K23) (a34, µ3) (a34, µ3) (a34, λ3) (a(N−1)N, x(N−1)N) (a(N−1)N, x(N−1)N) µN µN 1 1 1 1 B1 B2 B3 BN Andrea Marin University of Venice

slide-16
SLIDE 16

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Peculiarity of the model

  • For 1 < i < N a self-loop of state Bi has two roles:
  • it is passive with respect to cooperation label a(i−1)i
  • it is active with respect to cooperation label ai(i+1) and

has K(i−1)i as a forward rate

  • We apply (G)RCAT multiple times adding at each time

a new queue

Andrea Marin University of Venice

slide-17
SLIDE 17

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Application of RCAT to the first two queues

Q1 Q2 λ1 λ1 λ2 λ2 (a12, µ1) (a12, µ1) (a12, λ1) (a12, x12) (a12, x12) (a12, x12) (a23, µ2) (a23, µ2) (a23, λ2) 1 1 B1 B2

RCAT can be applied because:

  • Structural conditions on passive transitions are satisfied
  • Structural conditions on active transitions are satisfied
  • We have K12 = λ1

Andrea Marin University of Venice

slide-18
SLIDE 18

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Application of RCAT to the first two queues

Q1 Q2 λ1 λ1 λ2 λ2 (a12, µ1) (a12, µ1) (a12, λ1) (a12, x12) (a12, x12) (a12, x12) (a23, µ2) (a23, µ2) (a23, λ2) 1 1 B1 B2

RCAT can be applied because:

  • Structural conditions on passive transitions are satisfied
  • Structural conditions on active transitions are satisfied
  • We have K12 = λ1

Andrea Marin University of Venice

slide-19
SLIDE 19

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Application of RCAT to the first two queues

Q1 Q2 λ1 λ1 λ2 λ2 (a12, µ1) (a12, µ1) (a12, λ1) (a12, x12) (a12, x12) (a12, x12) (a23, µ2) (a23, µ2) (a23, λ2) 1 1 B1 B2

RCAT can be applied because:

  • Structural conditions on passive transitions are satisfied
  • Structural conditions on active transitions are satisfied
  • We have K12 = λ1

Andrea Marin University of Venice

slide-20
SLIDE 20

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Application of RCAT to the first two queues

Q1 Q2 λ1 λ1 λ2 λ2 (a12, µ1) (a12, µ1) (a12, λ1) (a12, x12) (a12, x12) (a12, x12) (a23, µ2) (a23, µ2) (a23, λ2) 1 1 B1 B2

RCAT can be applied because:

  • Structural conditions on passive transitions are satisfied
  • Structural conditions on active transitions are satisfied
  • We have K12 = λ1

Andrea Marin University of Venice

slide-21
SLIDE 21

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Application of GRCAT to Q2 and Q3

Q2 Q3 λ2 λ2 λ3 λ3 (a12, λ1) (a12, λ1) (a23, λ1) (a23, µ2) (a23, µ2) (a23, λ2) (a23, x23) (a23, x23) (a23, x23) (a34, µ3) (a34, µ3) (a34, λ3) 1 1 B2 B3

  • Structurally, the situation is analogue to the previous case
  • Note that state B2 has two transitions incoming with the

same label ⇒ We apply GRCAT and sum the reversed rates

  • btaining λ2 + λ1
  • The reversed rate of the death transitions is λ2 + λ1 which is

the value of x23

Andrea Marin University of Venice

slide-22
SLIDE 22

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Steady-state distribution

  • Multiple applications of (G)RCAT lead to the following

values of the reversed rates: Ki(i+1) =

i

  • ℓ=1

λi 1 ≤ i < N

  • The steady-state distribution is in product-form:

π(n1, . . . , nN) ∝

N

  • ℓ=1

ρnℓ

ℓ ,

with 0 ≤ nℓ ≤ Bℓ and ρℓ = ℓ

j=1 λj

µℓ

Andrea Marin University of Venice

slide-23
SLIDE 23

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Some notes

  • The result may be easily extended to more general

topologies

  • Does the product-form yield in case of multiple server

stations?

  • Yes! ⇒ the reversed rates do not change!
  • Does the product-form yield in case of negative

customers?

  • No! ⇒ the reversed rates of the “death” transitions are

different (smaller) from those of the self-loops

  • But if we properly slow-down the arrival rates to

saturated queues we may still obtain a product-form solution!

Andrea Marin University of Venice

slide-24
SLIDE 24

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Some notes

  • The result may be easily extended to more general

topologies

  • Does the product-form yield in case of multiple server

stations?

  • Yes! ⇒ the reversed rates do not change!
  • Does the product-form yield in case of negative

customers?

  • No! ⇒ the reversed rates of the “death” transitions are

different (smaller) from those of the self-loops

  • But if we properly slow-down the arrival rates to

saturated queues we may still obtain a product-form solution!

Andrea Marin University of Venice

slide-25
SLIDE 25

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Some notes

  • The result may be easily extended to more general

topologies

  • Does the product-form yield in case of multiple server

stations?

  • Yes! ⇒ the reversed rates do not change!
  • Does the product-form yield in case of negative

customers?

  • No! ⇒ the reversed rates of the “death” transitions are

different (smaller) from those of the self-loops

  • But if we properly slow-down the arrival rates to

saturated queues we may still obtain a product-form solution!

Andrea Marin University of Venice

slide-26
SLIDE 26

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Outline

1 A mild introduction 2 Finite capacity queues with skipping: the RCAT solution 3 Product-form solution for G-networks with positive

Andrea Marin University of Venice

slide-27
SLIDE 27

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Model description

  • Network of N exponential queues Q1, . . . , QN with

external Poisson customer arrivals with rate λi and service rate µi

  • At a job completion at Qi a customer can:
  • go to queue Qj, j = i, with probability P+

ij as a standard

customer

  • go to queue Qj, j = i, with probability P−

ij as a trigger

  • leave the system with probability 1 −

j(P+ ij + P− ij )

  • At a trigger arrival at Qj it:
  • vanishes if Qj is empty
  • removes a customer from Qj and add a customer to Qk,

k = j, with probability Rjk, if Qj is non-empty

  • removes a customer from Qj with probability

1 −

k Rjk, if Qj is non-empty

Andrea Marin University of Venice

slide-28
SLIDE 28

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Model picture

Qi Qj Qk µi µj µk a−

ij

bjk

  • The picture shows just the cooperation among three

queues Qi, Qj, Qk embedded in a general networks

  • We focus on the analysis of the trigger behaviours
  • Positive customer analysis is the same of Jackson’s

networks

  • A job completion in Qi may change the state of three

queues simultaneously: Qi, Qj, Qk

Andrea Marin University of Venice

slide-29
SLIDE 29

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Process underlying a generic queue Qi

Qi 1 2 λi λi λi (a+

ji, xa+ ji)

(a+

ji, xa+ ji)

(a+

ji, xa+ ji)

(bji, xbji) (bji, xbji) (bji, xbji) (a−

ji, xa− ji)

(a+

ij, µiP + ij )

(a+

ij, µiP + ij )

(a−

ij, µiP − ij )

(a−

ij, µiP − ij )

(a−

ij, µiP − ij )

(a−

ji, xa− ji)/(bij, Ka− ji)

(a−

ji, xa− ji)/(bij, Ka− ji)

(a−

ji, xa− ji)/(bij, Ka− ji)

µi(1 −

j(P − ij + P + ij ))

  • 1 ≤ j ≤ N, j = i
  • a+

ij : positive customer from Qi to Qj

  • a−

ij : trigger from Qi to Qj

  • bij: customer arrival at Qj caused by a trigger arrival at

queue Qi

Andrea Marin University of Venice

slide-30
SLIDE 30

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Example

Q1 Q2 Q3 µ1 µ2 µ3 a+

12

a+

21

a+

31

a−

12

b23 λ1 λ3

  • We set up the RCAT traffic equations by the analysis of

each queue in isolation

  • This operation can be done algorithmically

Andrea Marin University of Venice

slide-31
SLIDE 31

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Queue 1

Q1 1 (a+

31, xa+ 31)

(a+

21, xa+ 21)

λ1 (a−

12, µ1P − 12)

(a+

12, µ1P + 12)

  • Ka−

12 = (λ1 + Ka+ 31 + Ka+ 21)P− 12

  • Ka+

12 = (λ1 + Ka+ 31 + Ka+ 21)P+ 12

Andrea Marin University of Venice

slide-32
SLIDE 32

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Queue 2

Q2 1 (a+

12, xa+ 12)

(a−

12, xa− 12)

(a+

21, µ2P + 21)

µ2(1 − P +

21)

(a−

12, xa− 12)/(b23, Ka− 12)

  • Ka+

21 =

Ka+

12

µ2 + Ka−

12

µ2P+

21

  • Kb23 =

Ka+

12

µ2 + Ka−

12

Ka−

12

Andrea Marin University of Venice

slide-33
SLIDE 33

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Queue 3

Q3 1 λ3 (b23, xb23) (a+

31, µ3)

  • Ka+

31 = λ3 + Kb23

Andrea Marin University of Venice

slide-34
SLIDE 34

Andrea Marin Introduction Skipping queues G-networks and triggers Introduction Skipping queues G-networks and triggers

Concluding the example

  • The solution of the traffic equations straightforwardly

gives the product-form solution

  • The traffic equations may be solved either symbolically
  • r numerically
  • The algorithm presented in [Marin et al. ’09] applies an

iterative schema to efficiently solve such networks of queues

  • The approach may be extended to deal with negative

triggers (at a trigger arrival the receiving non-empty queue may send a trigger to another queue)

Andrea Marin University of Venice

slide-35
SLIDE 35

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Part II Extended Reversed Compound Agent Theorem (ERCAT)

Andrea Marin University of Venice

slide-36
SLIDE 36

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

4 Motivations by example 5 The theorem 6 Solution of the running example 7 Open networks of exponential queues with finite capacity

and blocking

8 Conclusion

Andrea Marin University of Venice

slide-37
SLIDE 37

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

A system in Boucherie’s product-form

Q1 Q2 λ1 λ2 µ1 µ2

  • Two exponential queues Q1 and Q2 with independent

Poisson arrival streams with rate λ1 and λ2

  • Service rates are µ1 and µ2
  • If one of the queues enters in state 0 the other one is

blocked (i.e. no arrivals or service completions occur)

  • The model is known to be in Boucherie’s product-form

Andrea Marin University of Venice

slide-38
SLIDE 38

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Process representation

Q1 Q2 (c, λ1) (c, λ1) (c, λ1) (d, λ2) (d, λ2) (d, λ2) (b, µ2) (b, µ2) (b, µ2) (a, µ1) (a, µ1) (a, µ1) (d, xd) (d, xd) (b, xb) (b, xb) (c, xc) (c, xc) (a, xa) (a, xa) 1 1 2 2

Are (G)RCAT structural conditions satisfied? NO!

Andrea Marin University of Venice

slide-39
SLIDE 39

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Process representation

Q1 Q2 (c, λ1) (c, λ1) (c, λ1) (d, λ2) (d, λ2) (d, λ2) (b, µ2) (b, µ2) (b, µ2) (a, µ1) (a, µ1) (a, µ1) (d, xd) (d, xd) (b, xb) (b, xb) (c, xc) (c, xc) (a, xa) (a, xa) 1 1 2 2

Are (G)RCAT structural conditions satisfied? NO!

Andrea Marin University of Venice

slide-40
SLIDE 40

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Joint state space

  • ERCAT requires to check a rate equation for each state
  • f the irreducible subset of the joint process
  • Often, states can be opportunely clustered and hence

the computation becomes feasible

  • The computational complexity is higher than the

standard (G)RCAT

  • Let (s1, s2) be a state of the irreducible subset of the

joint process

Andrea Marin University of Venice

slide-41
SLIDE 41

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Fundamental definitions

  • P(s1,s2)→: outgoing labels from s1 or s2
  • P(s1,s2)←: incoming passive labels into s1 or s2
  • A(s1,s2)→: outgoing active labels from s1 or s2
  • A(s1,s2)←: incoming active labels into s1 or s2
  • α(s1,s2)(a): rate of transition labelled by a outgoing from

(s1, s2)

  • β

(s1,s2)(a): reversed rate of the passive transition

labelled by a incoming into (s1, s2)

Andrea Marin University of Venice

slide-42
SLIDE 42

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

ERCAT formulation

Theorem (ERCAT)

Given two models Q1 and Q2 in which RCAT structural conditions are not satisfied but the reversed rates of the active transitions are constant, their cooperation is in product-form if the following rate equation is satisfied for each state (s1, s2) of the irreducible subset of states of the joint process:

  • a∈P(s1,s2)→

xa −

  • a∈A(s1,s2)←

xa =

  • a∈P(s1,s2)←A(s1,s2)←

β

(s1,s2) a

  • a∈A(s1,s2)→P(s1,s2)→

α(s1,s2)

a

Andrea Marin University of Venice

slide-43
SLIDE 43

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

4 Motivations by example 5 The theorem 6 Solution of the running example 7 Open networks of exponential queues with finite capacity

and blocking

8 Conclusion

Andrea Marin University of Venice

slide-44
SLIDE 44

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

State (0,0)

Q1 Q2 (c, λ1) (d, λ2) (b, µ2) (a, µ1)

P(0,0)→ = {} A(0,0)← = {a, b} P(0,0)← A(0,0)← = {} A(0,0)→ P(0,0)→ = {c, d} −xa − xb = −α(0,0)

c

− α(0,0)

d

Ok Note that: xa = λ1, α(0,0)

c

= λ1, xb = λ2, α(0,0)

d

= λ2

Andrea Marin University of Venice

slide-45
SLIDE 45

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

State (0,0)

Q1 Q2 (c, λ1) (d, λ2) (b, µ2) (a, µ1)

P(0,0)→ = {} A(0,0)← = {a, b} P(0,0)← A(0,0)← = {} A(0,0)→ P(0,0)→ = {c, d} −xa − xb = −α(0,0)

c

− α(0,0)

d

Ok Note that: xa = λ1, α(0,0)

c

= λ1, xb = λ2, α(0,0)

d

= λ2

Andrea Marin University of Venice

slide-46
SLIDE 46

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

State (0,n), n>0

Q1 Q2 (c, λ1) (d, λ2) (d, λ2) (b, µ2) (b, µ2) (a, µ1) (c, xc) (a, xa) n

P(0,n)→ = {a, c} A(0,n)← = {a, b, d} P(0,n)← A(0,n)← = {c} A(0,n)→ P(0,n)→ = {b, d} xa + xc − xa − xb − xd = β

(0,n) c

− α(0,n)

b

− α(0,n)

d

Ok! Note that: xb = λ2, xc = µ1, xd = µ2, β

(0,n) c

= µ1, α(0,n)

b

= µ2, α(0,n)

d

= λ2

Andrea Marin University of Venice

slide-47
SLIDE 47

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

State (0,n), n>0

Q1 Q2 (c, λ1) (d, λ2) (d, λ2) (b, µ2) (b, µ2) (a, µ1) (c, xc) (a, xa) n

P(0,n)→ = {a, c} A(0,n)← = {a, b, d} P(0,n)← A(0,n)← = {c} A(0,n)→ P(0,n)→ = {b, d} xa + xc − xa − xb − xd = β

(0,n) c

− α(0,n)

b

− α(0,n)

d

Ok! Note that: xb = λ2, xc = µ1, xd = µ2, β

(0,n) c

= µ1, α(0,n)

b

= µ2, α(0,n)

d

= λ2

Andrea Marin University of Venice

slide-48
SLIDE 48

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

State (m,n), m,n>0

Q1 Q2 (c, λ1) (c, λ1) (d, λ2) (d, λ2) (b, µ2) (b, µ2) (a, µ1) (a, µ1) (d, xd) (b, xb) (c, xc) (a, xa) m n

P(m,n)→ = {a, b, c, d} A(m,n)← = {a, b, c, d} P(m,n)← A(m,n)← = {} A(m,n)→ P(m,n)→ = {} 0=0 Note that states (m, 0) with m > 0 are similar to (0, n), n > 0.

Andrea Marin University of Venice

slide-49
SLIDE 49

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Conclusion of the running example

  • The model, as expected, is in product-form:

π(m, n) ∝ λ1 µ1 m λ2 µ2 n

  • Note that state (0, 0) is either the only ergodic state or

does not belong to the irreducible subset

  • Hence, the normalising constant distinguishes this

solution from the case of independent queues

  • Every Boucherie’s product-form with full blocking can

be studied by ERCAT [Harrison ’04a]

Andrea Marin University of Venice

slide-50
SLIDE 50

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

4 Motivations by example 5 The theorem 6 Solution of the running example 7 Open networks of exponential queues with finite capacity

and blocking

8 Conclusion

Andrea Marin University of Venice

slide-51
SLIDE 51

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Queues with finite capacity and Repetitive Service (RS) blocking

  • We consider a network of queues, Q1, . . . , QN with

finite capacity Bi and service rate µi

  • At a job completion at Qi the customer goes to Qj with

probability Pij. If Qj if saturated the customer service is restarted and a new target station is selected at job completion

  • In open networks λi is the arrival rate at Qi and

customers leave the system with probability 1 −

j Pij.

Arrivals at saturated queues are not allowed

Andrea Marin University of Venice

slide-52
SLIDE 52

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Example

Q1 Q2 λ1 λ2 µ1 µ2 p 1 − p q 1 − q

Q1 Q2 λ1 λ1 λ2 λ2 (a, qµ2) (a, qµ2) (b, xb) (b, xb) (b, pµ1) (b, pµ1) (a, xa) (a, xa) (1 − q)µ2 (1 − q)µ2 (1 − p)µ1 (1 − p)µ1 1 1 B1 B2 Andrea Marin University of Venice

slide-53
SLIDE 53

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Notes

  • Differently from ordinary queueing networks we use

active transitions to model synchronised arrivals and passive to model synchronised departures

  • Which states shall we consider?

1 (0, 0) 2 (0, K) with 0 < K < B2 (and symmetrically we obtain

(K, 0) with 0 < K < B1)

3 (0, B2) 4 (K, B2) with 0 < K < B1 (and symmetrically we obtain

(0, K) with 0 < K < B2)

5 (B1, B2)

  • Note that α(·,·)

a

= qµ2, α(·,·)

b

= pµ1 and also β

(·,·) a

= βa and β

(·,·) b

= βb

Andrea Marin University of Venice

slide-54
SLIDE 54

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

State (0, B2)

Q1 Q2 λ1 λ2 (a, qµ2) (b, xb) (b, pµ1) (a, xa) (1 − q)µ2 (1 − p)µ1 B2

P(0,B2)→ = {a} A(0,B2)← = {b} A(0,B2)→ P(0,B2)→ = {} P(0,B2)← A(0,B2)← = {} xa − xb = 0 ⇒ xa = xb (1)

Andrea Marin University of Venice

slide-55
SLIDE 55

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

State (0, K)

Q1 Q2 λ1 λ2 (a, qµ2) (b, xb) (b, pµ1) (b, pµ1) (b, pµ1) (a, xa) (a, xa) (1 − q)µ2 (1 − q)µ2 (1 − p)µ1 K

P(0,K)→ = {a} A(0,K)← = {b} A(0,K)→ P(0,K)→ = {b} P(0,K)← A(0,K)← = {a} i.e.: xa − xb = β

(0,K) b

− α(0,K)

a (1)

− − → βb = αa (2) By symmetry, state (K, 0) gives βa = αb

Andrea Marin University of Venice

slide-56
SLIDE 56

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

State (0, 0)

Q1 Q2 λ1 λ2 (a, qµ2) (b, xb) (b, pµ1) (a, xa) (1 − q)µ2 (1 − p)µ1

P(0,0)→ = {} A(0,0)← = {} A(0,0)→ P(0,0)→ = {a, b} P(0,0)← A(0,0)← = {a, b} β

(0,0) a

+ β

(0,0) b

= α(0,0)

a

+ α(0,0)

b

which is a consequence of (2)

Andrea Marin University of Venice

slide-57
SLIDE 57

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

States (K, B2) and (B1, K), (B1, B2)

Q1 Q2 λ1 λ1 λ2 (a, qµ2) (a, qµ2) (b, xb) (b, xb) (b, pµ1) (a, xa) (1 − q)µ2 (1 − p)µ1 (1 − p)µ1 K B2

  • For these states we have:
  • P(·,·)→ = {a, b}
  • A(·,·)← = {a, b}
  • Since all the synchronising labels are present in both

these sets, the rate equation for these states is an identity.

Andrea Marin University of Venice

slide-58
SLIDE 58

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Conditions derived from the ERCAT rate equations

     xa = xb βb = αa = qµ2 βa = αb = pµ1 The process analysis gives: βb = xb(λ1 + qµ2) xb + (1 − p)µ1 βa = xa(λ2 + pµ1) xa + (1 − q)µ2 From which we straightforwardly derive: xa = (1 − q)pµ1µ2 λ2 xb = (1 − p)qµ1µ2 λ1 (3)

Andrea Marin University of Venice

slide-59
SLIDE 59

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Product-form rate condition

Since xa = xb by (1) we have the product-form rate condition: (1 − p)qλ2 = (1 − q)pλ1 Under this assumption expressions (3) for xa, xb satisfies: xa = (xb + (1 − p)µ1)qµ2 λ1 + qµ2 xb = (xa + (1 − q)µ2)pµ1 λ2 + pµ1

Q1 Q2 λ1 λ1 λ2 λ2 (a, qµ2) (a, qµ2) (b, xb) (b, xb) (b, pµ1) (b, pµ1) (a, xa) (a, xa) (1 − q)µ2 (1 − q)µ2 (1 − p)µ1 (1 − p)µ1 1 1 B1 B2

Andrea Marin University of Venice

slide-60
SLIDE 60

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Generalisation

  • ERCAT may be applied to a set of agent with pairwise

cooperations (this is also known a MARCAT)

  • In case of QN with RS blocking and general topology in

[Balsamo et al. ’10] is proved that:

Theorem

A QN (open or closed) with finite capacity stations and RS blocking policy with reversible routing matrix always satisfies ERCAT rate equations.

  • Product-form for reversible routing has been proved in

[Akyildiz ’87]

Andrea Marin University of Venice

slide-61
SLIDE 61

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Closed QN with RS blocking

  • Consider a closed QN with RS blocking policy
  • Note that the ERCAT rate equation is an identity for

state n when none of the stations is empty in n

  • We immediately have the following result:

Theorem (QN with strict non-empty condition)

A closed QN with finite capacity stations and RS blocking is in product-form if the number of customers is such that none

  • f the station can be empty (strict non-empty condition)
  • In [Balsamo et al. ’10] we prove that the same result for

QN in which at most one station can be empty (non-empty condition)

Andrea Marin University of Venice

slide-62
SLIDE 62

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

4 Motivations by example 5 The theorem 6 Solution of the running example 7 Open networks of exponential queues with finite capacity

and blocking

8 Conclusion

Andrea Marin University of Venice

slide-63
SLIDE 63

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Final remarks

  • In the second part of the tutorial we have shown how to
  • vercome some limitations of original RCAT and

GRCAT formulation

  • In case of some non-pairwise cooperations we can

apply (G)RCAT iteratively to obtain the product-form

  • In case structural conditions of (G)RCAT are not satisfy

we may apply ERCAT

  • Application of (G)RCAT or ERCAT may be done

algorithmically, however the computational cost of ERCAT is higher than that of (G)RCAT

Andrea Marin University of Venice

slide-64
SLIDE 64

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Applications

  • Other models than those presented here may be

studied by RCAT and its extensions (e.g. product-form Stochastic Petri Nets)

  • New product-form may be derived
  • The solution of the traffic equations may be efficiently

computed by means of the algorithm presented in [Marin et al. ’09]

  • Numerical and iterative algorithm
  • Product-form of models expressed in terms of different

formalisms may be derived.

Andrea Marin University of Venice

slide-65
SLIDE 65

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

Appendix: Reversible routing matrix

  • Consider a queueing network with N stations and fixed

routing probability matrix P = [pij], 1 ≤ i, j ≤ N

  • pi0 is the probability of leaving the network after a job

completion at station i

  • ei is the (relative) visit ratio to station i
  • λi is the arrival rate at station i

Definition (Reversible routing matrix)

The routing matrix P is said reversible if:

  • eipij = ejpji

for 1 ≤ i, j ≤ N λi = eipi0 for 1 ≤ i ≤ N

Andrea Marin University of Venice

slide-66
SLIDE 66

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

For Further Reading I

  • B. Pittel:Closed exponential networks of queues with

saturation: The Jackson-type stationary distribution and its asymptotic analysis,

  • Math. of Op. Res., vol. 4, n. 4, pp. 357–378, 1979

I.F . Akyildiz: Exact product form solution for queueing networks with blocking, IEEE Trans. on Computers, vol. C-36-1, pp. 122-125, 1987 P .G. Harrison: Turning back time in Markovian process algebra, Theoretical Computer Science, vol. 290, n. 3, pp. 1947–1986, 2003

Andrea Marin University of Venice

slide-67
SLIDE 67

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

For Further Reading II

P .G. Harrison: Reversed processes, product forms and a non-product form, Linear Algebra and its App., vol. 386, pp. 359–381, 2004. P .G. Harrison: Compositional reversed Markov processes, with applications to G-networks,

  • Perf. Eval., vol. 57, n. 3, pp. 379–408, 2004
  • A. Marin and S. R. Bulò: A general algorithm to

compute the steady-state solution of product-form cooperating Markov chains, in Proc. of MASCOTS 2009, pp. 515–524, 2009

Andrea Marin University of Venice

slide-68
SLIDE 68

Andrea Marin Motivations The theorem Running example Networks with blocking Conclusion Motivations The theorem Running example Networks with blocking Conclusion

For Further Reading III

  • A. Marin, M.G. Vigliotti: A general result for deriving

product-form solutions of Markovian models,

  • Proc. of WOSP/SIPEW Int. Conf. on Perf. Eval.
  • S. Balsamo, P

. G. Harrison, A. Marin: A unifying approach to product-forms in networks with finite capacity constraints,

  • Proc. of the 2010 ACM SIGMETRICS, pp. 25–36, 2010

Andrea Marin University of Venice
