DOSING-SAMPLING-ENGINEERING-CONTROL FLUIDECO: FLUID ENGINEERING COMPANY

FLUID ENGINEERING COMPANY

Company

 Turn-key projects: design/engineering + manufacturing + commissioning.  Continuous customer service.  ISO 9001, 14001, OHSAS18001:  Worldwide deliveries and service. Headquarters: Madrid, Spain

FLUIDECO IS AN ACTIVE AND DYNAMIC COMPANY DEDICATED TO SKID-MOUNTED EQUIPMENT FOR CONTROL, DOSING, MEASURING AND MIXING FLUIDS.

FLUID ENGINEERING COMPANY

What we do

Pumping skids

SYSTEMS INDUSTRIES

Oil & Gas Power Generation Pulp & Paper Food & Beverages Detergents & Cosmetics Water Treatment

Dosing systems Sampling systems Chemical injection packages Gas and LNG Odorization systems Hydropneumatic systems

FLUID ENGINEERING COMPANY

Dosing systems

Our packages are used in the industrial processes where it is needed to have precise control of flows, transfer fluids

• r Sampling analysis.
• Aggressive fluids
• Delicate fluids with fragile solids
• Viscous
• Abrasive
• Poisonous
• Liquefied gas
• Ambient temperature: from -55ºC to +50ºC
• Hazardous area or non hazardous
• Flow rate from 6 ml/h to 500 m3/h
• Pressures: up to 2.300 bar
• Fluid temperatures: up to 510 º C
• Viscosities: up to 2.000.000 cps

Liquids of all types: In any circumstance:

FLUID ENGINEERING COMPANY

Chemical dosing systems

• Dosing of chemical additives to the process
• Boiler chemical dosing treatment
• Steam water cycle chemical dosing
• Chemical dosing to cooling towers
• Wastewater neutralization systems
• Odorization systems

Chemical injection packages are used when chemicals are needed to be added into a process, as an additive in the Oil & Gas and Paper industries, or to maintain water quality in Power and Water Treatment industries.

FLUID ENGINEERING COMPANY

OIL & GAS Chemical injection

Our packages comply the strict requirements of the Industry, among them: API, ASME, CUTR, ATEX / NFPA / NEC / CEC for Hazardous areas, non destructive tests

FLUID ENGINEERING COMPANY

Chemical injection for boiler and WS Cycle

Chemical injection package is needed to maintain boiler and water-steam cycle with proper pH, oxygen and conductivity conditions and to avoid scale and corrosion.

• Carbohydrazide
• Phosphate
• Ammonia
• Corrosion Inhibitor

Chemicals to be dosed are:

FLUID ENGINEERING COMPANY

Chemical injection Cooling tower

• Sodium Hypochlorite
• Biodispersant
• Sulfuric Acid
• Anti-fouling
• Biocide

Chemical injection package is needed to maintain cooling tower water with proper pH, free chlorine and conductivity conditions and to avoid scale, biofouling and legionella.

Chemicals to be dosed are:

FLUID ENGINEERING COMPANY

Pumping skids

Chemical Fluids Pumping Water Pumping

FLUID ENGINEERING COMPANY

Sampling systems

We manufacture SWAS sampling systems for measuring pH, conductivity, disolved

• xygen,

conductivity degassed, etc.

• With or without HART protocol
• Combination of measures
• Installed inside a container

FLUID ENGINEERING COMPANY

Gas odorization systems

LNG odorization systems

Natural gas and LNG have no smell and are highly

• explosive. Regulations require odorization in exact quantities, in
• rder to detect every gas leak, no matter how slight, during

distribution, reloading or transport. Therefore Natural gas and LNG must be processed with absolutely leakproof systems. In FLUIDECO odorizing systems, the odorant is metered reliably, proportionally and economically. They minimize costs and maximize performance

FLUID ENGINEERING COMPANY

Hydropneumatic systems

Used to increase the pressure in the local water networks. Materials: stainless steel 316SS, 304SS and carbon steel.

FLUID ENGINEERING COMPANY

Wastewater neutralization systems

The regulations require that the waste water have a controlled pH before being discharged into the network.

• Dosing of hydrochloric acid
• Dosing of sulfuric acid
• Dosing of soda

FLUID ENGINEERING COMPANY

Detergent & Cosmetic systems

FLUIDECO designs and manufactures systems for the Detergents and cosmetic industry to produce:

• LES Dilution
• Bath gels
• Shampoo
• Lotions
• Household cleaners
• Neutralization of sulfonic acid
• Toothpaste
• Deodorants
• Hair spray
• Softens
• Water of Cologne
• Versatility and flexibility
• Automation on Demand

FLUID ENGINEERING COMPANY

Drinks:

• Fruit juices
• Champagne
• Carbonated drinks
• Liquor
• Vodka

We provide to the food industry knowledge and experience in skid-based equipment in food process, always in compliance with the strictest health and hygiene regulations. Food:

• Margarine
• Mayonnaise
• Ice Cream
• Aromas and Coloring
• Sauces

Food & Beverages systems

• Yogurt
• Ketchup
• Chocolate
• Syrup
• Lactic acid
• Additives

FLUID ENGINEERING COMPANY

3D Design Solidworks

• Integration

into the customer’s own design

• More detail for both

the customer and manufacturing process

• Design

modifications are done faster

FLUID ENGINEERING COMPANY

Electric control

PLC Siemens, ABB, Schneider … Communication protocol: Modbus, Ethernet, Profibus, Hart… Automatic/manual control Remote/ local control

FLUID ENGINEERING COMPANY

Materials

Carbon steel HDPE Stainless steel PP PVDF GRP PVC

FLUID ENGINEERING COMPANY

Container

Installing the dosing or sampling system inside a conditioned container provides: Easier and faster erection at Site Equipment protection Better working conditions

FLUID ENGINEERING COMPANY

Welding quality

Welding procedure PQR WPS WPQ:

• ASME procedure
• EN procedure

Welding types:

• Butt weld (BW)
• Socket weld (SW)

Quality control:

• X Ray
• Liquid penetrant
• Magnetic particles
• PMI positive material identification
• Hydrostatic test

FLUID ENGINEERING COMPANY

Certifications

ISO 9001 / ISO 14001 / OSHAS 18001 CU-TR10 / CU-TR32

FLUID ENGINEERING COMPANY

Customers

DOSING-SAMPLING-ENGINEERING-CONTROL

FLUIDECO: FLUID ENGINEERING COMPANY
