• SURYACLICK is a Direct Pressure Laminated (DPL) Plantation Wood based HDF

flooring having a homogenous construction with an uniform density of approximately 900 kg/m3 resulting in uniform physical & mechanical properties across the dimensions of the board.

• In any flooring solution, the locking system is the heart & the single most

important factor that determines the success of flooring solution both in terms of weight bearing capacity, Strength of the locking profile, longevity & finally the finish of the locked flooring. Surya click Laminate Flooring uses the unique 5G VALINGE TECHNOLOGY CLICK SYSTEM.

• The quality of the locking mechanism is critical to the durability and look of

your floating laminate floor. Such locking solution is also known as the glue less locking system & are also known as the Click technology .

• Ensuring that moisture seepage does not effect the joint and the flooring
• system. SURYACLICK Laminate Flooring is Indianized / Tropicalized by a

surface sealant coat on the exposed HDF area on the locking edges.

• SURYACLICK Flooring is anti-bacterially treated for better hygiene.
• SURYACLICK HDF Based Laminate Flooring comes with the revolutionary

5G Valinge Technology & is dimensionally stable.

• SURYACLICK flooring has an Ultra Smooth surface.
• SURYACLICK flooring is exclusively manufactured from Plantation Timber

hence is environment friendly.

LAMINATE FLOORING

1.OVERLAY: The highly wear-resistant, watertight top layer made of melamine resin protects the SURYACLICK laminate floor from normal everyday wear and tear, micro-scratches and dropped objects. The high corundum content is responsible for this, as its hardness is only surpassed by diamond. 2.DECOR PAPER: The elaborately reproduced decors are fascinating with amazingly genuine imitations of many natural materials. The décor print made with solvent free colours impresses with extraordinary brilliance. The impregnation using melamine resin also protects against moisture. 3.HDF CORE BOARD: The highly compressed, swell-resistant core board provides high dimensional stability and thus minimises the influences caused by the climate fluctuations or extraordinary stresses and strains. In addition, the all-round edge impregnation ensures excellence edge swell protection. On the Classic and Trend time product lines, the swell protection of the special core board is almost doubled by the 5G Valinge Technology.

• 4. BALANCING LAYER: The reverse side of the laminate floor is formed by

the balancing layer paper, which compensates against tension and prevents the planks from warping. At the same time, the impregnated balancing layer paper protects the core board against moisture from beneath.

• 5. 5G CLICK: The improved patented 5G click mechanism, is milled

directly in the special core board and is characterised by several benefits:

• High fitting accuracy for visible plank transitions totally even surfaces,
• Extremely high connection stability for permanent fitting accuracy,
• Effortless handling: Marks on the click connection specify the starting

points for inserting the planks, easy to handle & faster installation.

• Combined with the revolutionary 5G Click systems with unique inbuilt

glass fibre reinforced tongue on the short side of the panel adds as a barrier to moisture & prevents dewaxing.

• Made from 8mm thick HDF
• Plank Size : 1200mm x 191mm
• Click locking profile
• Available in AC3 / AC4 / AC5 variants
• Comes in 34 exotic décors
• Unique 5G Valinge Technology
• Accompanied with EVA under lay for cushioning effect

SURYA CLICK BRINGS YOU - 5G TECHNOLOGY MADE IN INDIA

• Surya click laminate flooring is made in India, plant located at the serene foothills of

south western ghat.

• SURYACLICK will ensure for delivering consistent quality HDF laminated boards in India.
• Worlds 4th Manufacturer having the Patented rights from 5G Valinge Technology.
• Unique 5G Valinge Technology in 8mm in consistent 4ft Length.
• Plant equipped with 8 cylindered direct pressure laminating(DPL)press with specific

pressure of 2800 MT enables to ensure perfect bonding.

• Resulting in ultra smooth surfaced boards with High Internal Bond.

SURYA CLICK BRINGS YOU STATE OF ART UNIT WITH HOMAG – LITEZ TOOLING

• Made from High Density Fiber Board.
• Lengths better Elasticity to the flooring solution.
• Balanced construction & dimensionally stable.
• Strong Locking profiles.
• Significantly water resistant – Ideal for tropical climate.
• The ideal for medium to high traffic.

• Ensures Optimal Moisture Content.
• Ensures Core Compactness.
• Balanced Construction.
• Ensures Dimensional Stability.
• Ensures Higher Internal Bond, hence higher strength.

PRODUCT

AC3

SURYACLICK Flooring is a specially designed for domestic application & will standup to consistent daily foot traffic – Ideally for the Bed Room/Family Rooms/Drawing Rooms/Hotel Rooms. It’s classified as AC3.

AC4

SURYACLICK Flooring is a perfect choice for busy boutiques/cafes/ shops/ showrooms/offices with medium to high Medium foot traffic . It’s classified as AC4.

AC5

SURYACLICK laminate flooring is best suited for heavy foot traffic in commercial properties. It’s classified as AC5.

• The Under Lay Of SURYA CLICK Laminate Flooring Consists Of
• EPE Foam 2 - 2.5mm Thick With Density Of 24kg/M3.
• Cement Floor Cladding With PE Sheet Of 130gsm.
• A Soft Cushioning Effect While Walking On The Floor Surface.
• Recommended Self-levelling Components .

INSTALLATION

STANDARD FOLLOWED AT SURYA PANEL FOR LAMINATE FLOORING

European Standard : EN 13329

STANDARDS OF INDIAN RELEVANT

SURYACLICK loves wood. Wood is beautiful. It is the

• ldest construction material

in human history. Wood has sustained generations. Wood is sustainable. Its valuable characteristics and natural advantages are

• irreplaceable. Regenerating

forests stabilise the climate and absorb greenhouse gas emissions.

ENVIRONMENTALLY FRIENDLY

Our work is characterized by the way we conserve resources. We prevent emission and feed recyclable materials back into the production cycle. Whilst the use of predominantly domestic timbers in the manufacture of laminate flooring guarantees short transport routes, the support material of our other floors and panels consists entirely of recyclable materials. The decor papers used on our laminate floors are composed of certified materials.

• SURYACLICK is made from “Rapidly Renewable Resource” – Plantation

Timber, primarily of the Eucalyptus species.

• With its own Nursery growing Clonally Propagate fast growing species of

Eucalyptus till the sapling stage before being transplanted to the willing planters absolutely free with a viable buyback guarantee.

• The Plantation is situated very close to the factory.
• SURYACLICK has a 100% recyclable content hence meets a primary

prerequisite for a CDM rate product.

• Made from low emission resin making it fit for indoor application without a

discomfort to the inhabitants.

• https://youtu.be/X-0fQ7uvAQI?t=12
• https://youtu.be/JGqEO9qfOqE
• https://youtu.be/Mu0-yZKCdek

PROCESS
