49er Rocketry Team The University of North Carolina at Charlotte Flight Readiness Review 1 Agenda Launch Vehicle Recovery Payload Primary Payload: UAS Retention and Deployment Camera Vision Safety
1
The University of North Carolina at Charlotte
2
The University of North Carolina at Charlotte
3
○ Booster (ID) : 5 in. ○ Payload (ID) : 6 in. ○ Thickness : 1/16 in.
○ Total Length: 111 in. ○ Loaded Mass: 67.7 lbm.
○ 4000 ft. AGL
The University of North Carolina at Charlotte
4
○ Length: 9 in. ○ Aft Diameter: 6 in. ○ Material: ABS
○ Length: 46 in. ○ Inner Diameter: 6 in. ○ Material: Quasi-isotropic Carbon Fiber
The University of North Carolina at Charlotte
5
○ Loacates SRA locations on ascent
○ Camera (4x) ○ Computer ○ Battery
○ Inner mount - 5.5 in. length ○ camera mount - angles camera 30 deg ○ camera shield - teardrop shape ○ All hardware 3D printed from PETG
The University of North Carolina at Charlotte
6
○ Quasi-isotropic Carbon Fiber ○ 56 in.
The University of North Carolina at Charlotte
7
The University of North Carolina at Charlotte
8
Booster Section Component Mass (lbm) Booster Recovery 5.90 Transition 1.77 Modular Fin Can 3.63 Motor And Retention 15.9 Booster Airframe 1.70 Total 28.9 Payload Section Component Mass (lbm) Nose Cone 2.15 Payload Recovery 7 GSOS 9.5 Computer Vision 3.53 Primary Payload 14.05 Payload Airframe 2.57 Total 38.8
Launch Vehicle Section Mass (lbm) Payload 38.8 Booster 28.9 Total 67.7
The University of North Carolina at Charlotte
9
2.3 (s)
10.5 (lbm)
The University of North Carolina at Charlotte
10
Total Mass (lbm) Ballasted Mass (lbm) Static Stability Post-Burnout Stability 67.7 0.0 3.0 3.73
The University of North Carolina at Charlotte
11
Wind Speed (mph) Simulated (ft) Calculated (ft) Percent Difference
3766 3875 2.81 5 3740 3854 2.96 10 3723 3797 1.95 15 3659 3711 1.40 20 3621 3604 0.47
The University of North Carolina at Charlotte
1. Initial separation at apogee with booster drogue deployment.
ft-lbf of kinetic energy
12
The University of North Carolina at Charlotte
13
○ Size: 96 in. ○ Cd: 2.2 ○ Shape: Annular ○ Descent Rate: 12.12 ft/s
○ Size: 144 in ○ Cd: 2.2 ○ Shape: Annular ○ Descent Rate: 10.53 ft/s
○ Size: 15 in. ○ Cd: 1.5 ○ Booster Descent Rate: 93.94 ft/s ○ Payload Descent Rate: 133.2 ft/s
The University of North Carolina at Charlotte
○ 45 ft total
○ 3/16 in. Quick Links ○ 1/4 in. Quick Links ○ 1/4 in. Stainless Steel Eyebolt ○ 3/8 in. Stainless Steel Eyebolt ○ Tender Descender Level 3
14
The University of North Carolina at Charlotte
○ 30 ft total
○ 3/16 in. Quick Links ○ 1/4 in. Stainless Steel Eyebolt ○ 3/8 in. Stainless Steel Eyebolt
15
Full details of the recovery system are located in Section 3.3.
The University of North Carolina at Charlotte
16
Parachute deployment bag Tender Descender L3
Component Payload Section Booster Section Deployment Bag 1 Stratologger CF 2 2 Telemega 1 B.P. Charge Wells 2 4 Nomex Blankets 1 2 CF Bulkhead 2 AL Bulkhead 1 1
PerfectFlite StratologgerCF
The University of North Carolina at Charlotte
17
Wind Speed (mph) Booster Drift (ft) Payload Drift With UAS (ft) Payload Drift Without UAS (ft) 5 476.9 518.2 540.7 10 953.8 1036.5 1081.4 15 1430.6 1554.7 1662.0 20 1907.5 2073.0 2162.7
Within NASA requirement of 2,500 ft.
Full drift calculations are located in Section 3.4.9.
The University of North Carolina at Charlotte
18
Section Landing KE (ft-lbf ) Booster 25.56 Booster Recovery 8.95 Payload with UAS 67.38 Payload without UAS 46.69 Nosecone .47
Full calculations are located in Section 3.4.7 and 3.4.8.
Within NASA requirement of 75 ft-lbf
Booster (s) Payload with UAS (s) Payload without UAS (s) 65.03 70.67 73.73
Within NASA requirement of 90 sec.
The University of North Carolina at Charlotte
19
Tracker Frequency Location Comm Specialists, Inc RC-MP 222.330 MHz Booster Shock Cord Comm Specialists, Inc RC-MP 223.010 MHz Payload Shock Cord
Full specifications are located in Section 3.3.10.
The University of North Carolina at Charlotte
20
Launch Day Conditions - 02/22/2020
Onboard Equipment
The University of North Carolina at Charlotte
21
Apogee (ft) Time to Apogee (s) Velocity (ft/s) Acceleration (ft/s^2) 4098 16.7 920 308
The University of North Carolina at Charlotte
22
Payload Section
Apogee: 4180 ft.
Booster Section
Apogee: 4099 ft
The University of North Carolina at Charlotte
23
Payload Section ~2190 ft. drift Booster Section ~1850 ft. drift
Full results are located in Section 5.1.2.
The University of North Carolina at Charlotte
24
Full analysis of the flight is Located in Section 5.1.2. Vehicle Section Landing Velocity (ft/s) Payload 83.2 Booster 14.1 Vehicle Section Landing Kinetic Energy (ft-lbf) Nosecone 332.6 Payload 678.5 Booster 45.4 Booster Recovery 26.8
The University of North Carolina at Charlotte
25
Full vehicle test plans are located in Section 7.1.
The University of North Carolina at Charlotte
26
Full Vehicle Verification Requirements Located in Section 8.4.
The University of North Carolina at Charlotte
27
Full Vehicle Verification Requirements Located in Section 8.4.
The University of North Carolina at Charlotte
28
The University of North Carolina at Charlotte
29
The University of North Carolina at Charlotte
30
1. UAS travels to flight altitude of 25 ft. 2. UAS navigates towards SRA GPS coordinate. 3. UAS implements CV
SRA. 4. UAS arrives at SRA. 5. UAS lands outside and waits for sample collection signal. 6. UAS receives sample collection signal, lands in SRA, and collects sample. 7. UAS transports sample 10 ft away from SRA.
The University of North Carolina at Charlotte
○ Thrust-to-weight ratio: 3.1
31
The University of North Carolina at Charlotte
32
The University of North Carolina at Charlotte
33
1.00 in. 1.25 in. 16.0 in. 5.43 in. 4.79 in. 5.43 in.
The University of North Carolina at Charlotte
34
12.1 in. 14.4 in. 5.86 in. 16.6 in. With Propellers Width = 28.6 in. Length = 26.4 in. Height = 5.86 in. Diagonal = 33.9 in.
The University of North Carolina at Charlotte
○ 0.0625 in. thick ○ High Modulus Twill Weave
Aluminum Standoffs
35
The University of North Carolina at Charlotte
36
1. Swivel Camera Mount 2. NanoPi Neo Core 2 3. LiDAR Sensor 4. 11000 mAh LiPo Battery 5. Sample Collection and Storage 6. EJ501a Quick Disconnects 7. LM2596 Power Converters 8. FrSky Taranis Receiver 9. Airbot 200 A PDB 10. Pixhawk 4 11. Grayson Hobby 50A ESCs 12. STM32 Blue Pill 13. Pixhawk 4 GPS 14. Maxbotix MB1240 Ultrasonic Sensor
The University of North Carolina at Charlotte
Standoffs and fixtures used
to carbon fiber frame plates.
using velcro tape.
plate using dampening foam strip.
37
Pixhawk 4 GPS LiDAR & NanoPi Ultrasonic Sensor Quick Disconnect
The University of North Carolina at Charlotte
tube supports load
38
The University of North Carolina at Charlotte
39
The University of North Carolina at Charlotte
○ 12 in. diameter ○ 5 in. pitch
○ 770 W maximum continuous power ○ Weight: 5.89 oz.
○ 50 A maximum continuous current draw ○ 55 A peak current draw (<30 seconds) ○ Input voltage: 11.1 V, 3S
○ Additively manufactured from PETG ○ Strength successfully verified through testing
40
The University of North Carolina at Charlotte
sample
manufactured from PETG
theoretically ○ 32 mL collected in testing
○ 170 oz/in torque at 6 V ○ 1:1000 gearbox ○ Weighs 0.257 oz. ○ 360 degrees of rotation
41
The University of North Carolina at Charlotte
○ Main flight controller ○ Supports UART and I2C protocols ○ Supports autonomous flying and mission planning
○ Companion computer ○ Sends autonomous control commands to Pixhawk 4 ○ Sends microcontroller when to start sample collection
42
UART
The University of North Carolina at Charlotte
○ UBLOX M8N GPS unit ○ IST8310 Compass unit ○ Primary sensor for navigation
43
The University of North Carolina at Charlotte
○ Used for Stereovision ○ Detects obstacles and SRA site
○ Backup sensor for object avoidance
○ Handled by NanoPi Neo Core 2 ○ Uses OpenCV library
○ Actuated using MG90s micro servo
44
The University of North Carolina at Charlotte
○ 10 Hz sample rate ○ Range: 0.7-25 ft. ○ 0.4 in. resolution
○ 600 Hz sample rate ○ Range: 45.9 ft. ○ 1.57 in. resolution
○ Processed by NanoPi SBC ○ Used to construct autonomous commands
45
The University of North Carolina at Charlotte
○ 2.4 GHz ○ 16 Channels
○ 2.4 GHz ○ 8 Channels ○ 16 Channels with SBUS
○ Three position switch ‘SE’ for autonomous flight, UAS hover, and manual flight ○ Two position switch ‘SF’ for UAS SRA landing ○ Two position switch ‘SH’ for sample collection
46
SE SF SH
FrSky X8R Receiver FrSky Taranis X9D Transmitter
The University of North Carolina at Charlotte
flight
47
SE SF SH
The University of North Carolina at Charlotte
○ 11000 mAh ○ 3 cell ○ 11.1 V ○ 40C discharge rate
○ Adjustable output by potentiometer ○ Converts 11.1 V to 5 V ○ Converts 11.1 V to 3.3 V
○ 16 AWG for 50A ○ 8 & 10 AWG for 200A
48
11.1 V LiPo Battery Airbot 200A PDB LM2596 DC-DC Converter
The University of North Carolina at Charlotte
supply from launch vehicle battery to the UAS battery at launch
49
The University of North Carolina at Charlotte
50
The University of North Carolina at Charlotte
○ 902 - 928 MHz @ 250 mW ○ 200 Kbps up to 4 miles ○ Used for both transmitter and receiver
○ Altitude receiving antenna ○ Deployment transmitting antenna ○ Connects to GCS
51
○ 900 MHz @ 250 mW ○ Deployment receiving antenna ○ Located inside sealant cap
TeraWave 900 MHz 15 dBi Yagi Antenna ArcAntenna Dipole Whip Antenna in Sealant Cap
The University of North Carolina at Charlotte
○ Graphs real-time altitude of payload section ○ Generates deployment signal ○ Generates reset commands
○ Transmits signal from laptop to payload section ○ Receives signal from payload section
52
The University of North Carolina at Charlotte
○ Single board computer ○ Sends SRA GPS location to UAS over CAN bus ○ Sends Telemega altimeter data to deployment microcontroller to be sent to GCS
53
Coordinate
53
ODROID-N2 ELP USB Camera
The University of North Carolina at Charlotte
Four Subsystems:
Orientation (GSOS)
54
The University of North Carolina at Charlotte
55
CAD Rendering Bulkhead and Lead Screw UAS Interference
The University of North Carolina at Charlotte
56
The University of North Carolina at Charlotte
brushless DC motor
○ 3 mm pitch ○ Additively Manufactured PETG Belt Clamp
○ 4.71:1 gear ratio ○ Park brake mechanism with MG90s micro servo ○ Additively manufactured from PETG
57
The University of North Carolina at Charlotte
door for stabilization
rotation for orientation ○ 2678 oz.-in. torque ○ GT2 Belt, 5 mm pitch ○ Additively manufactured belt clamp
determine orientation
58
The University of North Carolina at Charlotte
59
1 2 3 4 5
The University of North Carolina at Charlotte
○ 611 oz. - in. of torque
60
The University of North Carolina at Charlotte
61
Payload Demonstration Flight can be found in Section 5.2
The University of North Carolina at Charlotte
62
Testing of Payload Systems can be found in Section 7.2
The University of North Carolina at Charlotte
63
Unique ID Verification Plan Verification Status and Progress Report Location SOW 4.2 A system will be designed capable of being launched in a high-powered rocket, deploying safely, and recovering simulated lunar ice from one of several locations on the surface
safe by NAR, FAA, and NASA as well as will
adhere to the intent of the challenge. Additional experiments will be documented appropriately and will not contribute to scoring. In Progress The design, analysis, construction, and testing
verification flight remaining. Section 4 SOW 4.3.1 The launch vehicle will be launched from the NASA-designated launch area using provided launch pad. All hardware utilized during the mission must be launched within the launch vehicle. Complete Payload systems have not been designed to use hardware besides that included within the launch vehicle and to be launched from a NASA-designated launch area using provided launch pad. Section 4
Requirements Verification can be found in Section 8.4
The University of North Carolina at Charlotte
64
Team Derived Payload Requirements can be found in Section 8.3
The University of North Carolina at Charlotte
○ Updated list items ○ Payload preparation
○ Troubleshooting
○ Finalized verifications
○ Finalized assembly manual
65
The University of North Carolina at Charlotte
○ Packing List ○ Component Inspection
○ Recovery ○ Payload ○ Vehicle
○ Setup on pad ○ Igniter Installation
○ Component Inspection
66
Full Scale Launch Checklists can be found in section 6.1
The University of North Carolina at Charlotte
67
Personnel Hazard Analysis can be found in section 6.2.2
The University of North Carolina at Charlotte
68
Vehicle FMEA can be found in section 6.2.3
The University of North Carolina at Charlotte
69
Payload FMEA can be found in section 6.2.4
The University of North Carolina at Charlotte
70
Environmental Hazard Analysis can be found in section 6.2.5
The University of North Carolina at Charlotte
71
Verification of Requirements can be found in section 8.4
The University of North Carolina at Charlotte
○ Vehicle Demonstration Flight - February 22, 2020 ○ Payload Demonstration Flight - March 7, 2020
72
Project Plan can be found in Section 9.5, Appendix D
The University of North Carolina at Charlotte
73
Events Date
Charlotte Kid’s Fest 10/12 314 Freshman Learning Community 9/9 400 J.M. Robinson Middle School 10/7-10/8 150 Weddington High School 10/21 60 TARC Team Mentoring Recurring 8 Explore! 10/12 200; 200 UNCC Athletics 2/8 150 Mallard Creek Elementary 12/17, 2/4-2/24 75 Discovery Day Takeover 2/21 400 Total 1,965
Educational Engagement can be found in Section 8.7
The University of North Carolina at Charlotte
74
Source Amount Niner Nation Gives $7,103.00 NC Space Grant $6,000.00 Crowdfunding $11,497.00 Bridge Tournament $1,700.00 ISL Department/College $4,000.00 Total: $30,300.00 Category Amount Vehicle $12,478.19 Payload $4,274.78 Testing $1,000.00 Outreach $500.00 Travel $6,104.00 Shipping $211.34 Total: $24,568.31
Budget and Funding Plan can be found in Sections 8.6 and 8.7
The University of North Carolina at Charlotte
75
General NASA Requirements can be found in Section 8.4
The University of North Carolina at Charlotte
