First Run II Measurement of the W Boson Mass by CDF Oliver Stelzer-Chilton Stelzer-Chilton Oliver University of Oxford High Energy Physics Seminar Michigan State University April 3 rd , 2007 Outline 1. Motivation 1. Motivation 2. W

slide-1
SLIDE 1

First Run II Measurement of the W Boson Mass by CDF

High Energy Physics Seminar Michigan State University Oliver Oliver Stelzer-Chilton Stelzer-Chilton University of Oxford

April 3rd, 2007

slide-2
SLIDE 2

HEP Seminar Oliver Stelzer-Chilton - Oxford 2

Outline

1. 1. Motivation Motivation 2. 2. W Production at the W Production at the Tevatron Tevatron 3. 3. Analysis Strategy Analysis Strategy 4. 4. Detector Calibration Detector Calibration

  • Momentum Scale

Momentum Scale

  • Energy Scale

Energy Scale

  • Recoil

Recoil 5. 5. Event Simulation Event Simulation 6. 6. Results Results 7. 7. Conclusions Conclusions

slide-3
SLIDE 3

HEP Seminar Oliver Stelzer-Chilton - Oxford 3

The W Boson and the Standard Model

  • 1930’s: Fermi explains nuclear β-decay as 4-point interaction
  • 1960’s: Glashow, Weinberg and Salam

→ unify electromagnetic and weak interaction → explain interaction by exchange of massive vector bosons

  • Became foundation of the

Standard Model

  • W boson mass is fundamental

parameter

slide-4
SLIDE 4

HEP Seminar Oliver Stelzer-Chilton - Oxford 4

Introduction

  • Derive W mass from precisely measured electroweak quantities
  • where MW=MZcosθW
  • αEM(MZ)=1/127.918(18)
  • GF=1.16637(1) 10-5 GeV-2
  • MZ=91.1876(21) GeV
  • Δr: radiative corrections dominated by tb and Higgs loop

mW

2 =

em 2GF sin2W (1 r)

slide-5
SLIDE 5

HEP Seminar Oliver Stelzer-Chilton - Oxford 5

Measured Top Mass

New Tevatron average (3 weeks ago): Top mass now measured to 1.8 GeV http://tevewwg.fnal.gov/top

slide-6
SLIDE 6

HEP Seminar Oliver Stelzer-Chilton - Oxford 6

  • Progress on W mass uncertainty now has the biggest impact on

Higgs mass constraint

  • With improved precision also sensitive

to possible exotic radiative corrections

Motivation

Current top mass uncertainty 1.1% (1.8 GeV) → contributes 0.014 % (11 MeV) to δMW Before Winter 2007: W mass uncertainty 0.036% (29 MeV)

slide-7
SLIDE 7

HEP Seminar Oliver Stelzer-Chilton - Oxford 7

Higgs Mass Prediction

Predicted Higgs mass from W loop corrections (LEP EWWG): mH=85+39

  • 28 GeV (<166 GeV at 95% CL)

direct search from LEP II: mH>114.4 GeV Before Winter 2007

http://lepewwg.web.cern.ch/LEPEWWG/

slide-8
SLIDE 8

HEP Seminar Oliver Stelzer-Chilton - Oxford 8

Analysis Strategy

slide-9
SLIDE 9

HEP Seminar Oliver Stelzer-Chilton - Oxford 9

Tevatron Collider

  • Tevatron is a proton

antiproton collider with ~1 TeV per beam

  • Currently the only place in

the world where W and Z bosons can be produced directly

  • 36 p and pbar bunches,

396 ns between bunch crossing, ECM=1.96 TeV

slide-10
SLIDE 10

HEP Seminar Oliver Stelzer-Chilton - Oxford 10

W Production

precise charged lepton measurement is the key (achieved ~0.03%) mT = 2pT

l pT (1 cosl )

Combine information into transverse mass mT: Recoil measurement (restricted to u<15 GeV) allows inference of neutrino pT pT

ν=|-u-pT l|

Quark-antiquark annihilation dominates (80%)

slide-11
SLIDE 11

HEP Seminar Oliver Stelzer-Chilton - Oxford 11

W/Z Boson Production at the Tevatron

  • Initial state QCD radiation appears

as soft “hadronic recoil” in calorimeter

  • Pollutes W mass information

fortunately pT

W << MW

W W±

±

Z Z0

  • Can use Z→ll decays to calibrate recoil model
slide-12
SLIDE 12

HEP Seminar Oliver Stelzer-Chilton - Oxford 12

W/Z Boson Production and Decay

σ(W→lν)=2775 pb After event selection ET(l,ν) > 30 GeV 51,128 W→µν candidates 63,964 W→eν candidates σ(Z→ll)=254.9 pb After event selection ET(l) > 30 GeV 4,960 Z→µµ candidates 2,919 Z→ee candidates From the high pT lepton triggers (pT>18 GeV)

slide-13
SLIDE 13

HEP Seminar Oliver Stelzer-Chilton - Oxford 13

81 GeV 80 GeV

Measurement Strategy

W mass is extracted from transverse mass, transverse momentum and transverse missing energy distribution

Detector Calibration

  • Tracking momentum scale
  • Calorimeter energy scale
  • Recoil

Fast Simulation

  • NLO event generator
  • Model detector effects

W Mass templates + Backgrounds Data Binned likelihood fit W Mass

slide-14
SLIDE 14

HEP Seminar Oliver Stelzer-Chilton - Oxford 14

W Mass Measurement

pT

W = 0

pT

W ≠ 0

measured

mT

  • Insensitive to pT

W to 1st order

  • Reconstruction of pT

ν sensitive

to hadronic response and multiple interactions

pT

  • Less sensitive to hadronic

response modeling

  • Sensitive to W production

dynamics

slide-15
SLIDE 15

HEP Seminar Oliver Stelzer-Chilton - Oxford 15

CDF II Detector

θ

η η = 1.0 = 1.0 η η = 2.8 = 2.8 η η = 2.0 = 2.0

■ Silicon tracking detectors ■ Central drift chambers (COT) ■ Solenoid Coil ■ EM calorimeter ■ Hadronic calorimeter ■ Muon scintillator counters ■ Muon drift chambers ■ Steel shielding

slide-16
SLIDE 16

HEP Seminar Oliver Stelzer-Chilton - Oxford 16

CDF II Detector

slide-17
SLIDE 17

HEP Seminar Oliver Stelzer-Chilton - Oxford 17

Tracking Momentum Scale Calibration

slide-18
SLIDE 18

HEP Seminar Oliver Stelzer-Chilton - Oxford 18

Tracker Alignment

  • Internal alignment is performed

using a large sample of cosmic rays → Fit hits on both sides to one helix

  • Determine final track-level

curvature corrections from electron-positron E/p difference in W→eν decays

  • Statistical uncertainty of

track-level corrections leads to systematic uncertainty ΔMW= 6 MeV

slide-19
SLIDE 19

HEP Seminar Oliver Stelzer-Chilton - Oxford 19

Momentum Scale Measurements

  • Template mass fits to J/Ψ→µµ, Υ→µµ, Z→µµ resonances
  • Fast simulation models relevant physics processes
  • internal bremsstrahlung
  • ionization energy loss
  • multiple scattering
  • Simulation includes event reconstruction and selection
  • First principles simulation of tracking
  • Detector material model
  • Map energy loss and radiation lengths

in each detector layer (3D lookup table in r, ϕ and z)

  • Overall material scale determined

from data

slide-20
SLIDE 20

HEP Seminar Oliver Stelzer-Chilton - Oxford 20

Momentum Scale from J/Ψ

  • J/ψ mass independent of pT
  • Slope affected by energy loss

modelling

  • Measurement dominated by

systematic uncertainties → QED and energy loss model

  • Data
  • Simulation

J/ψ→µµ

default material scaled to 0.94 to tune energy loss

slide-21
SLIDE 21

HEP Seminar Oliver Stelzer-Chilton - Oxford 21

  • Υ provide invariant mass inter-

mediate between J/Ψ and Z’s

  • Υ are all primary tracks: can be

beam-constrained, like W tracks

Momentum Scale from Υ

  • Test beam constraint by measuring

mass using unconstrained tracks

  • Correct by half the difference

between fits and take corrections as systematic uncertainty

  • Data
  • Simulation
  • Data
  • Simulation
slide-22
SLIDE 22

HEP Seminar Oliver Stelzer-Chilton - Oxford 22

Δp/p = (-1.50 ± 0.20) x 10-3

  • Systematic uncertainties:

Combined Momentum Scale from Quarkonia

slide-23
SLIDE 23

HEP Seminar Oliver Stelzer-Chilton - Oxford 23

Momentum Scale Cross-Check

Z→µµ Apply momentum scale to Z→µµ sample Z mass in good agreement with PDG (91188±2 MeV) ΔMW= 17 MeV All momentum scales consistent

  • Data
  • Simulation
slide-24
SLIDE 24

HEP Seminar Oliver Stelzer-Chilton - Oxford 24

EM Calorimeter Scale Calibration

slide-25
SLIDE 25

HEP Seminar Oliver Stelzer-Chilton - Oxford 25

Calorimeter Energy Calibration

  • Transfer momentum calibration to calorimeter by fitting peak
  • f E/p distribution of electrons from W decay
  • Additional physics effects beyond those for muon tracks
  • photon radiation and conversion

E p

slide-26
SLIDE 26

HEP Seminar Oliver Stelzer-Chilton - Oxford 26

Full Electron Simulation

Response and resolution In EM calorimeter Energy loss into hadronic calorimeter Energy loss in solenoid Track reconstruction In outer tracker Bremsstrahlung and Conversions in silicon

Electromagnetic Calorimeter

t

z[m] r[m]

slide-27
SLIDE 27

HEP Seminar Oliver Stelzer-Chilton - Oxford 27

Energy Scale Calibration

W→eν

  • Calibrate calorimeter energy with peak of E/p distribution
  • Energy Scale SE set to SE=1±0.00025stat±0.00011X0±0.00021Tracker
  • Setting SE to 1 using E/p calibration

Calorimeter Energy< Track Momentum: Energy loss in Hadronic calorimeter Calorimeter Energy> Track Momentum: Energy loss in tracker

  • Data
  • Simulation
slide-28
SLIDE 28

HEP Seminar Oliver Stelzer-Chilton - Oxford 28

Consistency of Radiative Material Model

  • Excellent description of E/p tail
  • Radiative material tune factor:

Smat=1.004±0.009stat±0.002bkg

  • Z mass reconstructed from

electron track momenta only geometry confirmed: Smat independent of |η| Measured value in good agreement with PDG

  • Data
  • Simulation
  • Data
  • Simulation

Smat |ηi|

slide-29
SLIDE 29

HEP Seminar Oliver Stelzer-Chilton - Oxford 29

  • Fit Z Mass using scale from E/p calibration
  • Measure non-linearity through E/p fits in bins of ET in W→eν and

Z→ee data and apply correction to simulation

  • Include Z→ee mass for final energy scale (30% weight)

ΔMW= 30 MeV

Z Mass Cross-Check and Final Energy Scale

Z→ee Z mass in good agreement with PDG (91188±2 MeV)

  • Data
  • Simulation
slide-30
SLIDE 30

HEP Seminar Oliver Stelzer-Chilton - Oxford 30

  • Tracking resolution parametrized in fast Monte Carlo by
  • Drift chamber hit resolution σh=150±3stat µm
  • Beamspot size σb=39±3stat µm
  • Tuned on widths of Z→µµ and Υ→µµ distribution

ΔMW= 3 MeV

  • Electron cluster resolution parametrized by 13.5%/√ET ⊕ κ
  • primary electron constant term: κ=0.89±0.15stat%
  • secondary photon resolution: κ=8.3±2.2stat%
  • Tuned on the widths of the E/p peak and Z→ee peak

(selecting radiative electrons) ΔMW= 9 MeV

Detector Resolutions

slide-31
SLIDE 31

HEP Seminar Oliver Stelzer-Chilton - Oxford 31

Hadronic Recoil Model

slide-32
SLIDE 32

HEP Seminar Oliver Stelzer-Chilton - Oxford 32

Hadronic Recoil Definition

Recoil definition: → Energy vector sum over all calorimeter towers, excluding:

  • lepton towers
  • towers near beamline

(“ring of fire”)

  • Lepton removal also removes

underlying event  Need to measure recoil under lepton

  • Recoil under lepton depends
  • n lepton tower definition
slide-33
SLIDE 33

HEP Seminar Oliver Stelzer-Chilton - Oxford 33

Lepton Removal

Electrons: Remove 7 towers keystone (shower) ΔMW= 8 MeV

  • Estimate removed recoil energy using towers separated in Φ
  • Model tower removal in simulation

Muons: Remove 3 towers (MIP) ΔMW= 5 MeV

slide-34
SLIDE 34

HEP Seminar Oliver Stelzer-Chilton - Oxford 34

Hadronic Recoil Simulation

Recoil momentum vector u has two components:

  • Soft spectator interaction component, randomly oriented
  • modelled using minimum bias data with tuneable magnitude
  • A hard ‘jet’ component, directed opposite the boson pT
  • pT-dependent response and resolution parametrization
  • Hadronic response R=(umeas/utrue)
  • R parametrized as a logarithmically increasing function of boson pT

motivated by Z boson data

  • Data
  • Simulation
slide-35
SLIDE 35

HEP Seminar Oliver Stelzer-Chilton - Oxford 35

Hadronic Recoil Response Calibration

  • Project vector sum of pT(ll) and u on orthogonal

axes defined by lepton directions

  • Use Z balancing to calibrate recoil energy scale
  • Mean and RMS of projections as a function of

pT(ll) provide information for model parameters Hadronic model parameters tuned by minimizing χ2 between data and simulation ΔMW= 9 MeV

  • Data
  • Simulation
slide-36
SLIDE 36

HEP Seminar Oliver Stelzer-Chilton - Oxford 36

Hadronic Recoil Resolution Calibration

µ µ η

u

ΔMW= 7 MeV Resolution at low pT(Z) dominated by underlying event Resolution at high pT(Z) dominated by jet resolution

  • Data
  • Simulation

ξ

slide-37
SLIDE 37

HEP Seminar Oliver Stelzer-Chilton - Oxford 37

Recoil Model Checks

  • Apply model to W sample to

check recoil model from Z’s

  • Recoil projection along lepton

direction u|| → directly affects mT fits → Sensitive to: lepton removal, efficiency model, scale, resolution, W decay

  • Recoil projection perpendicular

to lepton direction u⊥ → Sensitive to resolution model

  • Data
  • Simulation
  • Data
  • Simulation
slide-38
SLIDE 38

HEP Seminar Oliver Stelzer-Chilton - Oxford 38

Recoil Model Checks

  • Recoil distribution

→ Sensitive to recoil scale, resolution and boson pT

  • Recoil model validation plots

confirm the consistency of the model

  • Data
  • Simulation
slide-39
SLIDE 39

HEP Seminar Oliver Stelzer-Chilton - Oxford 39

Event Simulation

slide-40
SLIDE 40

HEP Seminar Oliver Stelzer-Chilton - Oxford 40

Signal Simulation and Template Fitting

  • All signals simulated using a fast simulation
  • Generate finely-spaced templates as a function of fit variable
  • perform binned maximum-likelihood fits to the data
  • Custom fast simulation makes smooth, high statistics templates
  • provides analysis control over key components of simulation
  • We will extract the W mass from six kinematic distributions:

mT, pT and ET for muon and electron channel

81 GeV 80 GeV

slide-41
SLIDE 41

HEP Seminar Oliver Stelzer-Chilton - Oxford 41

Generator-level Signal Simulation

  • Generator-level input for W&Z simulation provided by RESBOS

[Balazs et.al. PRD56, 5558 (1997)]

  • Radiative photons generated according to energy vs angle lookup

table from WGRAD [Baur et.al. PRD59, 013002 (1998)]

  • Simulate FSR (ISR, photons off the propagator, ΔMW< 5 MeV)
  • Apply 10% correction for 2nd photon

[Calame et.al. PRD69, 037301 (2004)] and take 5% systematic uncertainty ΔMW= 11 (12) MeV for e (µ) RESBOS WGRAD

slide-42
SLIDE 42

HEP Seminar Oliver Stelzer-Chilton - Oxford 42

Boson pT Model

  • Model boson pT using RESBOS

generator

  • non pertubative regime at low

pT parametrized with g1, g2, g3 parameters [Landry et.al. PRD67, 073016 (2003)]

  • g2 parameter determines

position of peak in pT distribution

  • Measure g2 with Z boson data

(other parameters negligible)

  • Find: g2 = 0.685±0.048

ΔMW= 3 MeV

  • Data
  • Simulation
  • Data
  • Simulation
slide-43
SLIDE 43

HEP Seminar Oliver Stelzer-Chilton - Oxford 43

Parton Distribution Functions

  • Affect W kinematic lineshape through acceptance cuts

(only use |η|<1)

  • We use CTEQ6M as the default
  • Use CTEQ6 ensemble of 20 ‘uncertainty PDFs’:

[Pumplin et.al. JHEP, 0207 (2002)]  20 free parameters in global fit  compute δMW contribution from each error PDF

  • Using CTEQ prescription and interpreting ensemble as 90% CL

ΔMW= 11 MeV

  • Cross-check: Fitting MC sample generated with MRST2003

[Martin et.al. Eur. Phys. Jour. C28, 455 (2003)] with default CTEQ6M template yields a 8 MeV shift in W mass

slide-44
SLIDE 44

HEP Seminar Oliver Stelzer-Chilton - Oxford 44

Backgrounds

  • Backgrounds have very different lineshapes compared to W signal
  • distributions are added to template
  • QCD measured with data
  • EWK predicted with Monte Carlo

0.93±0.03 0.89±0.02 W→τν 0.24±0.04 6.6±0.3 Z→ll

  • 0.05±0.05

Cosmic Rays

  • 0.3±0.2

Decay in Flight 0.25±0.15 0.1±0.1 Hadronic Jets %(Electrons) %(Muons) Background

ΔMW= 8 (9) MeV for e (µ)

slide-45
SLIDE 45

HEP Seminar Oliver Stelzer-Chilton - Oxford 45

W Boson Mass Fits

slide-46
SLIDE 46

HEP Seminar Oliver Stelzer-Chilton - Oxford 46

Transverse Mass Fit (Muons)

  • Data
  • Simulation
slide-47
SLIDE 47

HEP Seminar Oliver Stelzer-Chilton - Oxford 47

Transverse Mass Fit (Electrons)

  • Data
  • Simulation

Muon and Electron combined: MW=80417±48 MeV P(χ2)=7%

slide-48
SLIDE 48

HEP Seminar Oliver Stelzer-Chilton - Oxford 48

Transverse Momentum Fit (Muons)

  • Data
  • Simulation
slide-49
SLIDE 49

HEP Seminar Oliver Stelzer-Chilton - Oxford 49

Transverse Energy Fit (Electrons)

  • Data
  • Simulation

Muon and Electron combined: MW=80388±59 MeV P(χ2)=18%

slide-50
SLIDE 50

HEP Seminar Oliver Stelzer-Chilton - Oxford 50

Missing Transverse Energy Fit (Muons)

  • Data
  • Simulation
slide-51
SLIDE 51

HEP Seminar Oliver Stelzer-Chilton - Oxford 51

Missing Transverse Energy Fit (Electrons)

  • Data
  • Simulation

Muon and Electron combined: MW=80434±65 MeV P(χ2)=43%

slide-52
SLIDE 52

HEP Seminar Oliver Stelzer-Chilton - Oxford 52

Systematic Uncertainty

Systematic uncertainty on transverse mass fit ⇒ Combined Uncertainty: 48 MeV for 200 pb-1

slide-53
SLIDE 53

HEP Seminar Oliver Stelzer-Chilton - Oxford 53

Results

  • Combining all six mass fits yields:

MW=80413±48 MeV (stat+syst), P(χ2)=44%

  • New CDF result is the world’s most precise single measurement
  • World average increases:

80392 to 80398 MeV

  • Uncertainty reduced ~15%

(29 to 25 MeV)

slide-54
SLIDE 54

HEP Seminar Oliver Stelzer-Chilton - Oxford 54

Previous MW vs Mtop

Summer 2006

slide-55
SLIDE 55

HEP Seminar Oliver Stelzer-Chilton - Oxford 55

Updated MW vs Mtop

Winter 2007 New CDF W Mass

slide-56
SLIDE 56

HEP Seminar Oliver Stelzer-Chilton - Oxford 56

Latest Higgs Constraint

March 2007 New top mass

slide-57
SLIDE 57

HEP Seminar Oliver Stelzer-Chilton - Oxford 57

Standard Model Higgs Constraint

  • Summer 2006 SM Higgs fit: (LEP EWWG)
  • MH = 85+39
  • 28 GeV
  • MH < 166 GeV (95% CL)
  • MH < 199 GeV (95% CL) Including LEPII direct exclusion
  • Updated preliminary SM Higgs fit: (With new CDF W Mass)
  • MH = 80+36
  • 26 GeV (M. Grünewald, private communication)
  • MH < 153 GeV (95% CL)
  • MH < 189 GeV (95% CL) Including LEPII direct exclusion
  • Updated preliminary SM Higgs fit: (With new Tevatron top mass)
  • MH = 76+33
  • 24 GeV
  • MH < 144 GeV (95% CL)
  • MH < 182 GeV (95% CL) Including LEPII direct exclusion
slide-58
SLIDE 58

HEP Seminar Oliver Stelzer-Chilton - Oxford 58

Progress since 1995

2007 indirect mt and mw Winter 2007 direct mt and mw 1995 direct mt and mw 1995 indirect mt and mw

slide-59
SLIDE 59

HEP Seminar Oliver Stelzer-Chilton - Oxford 59

Projection

  • Projection from previous Tevatron measurements
slide-60
SLIDE 60

HEP Seminar Oliver Stelzer-Chilton - Oxford 60

Summary

  • W boson mass remains a very interesting parameter to measure

with increasing precision

  • CDF Run II measurement is the most precise single measurement

MW = 80413 ± 34 ± 34 MeV = 80413 ± 48 MeV (preliminary)

  • New preliminary Higgs constraint MH = 76+33
  • 24 GeV (LEP EWWG)

(including new CDF W boson mass and new top quark mass average) → Mass has moved further into the directly excluded region Looking forward: → Expect ΔMW < 25 MeV with >1.5 fb-1 already collected by CDF

slide-61
SLIDE 61

HEP Seminar Oliver Stelzer-Chilton - Oxford 61

Higgs

What is the Higgs mass?

slide-62
SLIDE 62

HEP Seminar Oliver Stelzer-Chilton - Oxford 62

Backup Slides

slide-63
SLIDE 63

HEP Seminar Oliver Stelzer-Chilton - Oxford 63

Systematic Uncertainty

slide-64
SLIDE 64

HEP Seminar Oliver Stelzer-Chilton - Oxford 64

Signed χ

slide-65
SLIDE 65

HEP Seminar Oliver Stelzer-Chilton - Oxford 65

Latest Higgs Constraint

slide-66
SLIDE 66

HEP Seminar Oliver Stelzer-Chilton - Oxford 66

Higgs Sensitivity

slide-67
SLIDE 67

HEP Seminar Oliver Stelzer-Chilton - Oxford 67

Consistency Checks of Results

  • Use BLUE method to combine results and check consistency
  • List of obtained χ2 and probabilities for several combinations:
  • two transverse mass fits: χ2/dof = 3.2/1, prob = 7%
  • charged lepton fits: χ2/dof = 1.8/1, prob = 18%
  • two MET fits: χ2/dof = 0.6/1, prob = 43%
  • all three fits for electrons: χ2/dof = 1.4/2, prob = 49%
  • all three fits for muons: χ2/dof = 0.8/2, prob = 69%
  • all six fits, both channels: χ2/dof = 4.8/5, prob = 44%
slide-68
SLIDE 68

HEP Seminar Oliver Stelzer-Chilton - Oxford 68

Tevatron Run I Uncertainties

84 113 144 Total 10 10 10 Γ(W) 12 11 11 QED rad. Corrections 8 15 15 Parton dist. Functions 9 5 25 Backgrounds 12

  • 18

Selection bias 15 15 20 pT(W) 35 37 35 Recoil model 19 25 20 Lepton resolution 56 75 85 Lepton energy scale 60 65 100 Statistics D0 e CDF e CDF µ

slide-69
SLIDE 69

HEP Seminar Oliver Stelzer-Chilton - Oxford 69

Energy Loss Model

  • Use GEANT to parametrize energy loss in solenoid and leakage

into hadronic calorimeter

  • Energy loss in hadronic calorimeter
  • Relevant for E/p lineshape
slide-70
SLIDE 70

HEP Seminar Oliver Stelzer-Chilton - Oxford 70

Measurement of EM Calorimeter Non-Linearity

  • Perform E/p fit-based calibration in bins of electron ET
  • Parametrize non-linear response as SE=1+ξ(ET/GeV-39)
  • Apply energy dependent scale to simulated electron and photon
  • Tune W and Z data: ξ=(6±7)x10-5

SE SE ET (e) (GeV) ET (e) (GeV)

slide-71
SLIDE 71

HEP Seminar Oliver Stelzer-Chilton - Oxford 71

Tracker Alignment

Central Outer Tracker: Open-cell drift chamber

  • Use clean sample of cosmic

rays for cell-by-cell internal alignment

  • Fit COT hits on both sides

simultaneously to a single helix

  • Measure cell tilts and shifts
slide-72
SLIDE 72

HEP Seminar Oliver Stelzer-Chilton - Oxford 72

Alignment Example

Cell shift (microns) Final relative alignment of cells ~5µm (initial alignment ~50µm)

slide-73
SLIDE 73

HEP Seminar Oliver Stelzer-Chilton - Oxford 73

COT Wire Alignment

  • Fit separate helices to cosmic ray tracks on each side
  • Compare track parameters of the two tracks
  • Measure of track parameter bias

Curvature: Z[cm]

slide-74
SLIDE 74

HEP Seminar Oliver Stelzer-Chilton - Oxford 74

Material Distribution
