SLIDE 1
Orange A
Orange A
Getting Lost is Dangerous
“Before they ran out of air, they usually were lost.” [1]
Rick Lasky, Chief, Lewisville (TX) Fire Department
[2]
FireComm Orange A Getting Lost is Dangerous Before they ran out of - - PowerPoint PPT Presentation
FireComm Orange A Getting Lost is Dangerous Before they ran out of - - PowerPoint PPT Presentation
FireComm Orange A Getting Lost is Dangerous Before they ran out of air, they usually were lost. [1] Rick Lasky, Chief, Lewisville (TX) Fire Department [2] Orange A Identifying Needs Simple to Use Work in Large Buildings Lightweight
SLIDE 2
SLIDE 3
Orange A
Identifying Needs Simple to Use Work in Large Buildings Lightweight
[3]
SLIDE 4
Orange A
Our Vision
An indoor location tracking system for large buildings that is simple to use for firefighters
SLIDE 5
Orange A
Mockup Tests
An indoor location tracking system for large buildings that is simple to use
SLIDE 6
Orange A
Location Tracking Technology
Wearable Receiver Transmitters
[8] [4] [5] [6] [7]
SLIDE 7
Orange A
Product Contract - Technology
Customer Needs Product Attributes Engineering Specifications
Accurate in Location Detection Accuracy Range < 1.5 meters Able to Detect in Large Buildings Detection Range > 45 meters
SLIDE 8
Orange A
Tracking Technology Mock Up
Accurate but not precise enough
Lesson Learned
Up to 12 ft Receiver: Laptop Transmitter 1 Transmitter 2 Up to 16 ft
SLIDE 9
Orange A
Transmitter Housing Mock Up
Customer Need Product Attribute Engineering Specification
Simple to Use Setup Time < 30 sec/Transmitter
SLIDE 10
Orange A
Next Steps
Explore other tracking technologies Create Location Display
[9] [10]
SLIDE 11
Orange A
Citation
