FINAL PRESENTATION Purdue University Andrea Vacca 4/13/2018 PRESENTATION OVERVIEW The Team Bicycle Design Hydraulic design AMESim simulation and optimization Experimental and simulation results Mechanical design


slide-1
SLIDE 1

FINAL PRESENTATION Purdue University Andrea Vacca 4/13/2018

slide-2
SLIDE 2

PRESENTATION OVERVIEW

  • The Team
  • Bicycle Design

– Hydraulic design

 AMESim simulation and optimization  Experimental and simulation results

– Mechanical design

 Static analysis  Final design

– Electronic design

 Application design and functionalities

  • Conclusion

– Experimental results – Cost analysis – Lesson learned

slide-3
SLIDE 3

The team

Marcos Ivan Mireles (Mexico) Francesco Leschiera (Italy) Jiongyu Sun (China) Jeffrey Kuhn (U.S.A.)

slide-4
SLIDE 4

Andrea Vacca

Team Advisor Professor of Mechanical Engineering and Agricultural & Biological Engineering Maha Fluid Power Research Center Purdue University

Team advisor

slide-5
SLIDE 5

External gear pump Gerotor pump Internal gear pump Piston pump

Presentation highlight

Which is the best hydraulic unit for use in a human powered vehicle?

slide-6
SLIDE 6

Hydraulic design

  • Hydraulic units comparison

Hydraulic layout Operating modes AMESim circuit Optimization process Results

Goal : Find the most efficient hydraulic units for the design Goal : Find the most efficient hydraulic units for the design

slide-7
SLIDE 7

PISTON PUMP/MOTOR

Higher efficiency Contamination Heavier (cast iron ) Higher max pressure Cost inefficient

GEAR PUMP/MOTOR

Lower efficiency Contamination resistant Lighter (aluminum) Compact packaging Cost efficient

Hydraulic Units

Hydraulic unit comparison

Parker F-11 Casappa PLP Bent axis piston pump External gear pump

slide-8
SLIDE 8

Tank

HP V1 (NC) CV RP V2(NO) MG PG RG M MP RV

Acc

Valves

  • V1: Directional Control

Valve (Normally Closed)

  • RV: Relief Valve
  • CV: Check Valve
  • V2: Directional Control

Valve (Normally Open)

Gears

  • RG: Regeneration Gear
  • MG: Motor Gear
  • PG: Pump Gear

Pump Motor

  • M: Motor
  • MP: Main Pump
  • HP: Hand Pump
  • RP: Regeneration Pump
  • Acc: Accumulator

Hydraulic circuit layout

slide-9
SLIDE 9

High pressure line Low pressure line Flow direction

9

Operating modes : Pedaling

slide-10
SLIDE 10

HP Acc V1 (NC) CV RP V2(NO) RW MG PG RG M MP T RV

High pressure line Low pressure line Flow direction

10

Operating modes : Charging

slide-11
SLIDE 11

HP V1 (NC) CV RP V2(NO) MG PG RG M MP T RV

High pressure line Low pressure line Flow direction

Acc

11

Operating modes : Boost

slide-12
SLIDE 12

HP V1 (NC) CV RP V2(NO) MG PG RG M MP T RV Acc

High pressure line Low pressure line Flow direction

12

Operating modes : Regeneration

slide-13
SLIDE 13

Pedaling mode: Sizing

The resistance force would apply a torque on the shaft = Assuming a line pressure is p, the motor displacement is, =

  • ,

and the pump displacement is, = ,

  • With a shaft rotational speed of n, the flow rate Q is,

= , The linear velocity of the vehicle would be, = ,

  • 4 design variables + 5 assumption value  Velocity

Data Name Data

  • Slope

1% grade r Wheel Radius 0.324 m f Rolling Resistance 0.006 n Rotational Speed 70 rpm Assumption Name Value ,

Motor Hydro-mechanic Efficiency

0.9 ,

Pump Volumetric Efficiency

0.9 ,

Pump Hydro-mechanic Efficiency

0.9 ,

Motor Volumetric Efficiency

0.9 P Pressure 50 bar

Design Variable Name

  • Motor Displacement

gp

Gear Ratio (Pump)

  • Pump Displacement

gm

Gear Ratio (Motor)

Goal : Max velocity

slide-14
SLIDE 14

P CV1 CV2 M RP HP V2 V1 Variable slope ( 0-1%) 0.5 m/s wind speed Velocity

AMESim circuit

  • V1: Directional

Control Valve (Normally open)

  • RV: Relief Valve
  • CV: Check Valve
  • V2: Directional

Control Valve (Normally closed)

  • RG: Regeneration

Gear

  • MG: Motor Gear
  • PG: Pump Gear
Pump Motor
  • M: Motor
  • MP: Main Pump
  • HP: Hand Pump
  • RP: Regeneration

Pump

  • ACC: Accumulator
slide-15
SLIDE 15

Optimization circuit

slide-16
SLIDE 16

PISTON PUMP PISTON MOTOR GEAR MOTOR GEAR PUMP

Hydraulic units combinations

slide-17
SLIDE 17

Design Variable Range Lower bound Upper bound Pump displacement Changing 1 / 4.9 10 / 19 Motor displacement Changing 1 / 4.9 10 / 19 Pump gear ratio Not changing 1 20 Motor gear ratio Not changing

  • 1

20

Optimization Design Variable

Piston pump Piston motor Gear pump Gear motor

Optimization flow process

slide-18
SLIDE 18

Objective functions Algorithm Refine Velocity Scoring Ratio

*Non-Linear Programming by Quadratic Lagrangian The algorithm uses a quadratic approximation of the Lagrangian function It is available only for continuous be derivable input parameter s and can only handle one output parameter (other output parameters can be defined as constraints).

NLPQL*

Velocity+Scoring ratio/20

Optimization Design Variable Objective functions

Torque constrain = 27Nm

Piston pump Piston motor Gear pump Gear motor

Optimization flow process

slide-19
SLIDE 19

Iteration Optimization Design Variable Objective functions

Mass Displacement

Optimization NO YES

Result

Piston pump Piston motor Gear pump Gear motor

Optimization flow process

slide-20
SLIDE 20

5.41 5.52 5.65 5.82 56.38 57.76 58.54 59.81 10 20 30 40 50 60 70 Gear Pump Piston motor Gear pump Gear motor Piston pump Gear motor Piston pump Piston motor

= Velocity (m/s) = Scoring ratio

Simulation results

slide-21
SLIDE 21

Pressure Relief Valve Pressure Line Pressure Accumulator Regeneration lever pressed Both valve closed Regeneration valve

  • pens

HP V1 (NC) CV RP V2(NO) MG PG RG M MP T RV Acc

Time (s) Pressure(bar)

Max pressure accumulator

21

Regeneration system

slide-22
SLIDE 22

Best Design* Value Pump Displacement (F-11) 5.6 cc/rev Motor Displacement (F-11) 4.9 cc/rev Front Gear Ratio 6.48 Rear Gear Ratio

  • 2.07

Chosen components

Selected components Value Piston pump F-11 4.9 cc/rev Piston motor F-11 4.9 cc/rev Front Gear Ratio (MISUMI) 120/19 Rear Gear Ratio (MISUMI) 100/17 Regeneration gear ratio(ANDYMARK) 2.8 Other components Value Accumulator 2.0 L EATON LZJ 6.6 cc/rev Eaton NO valve

  • Sunhydraulics NC valve
  • Parker relief valve

200 bar

slide-23
SLIDE 23

Mechanical design

  • Mechanical units comparison

Hydraulic components Mechanical components Static analysis Final design

Goal : Streamline and appealing design Goal : Streamline and appealing design

slide-24
SLIDE 24

Pump / Motor Specifications

Material Cast iron Displacements 4.9 cc/rev Weight 11 lbs Provider Parker

Hydraulic components

Motor Motor Pump Pump CAD Motor CAD Motor CAD Pump CAD Pump

slide-25
SLIDE 25

Hand pump Hand pump Regeneration pump Regeneration pump CAD Regeneration pump CAD Regeneration pump CAD Hand pump CAD Hand pump

Regeneration pump Specifications

Material Aluminum Displacements 6.6 cc/rev Weight 3 lbs Provider Eaton

Hydraulic components

Hand pump Specifications

Material Steel Displacements 4.9 cc/stroke Weight 1.75 lbs Provider Hydac

slide-26
SLIDE 26

Pump Gear Box Technical Specifications

Material Stainless Steel # of stages 2 Primary Gear Ratio 120/19 Secondary Gear Ratio 120/120 Provider Misumi

Motor Gear Box Technical Specifications

Material Stainless Steel Number of Stages 1 Gear Ratio 100/17

Regeneration Gear Box Specifications

Gear Material Steel # of stages 1 Total Gear Ratio 2.8/1

Mechanical components

slide-27
SLIDE 27

Component Weight (Kg)

Parker F-11( x2 ) 10 Eaton LZJ 3 Hand pump 2 Accumulator 2 Rider 90 Oil 3.5 Frame 15 Other components 3 Total 128.5

Static analisys

slide-28
SLIDE 28

Final design

slide-29
SLIDE 29

Electrical design

  • Market available app

Electronic circuit Functionalities Extra features

Goal : Design an interactive modern Goal : Design an interactive modern

slide-30
SLIDE 30

12 VOLT CIRCUIT 5 VOLT CIRCUIT

Step down transformer

Monitoring Localization Instruction Control

Electric circuit design

slide-31
SLIDE 31

App features

Monitoring

slide-32
SLIDE 32

Valve control Shimano control

App features

Control

slide-33
SLIDE 33

App features

Extra features GPS positioning Instruction

slide-34
SLIDE 34

Experimental results

1 2 3 4 5 6 7 10 20 30 40 50 60 70

Velocity

Experimental Simulation

slide-35
SLIDE 35

Prototype Cost: $ 7911.27 Prototype Cost with Donation: $ 2960.07 Electronic circuit $ 730.52

ELECTRONIC 13.72% MECHANIC 11.63% HYDRAULICS 61.00% LABOR 13.65%

electronic mechanic hydraulic labor

Sensors $ 355.20 Frame $ 297.27 Gear Boxes $ 384.18 Other Bicycle Parts $ 238.45 $ 1080 $1085.72 $919.90 $4825.65 Pumps & Motor $ 4035.65 Hydraulic Circuit $ 790 Donated Parts $ 4951.20

Cost analysis

slide-36
SLIDE 36

Feature Cost [$] Shimano Alfine 8 Speed 328.92 Electronic Control System 730.52 Regeneration System 530.25 Customized Painting 100 Basic Version Cost: 2397.48 Premium Version Cost: 3373.68 Luxury Version Cost: 4003.93 Lite Version Cost: 3128

Cost analysis

slide-37
SLIDE 37

Some lessons learned

  • Budgeting management
  • Time management
  • Organization skills
  • Theoretical knowledge learning
  • Programming knowledge learning
  • Team cooperation
  • Problem Solving
slide-38
SLIDE 38

Conclusion

We all agreed that this project was able to expand our practical/theoretical knowledge as engineers. It also challenged our problem solving abilities while incorporating elements of hydraulic controls, mechanical manufacturing, and electronic circuit analysis.

slide-39
SLIDE 39
