Security Level: Confidential Spectra as Performance Metrics for Fiber-Optic Communication System pt 30pt Design : al 2018 Munich Workshop 47pt on Information Theory of Optical Fiber 28pt Mathematical and

SLIDE 1

HUAWEI TECHNOLOGIES CO., LTD. www.huawei.com Huawei Confidential

Security Level: Confidential

pt 30pt 反白 : al 47pt 黑体 28pt 反白细黑体

Spectra as Performance Metrics for Fiber-Optic Communication System Design

2018 Munich Workshop

n Information Theory of Optical Fiber

Mathematical and Algorithmic Sciences Lab Paris Research Center Georg Böcherer December 6, 2018

SLIDE 2

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

Motivation

 Recent efforts in community to provide information-theoretic tools

for design of fiber-optic communication systems.

 Nice summary in

L. Schmalen “Performance Metrics for Communication Systems with

Forward Error Correction,” ECOC 2018.

 Discuss current state and possible extensions.

Page 2

SLIDE 3

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

Outline

 Thresholds as performance metrics  Limitations of BER threshold  BER spectrum  Uncertainty spectrum  Conclusions Page 3

SLIDE 4

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

Design by Thresholds

Page 4

Interfaces between components are defined by

thresholds

Bit error rate (BER)
Mutual information
Generalized mutual information
GMI, NGMI, ABC, AIR, RBMD,…….
Components are designed to respect thresholds

Award-winning paper:

A. Alvarado et al “Replacing the Soft-

Decision FEC Limit Paradigm in the Design of Optical Communication Systems,” JLT, Vol 34, No 2, 2016.

SLIDE 5

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

Design by Thresholds

Page 5

 Crucial Assumption: ‘Infinite’ Interleavers.  Translates into latency in practical transceivers.

SLIDE 6

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

What if there is no ∞-interleaver?

Page 6

Example: DVB-S2

SLIDE 7

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

Simulation Results

Page 7

BER thresholds provide only limited insights for design

𝑢 = 12 BCH outer code achieves

FER = 3 × 10−6 at 0.96 dB.

With ∞-interleaver, 𝑢 = 1 BCH outer code

would achieve FER= 4 × 10−9 at 0.96 dB.

SLIDE 8

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

Design by BER Spectrum

 Quantify inner code performance by BER Spectrum, i.e., the statistics of

the fraction of erroneous bits per frame.

 Use BER spectrum for design:

 For given 𝑢, design inner code with constraint Pr #errors > t < target FER.  For given inner code, choose 𝑢 so that Pr #errors > t <target FER.

Page 8

SLIDE 9

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

Soft-Decision FEC: Uncertainty*

*Based on Gallager’s error exponent, details on uncertainty in [1] G. Böcherer, P. Schulte, and F. Steiner, “Probabilistic Shaping and Forward Error Correction for Fiber-Optic Communication Systems,” J. Lightw. Technol., 2019.

Page 9

SLIDE 10

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

Setup

Page 10  FEC Overhead: OHFEC = 1 −

𝑙 𝑜𝑛

For a given channel, what FEC-OH is achievable?

SLIDE 11

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

Achievable FEC Overhead

 We don’t know the exact channel, but we have a measurement

𝑦𝑜, 𝑧𝑜 (e.g., of a QAM signal)

 How large FEC Overhead 1 −

𝑙 𝑛𝑜 is required to recover 𝑦𝑜 from 𝑧𝑜

by FEC decoding?

Page 11

SLIDE 12

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

Achievable FEC Overhead

 Uncertainty  Theorem Page 12

Fraction of FEC codes that cannot decode 𝑦𝑜 from 𝑧𝑜 Decoding metric, e.g., 𝑄

𝑌|𝑍 𝑜 (𝑦𝑜|𝑧𝑜)

SLIDE 13

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

Interpretation

Page 13

FEC Overhead FEC Rate Uncertainty

For FEC overhead larger than uncertainty, exponent is negative.
Backing-off in FEC rate leads to exponential decay of probability to

pick a bad code.

Uncertainty identifies the phase transition to the possible.

Works for any measurement 𝑦𝑜, 𝑧𝑜 without any further assumptions.

SLIDE 14

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

From Measurement Property to Channel Property

Page 14

𝑜 → ∞,

ergodicity 𝑜 ≈FEC block length, many pairs 𝑦𝑜, 𝑧𝑜 Channel property: Achievable FEC overhead

𝑉𝑟 𝑛

Channel property: Uncertainty spectrum

Put forward in:

Essiambre et al “Capacity Limits of Optical

Fiber Networks”, JLT 2010.

Alvarado et al “Achievable Information

Rates for Fiber-Optics: Applications and Computations,” JLT 2018.

SLIDE 15

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

Example

Page 15

QPSK Measurement with 𝑜 =10 million bits at 1 dB SNR.
FEC block length 𝑜FEC =10 000.

Threshold  Use all 10 million samples to estimate uncertainty 𝑉𝑟 = 0.4373 bits  FEC overhead 0.4373 bits is achievable, asymptotically in the blocklength.  blocklength is finite, we have to back-

ff, how much?

Spectrum  Split measurement in

𝑜 𝑜FEC = 1000 chunks.

 Calculate 1000 uncertainties.  Plot the spectrum  Back-off to FEC overhead 0.47 bits.  Corresponds to 0.42 dB back-off in SNR.

𝑉 = 0.4373

Note: finite-length informationi theory accounts for variance, e.g., Polyankiy et al “Channel coding rate in the finite blocklength regime,” ITT 2010.

SLIDE 16

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

Conclusions

Page 16

Observations

Spectra account for finite-length effects.
Spectra account for correlations created by components.

 Alternative to threshold and ∞-interleaver. Possible Directions

New criteria for design of concatenated components?
To design components with desired spectra, can we borrow

from rate-distortion theory or information-theoretic security?

Shorter interleaver, better systems?

SLIDE 17

HUAWEI TECHNOLOGIES CO., LTD. Huawei Confidential

FEC Code Ensemble

 FEC Code

𝐷 = 𝐷𝑜 1 , 𝐷𝑜 2 , … , 𝐷𝑜 2𝑙 with symbols 𝐷𝑗(𝑥) in the channel alphabet (e.g., 16-QAM.)

 Encoder: map 𝑙 bits 𝑥 to code word 𝑦𝑜(𝑥).  Decoder:  Error probability:*

*=fraction of FEC codes that cannot decode 𝑦𝑜 from 𝑧𝑜.

Page 17

Decoding metric
