Feature Representation – Vision

BoWs and Beyond

Praveen Krishnan

Feature Representation in Vision

 Low Level

 Local Detectors and Descriptors  Bag of Words

 Mid Level

 Parts  Attributes

 Hierarchical

 Deep Representations

Low Level Vision

 Bag of

Visual Words (BoWs)

 Visual

Vocabulary

 Vector Quantization  Spatial

Verification

 Inspirations from IR

 Advanced coding and pooling schemes

 Soft quantization  Higher order representation

Bag of Words (BoWs)

A quick walk through..

 BoWs

Image Bag

A quick walk through..

 Origins in text processing

Slide: ICCV 2005 short course, L. Fei-Fei Salton & McGill (1983)

A quick walk through..

 Origins in texture recognition

Universal texton dictionary Histogram Julesz, 1981

A quick walk through..

 BoWs Representation

(i) Interest Point Detection (ii) Feature Extraction Visual Vocabulary (iii) Vector Quantization (iv) Coding and Pooling

Figure Courtesy: Tsai‟12

Devil is in the details

 Local detectors & descriptors

 SIFT, HOG, LBP, …

 Vocabulary

 k-means, approximate k-means, GMM

 Coding and Pooling

 Histogram, kernel code books, sparse codes, LLC, Fisher kernels,

Super Vectors, VLAD

 Average, Max

 Spatial

Verification

 Spatial pyramids, Min Hash, LLAH

 Recognition & Retrieval

 SVMs  Weighting schemes, query expansion, re-ranking etc.

Devil is in the details

 Local detectors & descriptors

 SIFT, HOG, LBP, …

 Vocabulary

 k-means, approximate k-means, GMM

 Coding and Pooling

 Histogram, kernel code books, sparse codes, LLC, Fisher kernels,

Super Vectors, VLAD

 Average, Max

 Spatial

Verification

 Spatial pyramids, Min Hash, LLAH

 Recognition & Retrieval

 SVMs  Weighting schemes, query expansion, re-ranking etc.

Assume dense sampling at multiple scales

Feature Extraction

 Detection

 Regular

 Fei-Fei et. al.‟ 05  Bosh et. al. „‟06

 Sparse or Interest point

 Mikolajczyk et. al ‟05  Csurka et al. 2004

 Description

 SIFT – Lowe‟99  MSER – Matas et.al. ‟02  HoG – Dalal et.al „05  many more… Descriptor

Descriptor

Learning Visual Vocabulary

 Partitioning the local descriptor

space into informative regions.

 Let be „N‟

SIFT descriptors from a subset of entire corpus.

 k-means

 Minimize sum of squared Euclidean

distances between points and their nearest cluster centers.

 Here B is the codebook

Clustering Visual vocabulary

• r Codebook

Visual Words/ Code Words Image patch example

Sivic et.al. ICCV‟05

Visual vocabulary

 Issues

 Size of vocabulary?

 Too small: visual words not

representative of all patches.

 Too large: quantization artifacts, over

fitting

 Generative or discriminative

learning?

 Gaussian mixture models. (More later)

 Computational Efficiency

 Approximate k-means using randomized

kd-trees. Phibin et.al . CVPR‟07

 Hierarchical K-Means. Nister et.al.

CVPR‟07

Nister et.al. CVPR‟07

Coding

  Vector quantization

 Assigns each feature to the nearest

visual word in the vocabulary.

 Hard quantization. Codebook

Pooling

  Invariance to changes in position,

lightning conditions.

 Robustness to clutter  Compactness of representation  Types

 Sum or average  Max Codebook

Pooling

  Invariance to changes in position,

lightning conditions.

 Robustness to clutter  Compactness of representation  Types

 Sum or average  Max Codebook There goes the geometry too



Spatial Pooling

 Pyramid Match Kernel

 Weighted sum of histogram

intersections at multiple resolutions.

 More weightage for matches

found at fine level than coarse level.

 Used for matching in high

dimensional spaces.

 Spatial Pyramid Matching

 Concatenate the histogram

vectors at all pyramid levels.

Pyramid Match Kernel, Grauman et.al. ICCV‟05 Spatial Pyramid Matching, Lazebnik et. al. CVPR‟06

Recognition & Retrieval

 Recognition

 Discriminative Methods

 K-nearest neighbor  SVMs

 Non-linear kernels

 Generative Methods

 Naïve Bayes.  Bayesian Models. (pLSA, LDA)

 Ranking & Retrieval

 Nearest neighbor search  Indexing Agenda for this talk

Ranking & Retrieval

 Similarity measures

 Cosine distance  L1 distance  Chi-square distance  Hellinger distance L1 Chi-Square Hellinger Applies discount to large values

Ranking & Retrieval

 Earth Mover‟s Distance (EMD)

 Computes dissimilarity between distribution.  Let be the distribution with „m‟ elements

and be the distribution with „n‟ elements. The flow F that minimizes the overall cost is given as:-

Transportation problem Distance between element si and qj

Ranking & Retrieval

 Evaluation measures

 Notations:

TP-True positives; FP-False positives; TN-True negatives; FN-False negatives

 Precision (P):  Recall (R):  F-measure:  Mean Average Precision (mAP)  Area under precision and recall curve

Query TP TP FP TP FP TN FN Cats and Dogs Database

Re-ranking using Geometric Verification

 Use the position and shape of the underlying

features to improve retrieval quality.

 Estimate geometric transformation to remove outliers  Approaches:

 RANSAC  Hough Transform Both images have many matches – which is correct?

Slide Credit: Cordelia Schmid

Re-ranking using Geometric Verification

 Fitting an affine transformation

 Assume we know the correspondences, how do we get the

transformation?

Slide Credit: Cordelia Schmid

Re-ranking using Geometric Verification

 RANSAC (Fischler & Bolles, 1981):

 Randomly select a seed group of matches  Compute transformation from seed group  Find inliers to this transformation  If the number of inliers is sufficiently large,

re-compute least-squares estimate of transformation on all of the inliers

 Keep the transformation with the largest

number of inliers

Randomly select minimal subset of points Hypothesize a model Compute error function Select points consistent with model Repeat hypothesize‐and verify loop E.g. Fitting a Line

Slide Credit: Kristen Grauman

Inspirations from IR

 Making faster

 Inverted indexing

 Reverse look up  Enables fast search by exploiting the sparse representation.

Image Courtesy : Jawahar et. al DAS‟14 #Images #Visual Words

Inspirations from IR

 Weighting schemes

 Zipf‟s Law: Frequency of any

word is inversely proportional to its rank.

 TF-IDF Weighting:  Stop Words: T

• p 5% of

frequent visual words.

Image Courtesy Wikipedia

Inspirations from IR

 Improving the recall

 Query expansion: Reformulating the query to increase its

• expressiveness. E.g. adding synonyms, jittering etc.

…

Query image Results New query Spatial verification New results Chum et.al., Total Recall, ICCV’07 Repeat

Inspirations from IR

 Query Expansion:

 Baseline  Transitive closure expansion

 Use of priority queue.

 Average query expansion  Recursive average query expansion  Multiple image resolution expansion

 Compute the median image resolution  Formulate query for other resolution bands. (0, 4/5) - (2/3, 3/2) - (5/4,

infinity)

 Do average query expansion for each band.

Chum et.al., Total Recall, ICCV’07

Advanced coding schemes

Lost in Quantization

 Hard quantization (VQ)  Issues

 codeword uncertainty  codeword plausibility.

Modeling Uncertainty

 Kernel code books

 Allowing a degree of ambiguity in assigning code words from

image features.

 Uses kernel density estimation

 Kernel size determine the amount of smoothing  Kernel shape is related to distance function

 Kernel Codebook Gemert et al, Kernel Codebooks for Scene Categorization, ECCV2008

Modeling Uncertainty

Gemert et al, Kernel Codebooks for Scene Categorization, ECCV2008

 Code word uncertainty  Code word plausibility

Encoding – Sparse Coding

 From

VQ to SC

 Max Pooling

Too restrictive. Relax by L1 norm ! Yang, e.t.al, CVPR‟09

Encoding – Sparse Coding

 Sparse Coding

 Fix

V and solve for U [LASSO]

 Fix U and solve for V [Least Square]

 Linear Classification using SPM kernel

Yang, e.t.al, CVPR‟09

Encoding

 SC results tends to be local.  Locality more essential than sparsity ?

 Local coordinate coding (LCC)  Locality-constrained Linear Coding (LLC)

 Dropping the sparsity term and evoking the locality term explicitly  Here denotes element wise multiplication and di is the locality

adaptor that gives different weights to different basis vector as per similarity .

Wang et. al., CVPR‟10

 Comparison with

VQ and SC

 Better reconstruction  Local smooth sparsity  Analytical solution

Encoding - LLC

Wang et. al., CVPR‟10

Interpretation so far…

 Discover sub spaces

• Each basis is a “direction”
• Sparsity: each datum is a

linear combination of only several bases.

• Related to topic model

 Geometry of data

manifold

• Each basis an “anchor

point”

• Sparsity is induced by

locality: each datum is a linear combination of neighbor anchors.

Slide Credit: Kai Yu

Higher Order Representation

Encoding

 So far…

 Representation extracted from the count statistics. (BoWs)  Why not include other statistics?

 mean of local descriptors  (co)variance of local descriptors

Slide Credit: Perronnin, CVPR‟12 tutorial on Large-Scale Visual Recognition

VLAD-Vector of Locally Aggregated Descriptors

 Given a codebook e.g.

learned with K-means, and a set of local descriptors,

• 1. Assign:
• 2. Compute (Residual

Vectors):

• 3. Concatenate and L2 nomalize

Slide Credit: Perronnin, CVPR‟12 tutorial on Large-Scale Visual Recognition

VLAD

 Characterizes the distribution w.r.t. center (first order

statistics)

 Dimensionality (D) = N x d. Here „N‟ is the codebook size

and „d‟ is the dimensionality of local descriptor.

Images and corresponding VLAD descriptors Jégou, Douze, Schmid and Pérez, “Aggregating local descriptors into a compact image representation”, CVPR‟10.

The Fisher vector

 Slides from:-

 Florent Perronnin, CVPR‟12 tutorial on Large-Scale

Visual Recognition

Packages

 The INRIA package:

 http://lear.inrialpes.fr/src/inria_fisher/

 The Oxford package:

 http://www.robots.ox.ac.uk/~vgg/research/encoding_ev

al/

References

 J. Sivic and A. Zisserman.

Video Google: A text retrieval approach to object matching in videos. In Proc. ICCV, 2003

 Nister CVPR‟06  M. Muja and D. G. Lowe. Fast approximate nearest neighbors with

automatic algorithmic configuration. In Proc. VISAPP , 2009

 Chatfield BMVC‟11  J. Philbin, O. Chum, M. Isard, J. Sivic, and A. Zisserman. Lost in quantization:

Improving particular object retrieval in large scale image databases. In Proc. CVPR, 2008.

 J. C. van Gemert, J. M. Geusebroek, C. J.

Veenman, and A. W. M. Smeulders. Kernel codebooks for scene categorization. In Proc. ECCV, 2008.

 Yang, Jianchao, et al. "Linear spatial pyramid matching using sparse coding for

image classification. In Proc CVPR 2009.

 Wang, Jinjun, et al. "Locality-constrained linear coding for image

• classification. In Proc. CVPR, 2010

References

 F. Perronnin and C. Dance. Fisher kernels on visual vocabularies for image

• categorization. In CVPR, 2007.

 Florent Perronnin,

Yan Liu, Jorge Sánchez, Herve Poirier, Large-scale image retrieval with compressed Fisher vectors. CVPR 2010

 Svetlana Lazebnik, Cordelia Schmid, Jean Ponce, Beyond Bags of Features:

Spatial Pyramid Matching for Recognizing Natural Scene Categories. CVPR 2006

 R. Baeza-Yates and B. Ribeiro-Neto. Modern Information Retrieval, ACM

Press, ISBN: 020139829, 1999.

 Ondrej Chum, Andrej Mikulík, Michal Perdoch, Jiri Matas, Total recall II:

Query expansion revisited, CVPR 2011
