SLIDE 1
Feasibility Study of Mobile Phone WiFi Detection in Aerial Search and Rescue Operations
Wei Wang, Raj Joshi, Aditya Kulkarni, Wai Kay Leong, and Ben Leong National University of Singapore
Feasibility Study of Mobile Phone WiFi Detection in Aerial Search - - PowerPoint PPT Presentation
Feasibility Study of Mobile Phone WiFi Detection in Aerial Search - - PowerPoint PPT Presentation
Feasibility Study of Mobile Phone WiFi Detection in Aerial Search and Rescue Operations Wei Wang, Raj Joshi, Aditya Kulkarni, Wai Kay Leong, and Ben Leong National University of Singapore Search and Rescue Highest incidents - Hiking Current
SLIDE 2
SLIDE 3
Highest incidents - Hiking
SLIDE 4
Current Methods
Limitations
- Terrain
- Manpower
Ground Based
SLIDE 5
Aerial Based
SLIDE 6
Hobbyist UAV
Affordable Easy to fly
- iPad or Android
- Autopilot
Easy to deploy
SLIDE 7
Current Aerial Approach
- P. Rudol and P. Doherty. Human body detection and geolocalization for UAV search and
rescue missions using color and thermal imagery.
Cameras Real Time Image Processing
SLIDE 8
Drawbacks
Requires Line-of-Sight Requires daylight Heavy payload
Optics On-board CPU
SLIDE 9
Key Idea
SLIDE 10
Is it Feasible?
Signals from a phone? Battery life? Range of detection?
SLIDE 11
WiFi Scan/Probe
Probe Request Frame
SLIDE 12
WiFi Scan
Time WiFi Scan
…
802.11 Channel
…
Scan interval
Different Scenarios Different Devices Different Intervals
SLIDE 13
Different Scenarios
Settings Screen High Home Screen Moderate Display Off Low
Scan Frequency
SLIDE 14
Different Devices
HTC Desire
Every 6 s Settings Screen Every 15 s Home Screen Does not scan Display Off
iPhone 5
{8.7, 10.7, 10.7, 10.7, 10.7} repeat Settings Screen {31, 31, 62, 62} repeat Home Screen 3, 7, 12, 17, 62, 62, 62, … Display Off
More results in the paper (Table 1)
SLIDE 15
Battery Life
Settings Screen
High Short
Display Off
Low Long
Scan Frequency Battery Life
- Android WiFiManager API
- Increase scan frequency with display off
Custom Android App
SLIDE 16
Monsoon Power Monitor
SLIDE 17
Sample Result of Battery Life
Motorola Electrify Default Scanning Freq 11 X Default WiFi Setting Screen Our Custom App 11 hours 51 hours 21 hours
More results in the paper (Table 2)
SLIDE 18
Passive Detection
4 to 5 Probe Request Frames
WiFi Scan
…
Probe Request Frame
SLIDE 19
Active Probing
Request To Send Clear To Send
SLIDE 20
Is it Feasible?
Signals from a phone? Battery life? Range of detection?
SLIDE 21
DIY Quadrotor
SLIDE 22
Detection Range
Distance 250 m
SLIDE 23
Effective Range
≈200 m range
SLIDE 24
Effect of Phone Orientation
SLIDE 25
Conclusion
Phone WiFi signal Battery life: 2 days Range: 200 to 230 m
SLIDE 26
SLIDE 27
Backup Slides
SLIDE 28
RSSI Threshold
Good signal strength
SLIDE 29
Effect of Altitude
90 m 150 m 210 m
30 m
SLIDE 30
Effect of Altitude
No improvement
