Factory EST 1988 / PPI NY 2005 ISO 9001 14001 Certified +207 employees S level reliability Mil C 55681 Mil C 123 Factory Recent audit by a top German manufacturer resulted in a 93% score, best in

slide-1
SLIDE 1
slide-2
SLIDE 2

Factory

  • EST 1988 / PPI NY 2005
  • ISO 9001
  • 14001 Certified
  • +207 employees
  • S level reliability
  • Mil C 55681
  • Mil C 123
slide-3
SLIDE 3

Factory

  • Recent audit by a top German manufacturer resulted in a

93% score, best in the High Power capacitor industry

  • Modern, automated equipment:

A) Minimizes cycle time, enabling easier customer production scheduling. Lead times Stock-6 weeks. B) Minimizes operator error C) Minimizes process variation, ensuring product consistency

  • Continuous multi-million $ investments ensures critical

process control and short lead times

  • 33 Pcs of new Manufacturing equipment, and 22 pcs of test

equipment have been purchased in the last 3 years.

slide-4
SLIDE 4

Product Reliability

State of the art electro-plating eliminates caustic chemical intrusion, which eliminates cracking due to out-gassing Automated dicing of green state ceramic blocks minimizes chip outs and cracking Dense ceramic microstructure minimizes voids and ensures robust performance under voltage stress State of the art screen printing produces thick and continuous electrodes, decreasing ESR and minimizing discontinuities Lead attach is done in a 10 zone, nitrogen controlled Reflow ovens, preventing oxidation and ensuring reliable solder joints

slide-5
SLIDE 5

Product Reliability- An Industry First

  • Passive Plus is the only supplier to offer the following Hi

Reliability screening programs, in production, at no extra charge:

  • 100% Automated Sonoscan (CSAM) Inspection on all

case sizes 2225 and larger; screens out electrically undetectable internal defects such as voids, cracks, de- laminations or electrode dis-continuities. Performed on AQL basis for 0505 and 1111 case sizes.

  • 100% High Voltage Partial Discharge Testing on all

leaded 2225 and larger case size capacitors

  • 100 HR burn in on all leaded 1111 and larger case size

capacitors and assemblies ensures reliability

slide-6
SLIDE 6

Product Reliability

  • Scuff free parts minimize arc-over risk
  • All assemblies and leaded parts are lot code marked,

facilitating traceability and problem resolution

  • Customized Hi Rel programs available
slide-7
SLIDE 7

PPI Service and Sales

  • Worldwide engineering/sales/stock support
  • Huntington , NY Headquarters
  • +1 631 425 0938 / sales@passiveplus.com
  • Steve Beyel, President, 30+ years RF experience
  • Bob Grossbach, Director of engineering, 35+years

experience, RF and capacitor design

  • Mark Johnson, Sr. Sales Manager, Western USA, 30+ years

experience, RF design and sales

  • Flemming Gade, Sr. Sales Manager, Europe, 35+ years

experience, RF sales

  • 32 representative firms WW
  • 92 Representative Sales Engineers
slide-8
SLIDE 8

PPI Service and Sales

  • Easy to do business with; NO MOQ; Online store
  • Delivery performance to promise date - 98%
  • Well staffed and trained inside sales people
  • Generous and Fast sampling
  • Speedy quoting and confirmations
  • Proactive notifications
  • Stocking and VMI programs
  • Lot code identifier per line item on shipping paperwork
  • Plastic shipping molding for assemblies prevents scuffing

and damage during shipping

slide-9
SLIDE 9

Leading Edge Broadband Capacitors

  • Applications are ultra wide RF coupling / DC blocking
  • Resonant free from 16 KHZ to +65 GHZ
  • 0402
  • 0201
  • 01005
  • Supported by S parameters and Modelithics models
  • In production now, parts in stock, samples available
slide-10
SLIDE 10

Design Support for RF capacitors

  • S parameters on website
  • Modelithics Modeling data with 30 day free trial
  • In house Keysight Genesys
  • AWR data library
slide-11
SLIDE 11

PPI ROADMAP

  • Innovation – Leading edge Broadband capacitors for

ultra wide bandwidth applications

  • RF capacitor design tools
  • Best in High-Q Industry Electrical Models and Real-World

Data

  • Best in Industry High Voltage Low ESR Capacitors
  • Best in High-Q Industry Process Control, Quality,

Repeatability and Reliability

  • Best in High-Q Industry Technical and Sales Support
  • Quickest Turn Assembly Prototypes and Production
  • Shortest Lead Times and Fastest Quote Turnaround
  • Lowest Cost of Ownership
slide-12
SLIDE 12

Screen Printing

slide-13
SLIDE 13

PPI 3838 electrode comparison to another supplier: State of the art screen printing produces thick and continuous electrodes, decreasing ESR and minimizing discontinuities that can cause failures PPI Another supplier

slide-14
SLIDE 14

Reflow Ovens / 10 zone

slide-15
SLIDE 15

Automatic Stacking

slide-16
SLIDE 16

Automatic Stacking, NEW

slide-17
SLIDE 17

Press and Dicing

slide-18
SLIDE 18

Firing

slide-19
SLIDE 19

Laser Marking

slide-20
SLIDE 20

Termination

slide-21
SLIDE 21

Burn In Chambers

slide-22
SLIDE 22

Partial Discharge Tester

slide-23
SLIDE 23

VNA

slide-24
SLIDE 24

ESR Testing Final
