Saath: Speeding up CoFlows by Exploiting the Spatial Dimension

Rohan Gandhi Y. Charlie Hu Akshay Jajoo

1

Chengkok-Koh

Analytics Jobs in Big Data

• Analytics jobs in data-centers

– Process huge amount of data – Distributed in nature – Have multiple stages that communicate with each other

2

Example – Map Reduce Jobs

3

Map Stage Shuffle (Communication) Reduce Stage

Two compute stages: Map and Reduce Map communicates with reduce in shuffle phase

Impact of communication on job performance

4

Map Stage Shuffle (Communication) Reduce Stage

Facebook jobs spend 25% time in communication![1]

[1] Based on information from full facebook trace used in Aalo. Aalo slides.

CoFlow abstraction

5

Map Stage Shuffle Reduce Stage

CoFlow

CoFlow:

Collection of all flows that share same goal

Implication:

CoFlow finishes when all its flows are over

[2] Hotnets 2012, CoFlow: a networking abstraction for cluster application, Mosharaf Choudhary, Ion Stoica

CoFlow Completion Time (CCT): Completion time of its last flow

6

Reduce Stage Map Stage

Green Job 2 mappers and 2 reducers Orange Job 4 mappers and 2 reducers They share datacenter network Goal: minimize average CoFlow completion time (CCT) of all CoFlows

CoFlow Scheduling Problem

CoFlow 1 CoFlow 2

CoFlow Scheduling Problem

7

• CoFlow scheduling problem
• Minimize average CoFlow Completion Time (CCT)
• CoFlows have 2-dimensions
• Time – Length of individual flows
• Space – Many flows or ports
• CoFlow scheduling problem is NP Hard [3]

[3] M. Chowdhury, Y. Zhong, and I. Stoica. Efficient coflow scheduling with Varys. In SIGCOMM, 2014.

Outline

• Background of Aalo (State-of-the-art CoFlow scheduler)
• Limitations of Aalo
• Design of Saath
• Evaluation

8

Background of Aalo (State-of-the-art CoFlow scheduler)

– Shortest job first for sequential jobs – Online approximation of SJF – Aalo: Online SJF + Spatial dimension (many distributed tasks)

9

Scheduling 101

Shortest-Job-First (SJF): optimal in minimizing average completion time

P3 P2 P1 P1 < P2 < P3

First Last Process Scheduling

10

Outline

• Background of Aalo (State-of-the-art CoFlow scheduler)

– Shortest job first for sequential jobs – Online approximation of SJF – Aalo: Online SJF + Spatial dimension (many distributed tasks)

11

Online Approximation to SJF using Priority queues

12

P3 P2 P3

Q0 Q1 Q2

High Low

Process durations - Unknown P1 P2 P3 Priority queues (Higher Priority = more CPU time)

Shorter processes finish in High priority queues

P2 P2 P1

Outline

• Background of Aalo (State-of-the-art CoFlow scheduler)

– Shortest job first for sequential jobs – Online approximation of SJF – Aalo: Online SJF + Spatial dimension (many distributed tasks)

13

Datacenter Network abstraction: Non-blocking switch

• The entire datacenter fabric is one non-

blocking switch

– Makes analysis simple – Recent works like CONGA[Sigcomm’ 14], VL2 [Sigcomm’09] make the abstraction practical

• Only source of contention are end-hosts
• Implication: The CoFlow scheduling

problem boils down to ordering them at sending hosts/ports

Sender Node-1 Sender Node-2

14

DC Network Receiver Node-1 Receiver Node-2

[4] Sigcomm 2014, CONGA, M. Alizadeh et.al ;[5] Sigcomm 2009, VL2, A Greenberg et.al

C3 C2

Aalo: Online CoFlow Scheduler

Global Co-ordinator Sender Node-1 Sender Node-2

15

A CoFlow has many flows -- How to approximate SJF?

DC Network

• 1. Replicates priority queues at

each node

• 2. A CoFlow moved across priority

queues based on total bytes sent at all its ports

• 3. Different ports send

independently

• 4. Intra-queue: Use FIFO

Receiver Node-1 Receiver Node-2

[6] Sigcomm 2015, Aalo, Choudhary et.al.

C2 C1

Q0 Q1

High Low C2 C3

Q0 Q1

High Low

Outline

• Background of Aalo (State-of-the-art CoFlow scheduler
• Limitations of Aalo
• Design of Saath
• Evaluation

16

Aalo Drawback 1: Out-of-Sync

Global Co-ordinator Sender Node-1 Sender Node-2

17

C2 C3 C2 C1 DC Network

Q0 Q1 Q0 Q1

Ports schedule independent of each other Flows of a CoFlow may get scheduled at different times at different ports

Aalo Drawback 2: Contention Oblivion

18

Contention of a CoFlow – Number of other CoFlows it blocks

Global Co-ordinator Sender Node-1 Sender Node-2 DC Network

Q0 Q1 Q0 Q1

Global Co-ordinator Sender Node-1 Sender Node-2 DC Network C2 C1

Q0 Q1

C2 C3

Q0 Q1

• C1 – 1 – C2
• C2 – 2 – C1 & C3
• C3 – 1 – C2

C2 C3 C2 C1 Average CCT = (2+1+2)/3= 5/3 Average CCT =(1+2+1)/3 = 4/3

Aalo is not taking arrangement of CoFlows across Space into account

19

Outline

• State-of-the-art CoFlow scheduler - Aalo
• Limitations of Aalo
• Design of Saath
• Evaluation

20

Saath: Speeding up CoFlows by exploiting the Spatial Dimension

21

Saath

• Saath is an online scheduler.
• Takes spatial dimension into

account while scheduling CoFlows.

• Spatial dimension: Arrangement
• f flows of CoFlows across ports

22

Saath Key Ideas

• All-or-none
• Least-Contention-First within a queue
• Faster CoFlow-queue transition

23

Key idea 1: All-or-none

• Either schedule all flows of a CoFlow or schedule none.

– Not scheduling a CoFlow for which a subset of flow was being scheduled has no effect on CCT. – By freeing up some ports we potentially improve CCT for others

24

Challenges in All-or-none

25

Time C1 C2 P1 C3 C2 P2 P3 t 2t CCT: C1 = t , C2 = 2t, C3 = C4 = t 3t C1 C3 Time C1 C2 P1 C3 C2 P2 P3 t 2t CCT: C1 = t , C2 = 2t, C3 = C4 = t C3 C1 Saath handles low port utilization by carefully designed work conservation

Key idea 2: Least-Contention-First within a queue

• Contention of a CoFlow – Number of other CoFlows it blocks
• Saath sorts CoFlows in each queue in increasing order of

Contention

• Allows more CoFlows to be scheduled in parallel.

26

27

Key idea 2: Least-Contention-First within a queue

Global Co-ordinator Sender Node-1 Sender Node-2 C2 C3 C2 C1 DC Network

Q0 Q1 Q0 Q1

Global Co-ordinator Sender Node-1 Sender Node-2 C2 C3 C2 C1 DC Network

Q0 Q1 Q0 Q1

Average CCT = (1+2+2)/3 = 5/3 Average CCT = (1+2+1)/3 = 4/3

• C1 – 1 – C2
• C2 – 2 – C1 and C3
• C3 – 1 – C2

Contention of a CoFlow – Number of other CoFlows it blocks

Key idea 3: Faster CoFlow-queue transition

• Both Aalo and Saath use

priority-queue structure to move CoFlows across queues

• Aalo uses total bytes by all

flows

• Saath uses bytes per flow
• Saath has fast transition of

longer CoFlows to lower priority queue

28

Assume queue transition threshold for Aalo is portBandwidth × 4t P2 P3 P4 P1 C2 - Fast transition - Saath

t

P2 P3 P4

2t

P1 Aalo C2 transits Sender Ports

P1 P2 P3

C1 C2 C2 C2

P4

C1 C2 Setup C3 C4

Recap: Saath Scheduling Ideas

• All-or-none
• Least-Contention-First within a queue
• Faster CoFlow-queue transition

29

Outline

• State-of-the-art CoFlow scheduler - Aalo
• Limitations of Aalo
• Design of Saath
• Evaluation

30

Evaluation Methodology

31

• 1. Large scale trace driven simulations
• 2. Large scale testbed evaluation - 150 nodes
• 3. Implemented Saath in 5.2 KLoC in C++

Trace

32

• 1. FB Trace[7]
• 1. Collected from Facebook’s cluster.
• 2. 526 CoFlows, 150 ports
• 2. OSP
• 1. Collected from Microsoft’s cluster.
• 2. Ο(1000) CoFlows, Ο(100) ports

[7] : https://github.com/coflow/coflow-benchmark

33

• Saath approaches offline SEBF
• 1.53x for FB and 1.42x for OSP median speedup as compared to Aalo

Overall CCT improvement

CCT improvement – Design Components

34

• Each design component has considerable contribution in CCT improvement.

Things are In-Sync now

35

• Most of the equal flow coflow now have very small deviation in FCTs

Testbed

36

CCT CCT Speedup 1.88x on Average and 1.43x P50

Scheduling Overhead

37

SAATH Aalo Average P90 Average P90 Global Coordinator CPU % 37.8 42.7 33.5 35.5 Memory(MB) 229 284 267 374 Total time (msec) 0.57 2.85 0.1 0.2 (LCoF/All-or-none) (msec) (0.02/0.24) (0.03/0.7) Local Node CPU % 5.6 5.7 5.5 5.7 Memory(MB) 1.68 1.7 1.75 1.78

Conclusion

• CoFlow sheduling holds promise to optimize communication in Big

Data jobs

• Limitation of prior-art Aalo:

– Ignores spatial arrangement – Has no coordination across ports

• Flows can be out of sync
• CoFlow contention oblivious
• Saath:

– Fuses spatial dimension in CoFlow scheduling – Coordination across ports – Evaluation: CCT improvement: 1.53x (P50) and 4.5x (P90) for FB trace and 1.42x (P50) and 37x (P90)

38

Thank you!
