Evolving technique update: how to avoid the subtle lisfranc: 8 tips in 8 minutes. Michael J Coughlin MD Co-chairman, NFL Foot and Ankle Committee Conflicts None for this talk Consultant with Arthrex, Stryker, Integra Royalties from

slide-1
SLIDE 1

Evolving technique update: how to avoid the subtle lisfranc: 8 tips in 8 minutes. Michael J Coughlin MD

Co-chairman, NFL Foot and Ankle Committee

slide-2
SLIDE 2

Conflicts

  • None for this talk
  • Consultant with Arthrex, Stryker, Integra
  • Royalties from Arthrex, Stryker, Integra,

Erchonia

  • Textbook royalties- Elsevier
slide-3
SLIDE 3

Incidence

  • Uncommon injury
  • 1 in 55,000-60,000 per year
  • 0.2% of fractures
  • 50% incidence of

postraumatic arthritis

  • Missed/delayed diagnosis

can lead to midfoot instability, planovalgus deformity, and early

  • steoarthritis
slide-4
SLIDE 4

Anatomy: Lisfranc Complex Lisfranc

Ligament

  • Intermetarsal base

ligaments exist between 2-5

  • Lisfranc ligament=
  • nly direct

stabilizing feature between base of 1st and 2nd rays

  • Interosseous and

thicker plantarly

slide-5
SLIDE 5

Lisfranc Injury Pattern

  • In the NFL, almost

70% are non-contact injuries

  • Many are not surgical

cases

  • But huge time loss

before RTP

slide-6
SLIDE 6

If you miss these, you aren’t looking very closely!

We are talking about subtle injuries

slide-7
SLIDE 7

Lateral subluxation

Hard to miss!!

slide-8
SLIDE 8

Lisfranc Injury

slide-9
SLIDE 9
slide-10
SLIDE 10

Lisfranc Experimental Conditions

  • 13 limbs, 62

distinct loading events

  • Parameters

Varied: Axial load, Magnitude

  • f twist, Toe

flexion, Boundary at met heads, Axis

  • f twist, Direction
  • f axial force

vector

slide-11
SLIDE 11

Cuneiform Coordinates

Cuneiform

Cuneiform

slide-12
SLIDE 12

Lisfranc Injury Mechanism

slide-13
SLIDE 13
  • Approximately 20% of Lisfranc

injuries can be misdiagnosed or simply missed which can lead to potentially significant sequelae

Myerson et al. Foot Ankle 1986;6:225–42.

Don’t miss this injury: Steps 1-8 not to miss

slide-14
SLIDE 14

#1-Physical Examination

  • Unexplained swelling

http://www.footeducation.com/lisfranc-injury-fracture-midfoot-sprain/

slide-15
SLIDE 15

#2-Physical examination

  • Careful inspection
  • f skin and soft

tissue

  • Plantar ecchymosis

sign

slide-16
SLIDE 16

#3-Physical examination

  • Nothing beats

palpation of the foot

  • Where is the

tenderness?

slide-17
SLIDE 17

#4-Physical Exam

  • Provocative Maneuvers
  • Compression of

midfoot

  • Dorsal and plantar

deviation of the first met

  • Passive pronation

abduction

  • Squeeze 1st/2nd

interspace in coronal plane

Myerson, M, J. Bone Joint Surg., 2008

slide-18
SLIDE 18

The start!!!

  • Listening to the patient
  • And touching (examining)

the patient

slide-19
SLIDE 19

Imaging (5-8)

#5- Your first image

  • Plain radiographs are the

initial evaluation

  • 3 views
slide-20
SLIDE 20

You may see nothing!

slide-21
SLIDE 21

You may see something obvious!

slide-22
SLIDE 22

Subtle subluxation without fracture

wt bearing AP & lateral x-rays and compare to uninjured foot TC

slide-23
SLIDE 23

Subtle subluxation

slide-24
SLIDE 24

Plain Radiographs

  • May be obvious

(large bony Lisfranc fragment)

slide-25
SLIDE 25
  • The fleck sign

– Avulsion of base of 2nd met – Pathognomic for Lisfranc injury – Present in approximately 90% of Lisfranc injuries

May be a subtle fleck sign

slide-26
SLIDE 26

The Normal Foot Alignment

  • Space between 1st

and 2nd MT

  • Medial border of

2nd MT aligns exactly with medial border Middle Cuneiform

  • Medial border of

4th MT aligns with medial border Cuboid

  • Aligned TMT on

lateral views

slide-27
SLIDE 27

Mann's Surgery of the Foot and Ankle, 9th ed., 2014. Chapter 35 Dislocations of the Foot.

No dorsal stepoff

Plantar aspect of medial cuneiform is dorsal to plantar aspect of 5th met

Dorsal stepoff

slide-28
SLIDE 28

Physical Exam-leads you to be suspicious!

slide-29
SLIDE 29

#6 When in doubt Stress Radiographs

  • May be a subtle in

ligamentous Lisfranc

  • B/L Weight bearing

foot on same cassette X-ray to differentiate stable vs unstable sprain – Image

  • ppositesfoot to

compare

  • External rotation

stress X-ray

slide-30
SLIDE 30

#6--Stress Radiographs

slide-31
SLIDE 31

#7-CT scan

  • CT scan

– MRI You may see none of the se fracture patterns on plain radiographs

slide-32
SLIDE 32

#7 Advanced imaging: CT

  • Means to show
  • ccult fractures

and fracture extension into midfoot

  • Means to show

subluxed TMT (<2mm unable to be seen on plain films)

slide-33
SLIDE 33

#7 Advanced imaging: CT

slide-34
SLIDE 34

#7 Advanced imaging: CT

slide-35
SLIDE 35

#7-additional Spect scan

slide-36
SLIDE 36

Normal xray but pain

slide-37
SLIDE 37

Spect scan

slide-38
SLIDE 38

#8 Advanced Imaging MRI

  • Evaluate Lisfranc

ligamentous sprain when X-ray are inconclusive

slide-39
SLIDE 39

#8-MRI-Imaging

  • Radiographics. 2014 Mar-Apr;34(2):514-31. doi: 10.1148/rg.342125215. Evaluation of the tarsometatarsal joint using

conventional radiography, CT, and MR imaging. Siddiqui NA1, Galizia MS, Almusa E, Omar IM.

slide-40
SLIDE 40

Treatment Options

  • CRIF, ORIF, bridge plating
  • Arthrodesis
slide-41
SLIDE 41

Open Reduction with Internal Fixation

slide-42
SLIDE 42

Primary Arthrodesis

slide-43
SLIDE 43

Steps 1-4

(physical examination)

  • 1.Unexplained midfoot swelling
  • 2.Plantar ecchymoses
  • 3.Midfoot tenderness on palpation
  • 4.Provocative moves
slide-44
SLIDE 44

Steps 5-8

(imaging)

  • 5.Plain radiographs
  • 6.Stress radiographs
  • 7.CT/ spect imaging
  • 8.MRI
slide-45
SLIDE 45

References

1. Gilgenkrantz, Simone (2006). "[The Baron Guillaume Dupuytren]". Med Sci (Paris) 22 (8–9): 771–2. doi:10.1051/medsci/20062289771 2. Fischer, LP. Hist Sci Med. 2005 Jan-Mar;39(1):17-34. [Jacques Lisfranc de Saint-Martin (1787-1847)]. 3. Mann's Surgery of the Foot and Ankle, 9th ed., 2014. Chapter 35 Dislocations of the Foot. 4. Fractures and Dislocations of the Midfoot: Lisfranc and Chopart Injuries. An Instructional Course Lecture, American Academy of Orthopaedic Surgeons. Stephen K. Benirschke, MD, Eric Meinberg, MD, Sarah A. Anderson, MD, Clifford B. Jones, MD, and Peter A. Cole, MD. JBJS VOLUME 94-A d NUMBER 14 d JULY 18, 2012 5. Netter's Concise Orthopaedic Anatomy, 2nd ed., 2010. Chapter 10, Foot/Ankle 6. de Palma L, Santucci A, Sabetta SP, Rapali S: Anatomy of the Lisfranc joint complex. Foot Ankle Int 18:356-364, 1997. 7. Wiley JJ: The mechanism of tarso-metatarsal joint injuries. J Bone Joint Surg Br 53:474-482, 1971 8.

  • Radiographics. 2014 Mar-Apr;34(2):514-31. doi: 10.1148/rg.342125215. Evaluation of the tarsometatarsal joint

using conventional radiography, CT, and MR imaging. Siddiqui NA1, Galizia MS, Almusa E, Omar IM. 9. Aitken, A, Poulson, D. Dislocations of the Tarsometatarsal joint. JBJS Vol 45-A, 263. 1963 10. Fracture Dislocations of the Tarsometatarsal Joints: End Results Correlated with Pathology and Treatment Mark

  • S. Myerson, Robert T. Fisher, Andrew R. Burgess, and John E. Kenzora. Foot Ankle Int, April 1986; vol. 6, 5: pp.

225-242. 11. http://www.braceability.com/conditions/foot-orthotics/lisfranc-fracture-treatment 12. http://heelpadavulsion.blogspot.ch/2012/03/major-crush-injury-foot-with-heel-pad.html 13. J Orthop Trauma. 1996;10(2):119-22. Plantar ecchymosis sign: a clinical aid to diagnosis of occult Lisfranc tarsometatarsal injuries. Ross G1, Cronin R, Hauzenblas J, Juliano P. 14. Peicha G, Labovitz J, Seibert FJ, et al.The anat- omy of the joint as a risk factor for Lisfranc dislo- cation and fracture-dislocation: an anatomical and radiological case control study. J Bone Joint Surg Br 2002;84(7):981–985. 15. Watson TS, Shurnas PS, Denker J. Treatment of Lisfranc joint injury: current concepts. J Am Acad Orthop Surg 2010;18(12):718–728. 16. Kuo RS, Tejwani NC, Digiovanni CW, et al. Out- come after open reduction and internal fixation of Lisfranc joint

  • injuries. J Bone Joint Surg Am 2000; 82(11):1609–1618.
