SLIDE 1

Machine Intelligence Modern Infrastructure

http://mi2.live

Everything you want to know about Istio

SLIDE 2

What is MI2?

MI2 Webinars focus on the convergence of machine intelligence and modern infrastructure. Every alternate week, I deliver informative and insightful sessions covering cutting-edge technologies. Each webinar is complemented by a tutorial, code snippets, and a video. MI2 strives to be an independent and neutral platform for exploring emerging technologies.

SLIDE 3

Objectives

Overview of service mesh
Motivation to use Istio
Istio architecture
Demo
Summary

SLIDE 4

Challenges with Microservices

Based on polyglot development
Highly distributed
Difficult to debug
Hard to implement logging and tracing
Dynamic scale-in and scale-out
Disparate protocols
Implements internal and external load balancers

SLIDE 5

Challenges involved with Microservices

Service A Service B Service C Service D

External Service

Agent Agent Agent Agent

Python Java C# Ruby H T T P HTTP/2 gRPC GraphQL L7 L4

Central Monitoring Service

SLIDE 6

What is a Service Mesh?

Plugs itself into the intra-service communication
Intercepts east-west (even north-south) traffic
Captures telemetry related to services and traffic
Adds an implicit security layer
Enables service discovery
Implements policy-driven routing and traffic management
Interfaces well with legacy and modern infrastructure

SLIDE 7

Why Service Mesh?

Out of process architecture
Clean separation of data plane and control plane
Support internal and external load balancing (L3/L4/L7)
Consistent Service discovery
Extensible protocol support
Advanced health checks
Real-time monitoring, logging, tracing
Best practices of distributed computing

SLIDE 8

Service Mesh – Control Plane vs Data Plane

Service A Service B Service C Service D

External Service

Proxy Proxy Proxy Proxy

Python Java C# Ruby H T T P HTTP/2 gRPC GraphQL L7 L4

Control Plane

SLIDE 9

What is Istio?

Connect
Intelligent traffic routing and flow
Secure
Managed authentication, encryption
Control
Enforce policy-driven communication across services
Observe
Automatic tracing, monitoring, and logging

SLIDE 10

Istio – Control Plane vs. Data Plane

Service A Service B Service C Service D

External Service

Proxy Proxy Proxy Proxy

Python Java C# Ruby H T T P HTTP/2 gRPC GraphQL L7 L4

Istio Control Plane

SLIDE 11

Microservice 1 Microservice 2 Proxy Proxy

Istio Control Plane Observability Network Management Service Discovery Policy Definition

Istio Building Blocks

SLIDE 12

Istio Architecture

SLIDE 13 Pilot: Control plane to configure and push service communication policies. Envoy: Network proxy to intercept communication and apply policies. Mixer: Policy enforcement with a flexible plugin model for providers for a policy. Citadel: Service-to-service auth[n,z] using mutual TLS, with built-in identity and credential management. Galley: Configuration validation, distribution Control Plane API Mixer Service A Service B proxy proxy HTTP/1.1, HTTP/2, gRPC or TCP -- with or without mTLS Pilot Citadel Config data to Envoys TLS certs to Envoys Policy checks, telemetry Galley

Istio Architecture

SLIDE 14

Key Concepts of Istio Traffic Management

VirtualService defines the rules that control how requests for a service are routed

within an Istio service mesh.

DestinationRule configures the set of policies to be applied to a request after

VirtualService routing has occurred.

ServiceEntry is commonly used to enable requests to services outside of an Istio

service mesh.

Gateway configures a load balancer for HTTP/TCP traffic operating at the edge of

the mesh, most commonly to enable ingress traffic for an application.

Sidecar configures one or more sidecar proxies attached to application workloads

running inside the mesh.

SLIDE 15

Istio Telemetry

Metrics
Logs
Tracing
Visualization

SLIDE 16

What are we deploying?

SLIDE 17

DEMO

Installing Istio
Configuring Traffic Rules
Visualizing Telemetry

SLIDE 18

Summary

Automatic load balancing for HTTP, gRPC, WebSocket, and TCP traffic
Fine-grained control of traffic behavior with rich routing rules, retries, failovers, and fault

injection

A pluggable policy layer and configuration API supporting access controls, rate limits

and quotas

Automatic metrics, logs, and traces for all traffic within a cluster, including cluster

ingress and egress

Secure service-to-service communication in a cluster with strong identity-based

authentication and authorization

SLIDE 19

MI2 Sponsors

SLIDE 20

Next Webinar

Ru Running nning Appl pplica icatio ions ns at the Edge ge wit ith AWS Gr Greengr ngrass ss

AWS IoT Greengrass is software that lets you run local compute, messaging, data caching, sync, and ML inference capabilities on connected devices in a secure way. With AWS IoT Greengrass, connected devices can run AWS Lambda functions, execute predictions based on machine learning models, keep device data in sync, and communicate with other devices. This session will cover the fundamentals of AWS Greengrass.

Thursday, May 16th, 2019 9:00 AM PST / 9:30 PM IST
