SLIDE 1

Evaluation of Knee Injuries

  • Dr. Alan A. Zakaria, D.O., M.S.

1080 Kirts Blvd., Suite 400 Troy, Mi., 48084 Team Physician United States Soccer Federation University of Michigan Men’s and Women’s Soccer

slide-2
SLIDE 2

Objective

Identify main anatomic components of the knee Perform basic knee exam along with special tests Identify common knee injury patterns and their physical exam findings.

slide-3
SLIDE 3

Anatomy

  • Bony Anatomy
  • Ligaments
  • Cartilage
  • Musculature
  • Other Soft Tissue
slide-4
SLIDE 4

Knee Anatomy

Two functional joints

– Femorotibial – Femoropatellar

Femoral condyles

– Flex/extend

slide-5
SLIDE 5

Knee Anatomy

Patella

– Sesamoid with two concave surfaces and vertical ridge – Increases efficiency of extension

slide-6
SLIDE 6

Knee Anatomy: Anterior Cruciate Ligament (ACL)

Run inferior, anterior, and medially Arises from medial aspect lateral femoral condyle Insert lateral to medial tibial eminence Restrains anterior subluxation of tibia on femur

slide-7
SLIDE 7

Knee Anatomy: Posterior Cruciate Ligament (PCL)

Arises from the posterior intercondylar area of the tibia Inserts at the medial condyle of the femur Restrains posterior subluxation of the tibia on the femur

slide-8
SLIDE 8

Knee Anatomy: Medial Collateral Ligament (MCL)

Postero-superior medial femoral condyle to proximal end of tibia Maximum tension at full extension Restraint to valgus stress

slide-9
SLIDE 9

Knee Anatomy: Lateral Collateral Ligament (LCL)

Posterosuperior lateral femoral condyle to lateral head of fibula Restraint to varus stress

slide-10
SLIDE 10

Knee Anatomy: Meniscus

Load bearing, joint stability, shock absorption Peripheral third vascularized

slide-11
SLIDE 11

Knee Anatomy: Articular Cartilage

Hyaline cartilage that covers the femoral condyles, tibial plateau, and undersurface of the patella Shock absorbing structure that can withstand compression, tension, and shearing forces and dissipate load

slide-12
SLIDE 12

Knee Anatomy: Muscles

Quadriceps Hamstrings Iliotibial tract Pes Anserine

slide-13
SLIDE 13
slide-14
SLIDE 14

Knee Anatomy: Pes Anserine

Composed of the conjoined tendons of the semitendinosus, gracilis, and sartorius muscles Inserts onto the anteromedial proximal tibial bone

slide-15
SLIDE 15

Knee Anatomy: Patellar and Pes Anserine Bursa

Synovial fluid-filled sacs that provide a cushion between bones and tendons and/or muscles around a joint Prepatellar bursa located superior to the patella

slide-16
SLIDE 16

Patient History.

  • Nature of symptoms
  • Location
  • Timing/Duration
  • Quality and Quantity
  • Trauma or preceding

event

  • Exacerbating or

relieving factors

  • Past History
  • Age
  • Occupation or

recreational activities

  • Clicking or popping
  • Locking or catching
  • Giving Way
  • Swelling
slide-17
SLIDE 17

Physical Exam

  • Observation
  • Range of Motion
  • Palpation
  • Strength Testing
  • Special Testing
slide-18
SLIDE 18

Observation

Anterior view standing

  • Genu valgum/varum, patella position, foot architecture

Posterior view standing

  • Genu valgum/varum, foot architecture

Anterior and lateral views sitting

  • Patella position/tracking, osgood schlatter’s changes

Gait

  • General changes, motion of patella, foot architecture
slide-19
SLIDE 19
slide-20
SLIDE 20

Palpation

Anterior with knee extended

  • Swelling or effusion
  • Prepatellar bursa, patellar

tendon, plica

  • Quad and tendon
  • Pes Anserine

Lateral

  • Lateral meniscus
  • LCL
  • IT Band

Medial

  • Medial meniscus
  • Medial collateral ligament
  • Pes Anserine

Posterior

  • Hamstrings
  • Gastrocnemius
  • Popliteal fossa
  • Baker’s Cyst
slide-21
SLIDE 21

Range of Motion

  • Flexion – 135 -140 degrees
  • Extension – 0 degrees
slide-22
SLIDE 22

Strength Testing (5 point scale)

Flexion

  • Hamstring
  • Gracilis, sartorius
  • Popliteus
  • Gastrocnemius

Extension

  • Quadriceps
  • Tensor Fasciae Latae
slide-23
SLIDE 23

Collateral Ligaments

MCL

  • Valgus stress at 0

and 30 degrees LCL

  • Varus stress at 0 and

30 degrees

slide-24
SLIDE 24

ACL

  • Lachman
  • Anterior Drawer
  • Pivot Shift
slide-25
SLIDE 25

PCL

  • Posterior Sag
  • Posterior Drawer
slide-26
SLIDE 26

Meniscus

  • McMurray
  • Apley’s
  • Bounce Home
slide-27
SLIDE 27

Patellofemoral

  • Active patellar

grind/crepitus

  • Apprehension/hyper

mobility

slide-28
SLIDE 28

Others

Ober’s Test

slide-29
SLIDE 29

Diagnostic Imaging

X-rays:

  • AP
  • Lateral
  • Sunrise
  • Notch
  • Weight bearing
slide-30
SLIDE 30

Diagnostic Imaging

  • CT – More detailed bony evaluation
  • MRI – More detailed bony evaluation and

good evaluation of soft tissue structures

  • Ultrasound – Good, detailed evaluation of

more superficial soft tissue structures

slide-31
SLIDE 31

Summary

Knee Anatomy Basic physical exam Special tests

slide-32
SLIDE 32

Thank You!
