Evaluating BFT Protocols for Spire

Henry Schuh & Sam Beckley

600.667 Advanced Distributed Systems & Networks

• SCADA & Spire Overview
• High-Performance, Scalable Spire
• Trusted Platform Module
• Known Network Characteristics
• Evaluating BFT-SMART
• Benchmarking Results
• Conclusions

Power Grid Overview

SCADA Overview

SCADA Requirements

• Must have very low latencies

(100-200ms)

• Must have very high reliability
• Must be able to run for decades

SCADA Adopting IP & Internet

• In the past SCADA used proprietary

protocols on air gapped systems

• Now moving to both IP & the Internet

to reduce costs

“These devices were not only internet facing, they did not have
 security mechanisms to prevent unauthorized access”

• Trend Micro Incorporated, Who’s Really Attacking Your ICS Systems

Attacks on SCADA Systems

28 Days: 39 Attacks
 All targeted specifically at SCADA systems

 The first attack was within 18 hours of the honeypot going live

Source: Trend Micro Incorporated, Who’s Really Attacking Your ICS Systems

Distributed Replication

• Several machines that coordinate their

actions such that they appear to be a single unified machine to a client.

 Pros: High Availability and Performance
 Cons: Cost of Synchronization

Intrusion Tolerant Replication

Somewhat Formally: The ability to make progress in the presence of some number of malicious replicas with guaranteed

• correctness. Some protocols also guarantee a level
• f performance under attack.


 Informally: If some of the replicas get hacked the system still works.

Defense Across Space & Time

Defense Across Time: Have to periodically regain control of a compromised machine to stop the attacker from eventually gaining control of the entire network. Defense Across Space: Every replica must present a unique attack surface so that one attack cannot be used to compromise every replica.

• SCADA & Spire Overview
• High-Performance, Scalable Spire
• Trusted Platform Module
• Known Network Characteristics
• Evaluating BFT-SMART
• Benchmarking Results
• Conclusions

Spire

Open Source SCADA system that provides both standard crypto defense mechanisms as well as an intrusion tolerant SCADA Master. Spire uses several different technologies

• Prime
• Spines
• PVBrowser

Spire

SCADA Master Prime pvbrowser HMI SCADA Master Prime SCADA Master Prime SCADA Master Prime RTU / PLC Proxy RTU

External Spines Network Internal Spines Network

RTU / PLC Proxy PLC

Scaling Spire

In order to tolerate more intrusions we need more replicas The more replicas, the higher the latency becomes We rely on having very low latency

Our Mission

Find a way to make Spire more scalable, to allow for more replicas, and thus more intrusions

3 Angles of Attack

Trusted Hardware - using a TPM Taking Advantage of Known Network Characteristics Hierarchy of Protocols

• SCADA & Spire Overview
• High-Performance, Scalable Spire
• Trusted Platform Module
• Known Network Characteristics
• Evaluating BFT-SMART
• Benchmarking Results
• Conclusions

Trusted Platform Module

Specialized chip that holds a secret key and can perform cryptographic functions for the rest of the machine The key never leaves the TPM

Too slow :’(

• SCADA & Spire Overview
• High-Performance, Scalable Spire
• Trusted Platform Module
• Known Network Characteristics
• Evaluating BFT-SMART
• Benchmarking Results
• Conclusions

Leverage Network Characteristics

SCADA deployments are static and predictable Most importantly, we know:

• Geographically close - low latency

communication

• Consistent number of clients and messaging

pattern

The Three BFT Protocol Families

PBFT Spinning Prime

PBFT

PBFT Spinning Prime

PBFT

When the leader fails we must perform a “view change” This is by far the most expensive operation in PBFT

 “[The view change] is the Achilles Heel”

• Yair Amir

Spinning

Every ordering is done by a different leader A bad leader can delay exactly one ordering before it is evicted from the protocol

Prime

Designed to remove load from the leader to allow for many clients without performance degradation Performs one ordering every X milliseconds

Prime

• SCADA & Spire Overview
• High-Performance, Scalable Spire
• Trusted Platform Module
• Known Network Characteristics
• Evaluating BFT-SMART
• Benchmarking Results
• Conclusions

BFT-SMART

• Implements “Yet Another Visit to Paxos” protocol


(IBM Zurich) in Java

• Modular, multi-threaded server replicas
• Standard BFT message pattern
• Modern protocol with ongoing development

Multithreaded Design

Request Thread 1 Leader Thread Request Timer Thread Message Processor Thread Receiver Thread 1 Receiver Thread n-1 Reply Thread Service Replica

Client Request Server Reply

Sender Thread 1 Sender Thread n-1

Server Consensus Communication

… …

(primary) 1 2 3 Pre-Prepare Malicious Delay

BFT-SMART and Performance Attacks

• Consensus relies on leader to order messages
• A malicious leader could delay progress
• Timeouts limit the leader’s worst-cast performance

Leader Client Replica 1 Replica 2 Replica 3 Propose (Pre-Prepare)

Malicious Delay

• SCADA & Spire Overview
• High-Performance, Scalable Spire
• Trusted Platform Module
• Known Network Characteristics
• Evaluating BFT-SMART
• Benchmarking Results
• Conclusions

Simulating a SCADA Network

WAS JHU NYC

SVG

3 replicas per site n = 12 f = 3

3ms 3ms 4ms 2ms 2ms 4ms

Normal-Case Latency

5 10 15 20 25 30 35 40 45 10 20 30 40 50 60 70 80 90 100 Mean Latency (ms) Number of Clients

Me Mean Latency vs. Number of Clients

BFT-SMART Prime

Normal-Case Latency

• Significantly lower with BFT-SMART, but

increasing with number of clients

• Matches expectations given fewer

consensus rounds

• Constant with Prime, due to batch
• rdering on a preset interval of 20ms

Performance Attack Latency

• Tested 4 timeouts, chosen based on normal performance
• 1. 8ms (aggressive)
• 2. 10ms (conservative)

Performance Attack Latency

• Tested 4 timeouts, chosen based on normal performance
• 1. 8ms (aggressive)
• 2. 10ms (conservative)
• 3. 16ms (aggressive, forwarding request at 8ms)
• 4. 20ms (conservative, forwarding request at 10ms)

Performance Attack Latency

• Developed a malicious replica to delay

sending pre-prepare messages as leader

• Experimentally maximized delay up to

each view change timeout

• Measured worst-case latency seen by

client under this condition

Performance Attack Latency

5 10 15 20 25 30 35 5 7 9 11 13 15 17 19 21 23 Mean Worst-Case Latency (ms) Pre-Prepare Timeout (ms)

Me Measured Latency vs. Timeout

Worst-Case Latency Normal Latency

Performance Attack Latency

• With a tight timeout, performance degradation is

minimal

• With a conservative timeout, performance degradation

approaches 50% (26ms latency)

• In either case, lower than normal-case Prime and exceeds

the required performance

• This performance attack would not pose a risk to the

SCADA system

View Change

• 50-70ms depending on number of pending requests
• Slow due to unoptimized serialization, data structures, taking up

to 40ms

• Sequential view changes are an issue with multiple faulty replicas
• With f ≥ 3, view change must be improved to meet the

200ms requirement

• Prime view changes are on the order of 60-90ms

Scalability Overhead

100 200 300 400 500 600 5 10 15 20 25 La Latency (µs) Nu Number of replicas (n)

LA LAN La Latency vs. Number of Replicas

Scalability Overhead

• Shows the computational overhead of increasing n
• Latency appears linear with n, and grows at a

reasonable rate

• Actual latency determined by location of added

replicas

• Another geographic site vs. more replicas


per site

• SCADA & Spire Overview
• High-Performance, Scalable Spire
• Trusted Platform Module
• Known Network Characteristics
• Evaluating BFT-SMART
• Benchmarking Results
• Conclusions

BFT-SMART: Pros & Cons

PROS

• Lightweight protocol & implementation
• Possible to apply aggressive timeout
• Low normal-case latency
• Support for dynamic state transfer, reconfiguration/recovery

CONS

• Latency increases with number of clients, concurrent requests
• High view change cost
• Java implementation

Prime: Pros & Cons

PROS

• Leader is not burdened by client requests
• Bounded performance guarantee under attack
• Latency remains constant as number of clients increases
• Measurements performed so replicas can adapt to network conditions

CONS

• 2 more consensus rounds per ordering
• High view change cost
• Significantly higher normal-case latency

Conclusions

• Strict limit on performance attacks possible with a

lightweight protocol and bounded network latencies

• View change still a high cost, but could be
• ptimized
• A viable path to scaling Spire
• However, BFT-SMART introduces some new issues

Conclusions: BFT-SMART

• BFT-SMART is a good implementation, but

not exactly what we need

• Very good proof of concept that something

with weaker guarantees than Prime could

• utperform Prime in this specific context

using known network characteristics

Conclusions: Prime

• We want some of the features Prime has,

specifically, network measurements and batching.

• We can live without Prime’s expensive offloading
• f the leader - we can assume that the computers

can do the intended job fast enough (need to measure how long it takes for a full update compared with how long it takes for immediate response in Prime).

Next Steps

• Consider diversity and client-server

communication

• Interface with the Spines and SCADA

hardware

• Or, apply this approach to something

new?

Thank You

• To Yair, Tom, Amy and Trevor
• To the class
• To Alysson Bessani and the


BFT-SMART group
