Ev Evolutionary Computation plus Dynamic Pr Programming for the Bi-Ob Objec ective e Travel elling Thie Th ief f Proble lem Junhua Wu, Sergey Polyakovskiy, Markus Wagner, Frank Neumann Frank.Neumann@Adelaide.edu.au Project page:

slide-1
SLIDE 1

Ev Evolutionary Computation plus Dynamic Pr Programming for the Bi-Ob Objec ective e Travel elling Th Thie ief f Proble lem

Junhua Wu, Sergey Polyakovskiy, Markus Wagner, Frank Neumann Frank.Neumann@Adelaide.edu.au Project page: https://cs.adelaide.edu.au/~optlog/research/ttp.php Or google “travelling thief Adelaide” Tuesday, July 17, 10:40-12:20, Conference Room D (3F)

slide-2
SLIDE 2
slide-3
SLIDE 3

Composed of the merging of the Traveling Salesman Problem and the Knapsack Problem

1 3 4 2 5 8 7 6

The Travelling Thief Problem (TTP)

slide-4
SLIDE 4

Composed of the merging of the Traveling Salesman Problem and the Knapsack Problem

1 3 4 2 5 8 7 6

The Travelling Thief Problem (TTP)

slide-5
SLIDE 5

The Travelling Thief Problem (TTP)

Composed of the merging of the Traveling Salesman Problem and the Knapsack Problem

1 3 4 2 5 8 7 6

1 2 5

17

8 10 11 13 14 15 7 9 3 4 6 12

Knapsack

16

slide-6
SLIDE 6

The Travelling Thief Problem (TTP)

Composed of the merging of the Traveling Salesman Problem and the Knapsack Problem

1 3 4 2 5 8 7 6

2 5

17

6 8 10 11 12 13 14 15 7 9 3 4 1 2 5

14

7

Knapsack

1 16

slide-7
SLIDE 7

THE TRAVELING THIEF PROBLEM (TTP)

Goal: Visit each city exactly once, maximising the total profit 𝑄 such that the total weight does not exceed the knapsack capacity 𝑋, where 𝑄 is defined as: 𝑄 = $

%&' (

𝑞% 𝑦% − 𝑆 $

%&'

  • 𝑢%,%0'

where 𝑦% = 1 0 depending on whether the item 𝑗 is picked 1 or not 0 , and 𝑢%,4 is defined as: 𝑢%,4 = 𝑒(Π%, Π4) 𝑤(:; − 𝑋

<=

𝑤(:; − 𝑤(%- 𝑋 where Π% is the city at tour position 𝑗 in tour Π, and 𝑋

<= is the

current weight of the knapsack at city Π%.

slide-8
SLIDE 8

The Bi-Objective TTP

a natural extension: maximise the reward for a given weight of collected items, or determine the least weight subject to bounds imposed on the reward

  • Objective one: profit P as defined before
  • Objective two: total accumulated weight
slide-9
SLIDE 9

Packing-While-Travelling (PWT)

  • …
slide-10
SLIDE 10

Weight Total Reward

ρ1->(z1, w1, ) ρ1->(z2, w2) ρ1->(z3, w3) ρ1->(z4, w4) ρ1->(z5, w5) π1

slide-11
SLIDE 11

Weight Total Reward

(z1, w1) (z2, w2) (z3, w3) (z4, w4) (z5, w5) (π1, ρ1) (π2, ρ2) (π3, ρ3) (π4, ρ4) (π5, ρ5)

(the “natural” approach would be the following)

slide-12
SLIDE 12

Solving the Bi-Obj. TTP

  • Many single-objective TTP heuristics take a good

TSP tour as a starting point. What does this mean here?

  • TSP solvers; CONCORDE (CON), ACO, LKH and LKH2

1000 2000 3000 4000

Weight

  • 5000

5000

Total Reward Max reward:4791.466 Corresponding tour length:586

eil76_n75_uncorr_01.ttp, inver over

  • 2000

2000 4000 6000 8000 10000

Total Reward

ACO_Bounded01 CON_Bounded01 INV_Bounded01 LKH_Bounded01 LKH2_Bounded01 ACO_Bounded06 CON_Bounded06 INV_Bounded06 LKH_Bounded06 LKH2_Bounded06 ACO_SimilarWeights01 CON_SimilarWeights01 INV_SimilarWeights01 LKH_SimilarWeights01 LKH2_SimilarWeights01 ACO_SimilarWeights06 CON_SimilarWeights06 INV_SimilarWeights06 LKH_SimilarWeights06 LKH2_SimilarWeights06 ACO_Uncorrelated01 CON_Uncorrelated01 INV_Uncorrelated01 LKH_Uncorrelated01 LKH2_Uncorrelated01 ACO_Uncorrelated06 CON_Uncorrelated06 INV_Uncorrelated06 LKH_Uncorrelated06 LKH2_Uncorrelated06

slide-13
SLIDE 13
slide-14
SLIDE 14

Indicators

Def 3.2: Given q different DP fronts, let 𝜚 denote a set of possible unique solution points derived by 𝜐1.. 𝜐q. Then 𝜕 is a Pareto front formed by the points of 𝜚 and 𝜕 is named as the surface of 𝜚. Given a tour 𝜐𝜌, and its corresponding solution set T𝜌:

  • Surface Contribution: number of objective vectors

contributed by T𝜌

  • Hypervolume: volume covered by T𝜌 w.r.t (0,C)
  • Loss of Contribution:
slide-15
SLIDE 15

Parent Selection Mechanisms

  • Rank-Based Selection (RBS), Fitness-Proportionate

Selection (FPS), Tournament Selection (TS), Arbitrary Selection (AS), Uniformly-at-Random Selection (UAR)

Crossover and Mutation Operators

  • TSP-only: multi-point crossover, 2-opt mutation,

jump

slide-16
SLIDE 16

Experimental Study

  • 2 indicators X 8 parent selection strategies
  • TTP instances from the classes eil51, eil76, eil101;

three knapsack types Assessment

  • 30 repetitions, Welch’s t-test with UAR as a

baseline (like the Student's t-test, but more reliable when the two samples have unequal variances and unequal sample sizes)

slide-17
SLIDE 17

5 10 15 20 25 AS-BST AS-EXT FPS RBS-EXP RBS-HAR RBS-IQ TS Bounded SimilarWeights Uncorrelated 5 10 15 20 25 30 AS-BST AS-EXT FPS RBS-EXP RBS-HAR RBS-IQ TS Bounded SimilarWeights Uncorrelated 5 10 15 20 25 30 AS-BST AS-EXT FPS RBS-EXP RBS-HAR RBS-IQ TS Bounded SimilarWeights Uncorrelated 5 10 15 20 25 AS-BST AS-EXT FPS RBS-EXP RBS-HAR RBS-IQ TS Bounded SimilarWeights Uncorrelated

animation with “appear”

Loss Surface Contribution Loss Hypervolume

hypervolume hypervolume total reward total reward Note: bars are sums of log-scaled p-values

slide-18
SLIDE 18

Comparison of bi-obj. approaches with single-

  • bjective MA2B

MA2B by El Yafrani and Ahiod [GECCO’16] Fitness-Proportionate Selection Loss of Hypervolume Loss of Surface Contribution

slide-19
SLIDE 19

Summary

  • Bi-Objective TTP: profit vs. weight
  • Dynamic programming provides provably optimal

trade-off fronts for a given tour

  • Indicator-based EA with a population of tours: with

”loss of surface contribution” and “loss of hypervolume”

  • Best bi-objective approaches beat single-objective

state-of-the-art
