ESCAPE: An Adaptive Framework for Managing and Providing Context Information in Emergency Situations Hong-Linh Truong, Lukasz Juszczyk, Atif Manzoor, Schahram Dustdar Distributed Systems Group, Vienna University of Technology


slide-1
SLIDE 1

1

ESCAPE: An Adaptive Framework for Managing and Providing Context Information in Emergency Situations

Hong-Linh Truong, Lukasz Juszczyk, Atif Manzoor, Schahram Dustdar Distributed Systems Group, Vienna University of Technology truong@infosys.tuwien.ac.at http://www.vitalab.tuwien.ac.at/autocompwiki

W O K R P A D

slide-2
SLIDE 2

23rd Oct 2007 EuroSSC 07, Kendal, UK 2

Outline

Scenario, requirements and motivation Approach Levels of context information ESCAPE framework overview Implementation status Experiments and current applications Conclusion and future work

slide-3
SLIDE 3

23rd Oct 2007 EuroSSC 07, Kendal, UK 3

Scenario

Emergency situations

E.g., Natural disasters (earthquakes, hurricanes, floods)

Multiple support teams

Established on demand Deployed at front-end (disaster fields) and back-end sites Conduct various processes to respond to the emergency situation

Collecting information, performing relief tasks, etc.

How to achieve effective response processes?

slide-4
SLIDE 4

23rd Oct 2007 EuroSSC 07, Kendal, UK 4

Requirements and Motivation

Response processes to emergency situations, such as natural disasters:

Established on demand and changed rapidly, depending context

  • f the situations

context information associated with entities inherent in the situation is critical to effective response processes Context information in emergency situation is complex

Reflects situation, responses, sites, teams and individuals Related to people, resources and services, their status and activities.

slide-5
SLIDE 5

23rd Oct 2007 EuroSSC 07, Kendal, UK 5

Requirements and motivation(cont.) Many context management frameworks exist

Mostly for normal environments, domotics, HCI for emergencies,lack of integration with crisis management systems

Some scientific and engineering issues: how to

Support multiple teams collaborating in pervasive Grid environments Make context information available to many crisis management supporting tools and services Ensure that context information in emergency situations are extensible and interoperable Runtime interpretation and engineering of context info

slide-6
SLIDE 6

23rd Oct 2007 EuroSSC 07, Kendal, UK 6

Our Approach

Integration with other tools/services

SOAP-based and REST (Representational State Transfer)- based models Different techniques for front-end and back-end integration

Extensible context information representations

Support XML-based context information Accept any representations as long as the information is in XML

Flexibility in pervasive environments

Customizable software components

Tracing capability

Context provenance This paper focuses on middleware aspects

slide-7
SLIDE 7

23rd Oct 2007 EuroSSC 07, Kendal, UK 7

Levels of Context Information in Emergency Situation

Situation Response Site Team Individual Individual Individual Response Earthquake Recover railways systems Team OEBB Salzburg

slide-8
SLIDE 8

23rd Oct 2007 EuroSSC 07, Kendal, UK 8

ESCAPE Framework Overview

  • SOAP-based communication
  • Mobile adhoc network

REST-based communication XML-based context information

slide-9
SLIDE 9

23rd Oct 2007 EuroSSC 07, Kendal, UK 9

ESCAPE Framework Overview

Context information is application-specific The middleware accepts any XML-based context information

Team member discovery Plugin internal software sensors XPath/XQuery requests

slide-10
SLIDE 10

23rd Oct 2007 EuroSSC 07, Kendal, UK 10

Query/Subscription and Storage Query and Subscription APIs

Core APIs support requests based on XPath/XQuery Application-specific query and subscription APIs built atop core APIs

Lightweight Data Storage

High-end devices: eXist database with XQuery, XUpdate, etc. PDAs: round-robin model in which XML data is stored in files

slide-11
SLIDE 11

23rd Oct 2007 EuroSSC 07, Kendal, UK 11

Management of Context Information

Stored at the front-end in team devices

Individual Site Response Situation Team

Stored at back- end systems

Data aggregration flows

Aggregration without knowing content of context information

Pull and push manner XPath/XQuery-based filters

Aggregation of snapshots of context information in [ti, tj]

Level

slide-12
SLIDE 12

23rd Oct 2007 EuroSSC 07, Kendal, UK 12

Context Provenance Support For supporting tracing capability Types of context provenance information

Application-specific information Middleware-specific information

ESCAPE supports middleware-specific context provenance Storing provenance information into the back-end system

slide-13
SLIDE 13

23rd Oct 2007 EuroSSC 07, Kendal, UK 13

Implementation Status

Web services

kSOAP for handling SOAP-based Web services, between CIMSs REST model between CIMS and SCIMS

XPath/XQuery/XUpdate for querying and updating information Hosting environments:

At the front-end: normal laptops and PDAs At the back-end: SMP machines

slide-14
SLIDE 14

23rd Oct 2007 EuroSSC 07, Kendal, UK 14

Experiments: WORKPAD context information model

slide-15
SLIDE 15

23rd Oct 2007 EuroSSC 07, Kendal, UK 15

Experiments – Performance Tests

  • Devices
  • 3 iPAQ 6915 PDAs (Intel PXA 270 416 Mhz, 64 RAM, Windows CE 5.0, 2GB external

miniSD, IBM J9

  • Dell XPS M1210 (Intel Centrino Duo Core 1.83 Ghz, 2GB RAM, Windows XP)
  • Dell D620 (Intel Core 2 Duo 2Ghz, 2GB RAM, Debian Linux
  • Dell Blade (2 Xeon 3.2 Ghz CPUs with hyperthreading, 2GB RAM, Ubuntu Linux)
  • Network
  • Mobile adhoc: setting 220Kbits/s (150Kbits/s, observed)
  • 100 MB/s to back-end
  • Two modes
  • Single team and multiple team leaders
slide-16
SLIDE 16

23rd Oct 2007 EuroSSC 07, Kendal, UK 16

Experiments: Performance Tests

  • Single data transfer between a

CIMS member (PDA) and CIMS team leader (Laptop)

  • Concurrent data transfers

between a CIMS (PDA) and its client (Laptop)

PDA is not suitable for team leader‘s device due to performance reasons

slide-17
SLIDE 17

23rd Oct 2007 EuroSSC 07, Kendal, UK 17

Experiments: Performance Tests

  • Performance of transferring data to the back-end system

~17KB, every 5 seconds High variation between different runs in PDAs

190 ms – 5170 ms

Should not update an XML document in the back-end with small documents

Store small XML documents and use back-end high capability to process information

slide-18
SLIDE 18

23rd Oct 2007 EuroSSC 07, Kendal, UK 18

Current applications

Enrich GIS management tools with context information

Combine static and heavyweight GIS data (back-end) with volatile and in-situ context information Emergency management tools show GIS information annotated with context information describing current status of entities within the emergency situation

Provide context information for adaptive process management

Context information is used in adapting tasks performed in disaster responses

improving coordination and decision making of response activities based on real-time context information

slide-19
SLIDE 19

23rd Oct 2007 EuroSSC 07, Kendal, UK 19

Example: search for relevant context information

Context information and GIS: Team A wants to reach to a place „P“. Let‘s check unusable roads leading to „P“

for $infrastructure in collection('/db/contextinformation')//includeInfrastructure where $infrastructure/category="ROAD" and $infrastructure/condition="UNUSABLE" return $infrastructure for $worker in collection('db/contextinformation')//SupportWorker where $worker//hasCamera and $worker/belongsTo/description="Team 1" and $worker//Activity/status="LOW" return $worker

Context information and adaptive processes: Let‘s send one worker to place „P“ to take a photo

slide-20
SLIDE 20

23rd Oct 2007 EuroSSC 07, Kendal, UK 20

Conclusion and Future Work

ESCAPE (Emergency Situations, Context Awareness, Pervasive Environments)

Supports extensible context information model and provenance Makes context information available to front-end and back-end teams Provides a basis framework for further developments of smart sensing and context in crisis situations

Future work

Applications integration: GIS-based and in situ context information support and adaptive processes in disaster responses Quality aspects of context information Data aggregation based on rules and XML transformation techniques Automatically process context information using Event- Condition-Action and Complex Event Processing techniques

slide-21
SLIDE 21

23rd Oct 2007 EuroSSC 07, Kendal, UK 21

Thanks for your attention!

Hong-Linh Truong Distributed Systems Group Vienna University of Technology http://www.vitalab.tuwien.ac.at/autocompwiki
