EOS MARKETING - ENG - REV. 1.1.0 08 2018 1 EOS MARKETING - ENG - REV. 1.1.0 08 2018 2 Compact Type 4 and Type 2 Safety Light Curtains and Grids EOS MARKETING - ENG - REV. 1.1.0 08 2018 3 Typical applications Food & beverage

slide-1
SLIDE 1 08 2018 1 EOS MARKETING - ENG - REV. 1.1.0
slide-2
SLIDE 2 08 2018 2 EOS MARKETING - ENG - REV. 1.1.0
slide-3
SLIDE 3

Compact Type 4 and Type 2 Safety Light Curtains and Grids

08 2018 3 EOS MARKETING - ENG - REV. 1.1.0
slide-4
SLIDE 4 08 2018 4 EOS MARKETING - ENG - REV. 1.1.0
  • Food & beverage
  • Packaging
  • Pharmaceutics
  • Printing

Typical applications

  • Paper
  • Logistics
  • Metalworking
  • Woodworking
  • Chemicals
  • Injection moulding
  • Many more ...
slide-5
SLIDE 5 08 2018 5 EOS MARKETING - ENG - REV. 1.1.0
  • Type 2 and Type 4
  • Minimal cross section
  • Zero dead zone on one side
  • -30 to 55 °C
  • IP65 and IP67
  • Start-up time ≤ 2 sec
  • Cascade connection

Main features

slide-6
SLIDE 6 08 2018 6 EOS MARKETING - ENG - REV. 1.1.0
  • 28 x 30 mm
  • Not invasive in

machine design

  • All safety

functions are integrated

Minimal cross section

slide-7
SLIDE 7 08 2018 7 EOS MARKETING - ENG - REV. 1.1.0
  • The nominal resolution
  • f the light curtain is

maintained

  • Fingers and hands are

always detected and protected

Zero dead zone on one side

slide-8
SLIDE 8 08 2018 8 EOS MARKETING - ENG - REV. 1.1.0
  • High resistance to

infiltration of dust and liquids

  • IP69K with additional

enclosure

IP65 and IP67 protection grade

slide-9
SLIDE 9 08 2018 9 EOS MARKETING - ENG - REV. 1.1.0
  • No optical interferences

between the light curtains

  • Possibility of combining

different resolutions and protected heights

Cascade connection

slide-10
SLIDE 10 08 2018 10 EOS MARKETING - ENG - REV. 1.1.0

Cascade connection

slide-11
SLIDE 11 08 2018 11 EOS MARKETING - ENG - REV. 1.1.0

No programming necessary

Hardware connection

Use of unshielded cables up to 100 meters Easy to install and replace

slide-12
SLIDE 12 08 2018 12 EOS MARKETING - ENG - REV. 1.1.0

Finger, Hand and Body detection

Safety Light Curtains

Multibeam grids for access control

Safety Light Grids

slide-13
SLIDE 13 08 2018 13 EOS MARKETING - ENG - REV. 1.1.0
slide-14
SLIDE 14 08 2018 14 EOS MARKETING - ENG - REV. 1.1.0
slide-15
SLIDE 15 08 2018 15 EOS MARKETING - ENG - REV. 1.1.0

Type 4 Safety Light Curtain

EOS4

Type 2 Safety Light Curtain

EOS2

S A F E T Y L E V E L S I L 3

  • S

I L C L 3 P L e

  • C

a t . 4

TYPE

4

SAFETY LEVEL SIL 1 - SILCL 1 PL c - Cat. 2

TYPE 2

slide-16
SLIDE 16 08 2018 16 EOS MARKETING - ENG - REV. 1.1.0

Type 4 Safety Light Curtain

EOS4

Type 4 IEC 61496-1-2 Category 4 ISO/EN 13849-1 PL e ISO/EN 13849-1 SIL 3 IEC 61508 SIL CL 3 EN 62061 Type 2 IEC 61496-1:2004 IEC 61496-2:2006 Category 2 ISO/EN 13849-1:2008 PL c ISO/EN 13849-1:2008 SIL 1 IEC 61508-1:1998 IEC 61508-2:2000 SIL CL 1 EN 62061:2005

Type 2 Safety Light Curtain

EOS2

slide-17
SLIDE 17 08 2018 17 EOS MARKETING - ENG - REV. 1.1.0

Finger, Hand and Body detection

Safety Light Curtains

Multibeam grids for access control

Safety Light Grids

14 20 30 40 50 90 2 3 4

slide-18
SLIDE 18 08 2018 18 EOS MARKETING - ENG - REV. 1.1.0

Max range and Protected height

Finger resolution: 6 m All other resolutions: 12 m H versions: 20 m Protected height From 160 … … to 2250 mm

slide-19
SLIDE 19 08 2018 19 EOS MARKETING - ENG - REV. 1.1.0

Automatic

Automatic or Manual restart

Manual

With restart button

slide-20
SLIDE 20 08 2018 20 EOS MARKETING - ENG - REV. 1.1.0

ACCESSORIES

slide-21
SLIDE 21 08 2018 21 EOS MARKETING - ENG - REV. 1.1.0
  • Back T-slot for fastening
  • Robust and simple
  • Included in the package

Standard brackets

slide-22
SLIDE 22 08 2018 22 EOS MARKETING - ENG - REV. 1.1.0

Special purpose brackets

slide-23
SLIDE 23 08 2018 23 EOS MARKETING - ENG - REV. 1.1.0
  • Avoid mechanical damage
  • Avoid unalignment

Vibration dampers

slide-24
SLIDE 24 08 2018 24 EOS MARKETING - ENG - REV. 1.1.0
  • Protects against welding

sparks and the presence of acids in the workspace

  • Can be quickly replaced

Protective screens

slide-25
SLIDE 25 08 2018 25 EOS MARKETING - ENG - REV. 1.1.0

Floor support columns

slide-26
SLIDE 26 08 2018 26 EOS MARKETING - ENG - REV. 1.1.0
slide-27
SLIDE 27 08 2018 27 EOS MARKETING - ENG - REV. 1.1.0

Optical alignment laser

LAD4

slide-28
SLIDE 28 08 2018 28 EOS MARKETING - ENG - REV. 1.1.0

Safety relays, interfaces and controllers…

Safety Interfaces Safety Controllers Safety Relays

slide-29
SLIDE 29 08 2018 29 EOS MARKETING - ENG - REV. 1.1.0

SPECIAL VERSIONS

slide-30
SLIDE 30 08 2018 30 EOS MARKETING - ENG - REV. 1.1.0

IP69K enclosure for EOS Safety Light Curtains

slide-31
SLIDE 31 08 2018 31 EOS MARKETING - ENG - REV. 1.1.0

Explosion proof enclosure for EOS Safety Light Curtains

Zone 2, 22

slide-32
SLIDE 32 08 2018 32 EOS MARKETING - ENG - REV. 1.1.0
slide-33
SLIDE 33

Thank you
