Energy Area Presentation November 19th, 2011 Ryan Arch Ryan Asa Fabian Lopez Ogee Nnamdi-Emetarom Jerron Smith Hardy Solar 4.4kw back up system. Provides thorough switching. Electrical heating will be required for power shed due to batter
November 19th, 2011
Ryan Arch Ryan Asa Fabian Lopez Ogee Nnamdi-Emetarom Jerron Smith
Power Fluctuations: Blue = Wind power supplied by time. Red = Solar power supplied by time. Green = Power needs of the home Grey = Threshold to avoid interruption. Hardy Solar 4.4kw back up system. Provides thorough switching. Electrical heating will be required for power shed due to batter temperature requirements.
Features: 60 MOTECH multicrystalline solar cells connected in series For commercial or residential applications Output power tolerance of -3% to +5% Robust anodized aluminum frame and tempered glass Tyco junction box, easy-click SOLARLOK connectors, and cable 25-Year Extended Warranty *
Qty Part Number Description 9 MTPVP-235-MSC Motech 235W PV MODULE USA 1 Classic-150 Classic 150W Charge Controller for solar modules 1 MNPV4-TYCO PV Combiner Box Prewired for Tyco Connectors 6 51-7000-168A Rail, XRS at 168" (14 feet) clear 3 29-7000-204 4-pack, end clamp (G) 1.97", Mill 3 29-7000-108 4-pack, mid clamp (G) 2.5" , Mill 12 29-7001-000 SGA Rail Connector at 3" 4 70-0300-SGA SGA Top Cap at 3" 12 29-4000-001 WEEB Compression Clip 12 29-4000-002 WEEB Grounding log 2 70-0300-CBR SGA 3" Brace Assembly 3 TYCO-50 Home Run Cable 50ft- TYCO 1 WL1000 Electrical Shock Warning label 1 WL2000 Solar Disc Warning label
Hardy Solar 2.1 kW Ground Mounted Solar System
Utility Shed:
External Dimensions: 6'x6'x6'-7' : This will give us a snow- slope to the roof. Wall/Roof Composition: Match the home construction. At 6” wall thickness a total of ~126ft3 insulation volume. Simple metal roofing should suffice. Floor: 6” reinforced concrete. 24.5ft3 volume
(not adjusted for cost of living for the region.)
TALON2 2KW Home Wind Turbine System $12,743.76 + $2,306.50 shipping 2 Stage Geothermal Heat Pump 3 Ton Install Package for Closed Loop Vertical Application $8,462.00 + $12,000 digging + $1,200 shipping Homesteader Off Grid System 2
(includes batteries)
$12,799.00 + $2,400 shipping Hardy Solar 2.1 kW Ground Mounted Solar System $7,880.00 + $1,200 shipping Utility Shed TBD Total: $60,991.26 + Shed costs
