END-TO-END RFID BAGGAGE SOLUTION FOR AIRPORTS, AIRLINES & HANDLING OPERATORS WITH BRS, TRACKING & MANAGEMENT FUNCTIONS May, 2018 0 RFID BAGGAGE SOLUTION INDEX About Longest Chance (LC) LC & IATA collaboration

slide-1
SLIDE 1

END-TO-END RFID BAGGAGE SOLUTION FOR AIRPORTS, AIRLINES & HANDLING OPERATORS

WITH BRS, TRACKING & MANAGEMENT FUNCTIONS

May, 2018

slide-2
SLIDE 2

1

 About Longest Chance (LC)  LC & IATA collaboration  Hands-Free Automatic RFID Solution  RFID Hardware – Bag Tags  Reporting and Integration  LC & IATA RFID Project Case, 2015  RFID project in Sochi International Airport (AER) - 2018  RFID Advantages  Project implementation stages & time estimate  Contacts

INDEX

RFID BAGGAGE SOLUTION

slide-3
SLIDE 3

2

  • 1. About LC
slide-4
SLIDE 4

3

  • LC is a Strategic Partner of IATA at RFID baggage area
  • LC is a member of IATA Baggage Working and RFID Groups and ACI

Europe since 2013 and clearly understand the challenges, requirements, and desired outcomes.

  • LC, in collaboration with IATA, has developed innovative End-to-End RFID

Baggage Solution to meet the airlines, airports baggage needs and 753 Resolution IATA.

  • IATA and LC have a 5-year collaboration in the development of RFID

baggage solution.

  • LC team has 10-years experience in RFID technology and have

implemented RFID projects in aviation.

About Longest Chance «LC»

RFID BAGGAGE SOLUTION

slide-5
SLIDE 5

4

  • LC is an IATA strategic partner for the

introduction of RFID baggage tracking.

  • LC team are fully engaged with the IATA

Baggage Working Group (BWG) and RFID Baggage Sub Group.

  • LC, in collaboration with IATA, has

developed the End-to-End RFID Baggage Solution to meet the airline & airport baggage needs.

RFID BAGGAGE SOLUTION

LC - IATA collaboration

slide-6
SLIDE 6

5

  • 2. Hands-Free Automatic

RFID Solution

slide-7
SLIDE 7

6

RFID solution covers the entire baggage operations

RFID BAGGAGE SOLUTION

slide-8
SLIDE 8

7

RFID CHECK-IN – Process Flow

RFID BAGGAGE SOLUTION

I II III

  • RFID baggage check-

in solution allows provides automatic monitoring of baggage movement, baggage handling from check-in up to baggage loading into the aircraft, including delivery to arrival airport via transit airport if needed.

slide-9
SLIDE 9

8

SCANNING POINTS FROM CHECK-IN TO MAKEUP

RFID BAGGAGE SOLUTION

  • RFID technology

allows monitor baggage movements through the kilometers of conveyor belts at any critical points such as custom and security checking.

slide-10
SLIDE 10

9

Video and photos from Sochi International Airport (AER)

https://youtu.be/DemIOcLtFRg https://youtu.be/npiMHdaPYQY https://youtu.be/LtJy0KF1_3M https://youtu.be/1VsYE2XvJMs RFID BAGGAGE SOLUTION

SCANNING POINT – MAKE UP – CAROUSEL

1. RFID solution identifies the numbers of flight and bag and shows this on the TV monitor. 2. RFID solution checks the accuracy of bag loading onto ULD or cart and informs the handler through light and voice signals.

slide-11
SLIDE 11

10

RFID BAGGAGE” SOLUTION

SCANNING POINTS– Departure/Arrival

LC’s RFID solution for belt loader is mobile, hands-free and easy

  • install. Our solution provides automatic scanning and checking the

accuracy of bags loading or unloading in or out from the aircraft. This possible to use in aircraft to find a quickly needed bags.

slide-12
SLIDE 12

11

RFID BAGGAGE SOLUTION

Video and photo from Sochi International Airport (AER)

https://youtu.be/aaler4MPe9g https://youtu.be/8bXZMp7TA1g

SCANNING POINTS– Departure/Arrival

1. Mobile RFID solution can work in fixed and manual modes and inform handler about the accuracy of bag loading via Bluetooth connected with headphones. 2. Mobile RFID solution can check the accuracy of bag loading & unloading without a connection with the main server. This is the smart and effective option.

slide-13
SLIDE 13

12

SCANNING POINTS- LOCAL CLAIM

RFID BAGGAGE SOLUTION

  • RFID baggage

solution allows automatically monitoring baggage delivery and fixing place and time of baggage claim.

slide-14
SLIDE 14

13

  • 3. RFID HARDWARE – BAG TAGS
slide-15
SLIDE 15

14

  • The RFID solution developed by LC is fully compliant

with IATA RFID standard ISO18000-6C standard and the EPC Gen2 protocol. This allows the system to use off the shelf hardware from any vendor. Any hardware that supports standardized LLRP (Low-Level Reader Protocol) can be considered as Plug-and-Play compatible.

  • The proposed hardware will be fully compliant with

regulations any countries where airports, airlines

  • perate.
  • LC only using best of the breed, quality hardware from

the best and most reliable manufacturers. This fact was proven through attaining 99.9958% read rates during the joint pilot with IATA

RFID Reader RFID Antenna RFID Printer Belt Loader Reader Light Stack

INTEGRATION - EQUIPMENT - HARDWARE

RFID BAGGAGE SOLUTION

UHF Inlay

slide-16
SLIDE 16

15

  • 4. REPORTING & INTEGRATION
slide-17
SLIDE 17

16

RFID BAGGAGE” SOLUTION

  • Web-based analytical

engine.

  • Easily adaptable for

customer needs

  • Video of the web interface
  • https://youtu.be/SBTksnjb6Hk
  • https://www.youtube.com/wa

tch?v=aVFz- VZBqS0&feature=youtu.be

FLEXIBLE REPORTING AND MANAGEMENT TOOLS

slide-18
SLIDE 18

17

RFID BAGGAGE SOLUTION

  • Staff can track bags via the web portal or mobile devices

so that they can take quick action and reduce delays

CUSTOMER & STAFF REPORTING

CUSTOMERS STAFF

  • When integrated with the airline mobile application,

customers will be able to track their bags in real time, the fact which can increase customer satisfaction and reduce travel stress

slide-19
SLIDE 19

18

RFID BAGGAGE SOLUTION

  • BSM integration is supported
  • BHS integration is supported
  • Push messaging is supported
  • Status messaging is supported
  • Other integration options are available

SYSTEM IT INTEGRATION

slide-20
SLIDE 20

19

  • 5. LC & IATA RFID PROJECT - 2015

RFID PROGECT AT SOCHI AIRPORT - 2018

slide-21
SLIDE 21

20

Participants: IATA – Longest Chance Pilot Project, 2015 Airports Airlines SVO PRG TLL BLQ SU OV IT Provider

RFID BAGGAGE SOLUTION

slide-22
SLIDE 22

21

RFID BAGGAGE SOLUTION

  • 25 scanning points at 4 airports
  • System integration with ARINC BagLink

Pilot Scanning Points

16 scanning points at Moscow (SVO) airport

slide-23
SLIDE 23

22

Airports: Prague (PRG), Bologna (BLQ), Tallin (TLL)

RFID BAGGAGE SOLUTION

slide-24
SLIDE 24

23

PILOT RESULTS

№

THE NUMBER OF: INSIDE SVO to PRG to BLQ to TLL TOTAL

1

FLIGHTS 1155 164 40 87 1446

2

RFID TAGS 42 953 6 044 2 106 1 528 52 631

3

UNREAD TAGS ON CAROUSELES IN SVO 64 16 6 86

4

UNREAD TAGS IN PRG, BLQ,TLL 24 3 7 98

5

LEVEL OF READABILITY, % 99,9985 99,9934 99,9957 99,9954 99,9958

Main results – 99,9958% read accuracy achieved.

Baggage sent to the wrong destination airport

523 27.09.15 SU 2184 64 64 9555191162001 Bag flew to Vienna, but arrived to Tallinn 905 14.10.15 SU 2040 15 15 9555302485001 Bag flew to Zagreb but arrived to Prague

During the pilot project we had two examples of Hand-to-Hand baggage system providing an easy way to find mishandled bags.

RFID BAGGAGE SOLUTION

slide-25
SLIDE 25

24

  • 9. RFID ADVANTAGES
slide-26
SLIDE 26

25

LC’s RFID solution provides significant advantages

RFID BAGGAGE SOLUTION

№

Baggage processes description Comparing productivity and accuracy of baggage

  • perations based on Barcode & RFID technology

RFID productivity and accuracy advantages

No BRS solution BRS via Barcode LC's baggage solution via RFID 1 Check-in barcode printing barcode printing barcode printing & LPN encoding in RFID chip automatic tracking and inventory 2 Makeup handler have to moves along carousel and manually check each tag https://youtu.be /P1AZr6VTrmM handler have to moves along carousel and manually scan each tag handler stay opposite monitor and wait for when RFID identify and show on monitor needed flight and tag number. https://youtu.be/npiMHda PYQY 1). There are no superfluous

  • movements. 2). No need to bend over

and look at each tag. 3). No need to flip bags when the tag is not visible. 4). Hands-free, reliable automatic solution 3 Oversized baggage no option manually scanning automatic scanning 99,9 % accuracy of reading 4 Carry-on checked baggage no option manually scanning automatic scanning 5 Baggage loading in ULD or carts no option manually scanning automatic scanning https://youtu.be/1VsYE2Xv JMs RFID check the accuracy and shows green or red light to the handler. Handler no need to think 6 Baggage loose loading/unloading aircraft no option manually scanning automatic scanning https://youtu.be/aaler4MP e9g RFID check the accuracy of bag loose loading/unloading and inform a handler 7 Baggage claim no option manually scanning automatic scanning Baggage delivery confirmation and reliable data

slide-27
SLIDE 27

26

LC’s RFID solution provides significant advantages:

  • 99,9% reliability of baggage tracking from check-in to arrival including

transit airports

  • Increasing productivity and accuracy of baggage processes
  • Mishandling and financial losses reduction
  • New mobile services of baggage monitoring and location for staff and

customers

  • A proven concept and an IATA recommendation and endorsement

RFID BAGGAGE SOLUTION

Our RFID solution is the best solution for airports without BRS and for airports and airlines which want significantly increase the productivity of baggage operations, reduce mishandling and improve customer experience.

slide-28
SLIDE 28

27

  • 6. Project Implementation

Stages & Time Estimate

slide-29
SLIDE 29

28

RFID BAGGAGE SOLUTION

Project implementation stages and time estimate

1. RFID project implementation process goes quickly and no need stop conveyor belt. 2. Project stages:

  • Defining project scope & the places

for equipment installation

  • HW and SW installation
  • Staff learning Running RFID system
  • 3. The project implementation time is

from 2 to 3 months for average size airport from date of agreement signing.

slide-30
SLIDE 30

29

Good time for start to:

  • Increase productivity of baggage operations
  • Comply 753 Resolution of IATA
  • Improve customer experience

RFID BAGGAGE SOLUTION

slide-31
SLIDE 31

30

Useful information

  • 1. IATA recommendation documents
  • http://www.longestchance.com/wp-

content/uploads/2016/10/IATA_Recomendation_Letter_LC_SuccessfullPilot.pdf

  • http://www.longestchance.com/wp-content/uploads/2016/10/Letter_to_airports_from_IATA.pdf
  • http://www.longestchance.com/wp-content/uploads/2017/02/IATA_Recomendation_Letter_LC.pdf
  • 2. Video presentations
  • https://www.youtube.com/watch?v=lJqzBMw1Ans&feature=youtu.be
  • https://www.youtube.com/watch?v=TYspNRC8NnU
  • https://www.youtube.com/watch?v=6imaJCh2Jio&feature=youtu.be
  • https://www.youtube.com/watch?v=0q9UyNaZ_M0&t=83s

RFID BAGGAGE SOLUTION

  • 3. RFID Baggage Tracking Map
  • http://www.longestchance.com/wp-content/uploads/2017/07/LC_End_to_end_RFID_Baggage_Tracking_Map_2017.pdf
slide-32
SLIDE 32

31

CONTACTS: Sergey Tsybouk CEO of Longest Chance Mobile: +7 915 040 03 03 Skype: longestchance Mail: s.tsybouk@longestchance.com
