FERMILAB-SLIDES-17-017-AD Electrospun nanofiber materials for high power target applications Sujit Bidhar 21-22 nd Sept., 2017 J-PARC, Tokai, Japan This manuscript has been authored by Fermi Research Alliance, LLC under Contract No.


  1. FERMILAB-SLIDES-17-017-AD Electrospun nanofiber materials for high power target applications Sujit Bidhar 21-22 nd Sept., 2017 J-PARC, Tokai, Japan This manuscript has been authored by Fermi Research Alliance, LLC under Contract No. DE-AC02-07CH11359 with the U.S. Department of Energy, Office of Science, Office of High Energy Physics.

  2. Outline • Background & Objectives • Electrospinning process • In-house electrospinning unit • Candidate target materials manufacturing • Single nanofiber mechanical characterization • Future plans and summary 2 7/12/2018

  3. Background- Target material • Demand of multi-MW high performance particle production targets – LBNE 2.3MW proton beam, 1.6X10 14 p/pulse • Structural integrity over time – High temperature, thermal stresses, dynamic stresses • Withstand radiation damage – Embrittlement, radiation corrosion, swelling 3 7/12/2018

  4. Current Target • ANU/NOvA, 700KW  Graphite blocks Water cooling Compressive strength 345MPa Proton beam Tensile strength : 60~140 MPa Endurance Limit : 20 MPa Water cooling Beam spot size<<target dimension Solid continuum  high local temperature gradient, thermal stress wave Can it perform satisfactory at higher energy?? 4 7/12/2018

  5. HPT Issues -Stress wave Radial temperature distribution at end of pulse T2K window 750kW Spill width: 4.2 µsec Gaussian beam Sigma 4.2mm 40mm Prone to fatigue failure (Mode II) ∆ σ T2K window Reduce amplitude, decrease wave speed 5 7/12/2018

  6. Fatigue life Initial stress wave amplitude ∆ T ∆ σ = ρ α E . . 0 ∆ t temperature gradient Number stress cycles ~Elastic wave speed E c = ρ Possible by microstructure design 6 Presenter | Presentation Title 7/12/2018

  7. Sinuous Target -Candidate Microstructure Design Microstructure to mitigate issues Electrospun nano-fiber  Sinuous target Electrospun Zirconia nanofiber* 7 * Journal of Alloys and Compounds 649 (2015) 788e792 7/12/2018

  8. Advantages & Limitations Advantages: • Local damage of single fiber won’t affect target structural integrity as a whole • Reduced thermal stress wave – Reduced temp. gradient – High surface area & gaps  effective local heat removal by passing He gas • Customize material properties by mixing different materials Limitations: • Widely used for polymer nanofibers • Limited research in ceramics/metal nanofiber • Low density (long target) 8 7/12/2018

  9. Objective Fabricate ceramic/metal, composite material nano-fiber with high strength, high density and alloying elements to reduce radiation damage. • Set up in-house electrospun unit • Fabricate ceramic composites nanofiber • Micro-mechanic study single fiber mechanical characterization 9 7/12/2018

  10. Basic Electrospinning Set up Collector • Fixed type • Rotating drum type 5-10 cm 10-30 kV DC 10-30 cm Process carried out at room temp. and atm. pressure 10 7/12/2018

  11. Electrospinning Principle Jet Initiation stages Convective Ohmic flow flow solution Slow Rapid acceleration acceleration Flat needle Collector +/- kV plate Transition liquid to solid Taylor cone Bending Instability Electrostatic repulsion> surface tension • Droplet is stretched Liquid • Jet elongated by Solid whipping action Flow direction 11 7/12/2018

  12. Ceramics Nanofiber Fabrication Inorganic precursor(inorganic compound+solvent) Polymer solution(polymer+solvent) Salt additives (surfactants) Solution for electrospinning  polymer-ceramic nanofiber Calcination (Heat treatment)  Vaporize polymer  Promotes crystal growth  Bonding Representative heating profile 12 7/12/2018

  13. Lab Set-up Furnace Electrospinning unit 13 7/12/2018

  14. Electrospinning Set-up High voltage power supply Needle Collector plate Syringe pump 14 7/12/2018

  15. Electrospinning Jet Needle Stable jet 15 7/12/2018

  16. Nanofiber Mat – Random Orientation Nanofiber 16 7/12/2018

  17. Nanofiber Mat- Aligned Reflector plate C-Channel Needle 17 7/12/2018

  18. Focused Deposition Reflector plate Needle 18 7/12/2018

  19. Improvised Compact Power Supply 120 Watt, 120VAC in -5kV DC out 4 Watt, 6~12VDC in, +/-20kV DC out 60kV DC out -20kV  Much safe to use (120W  4W!)  Mobile compact unit • Can be run on 9 or 12 V battery 19 7/12/2018

  20. Candidate electrospun nanofiber-Raw materials Polymer solution • PVP+Ethanol+Aceton Metal/Ceramic • Alumina  Aluminum 2,4-pentadionate+Aceton • Zirconia  Zirconium Carbonate +Acetic Acid Done • WO 3  Ammonium meta-tungstate + D.I. Water • TiO 2  Titanium Isopropoxide Carbon-nanotube Composite • CNT-Alumina Proposed • CNT-Zirconium 20 7/12/2018

  21. Alumina Nanofiber After heat treatment As spun 21 7/12/2018

  22. EDS Mapping Alumina Nanofiber After heat treatment As spun 1600 Alumina heating profile 1400 1200 Theoretical Al wt% in Al 2 O 3 is 53% 1000 Temp, C Achieved in actual 25% 800 600 400 200 0 0 500 1000 1500 2000 2500 3000 3500 Time, min 22 7/12/2018

  23. Titania(TiO2) Nanofiber After heat treatment As spun 23 7/12/2018

  24. EDS Mapping TiO2 After heat treatment As spun Titanium Heating profile 700 Theoretical Ti wt% in TiO2 is 60% 600 500 Temp. , C Achieved in actual 51% 400 300 200 100 0 0 500 1000 1500 2000 2500 Time, min 24 7/12/2018

  25. Tungsten Oxide (WO3) Nanofiber After heat treatment As spun 25 7/12/2018

  26. Zirconia Nanofiber After heat treatment As spun 1.2 gm 0.5 gm 26 7/12/2018

  27. EDS Mapping- Zirconia Nanofiber After heat treatment As spun 1400 Zr-heating profile 1200 1000 Theoretical Zr wt% in ZrO 2 is 74% Temp., C 800 Achieved in actual 62% 600 400 200 0 0 500 1000 1500 2000 Time, minute 27 7/12/2018

  28. Zirconia Nanofiber- Yttrium doped Improve thermal shock resistance by Yttrium doping Improve radiation resistance • More grain boundaries blocks dislocation, defect movements, defect recombination*. • YSZ strong resistance to amorphization *Sci Rep. 2015; 5: 7746. 28 7/12/2018

  29. CNT-Ceramics Nanofiber Composites Excellent mechanical properties E : 1~5 Tpa 1-3 nm Tensile strength : 15-50 Gpa Elongation % : 16% High thermal conductivity (axial), insulator lateral SWCNT 1~2 Vol% CNT Protects Aluminum metal against radiation damage~70 DPA • 1-D transport network for He to escape • Reduce embrittlement by 5-10 times. Bulk not nanofiber!! MIT-research* 29 7/12/2018 *http://news.mit.edu/2016/carbon-nanotubes-improve-metal-longevity-under-radiation-0302

  30. CNT-Zirconia/Alumina Proposed Nanofiber Sonification Add Alumina deionized water SWNT Surfactant Calcination/ Add polymer Heat treatment Solution +ve charged alumina CNT filled ceramic Electrospin Nano-particle nanofiber • Ceramic(Zirconia) will have high Z value • CNT will enhance mechanical strength, provide protection against radiation damage 30 7/12/2018

  31. Nano-mechanical mapping – Atomic Force Microscopy Tungsten – Polymer nanofiber Elastic Modulus map 340MPa Peak Force, nN Separation, µm Tip Deflection in contact mode Nanofibers fixed to substrate using double sided tape Soft substrate compared to nanofiber 31 7/12/2018

  32. Nano-mechanical mapping – Atomic Force Microscopy Elastic Modulus map 225GPa Nanofiber solution casted on harder smooth mica substrate 200GPa 150GPa Average Elastic modulus ~ 100GPa 100GPa 32 7/12/2018

  33. Mechanical characterization Macro testing electrospun Fracture strength single nanofiber nanofiber mat 1. 3 point Bending test on TEM Grid Set up • Solution cast • Fix to TEM grid using Ion beam (Pt tape) • Press using diamond AFM tip 2. Nano-indentation using AFM tip 33 7/12/2018

  34. Propose target shape Alumina nano-fiber block No major modification to current target holder Customizable Cheaper and scalable 34 7/12/2018

  35. Physical Properties Characterization (In progress) • Raman spectroscopy: • disorderness, bond information • Electron energy loss spectrometry (EELS): • sp2/sp3 ratio, atomic composition (low Z) • Wide Angle X-ray Diffraction (WAXD): • lattice parameters, orientation, isotropy. • Thermal analysis: • DSC and DMA :melting and glass transition temperature 35 7/12/2018

  36. Summary and Future Work • Installation of a low cost electrospinning set up completed. • Success in fabricating metallic and ceramic nanofiber. • Physical properties of single nanofiber evaluation in progress. Future work • Expose nanofiber mat to HiRadMat test • Single fiber radiation damage study • Improve ductility of ceramic nanofiber • Fabricate ceramics-CNT composite. • Heat treatment profile • Physical properties before and after radiation. • Damage modeling 36 7/12/2018

  37. Thank You for Your Attention!! 37 7/12/2018

  38. Parameters • Molecular weight of polymer • Solution properties (Viscosity, conductivity, surface tension) • Concentration, electrical potential, flow rate • Distance between needle and collector • Needle gage • Ambient temperature, humidity, air flow 38 7/12/2018
