Electronically coarse grained water Andrew Jones Flaviu Cipcigan Vlad Sokhan Jason Crain Glenn Martyna Problem Problem Intermolecular interactions depend on environment Challenge Develop simplest water model with electronic responses 1. Quantum

SLIDE 1

Electronically coarse grained water

Andrew Jones Flaviu Cipcigan Vlad Sokhan Jason Crain Glenn Martyna

SLIDE 2

Problem Challenge

Intermolecular interactions depend on environment Develop simplest water model with electronic responses

Problem

SLIDE 3

1. Quantum Drude Oscillator (QDO)

Light negative particle tethered harmonically to heavy positive, oppositely charged nucleus Free parameters reduced mass spring constant charge

SLIDE 4

Polarisabilities Dispersion coeffjcients

dipole dipole–dipole dipole–quadrupole

…

1. Quantum Drude Oscillator (QDO)

SLIDE 5

2. The responses of QDOs are realistic

CH4 H2O He Ne Ar Kr Xe H Li K Rb Cs 1.5 1.5 1.5 0.5 0.5 0.5 1 1 1

Polarisation

SLIDE 6

Dispersion

1.5 1.5 1.5 0.5 0.5 0.5 1 1 1 CH4 BH3 NH3 H2O He Ne Ar Kr Xe H Li K Rb Cs

2. The responses of QDOs are realistic

SLIDE 7

3. QDO water

Frame: ground state charge distribution

+ 0.605 e

1.21 e

0.2667 Å 0.9572 Å

O H M H

104.52º

Frame: ground state charge distribution

SLIDE 8

= 0.3656 amu = 0.6287 = -1.1973 e

3. QDO water

QDO: responses

SLIDE 9

3. QDO water

Short range: empirical repulsion

SLIDE 10

4. Liquid QDO water

Radial distribution function

r / Å

2345 67

gOO(r)

0.0 0.5 1.0 1.5 2.0 2.5

Skinner et al. (exp).

Exp. (Soper)

QDO, N = 300

SLIDE 11

4. Liquid QDO water

Radial distribution function Vapour pressure

exp: 43.91 kJ/mol

r / Å

2345 67

gOO(r)

0.0 0.5 1.0 1.5 2.0 2.5

Skinner et al. (exp).

Exp. (Soper)

QDO, N = 300

46 ± 2 kJ / mol

SLIDE 12

4. Liquid QDO water

Radial distribution function Vapour pressure

exp: 43.91 kJ/mol

r / Å

2345 67

gOO(r)

0.0 0.5 1.0 1.5 2.0 2.5

Skinner et al. (exp).

Exp. (Soper)

QDO, N = 300

46 ± 2 kJ / mol Dielectric constant

exp: 78

79 ± 2

SLIDE 13

4. Liquid QDO water

Radial distribution function Vapour pressure

exp: 43.91 kJ/mol

r / Å

2345 67

gOO(r)

0.0 0.5 1.0 1.5 2.0 2.5

Skinner et al. (exp).

Exp. (Soper)

QDO, N = 300

46 ± 2 kJ / mol Dielectric constant

exp: 78

79 ± 2 Surface tension

exp: 71.73 mN / m

72.6 ± 1 mN / m

SLIDE 14

5. Liquid–vapour interface of QDO water

SLIDE 15

5. Liquid–vapour interface of QDO water

SLIDE 16

5. Liquid–vapour interface of QDO water

loss & gain of electronic charge in bulk

SLIDE 17

5. Liquid–vapour interface of QDO water

loss & gain of electronic charge at surface

SLIDE 18

5. Liquid–vapour interface of QDO water

loss & gain of electronic charge last surface layer

SLIDE 19

6. Conclusions

simple, but with a complex electronic structure transferability may be good, under investigation QDO water model of the isolated molecule, condensed properties emerge naturally

SLIDE 20

A. Jones, Quantum drude oscillators for accurate many-body intermolec-

ular forces, PhD thesis, The University of Edinburgh

A. Jones, F. Cipcigan, V. Sokhan, J. Crain, G. Martyna, Electronically coarse

grained model for water, PRL 110, 227801 (2013)

Electronically coarse grained water

Andrew Jones Flaviu Cipcigan Vlad Sokhan Jason Crain Glenn Martyna
