2019 2020 EDGE IN A BOX A joint solution with APC by Schneider Electric, StorMagic and HPE MAKING THE COMPLEX SIMPLE MAKING THE COMPLEX SIMPLE PRESENTERS & AGENDA 2 NEED FOR EDGE COMPUTING EXPLODING EDGE COMPUTING MARKET $47B WHAT IS


slide-1
SLIDE 1

MAKING THE COMPLEX SIMPLE

2019

MAKING THE COMPLEX SIMPLE

EDGE IN A BOX

A joint solution with APC by Schneider Electric, StorMagic and HPE

2020

slide-2
SLIDE 2

PRESENTERS & AGENDA

2

slide-3
SLIDE 3

3

NEED FOR EDGE COMPUTING EXPLODING

WHAT IS FUELING THE GROWTH?

  • Capture data where

the customer is

  • IoT – sensors, data collection
  • Need to run apps at the edge
  • Performance impact of cloud
  • Cost of transferring data

to cloud

By 2022…. 75 percent of enterprise-generated data will be created and processed outside the traditional, centralized data center or cloud, up from less than 10 percent in 2018” -

$3.5B $47B

EDGE COMPUTING MARKET

slide-4
SLIDE 4

4

PROBLEMS AT THE EDGE

slide-5
SLIDE 5

INTRODUCING: EDGE IN A BOX

Integrated solution designed specifically for Edge Computing

5

  • Small footprint
  • can hang on a wall
  • Compute, networking

& storage

  • Simple to install & manage
  • Starting at less than $10,000

650mm (22.5in) 331mm (13in) 969mm (38in)

slide-6
SLIDE 6

6

  • EcoStruxure Micro

Datacenter 6U Wall Mounted Rack

  • UPS, PDU and

networking options

  • Two or three HPE

Proliant Servers

THE HARDWARE

slide-7
SLIDE 7

7

  • No single point of failure

Start with only 2 nodes

  • Lightweight witness

One VM for up to 1,000 sites – can run on a Raspberry pi

  • Greater resiliency

Deploy a cluster locally or stretch it hundreds of miles

  • Hypervisor

VMware vSphere, Microsoft Hyper-V or Linux KVM

Optional three node configuration Maintain HA during one node failure and maintenance windows

THE SOFTWARE

slide-8
SLIDE 8

8

SvSAN WITNESS

TWO DEPLOYMENT OPTIONS:

  • 1. Build-it-yourself
  • 2. StorMagic Cloud – Witness as a Service

One lightweight witness supports up to 1,000 sites “Set and forget” software runs anywhere – just one VM Eliminate downtime with only 2 servers per cluster Keeps clusters running through a variety of failure

  • scenarios. Minimal networking: 9Kb/sec

bandwidth, 3000ms latency Reduce costs by at least 33% at all sites Eliminate the need for 1 or 2 servers at every site

DELIVERING 100% UPTIME WITH ONLY 2 SERVERS PER SITE

8

slide-9
SLIDE 9

SIMPLE - Secure data without the hassle

  • 100% software approach – FIPS 140-2 compliant
  • Data destruction on failed drives not needed

9

SLASHING THE COST OF DATA ENCRYPTION

FLEXIBLE - Use any key manager

  • Integrated with StorMagic SvKMS
  • Or use any KMIP-compliant KMS
  • Encrypt any volume and data

inflight between servers

COST-EFFECTIVE - 85% less than competitors

  • No OS or hypervisor-level

encryption required

  • No special hardware
slide-10
SLIDE 10

1

STORMAGIC SvKMS

VIRTUALIZED ENTERPRISE KEY MANAGEMENT FOR ANY ENVIRONMENT

  • Key management for any use case
  • Designed to be simple for admins
  • Surprisingly low cost
  • Runs as a VM on any hypervisor
  • Onsite, datacenter or cloud
  • Powerful, enterprise class features
slide-11
SLIDE 11

11

EXPLAINING THE APC MICRO DATA CENTER

slide-12
SLIDE 12 Confidential Property of Schneider Electric

Cybersecurity begins with physical security Design and deployment are simple Managing multiple sites is no problem

29%

Of data breaches are due to physical security

  • TrendMicro

75%

Of enterprises will face skills gap by 2020

  • CIO.com

25%

Of IT staff have suffered a stress-related illness

  • IT Admin Survey

12

slide-13
SLIDE 13

Low Profile, Wall-mounted Enclosure Lithium Ion Battery Backup (UPS) Air Filtration and Ventilation Intelligent Power Distribution Physical Security and Surveillance Pre-Integrated Solution Cloud-Based Remote Management

Confidential Property of Schneider Electric

13

slide-14
SLIDE 14

NEXT STEPS

14

NEXT STEPS

Schedule a live demo Email sales@stormagic.com Visit stormagic.com/request-a-quote Request a quote Visit stormagic.com/trial Download a free trial of SvSAN Further information and documentation Visit stormagic.com/apc
