SLIDE 1
- Our goal is to extract
a “line drawing” representation from an image
- Useful for recognition:
Edge Detection Ref: Forsyth+Ponce Ch. 7,8 Trucco+Verri Ch. 4 Our - - PowerPoint PPT Presentation
Edge Detection Ref: Forsyth+Ponce Ch. 7,8 Trucco+Verri Ch. 4 Our - - PowerPoint PPT Presentation
Edge Detection Ref: Forsyth+Ponce Ch. 7,8 Trucco+Verri Ch. 4 Our goal is to extract a line drawing representation from an image Useful for recognition: edges contain shape information invariance Edge detection Derivatives
SLIDE 2
SLIDE 3
Edge detection
SLIDE 4
Derivatives
- Edges are locations with high image
gradient or derivative*
- Estimate derivative using finite
difference
- Problem?
SLIDE 5
Smoothing
- Reduce image noise by smoothing with
a Gaussian
SLIDE 6
Convolution is Associative
- We compute derivative of smoothed
image:
- Since convolution is associative:
SLIDE 7
Separable Convolution
- Note that G can be factored as
and computed as two 1-D convolutions
SLIDE 8
Edge orientation
- Would like gradients in all directions
- Approximate:
– Compute smoothed derivatives in x,y directions – Edge strength – Edge normal
SLIDE 9
Canny Edge Detection
- Compute edge strength and orientation
at all pixels
- “Non-max suppression”
– Reduce thick edge strength responses around true edges
- Link and threshold using “hysteresis”
– Simple method of “contour completion”
SLIDE 10
Non-maximum suppression: Select the single maximum point across the width
- f an edge.
Slides by D. Lowe
SLIDE 11
Non-maximum suppression At q, the value must be larger than values interpolated at p or r.
SLIDE 12
Examples: Non-Maximum Suppression
courtesy of G. Loy
Original image Gradient magnitude Non-maxima suppressed
Slide credit: Christopher Rasmussen
SLIDE 13
SLIDE 14
fine scale high threshold
SLIDE 15
coarse scale, high threshold
SLIDE 16
coarse scale low threshold
SLIDE 17
Linking to the next edge point
Assume the marked point is an edge point. Take the normal to the gradient at that point and use this to predict continuation points (either r or s).
SLIDE 18
Edge Hysteresis
- Hysteresis: A lag or momentum factor
- Idea: Maintain two thresholds khigh and klow
– Use khigh to find strong edges to start edge chain – Use klow to find weak edges which continue edge chain
- Typical ratio of thresholds is roughly
khigh / klow = 2
SLIDE 19
Example: Canny Edge Detection
courtesy of G. Loy
gap is gone
Original image Strong edges
- nly
Strong + connected weak edges Weak edges
SLIDE 20
Problem?
- Texture
