ECONOMIC IMPACTS OF VALUE-ADDED USES OF OIL AND NATURAL GAS Evar - - PowerPoint PPT Presentation

Sep 05, 2022 361 likes •758 views

ECONOMIC IMPACTS OF VALUE-ADDED USES OF OIL AND NATURAL GAS Evar Umeozor, Ph.D. Senior Research Engineer June 20, 2020 www.ceri.ca WEBINAR PARTICIPATION Audio Your microphone has been muted for the duration of this presentation. To hear

slide-1
SLIDE 1

ECONOMIC IMPACTS OF VALUE-ADDED USES OF OIL AND NATURAL GAS

Evar Umeozor, Ph.D. Senior Research Engineer June 20, 2020

www.ceri.ca

slide-2
SLIDE 2

2

WEBINAR PARTICIPATION

2

Audio

Your microphone has been muted for the duration

  • f this presentation. To hear webinar audio:
  • Choose Mic & Speakers to use VoIP
  • Choose Telephone and dial using the

information provided:

  • CANADA: 1-647-497-9385
  • US: 1-213-929-4231
  • ACCESS CODE: 955-009-570

Questions

  • Please submit your text questions and

comments using the Questions panel.

  • Questions will be answered during the Q&A

period following the presentation. Note: A copy of this presentation can be downloaded by selecting the document in the Handouts panel.

Allan Fogwill

slide-3
SLIDE 3

3

OVERVIEW

Founded in 1975, the Canadian Energy Research Institute (CERI) is an independent, registered charitable

  • rganization specializing in the analysis of energy

economics and related environmental policy issues in the energy production, transportation, and consumption sectors. Our mission is to provide relevant, independent, and

  • bjective economic research of energy and environmental

issues to benefit business, government, academia and the public. CERI publications include:

  • Market specific studies
  • Geopolitical analyses
  • Quarterly commodity reports (crude oil, electricity

and natural gas) In addition, CERI hosts a series of study overview events and an annual Petrochemicals Conference.

slide-4
SLIDE 4

CORE FUNDERS FUNDING SUPPORT

IVEY FOUNDATION

IN-KIND SUPPORT

Alberta Energy Regulator | Bow Valley College | CEPA Foundation JWN Energy | Northern Alberta Institute of Technology Petroleum Services Association of Canada

S.M. BLAIR FAMILY FOUNDATION

slide-5
SLIDE 5

AGENDA

  • Background
  • Methodology
  • Results
  • Conclusions
  • Questions?

4

slide-6
SLIDE 6

BACKGROUND – Global Feedstocks

5

100 200 300 400 500 600 700 2015 2020 2025 2030 2035 2040 2045 2050

Mtoe

Year

Coal Oil Gas Biomass Source: Data by IEA, Figure by CERI

slide-7
SLIDE 7

BACKGROUND – Regional Feedstocks

6

71% 11% 66% 37% 11% 78% 15% 84% 56% 18% 11% 19% 16% 7% 0% 10% 20% 30% 40% 50% 60% 70% 80% 90% 100%

North America Europe Middle East China Other Asia

% of Feedstock used

Ethane Naphtha Other

Source: Data by Deloitte, Figure by CERI

slide-8
SLIDE 8

BACKGROUND – Feedstocks and Products

7

Source: IEA 2018

slide-9
SLIDE 9

BACKGROUND – Study Focus

8

Feedstock Product Assessment Methods

  • Gas-based
  • Oil-based
  • Gas-based (Natural

gas): Ammonia, Methanol

  • Oil-based (Naphtha):

Ethylene, Propylene

  • Process (amounts of

feedstocks, products and GHG emissions)

  • Microeconomic (FOB

supply cost)

  • Macroeconomic

(employment, salary/wage, tax revenue, GDP impacts)

slide-10
SLIDE 10

METHODOLOGY – IPEM Workflow

9

slide-11
SLIDE 11

METHODOLOGY – Business Cases & Attributes

10

Attribute Reference Business Case (RBC) Competitive Business Case (CBC) Facility Size Smaller Bigger Process Efficiency Lower Higher Project Funding Debt Equity Carbon Tax Yes No

slide-12
SLIDE 12

METHODOLOGY – Product Supply Scenarios

11

  • Business As Usual (BAU) Scenario;

𝐸𝑝𝑛𝑓𝑡𝑢𝑗𝑑 𝐸𝑓𝑛𝑏𝑜𝑒 + 𝐹𝑦𝑞𝑝𝑠𝑢𝑡 = 𝐸𝑝𝑛𝑓𝑡𝑢𝑗𝑑 𝑇𝑣𝑞𝑞𝑚𝑧 + 𝐽𝑛𝑞𝑝𝑠𝑢𝑡

  • Medium Supply Growth (MSG) Scenario;

𝐸𝑝𝑛𝑓𝑡𝑢𝑗𝑑 𝐸𝑓𝑛𝑏𝑜𝑒 + 𝐹𝑦𝑞𝑝𝑠𝑢𝑡 = 𝐸𝑝𝑛𝑓𝑡𝑢𝑗𝑑 𝑇𝑣𝑞𝑞𝑚𝑧

𝐸𝑝𝑛𝑓𝑡𝑢𝑗𝑑 𝑇𝑣𝑞𝑞𝑚𝑧 = 𝐸𝑝𝑛𝑓𝑡𝑢𝑗𝑑 𝑇𝑣𝑞𝑞𝑚𝑧𝐶𝐵𝑉 + 𝐽𝑛𝑞𝑝𝑠𝑢𝑡𝐶𝐵𝑉 + 1% 𝐻𝑚𝑝𝑐𝑏𝑚 𝐹𝑦𝑞𝑝𝑠𝑢 𝑁𝑏𝑠𝑙𝑓𝑢

  • High Supply Growth (HSG) Scenario;

𝐸𝑝𝑛𝑓𝑡𝑢𝑗𝑑 𝐸𝑓𝑛𝑏𝑜𝑒 + 𝐹𝑦𝑞𝑝𝑠𝑢𝑡 = 𝐸𝑝𝑛𝑓𝑡𝑢𝑗𝑑 𝑇𝑣𝑞𝑞𝑚𝑧

𝐸𝑝𝑛𝑓𝑡𝑢𝑗𝑑 𝑇𝑣𝑞𝑞𝑚𝑧 = 𝐸𝑝𝑛𝑓𝑡𝑢𝑗𝑑 𝑇𝑣𝑞𝑞𝑚𝑧𝐶𝐵𝑉 + 𝐽𝑛𝑞𝑝𝑠𝑢𝑡𝐶𝐵𝑉 + 3% 𝐻𝑚𝑝𝑐𝑏𝑚 𝐹𝑦𝑞𝑝𝑠𝑢 𝑁𝑏𝑠𝑙𝑓𝑢

slide-13
SLIDE 13

RESULTS – Supply Costs

12

200 400 600 800 1000 1200 1400 1600 1800

AB SK NL AB SK NL Reference Business Case (RBC) Competitive Business Case (CBC)

$/t

Ammonia Ethylene Methanol Propylene

slide-14
SLIDE 14

RESULTS – Cash Costs

13

400 800 1,200 1,600

Ammonia Methanol Ethylene/Propylene Ammonia Methanol Ethylene/Propylene Ammonia Methanol Ethylene/Propylene AB SK NL

$/t

RBC CBC

slide-15
SLIDE 15

RESULTS – Carbon Tax (Additional to Costs)

14

37.36 31.93 44.74 39.64 33.03 27.42 44.74 39.64

10 20 30 40

RBC CBC RBC CBC RBC CBC RBC CBC Ammonia Ethylene Methanol Propylene

$/t

slide-16
SLIDE 16

RESULTS – Cash Flows and Pay Back Periods

15

slide-17
SLIDE 17

RESULTS – Cash Flows and Pay Back Periods

16

slide-18
SLIDE 18

RESULTS – Regional Price Competitiveness

17

100 200 300 400 500 600 700

North America Europe Asia RBC CBC Price Range (US$/t)

Ammonia Price

slide-19
SLIDE 19

RESULTS – Regional Price Competitiveness

18

100 200 300 400 500 600 700

North America Europe Asia RBC CBC Price Range (US$/t)

Ammonia Price

$37 $32

slide-20
SLIDE 20

RESULTS – Regional Price Competitiveness

19

50 100 150 200 250 300 350 400 450 500

North America Europe Asia RBC CBC Price Range (US$/t)

Methanol Price

slide-21
SLIDE 21

RESULTS – Regional Price Competitiveness

20

50 100 150 200 250 300 350 400 450 500

North America Europe Asia RBC CBC Price Range (US$/t)

Methanol Price

$33 $27

slide-22
SLIDE 22

RESULTS – Regional Price Competitiveness

21

200 400 600 800 1000 1200 1400 1600 1800

North America Europe Asia RBC CBC Price Range (US$/t)

Ethylene Price

slide-23
SLIDE 23

RESULTS – Regional Price Competitiveness

22

200 400 600 800 1000 1200 1400 1600 1800

North America Europe Asia RBC CBC Price Range (US$/t)

Ethylene Price

$45 $40

slide-24
SLIDE 24

RESULTS – Regional Price Competitiveness

23

200 400 600 800 1000 1200 1400 1600 1800

North America Europe Asia RBC CBC Price Range (US$/t)

Propylene Price

slide-25
SLIDE 25

RESULTS – Regional Price Competitiveness

24

200 400 600 800 1000 1200 1400 1600 1800

North America Europe Asia RBC CBC Price Range (US$/t)

Propylene Price

$45 $40

slide-26
SLIDE 26

RESULTS – Economic Impacts of Scenarios

25

Economic Impacts BAU Total GDP Increase (USD Million) Total Tax Increase (USD Million) Jobs created Total Pay Increase (USD Million) Methanol 2020

  • 2030

5.69 0.88 16 0.46 2040 44.30 9.30 64 0.75 2050 107.02 28.27 103 1.21 Ammonia 2020

  • 2030

68.99 4.70 199 2.04 2040 261.22 20.49 376 3.83 2050 574.02 48.96 551 5.81 Ethylene 2020

  • 2030

134.10 53.41 386 4.27 2040 604.83 280.04 870 10.21 2050 1,528.16 777.57 1,466 18.35 Propylene 2020

  • 2030

15.77 5.38 45 0.61 2040 79.67 33.09 115 1.37 2050 204.22 96.83 196 2.50

slide-27
SLIDE 27

RESULTS – Economic Impacts of Scenarios

26

Economic Impacts MSG Total GDP Increase (USD Million) Total Tax Increase (USD Million) Jobs created Total Pay Increase (USD Million) Methanol 2020 4.01 0.62 115 0.63 2030 50.34 10.90 145 0.97 2040 131.79 35.50 190 1.57 2050 262.99 82.57 252 2.52 Ammonia 2020 7.45 0.37 214 1.17 2030 122.33 8.31 352 2.69 2040 357.91 28.05 515 4.54 2050 718.59 61.18 689 6.59 Ethylene 2020 26.63 8.31 766 4.17 2030 426.14 171.52 1,226 9.40 2040 1,288.35 593.25 1,854 17.25 2050 2,748.08 1,384.92 2,636 28.00 Propylene 2020 15.08 4.76 434 2.36 2030 194.07 76.83 559 3.80 2040 513.16 231.80 738 6.13 2050 1,019.11 504.83 978 9.62

slide-28
SLIDE 28

RESULTS – Economic Impacts of Scenarios

27

Economic Impacts HSG Total GDP Increase (USD Million) Total Tax Increase (USD Million) Jobs created Total Pay Increase (USD Million) Methanol 2020 6.39 1.23 184 1.00 2030 80.03 20.29 230 1.54 2040 208.95 62.80 301 2.48 2050 415.99 140.99 399 3.98 Ammonia 2020 14.91 0.85 429 2.34 2030 200.35 14.35 577 3.97 2040 522.11 41.95 751 5.96 2050 977.99 84.34 938 8.15 Ethylene 2020 48.62 15.66 1,399 7.62 2030 680.57 275.87 1,959 13.98 2040 1,891.42 871.36 2,722 23.52 2050 3,828.88 1,924.97 3,673 36.59 Propylene 2020 26.90 8.71 774 4.22 2030 336.63 135.50 969 6.46 2040 868.79 396.73 1,250 10.10 2050 1,693.17 844.49 1,624 15.56

slide-29
SLIDE 29

CONCLUSIONS

28

  • Tariffs on imports is a major driver of whether to import or produce

locally (relatively higher in Asian countries)

  • In terms of global trading opportunity, decreasing order would be:

methanol, ethylene, propylene, and ammonia

  • Lower emissions transportation is a major driver of methanol demand

growth

  • Many countries are going for self-sufficiency in ammonia production

due to its ties to agricultural sector for fertilizer production

  • A lot of countries with negative olefins trade balance, indicate

potential export opportunities

  • Export-focused olefins production might need to be in polymer form

for ease of movement to destination markets

  • Oil-based pathways may not be viable in Canada, still crude oil

access to market needed and future refinery-petrochemical investments integration maybe way forward

slide-30
SLIDE 30

QUESTIONS?

33

Please submit your text questions and comments using the Questions panel. A recording of the presentation will be sent to you following the event.

slide-31
SLIDE 31

UPCOMING EVENTS

34

Register at www.ceri.ca/events CERI 2020 Petrochemical Conference Petrochemicals and the Energy Evolution

slide-32
SLIDE 32

29

THANK YOU

Canadian Energy Research Institute ceri_canada Visit www.ceri.ca for the latest research

slide-33
SLIDE 33

Addendum – General Model Assumptions

30

Input Value OPEX inflation 2% Feedstock price inflation 2% Discount rate 10% Interest rate 3.5% Utilization factor 70% (Year 1), 80% (Year 2), 95% (Other) CAPEX allocation 20% (Year 1), 50% (Year 2), 30% (Year 3) Construction period 3 Years Operating period 27 Years Corporate tax AB (11%, 10%, 9%, 8% - all other years), SK (10%), NL (15%), Canada (15%)

slide-34
SLIDE 34

Addendum – Canadian Refining Capacity

31

479 67 318 130 392 402 130 100 200 300 400 500 600 Alberta British Columbia New Brunswick Newfoundland and Labrador Ontario Quebec Saskatchewan

Capacity Mb/d

slide-35
SLIDE 35

Addendum – Major Methanol Importers

32

500,000 1,000,000 1,500,000 2,000,000 2,500,000 3,000,000 3,500,000

Thousand USD

Imported value in 2015 Imported value in 2016 Imported value in 2017 Imported value in 2018 Imported value in 2019

slide-36
SLIDE 36

Addendum – Major Ammonia Importers

33

500,000 1,000,000 1,500,000 2,000,000 2,500,000 3,000,000 India USA South Korea Morocco China Belgium Turkey Germany Ukraine Taipei, Chinese France Mexico Norway Thailand Spain

Thousand USD

Imported value in 2015 Imported value in 2016 Imported value in 2017 Imported value in 2018 Imported value in 2019

slide-37
SLIDE 37

Addendum – Major Ethylene Importers

34

500,000 1,000,000 1,500,000 2,000,000 2,500,000 3,000,000 3,500,000

Thousand USD

Imported value in 2015 Imported value in 2016 Imported value in 2017 Imported value in 2018 Imported value in 2019

slide-38
SLIDE 38

Addendum – Major Propylene Importers

35

500,000 1,000,000 1,500,000 2,000,000 2,500,000 3,000,000 3,500,000

Thousand USD

Imported value in 2015 Imported value in 2016 Imported value in 2017 Imported value in 2018 Imported value in 2019
