Congoleum’s ArmorCore Sheet and Plank products provide solutions for builder and property management customers. With easy to understand, logical trade up features, installation options, and unparalleled performance backed by strong warranties, ArmorCore products are problem solvers.

SHEET & PLANK

SHEET PLANK ArmorCore ArmorCore Plank ArmorCore Pro ArmorCore Plank Pro ArmorCore UR ArmorCore Pro UR ArmorCore LC

ARMORCORE SHEET

• STYLE & VALUE ACROSS ANY SUBFLOOR

ArmorCore™ Sheet was designed specifically for the unique needs of the residential builder and multi-family property owner. ArmorCore sheet flooring provides a winning combination of resilience, aesthetics, durability and value. All ArmorCore Sheet products feature:

• A comprehensive warranty against asphalt tracking in both PVC and

Urethane constructions

• Tough wear layer and dense construction offering protection against rip,

tear, gouge and indent

• Universal Design delivers style that allows visual continuity across multiple

substrates

• Glue-free options for fast installation with no adhesive odors and minimal

disruption

• Designed and manufactured in the U.S.A. | HUD/FHA approved

Contributes to good indoor air quality as certified by Floor Score Proudly manufactured in the United States

Logical Trade-Up Story

Each ArmorCore product has logical feature and benefit values that provide an easy to understand and logical reasons to trade up.

Both ArmorCore and ArmorCore Pro have a PVC wearlayer, which has excellent performance properties. The other ArmorCore products have a urethane wear surface featuring an exclusive Stain Defense System. This enhanced urethane with Stain Defense System makes the surface the easiest to clean, maintain, and extends the life of the floor.

ArmorCore Pro, Pro UR and LC are produced with UltraTec construction. This construction provides versatility, durability, convenience and cost savings. . Unlike fiberglass sheet products that are filled with air UltraTec’s dense construction gives ArmorCore products exceptional rip, tear and gouge resistance. Finally, UltraTec’s installation options provide time and cost savings.

All ArmorCore products have outstanding stain resistance. In fact, we are so confident that ArmorCore and ArmorCore Pro’s PVC wearlayer resists tar and asphalt tracking that we warrant it.

KEY FEATURES AND BENEFITS OF ARMORCORE SHEET PRODUCTS FEATURE BENEFIT Felt & UltraTec Construction

• Rip, tear & gouge resistance
• Reduced callbacks

FloorScore Certified Good Indoor Air Quality HUD/FHA Approved Meets building codes Manufactured in the US Provides American Jobs

ARMORCORE

FEATURE BENEFIT White Shield Backing with Bac-Stop Protecton

• Flexible and easy to handle during

installation

• Resists cracking and tearing during

Installation

• Installs on all grade levels
• Will not discolor from mold, mildew
• r alkali created by moisture from

concrete subfloors Your Choice Installation System

• Saves subfloor costs with fully

adhered or perimeter fastened installation options 6’ and 12’ Widths

• Fewer seams & less waste

Patented wearlayer fusion process

• Best stain resistance of any

comparably price product

• Resists asphalt tracking

5 Year Warranty

• Confidence in product performance
• Consumer satisfaction

Installation Adhesive Congoleum 03044 Seam Sealer Congoleum SU80 or SU92

ARMORCORE PRO

FEATURE BENEFIT UltraTec Construction with Bac-Stop Protection and no- buckle guarantee

• Flexible and easy to handle during installation
• Resists cracking and tearing during

Installation

• Installs on all grade levels
• Will not discolor from mold, mildew or alkali

created by moisture from concrete subfloors

• Lays flat, stays flat without adhesive

Your Choice Plus Installation System

• Saves subfloor costs with fully adhered, loose

lay or perimeter fastened installation options 6’ and 12’ Widths

• Fewer seams & less waste

Patented wearlayer fusion process

• Best stain resistance of any comparably price

product

• Resists asphalt tracking

5 Year Warranty

• Confidence in product performance
• Consumer satisfaction

Installation Adhesive Congoleum AS01 or QuikStik Tape Seam Sealer Congoleum SU80 or SU92

ARMORCORE UR

FEATURE BENEFIT White Shield Backing with Bac-Stop Protecton

• Flexible and easy to handle

during installation

• Resists cracking and tearing

during Installation

• Installs on all grade levels
• Will not discolor from mold,

mildew or alkali created by moisture from concrete subfloors Your Choice Installation System

• Saves subfloor costs with fully

adhered or perimeter fastened installation options 6’ and 12’ Widths

• Fewer seams & less waste

Scuff-Tuff™ Urethane wearlayer

• Superior stain resistance
• Resists asphalt tracking
• Scuff resistant

10 Year Warranty

• Confidence in product

performance

• Consumer satisfaction

Installation Adhesive Congoleum 03044 Seam Sealer Congoleum SU106

ARMORCORE PRO UR

FEATURE BENEFIT UltraTec Construction with Bac-Stop Protection and no-buckle guarantee

• Flexible and easy to handle

during installation

• Resists cracking and tearing

during Installation

• Installs on all grade levels
• Will not discolor from mold,

mildew or alkali created by moisture from concrete subfloors

• Lays flat, stays flat without

adhesive Your Choice Plus Installation System

• Saves subfloor costs with fully

adhered, loose lay or perimeter fastened installation options 6’ and 12’ Widths

• Fewer seams & less waste

Scuff-Tuff™ Urethane wearlayer

• Superior stain resistance
• Resists asphalt tracking
• Scuff resistant

10 Year Warranty

• Confidence in product

performance

• Consumer satisfaction

Installation Adhesive Congoleum AS01 or QuikStik Tape Seam Sealer Congoleum SU106

The Main Street Commercial Market continues to see consistent growth. ArmorCore LC offers a perfect solution for those main street needs.

Main Street Commercial Sheet Market 9 10 11 12 13 14 2012 2013 2014 2015 2016 2017 2018 2019 2020

MM SY

ArmorCore LC

ArmorCore LC

Construction: UltraTec Construction - 82 mil Overall gauge Wearlayer: 20 mil Vinyl Resin and Urethane, featuring Stain Defense System (SDS) and Silver Antibacterial Protection Impact Insulation Class IIC Rating: 52 Warranty Coverage: ArmorCore 25 Year Residential Limited Warranty ArmorCore 5 Year Light Commercial Limited Warranty Installation Method: Residential: Your Choice Plus Loose, Perimeter or Fully Adhered over Approved Wood, Concrete, and Qualifying Existing Resilient Floors Light Commercial: Fully Adhered over Approved Wood, Concrete, and Qualifying Existing Resilient Floors

Light Commercial Intended Application

• Home and multi-family dwellings
• Assisted Living residential units
• Hospitality guest rooms and bathrooms
• Military Housing
• Privately owned business to include:
• Day Care Centers
• Doctor / Dentist / Veterinary Offices
• Beauty Salons / Barber Shops
• Small retail stores

Light Commercial Non-Intended Application

• Applications where commercial maintenance machines are used
• Applications subject to heavy rolling loads
• Heavy commercial applications, for example:
• Education / Institutional
• Hospitals / Healthcare
• Large Retail / Mercantile
• Corporate Offices
• Hospitality lobbies and common areas

ArmorCore LC

Full Spread Perimeter Fasten Loose Lay Full Spread Perimeter Fasten Loose Lay Double layer plywood construction over joists or trusses

√ √ √ √ √

Single Layer Sturd-I-Flor

√ √ √

Hardwood or Stripwood

√ √ √

Oriented Strand Board

√ √ √

NPA Rated Particleboard

√ √ √

Existing, smooth, well bonded resilient flooring

√ √ √ √ √

Concrete

√ √ √ √ √

Gypsum Topping

√ √ √ √ √

Common Substrates ArmorCore / ArmorCore UR

WHITE SHIELD FELT ULTRATEC

ArmorCore Pro / ArmorCore Pro UR / ArmorCore LC

Style and Value Across Any Subfloor ArmorCore™ was designed specifically for the unique needs of the residential builder and multi-family property owner. ArmorCore sheet flooring provides a winning combination of resilience, aesthetics, durability and value.

DESIGN PACKAGE We have made the design selection with input from builders and property management sources. This is a well-rounded offering with wood and tile looks that will resonate extremely well in those market segments. The designs for both ArmorCore Plank and ArmorCore Plank Pro are the same as some of the best-selling corresponding patterns in Triversa Prime. While the patterns may be the same, there will be differences in some of the patterns in the size. For example, the TX700 and TX701 Carrara Marble designs in Triversa Prime are 6” x 36” and 18” x 48” respectively. We used that same TX701 (18” x 48”) design in ArmorCore, but changed the format to 12” x 24”.

ARMORCORE PLANK AND PLANK PRO

ArmorCore Plank ArmorCore Plank Pro

Pattern PL002, PL010, PL050, PL061, PL081, PL180, PL900 PL400, PL401, PL700 PR002, PR010, PR050, PR061, PR081, PR180, PR900 PR400, PR401, PR700 Nominal Plank Size 7” x 48” 12” x 24” 7” x 48” 12” x 24” Edges Square Square Micro Bevel Micro Bevel Pieces Per carton 16 20 12 14 Coverage per carton 40.67 sq. ft. (3.78 m²) 42.04 sq. ft. (3.91 m²) 28.52 sq. ft. (2.65 m²) 28.04 sq. ft. (2.61 m²) Weight per carton 31.92 lbs. (14.48 kg) 32.96 lbs. (14.95 kg) 42.09 lbs. (19.9 kg) 41.4 lbs. (18.78 kg) Cartons per pallet 70 66 55 48 Square Feet per pallet 2,847.1 2,774.9 1,568.8 1345.8 Pallets Per Container 18 19 18 21 Square Feet per Container 51,247 52,723 28,238 28,261

Sound Properties

ArmorCore Plank ArmorCore Plank Pro

MATCHING TRANSITIONS Both ArmorCore Plank and Plank Pro have these matching Transition profiles Universal Transition Stair Nosing Quarter Round

The ArmorCore collection

• f

sheet and LVT products delivers solutions for the builder, property management and main street markets. With quality products at affordable price points, the strong ArmorCore lineup has affordable products to fit any need.

ARMORCORE ARMORCORE UR ARMORCORE PLANK PRO

SOLUTIONS
