Dust Removal Systems Work Safe, Stay Healthy, Improve Productivity - - PowerPoint PPT Presentation

1 www.hilti.com Dust 2009

Dust Removal Systems

Work Safe, Stay Healthy, Improve Productivity

3 www.hilti.com Dust 2009

Dust Chamber Video

11 www.hilti.com Dust 2009

Have you ever considered….

• The comfort and protection of the
• perator and adjacent personnel?
• Regulatory compliance and Risk?
• How does this impact the life of the tool

and consumables?

• The drilling/cutting speed of the tools?
• Jobsite preparation and cleaning –

productivity?

• The environment?

Up to 2.20 lbs of dust are produced with five minutes sawing / cutting. Now imagine working like this for one hour. Or a full day. Consider:

12 www.hilti.com Dust 2009

What’s Missing?

13 www.hilti.com Dust 2009

Inhalable dust: Trapped in mouth and nose thoracic dust: Trapped in upper part of the airway Respirable dust: penetrates deep into the lungs (alveole)

reference: www.lungenaerzte-im-netz.de; www.atmosphere.mpg.de

• Distinction of size
• inhalable dust
• thoracic dust
• respirable dust

What is dust? 2 1 3

14 www.hilti.com Dust 2009

General dust Base material 10 mg/m³ Wood dust

• Sweden 5 mg/m³
• Germany 2 mg/m³
• France 1 mg/m³
• NIOSH: 1 mg/m³

3 mg/m³ 1.25 mg/m³ Silica dust

• most EU: 0.1 mg/m³
• Netherland:0.075 mg/m³
• Italy/NEPSI: 0.05 mg/m³
• OSHA: 0.05 mg/m³

Inhalable dust I-Dust Respirable dust R-Dust

What is dust? Size and Type 2 1 3

15 www.hilti.com Dust 2009

OSHA’s Occupational Exposure Limits for Silica

* Note: 8-hr TWA, unless otherwise noted

Source Type Limit (mg/m3)* Cal/OSHA §5155 Total Respirable 0.3 0.1 Fed/OSHA §1910.1000 Z-3 table

* Proposed Change May 2013

Total Respirable 30/(%quartz + 2) 10/(%quartz + 2)

* 0.05 to 0.1 Estimated.

ACGIH Respirable 0.025 (adopted 2006)

16 www.hilti.com Dust 2009

What is dust?

Typ of dust Diameter of dust (EN 481) AGW – Germany (TRGS 900) Other countries < 100 µm 10 mg/m³ same or higher < 10 µm (3 mg/m³) 1,25 mg/m³ same or higher

Inhalable dust I-Dust Respirable dust R-Dust

Note: We don’t speak about chemicals, asbestos fibers, welding fumes or mould spores. Country

I-dust R-dust

Austria

10 5

France

10 5

Germany

10 3

Italy

10 3

Portugal

10 5

Spain

10 3

Sweden

10 5

U.K.

10 4

Switzerland

10 3

U.S.

15 5

2 1 3

17 www.hilti.com Dust 2009

Occupational Expose Limit [mg/m³]

Stat I-Dust R-Dust Silica Stat I-Dust R-Dust Silica Austria 10 5 0.15 Luxembourg 10 (D) 3 (D) (0.15) (D) Belgium 10 3 0.1 Malta

• - (10) (UK) -- (4) (UK)
• - (0.1) (UK)

Bulgaria 10 3.5 0.07 Netherlands 10 5 0.075 Cyprus 10 5 0.1 Poland 10 0.3 Czech Rep. 10 0.1 Portugal 10 5 0.1 Denmark 10 5 0.1 Romania 10 3 0.1 Estonia 10 5 0.1 Slovakia 10 0.1 Finland 10

• 0.2

Slovenia 0.15 France 10 5 0.1 Spain 10 3 0.1 Germany 10 3 (0.15) Sweden 10 5 0.1 Greece 10 5 0.1 UK 10 4 0.3 / 0.1 Hungary 10 6 0.15 Iceland 10 5 Ireland 10 4 0.05 Norway 10 5 0.1 Italy 10 3 0.05 Switzerland 10 3 0.15 Latvia 10 (CH) 3 (CH) 1 NZ 10 3 Lithuania 10 5 0.1 US 15 5 0.1 (0.05 …)

18 www.hilti.com Dust 2009

Grinding in Test Lab

19 www.hilti.com Dust 2009

Control of Concrete & Masonry Dust in Construction – CalOsha

20 www.hilti.com Dust 2009

Cal OSHA

Goal is to control employee exposure to airborne particulate during

• perations in which powered tools or equipment are used to cut, grind,

core or drill concrete or masonry materials.

21 www.hilti.com Dust 2009

Cal/OSHA Requirements

During operations in which powered tools or equipment are used to cut, grind, core, or drill concrete or masonry materials, a dust reduction system shall be applied to effectively reduce airborne particulate. Local exhaust ventilation systems must be used in accordance with manufacturer recommendations. Dust reduction systems must be maintained and effective.

22 www.hilti.com Dust 2009

Cal/OSHA Requirements - Definitions

Dust containment device – a device attached to a power tool such as a pouch, bag, plastic container, or similar attachment which is intended to capture dust generated by the tool. Dust reduction system – technology that utilizes the application of water or local exhaust ventilation to reduce airborne dust generated by the use of powered tools or equipment. Local exhaust ventilation may include vacuum systems, dust collection systems, and dust exhaust systems.

24 www.hilti.com Dust 2009

Exemptions

Plastering operations Powder-actuated tool work Downward drilling Work incidental to the installation of concrete work Wall Siding

25 www.hilti.com Dust 2009

26 www.hilti.com Dust 2009

Cal/OSHA Requirements

Employee Training – all employees covered by this standard must be trained at least annually in the following topics:

• Potential Health Hazards
• Methods used by the employer to control exposure of dust
• Use and maintenance of dust reduction systems
• Personal hygiene

27 www.hilti.com Dust 2009

Cal/OSHA Requirements

Supervisor Training – must be trained initially on tasks that lead employees to exposure and procedures for reducing employee risk. Training must be refreshed at least annually. Training must be documented

28 www.hilti.com Dust 2009

Respirator Requirements

A respirator should be worn when exposed to silica dust (in addition to engineering controls). Respirator use requires compliance with OSHA Regulations

• Current medical evaluation – annually
• Current fit test
• Training

29 www.hilti.com Dust 2009

Health Risks

Exposure to harmful dust may lead to: Silicosis

• Lung cancer

– Crystalline silica is a carcinogen. Over exposure to silica dust may cause lung cancer.

• Chronic Obstructive Lung Disease (COPD)

– Over exposure to silica dust may cause COPD.

• Decreased lung function

– Over exposure to silica may cause scarring of the lungs and decreased lung function. All of these are 100% preventable!

32 www.hilti.com Dust 2009

• 1. Hilti Consumables
• air turbulence and air flow are

defined exactly by the special shape and design of the tool

• built-in DRS air channels extract the

dust right at its source

• for best-possible dust removal

performance

• 2. Hilti Power Tool Design
• advanced ergonomic design captures

dust the moment it is generated

• optimized air-flow inside the

tool’s built-in dust removal hood

• the dust removal efficiency extends life
• f cutting discs, improves cutting

performance

• 3. Hilti Accessories
• extremely robust and durable
• keyless quick-release mounting

system

• dual-chamber dynamic air-flow

system

• compact and very convenient
• 4. Hilti Vacuum Cleaners
• combination of a small, mobile

and robust vacuum cleaner with continuous high suction performance

• new filter technology briefly reverses the

flow of air inside the system and thus blasts the filter clean every 15”

Hilti Dust Removal Systems

Four components – one winner

All system components, including power tools, drill bits, discs, blades or other accessories as well as fully integrated systems, are perfectly matched to maximize the amount of dust removed at its source and collected efficiently by the vacuum removal system.

33 www.hilti.com Dust 2009

Dust class

L (light hazard) M (medium hazard) H (high hazard)

Suitability for hazardous dust with limit values for occupatio- nal expose

> 1 mg/m³ > 0.1 mg/m³ < 0.1 mg/m³

Including carcinogenic dusts and dusts contaminated with carcinogens and/or pathogens Test material test (essential filter) element test (essential filter) Assabled applience material test (essential filter) element test (essential filter) Assabled applience material test (essential filter) element test (essential filter) Assabled applience Filtration efficiency

99 %

• 99.9 %
• 99.9 %
• 99.995%

99.995%

Test methode (Aerosol size) AA.22.201.1 (0.2-2µm) AA.22.201.1 (0.2-2µm) AA.22.201.3 (10%: <1µm) (22%: <2µm) (75%: <5µm) AA.22.201.2 (< 1µm) AA.22.201.3 (10%: <1µm) (22%: <2µm) (75%: <5µm) Product features

• Indicator

(air velocity < 20 m/s)

• Safe change filter
• Fitted with disposable

collection means

• Indicator

(air velocity < 20 m/s)

• Safe change filter
• Fitted with disposable

collection means

• Non-reusable

essential filter

• Essential filter only

removable by the use

• f a tool

Re Requirem irements ts fo for r va vacuum m clea leaners rs fo for r th the co coll llection tion of

• f

du dusts sts ha hazard zardou

• us

s to to hea health IE lth IEC C 60 6033 335-2-69 69

34 www.hilti.com Dust 2009

Re Requirem irements ts fo for r va vacuum m clea leaners rs and fi filter lter ma mate terials rials

vacuum cleaner filter material (“HEPA”)

(IEC 60335-2-69)

EU (EN 1822) US (UL 586)

Dust class Filtration efficiency Filter type Filtration efficiency (@ MPPS) Filter type Filtration efficiency (@ 0,3 µm)

EPA E 10 85 % HEPA 99,97 % E 11 95 %

L

(light hazard)

99 % E 12 99,5 %

M

(medium hazard)

99,9 % HEPA H 13 99,95 %

H

(high hazard)

99,995 % H 14 99,995 % ULPA U 15 99,9995 % U 16 99,99995 % U 17 99,999995 %

EPA: Efficient Particular Air Filter (E 10 – E 12) HEPA: High Efficient Particular Air Filter (H 13 – H14) ULPA: Ultra Penetration Air Filter (U 15 – U 17)

35 www.hilti.com Dust 2009

Why working virtually dust-free makes sense

no DRS

Tool Lifetime1

no DRS

Consumable Lifetime2

no DRS

Application Speed3

~3.5 oz ~35 lbs

no DRS Cleaning Effort

Longer Lifetime Labour Time Savings

1 Life-expectancy test with a Hilti DCH 230 cutter: The dust

resistance of the carbon brushes was tested in a dust chamber. Without Hilti DRS, the carbon brushes had to be changed for the first time after approx. 85 hours. In comparison, in dustless conditions, the same power tool ran for approx. 140 hours in the same test chamber before the brushes needed changing for the first time. Please note: Tests conducted on a test rig are not always directly comparable with real-life conditions. Results may differ based on operator technique, specific application and tool combination.

2 Life-expectancy test of disc with a Hilti DCH 230 cutter:

Hyosung M1 111007 Light Duty, without and with dust

• extraction. 230 mm cutting disc performance, KSV Augsburg,

system test (5600 rpm, 7 cm cutting depth). Please note: Tests conducted on a test rig are not always directly comparable with real-life conditions. Results may differ based on operator technique, specific application and tool combination.

3 Relative comparison with and without dust removal system,

DCH 230, system test (5,600 rpm, 7 cm cutting depth, concrete KSV Augsburg) Please note: Tests conducted on a test rig are not always directly comparable with real-life conditions. Results may differ based on operator technique, specific application and tool combination

37 www.hilti.com Dust 2009

Hilti Dust Reduction Systems have a positive impact on both tool and consumable lifetime

no DRS

Tool Lifetime1

no DRS

Consumable Lifetime2

Proven in multiple tests that dust has a negative impact on performance and lifetime on brushes and electronics Proven that DRS can have a positive impact on performance and lifetime on consumables Reason: Removal of old dust particles and air stream cooling improves life and speed

*Positive correlation so far found in different diamond consumables

1 Life-expectancy test with a Hilti DCH 230 cutter: The dust resistance of the carbon brushes was tested in a dust chamber. Without Hilti DRS, the carbon brushes had to be changed for

the first time after approx. 85 hours. In comparison, in dustless conditions, the same power tool ran for approx. 140 hours in the same test chamber before the brushes needed changing for the first time. Please note: Tests conducted on a test rig are not always directly comparable with real-life conditions. Results may differ based on operator technique, specific application and tool combination.

2 Life-expectancy test of disc with a Hilti DCH 230 cutter: Hyosung M1 111007 Light Duty, without and with dust extraction. 230 mm cutting disc performance, KSV Augsburg, system test

(5600 rpm, 7 cm cutting depth). Please note: Tests conducted on a test rig are not always directly comparable with real-life conditions. Results may differ based on operator technique, specific application and tool combination.

38 www.hilti.com Dust 2009

Hilti DRS brings significant productivity gains

no DRS

Application Speed3

~3.5 oz ~35 lbs

no DRS Cleaning Effort

No time studies performed so far Tests show: Total amount of concrete dust in the surrounding after 1h application is ~ 35lbs w/o DRS and ~3.5oz with Hilti DRS

(DC 20-SE + VC 40-UM)

Proven that DRS can have a positive impact on performance and lifetime on consumables Reason: Removal of old dust particles and air stream cooling improves life and speed

*Positive correlation so far found in different diamond applications

3 Relative comparison with and without dust removal system, DCH 230, system test (5,600 rpm, 7 cm cutting depth, concrete KSV Augsburg) Please note: Tests conducted on a

test rig are not always directly comparable with real-life conditions. Results may differ based on operator technique, specific application and tool combination

39 www.hilti.com Dust 2009

Hilti dust removal systems reduce dust exposure tremendously (drilling example)

Wit ithout hout dust dust r remo emoval val

TE TE 6-S S wit ith DR DRS-M

+

Sources: „Technischer Bericht 71316342 + 70094644“, TÜV Product Service, April 2005, March 2007

TE TE 6 6-S Wit ith h dust dust remo emoval val

Reduction ion of respir spirable le dust st by y factor 12

+

Reduction ion of respir spirable le dust st by y factor 32

+

Reduction ion of respir spirable le dust st by y factor 86

TE TE 56 56 TE TE 7 7-A

TE TE 7 A A wit ith DR DRS-M TE TE 56 w wit ith DRS-S S and VCD 40-M M vac vacuum

40 www.hilti.com Dust 2009

HY 200 video

41 www.hilti.com Dust 2009

Optimized air-flow due to specific geometries

• f insert tools

Optimized hood protections for dry cutting, grinding, sawing and drilling High performing HEPA Vac´s with automatic filter cleaning technology

Dus Dust t Rem emova val S l Sys ystem tems

+ +

Hilti dust removal systems reduce the exposure to respirable dust massively

43 www.hilti.com Dust 2009

Convertible

For most concrete dust applications we provide a tool and a DRS solution…

Cutting & Grinding Cutting & Slitting Drilling & Breaking

Convertible Integrated

Grinding

Vacs to complete the system DRS Accessories

Jig Sawing Drilling Core Drilling

DRS Accessories

44 www.hilti.com Dust 2009

…and we also offer “alternative methods”

Alternative to manual and breaker demolition

Vacs to complete the system

Alternative Methods

DX

Alternative to Drilling and Anchor setting

GX Wet Drilling Wet Sawing

46 www.hilti.com Dust 2009

Innovation TE 70 ATC

47 www.hilti.com Dust 2009

Hilti can help achieve substantial productivity gains with an unmatched offer

Why “Dust-control”*? Why Hilti?

Worker Protection

• Lifetime of power tools
• Lifetime of consumables

Labour Time Savings Increased Lifetime

• Higher application speed
• Reduced clean-up time
• Fewer Breakdowns
• Health & Safety
• Pure Comfort
• Higher visibility

Full Systems Service and competence Broad Offer

• Superior performance
• Full compatibility
• Allow future DRS add on
• All relevant applications
• One partner needed
• Alternative methods
• LTS and FM
• The right solution
• H&S training

Productivity – Getting the job done faster, on time, no re-work, clean = more profit

* Note: Working virtually dust-free

50 www.hilti.com Dust 2009

Tuck Pointing

51 www.hilti.com Dust 2009

Hilti Dust Removal Systems (DRS) for dry diamond grinding, tuck points, cutting, grinding

Concr Concrete ete grinding rinding

DG DG syst systems ms wit ith adjust justable le dust st hoo hood soluti solution

Tuc uck Point

• int

5” Tuck Point Dust Hood

Wit ith h Hilt Hilti i DR DRS (Dust (Dust Remo emoval val Syst System) em)

+

Hilti ilti saf afety ety clas lass a appr pproved ed HEPA A Vacuum acuum Cleaner Cleaners with ith automa automatic tic air f air filter ilter

Des Designed igned to meet to meet t the he limit limits

 High Highest est co constan nstant s t suc uction tion po power er  For co

• r conc

ncrete ete an and w d woo

• od

d du dust st  Univ Univer ersal sal for dr

• r dry a

y and w nd wet et use use

Cut Cutting ting and and Gr Grinding inding

53 www.hilti.com Dust 2009

Slitting / Cutting

Key Application Key Trade Hilti DRS solution Deep in-wall installation of conduits, pipes, small wall/floor openings or enlargements

DCH 230/DCH 300 DC-D 9“ / DCH – D 12“

M&E

VC 20-U / VC 40-U

M&E BC

DC-D 9“ / DCH – D 12“ DCG / DEG 125 DC-D 5“ C1 DC-EX 125 VC 20-U / VC 40-U

Small wall/floor openings or enlargements Adjusting slabs, bricks, blocks

VC 20-U / VC 40-U

54 www.hilti.com Dust 2009

Diamond cutting

55 www.hilti.com Dust 2009

Hilti Dust Removal Systems for dry diamond coring and sawing

Des Designed igned to meet to meet t the he limit limits Wit ith h Hilt Hilti i DR DRS (Dust (Dust Remo emoval val Syst System) em) Hand Hand Sawing Sawing

DC DCH s syst ystems ms w wit ith int integrated protection ion hoods

Dr Dry Cor Coring ing

DD DD dr dry y coring syst ing systems ms wit ith dust st-hose co se connection ion

Wood

• od

saw sawing ing

WSC WSC syst systems ms w wit ith dust st-hose se connection ion

+

Hilti ilti saf afety ety clas lass a appr pproved ed HEPA A Vacuum acuum Cleaner Cleaners with ith automa automatic tic air f air filter ilter

 High Highest est co constan nstant s t suc uction tion po power er  For co

• r conc

ncrete ete an and w d woo

• od

d du dust st  Univ Univer ersal sal for dr

• r dry a

y and w nd wet et use use

58 www.hilti.com Dust 2009

Demolition

59 www.hilti.com Dust 2009

Hilti Dust Removal Systems (DRS) for demolition

Demolit Demolition ion Wit ith h Hilt Hilti i DR DRS (Dust (Dust Remo emoval val Syst System) em)

+

Hilti ilti saf afety ety clas lass a appr pproved ed HEPA A Vacuum acuum Cleaner Cleaners with ith automa automatic tic air f air filter ilter

Des Designed igned to meet to meet t the he limit limits

 High Highest est co constan nstant s t suc uction tion po power er  For co

• r conc

ncrete ete an and w d woo

• od

d du dust st  Univ Univer ersal sal for dr

• r dry a

y and w nd wet et use use

62 www.hilti.com Dust 2009

AVR of TE 6-A36 DRS for TE 6-A36

• Decoupled handle system: more

reliable vs. DeWalt system

• Vibration level: 9 m/s2
• Weight of AVR system only 100g
• Compact design, with built-in motor

to optimize on capacity per charge

• f battery-pack
• Dust removal rate > then TE DRS-M
• Capacity of dust box: 20 holes; Ø 12

New TE 6-A36 cordless rotary hammer with leading solution against dust (DRS) and vibration (AVR)

63 www.hilti.com Dust 2009

The new TE DRS-6-A offers multiple advantages

Easy to use Compact Low energy consumption

Cross-marking for precise drilling

• 1st button: Define drilling depth
• 2nd button: Adjust to drill-bit length

1st button 2nd button

64 www.hilti.com Dust 2009

TE60 TE60 – op

• pti

timiz mized ed system system for

• r du

dust f st free ee coring coring

Total dust free coring solutions  new DRS for HBK and chisels Productivity, Safety AVR (decoupled handgrip)  Outperform: working comfort ATC  Outperform: Low injury risk (safety)

65 www.hilti.com Dust 2009

New New HB HBK K to op to opti timiz mize du e dust r st remo emova val l rate te

• New design for increased lifetime

eliminate breakages

• Improved center bit fixing to eliminate

loosing

• Ideal carbide position for easy core

disposal

• Dust free coring via DRS-BK

66 www.hilti.com Dust 2009

Br Broa

• ad

d syste system o m offering ering t to

• gu

guar aran antee tee max maximum imum ver ersa sati tili lity ty for

• r the

the end end use user

68 www.hilti.com Dust 2009

Thank you for your attention!
