Duqm, strategically located at entrance of Arabian Gulf, and on the trading route of Europe and Asia. Duqm Master Plan Quay 2,800 m Workshops: Graving Dock & Floating Dock: Hull shop Pipe Outfit shop Dock No.1 410 m x 95 m 600,000

SLIDE 1

SLIDE 2

Duqm, strategically located at entrance of Arabian Gulf, and on the trading route of Europe and Asia.

SLIDE 3

Duqm Master Plan

SLIDE 4

Quay 2,800 m Workshops:

Hull shop Pipe Outfit shop Machinery shop Cryogenic shop Blasting Paining shop Electric shop

Graving Dock & Floating Dock:

Dock No.1 410 m x 95 m 600,000 DWT Dock No.2 410 m x 80 m 500,000 DWT Floating Dock Panamax 80,000 DWT

(planned)

Jib Cranes:

100 T x 74 M 1 Set 80 T x 74 M 1 Set 40 T x 74 M 12 Sets

SLIDE 5

Shop Area – Front View

SLIDE 6

Shop Area – Back View

SLIDE 7

Shop Area – Back View Electric Shop

SLIDE 8

Blasting & Painting

Size: 25 m x 25 m: Providing best quality of blasting & painting work for:

Hatch covers,
Panels,
Blocks,
Steel structures.

SLIDE 9

Hull Processing Shop

Size: 200 m x 35 m:

Cutting bay,
plasma & Oxygen machine.
Bending bay,
Plate, Frame bending and Line

Heating.

Sub Assembly bay,
Block Assembly bay.

SLIDE 10

Machinery Shop

Size: 100 m x 30 m

Cryogenic Shop

Size: 20 m x 30 m Machines : Lathe for VLCC Shaft (12m long) Horizontal Boring & Milling Machine HYD‘ Cylinder Grinder Turning Center Machine

SLIDE 11

Pipe & Outfitting Shop

Size: 200 m x 30 m

Piping bay
Outfitting bay

Machines : Pipe Bending Machine Turning Roller Machine Positioner Machine Pipe Cutting Machine Facing Machine Roll Bending Machine Table Drill & Bench Grinder

SLIDE 12

Electric Motor Shop

Size: 50 m x 20 m

SLIDE 13

Slop Sludge Reception Terminal

ODC will take the slops of tankers upon arrival at slop reception terminal in shipyard premise for

ne-stop-service.

SLIDE 14

Business Scope:

Ship Repair & Conversion with technical support from DSME.

SLIDE 15

Business Scope: (Ship Repair)

A capacity to repair over 200 ships per year, including vessels as large as ULCCs.

SLIDE 16

Business Scope: (Conversion)

FPSO, Drillship, Lengthening, FSRU, Pipe Laying, Double Hull.

SLIDE 17

Business Scope: (Steel Fabrication)

Steel fabrication of structures, components and piping.

SLIDE 18

ODC ADVANTAGES:

Entrance of Arabian Gulf
One-Stop Service
Slop Reception Facility
Ideal Climate for Painting Work
Modern Facilities
