SLIDE 1

Everybody Into the Data Lake!

Gail Radecki, CHCP, American Academy of Allergy Asthma & Immunology Ezra Wolfe, EthosCE Devin Zuczek, EthosCE

Drupal as a Data Warehouse

SLIDE 2

Above all else, show the data

Edward Tufte

“ “

SLIDE 3

My name is Gail…

Pushy
A know-just-enough
Annoying

...and I’m one of “those” customers.

SLIDE 4

The World of Continuing Medical Education

Accreditation/Compliance
Needs Assessment
Grants Reconciliation

SLIDE 5

Data reporting...stayed the same

SLIDE 6

This is where Community comes in handy

EthosCE User Group
Support tickets
Online Community

SLIDE 7

The Importance of Outcomes

Medical Specialty Society
Needs assessment
Accreditation

SLIDE 8

We need a solution!

SLIDE 9

My name is Ezra. I am the product manager. This is a me with a bad haircut.

SLIDE 10

The Product:

65+ hospitals, health systems, associations
Almost 1 million learner accounts
7.9 million course enrollments

SLIDE 11

All happy families customers are alike; each unhappy family customer is unhappy about their reports.

Leo Tolstoy

“ “

SLIDE 12

Existing process

1. Customer requests a new report
2. Requirements
3. Development feasibility
4. Back and forth with customer
5. Make the view, put it in code
6. Change management, code review, documentation, tests
7. Custom report is deployed! We are done!
8. Repeat steps #1-7 again because "that" customer forgot something
9. Repeat steps #1-7 again later because of a product schema change

SLIDE 13

My name is Devin and I am a systems architect. Throwback to PHP 4? This is a duck.

SLIDE 14

Big data!!!

Phase 1 Big data Phase 2

?

Phase 3 Profit!

SLIDE 15

Making a plan

Previous solutions involved a suite of modules:

Views, Homebox, Charts + HighCharts, Views Data Export.

Building our own tool would have been a distraction

from our core business — we are not data scientists.

We needed a tool that we could give to customers

to report on their own data instead of us doing it.

SLIDE 16

Vendor selection

Vendors don’t know about...

○ Drupal ○ php serialization ○ webform

It’s your job to do your due diligence and

ensure you select the correct system

SLIDE 17

BYODW?

(Bring your own data warehouse?)

SLIDE 18

Did I mention where I work??

Non-profit
Tech maintenance vs. adding features
We have to justify EVERYTHING

SLIDE 19

SLIDE 20

First steps

Could we point a tool at Drupal and have it report
ut of the box?
Do we need a data warehouse?

To answer the question of why reporting on Drupal data in its native form is not optimal, we have to look at how the data is stored.

SLIDE 21

DBA 101: Tables

U. Corp. changed their name. Making this change requires...

people user_id name employer_name 1 Barry Cuda

U. Corp.

2 Abby Normal Gekko & Co. 3 Rita Book

U. Corp.

4 Ray O’Sun

U. Corp.

SLIDE 22

DBA 101: Tables

U. Corp. changed their name. Making this change requires...

3 row updates. Not good at scale, as this will lock those rows for editing!

people user_id name employer_name 1 Barry Cuda Initech 2 Abby Normal Gekko & Co 3 Rita Book Initech 4 Ray O’Sun Initech

SLIDE 23

Normalizing

Eliminate columns with duplicate data by creating separate tables, and identify that data with a key. Move data that is not relevant to the primary key.

People uid name employer_name 1 Barry Cuda Initech 2 Abby Normal Gekko & Co 3 Rita Book Initech People uid name eid 1 Barry Cuda X 2 Abby Normal X 3 Rita Book X Employer data eid name 5 Initech 6 Gekko & Co. Employer relation uid eid 1 5 2 6 3 5

SLIDE 24

DBA 201: Normalizing

How do we efficiently store a user, full name, location, and employer?

User user_id user_name 1 john 2 jane Profile profile_id user_id 2 1 3 2 Location loc_id province country 3 PA US 4 NJ US Profile location profile_id loc_id 2 3 3 4 Profile name profile_id fullname 2 John Smith 3 Jane Doe Profile employer profile_id emp_id 2 6 3 7 Employer employer_id name 6 A, LLC. 7 D Corp No data is unnecessarily dependent. An update only requires 1 write.

...that includes the database!

SLIDE 25

The problem

Operational database

Fast writes
Holds data
Relational model not

informative

Built for integrity

Reporting database

Fast, easy reads
Holds information
Relational model more

informative to users

— E.F. Codd, "Further Normalization of the Data Base Relational Model

SLIDE 26

Another module

SLIDE 27

Denormalizer module

This module pulls from Drupal defined schema to programmatically build denormalized tables or views for use in data warehousing flows. Example: A node of type “chinchilla” with a rate field. We could also request the raw vote table. 1. Denormalized table name 2. Entity/table to denormalize 3. The primary key to use 4. The changed key to use

SLIDE 28

SELECT * FROM...

developlocal.drupal_node dn_course LEFT JOIN developlocal.drupal_field_data_field_course_rating_access field_course_rating_access ON field_course_rating_access.entity_type = 'node' AND field_course_rating_access.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_catalog field_course_catalog ON field_course_catalog.entity_type = 'node' AND field_course_catalog.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_date field_course_date ON field_course_date.entity_type = 'node' AND field_course_date.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_disclosure field_course_disclosure ON field_course_disclosure.entity_type = 'node' AND field_course_disclosure.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_event_date field_course_event_date ON field_course_event_date.entity_type = 'node' AND field_course_event_date.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_external_url field_course_external_url ON field_course_external_url.entity_type = 'node' AND field_course_external_url.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_format field_course_format ON field_course_format.entity_type = 'node' AND field_course_format.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_taxonomy_term_data field_course_format_tax ON field_course_format_tid = field_course_format_tax.tid LEFT JOIN developlocal.drupal_field_data_field_course_image field_course_image ON field_course_image.entity_type = 'node' AND field_course_image.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_live field_course_live ON field_course_live.entity_type = 'node' AND field_course_live.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_location field_course_location ON field_course_location.entity_type = 'node' AND field_course_location.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_password field_course_password ON field_course_password.entity_type = 'node' AND field_course_password.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_rating field_course_rating ON field_course_rating.entity_type = 'node' AND field_course_rating.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_transcript field_course_transcript ON field_course_transcript.entity_type = 'node' AND field_course_transcript.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_enrollment_requirement_min field_enrollment_requirement_min ON field_enrollment_requirement_min.entity_type = 'node' AND field_enrollment_requirement_min.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_requirements_max field_requirements_max ON field_requirements_max.entity_type = 'node' AND field_requirements_max.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_requirements_min field_requirements_min ON field_requirements_min.entity_type = 'node' AND field_requirements_min.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_show_child_catalog field_show_child_catalog ON field_show_child_catalog.entity_type = 'node' AND field_show_child_catalog.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_show_child_transcript field_show_child_transcript ON field_show_child_transcript.entity_type = 'node' AND field_show_child_transcript.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_og_group_ref og_group_ref ON

g_group_ref.entity_type = 'node' AND og_group_ref.entity_id = dn_course.nid

LEFT JOIN developlocal.drupal_field_data_field_accme_data field_accme_data ON field_accme_data.entity_type = 'node' AND field_accme_data.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_activity_format field_activity_format ON field_activity_format.entity_type = 'node' AND field_activity_format.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_level field_course_level ON field_course_level.entity_type = 'node' AND field_course_level.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_topic field_course_topic ON field_course_topic.entity_type = 'node' AND field_course_topic.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_custom_target_audience field_custom_target_audience ON field_custom_target_audience.entity_type = 'node' AND field_custom_target_audience.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_presenter field_presenter ON field_presenter.entity_type = 'node' AND field_presenter.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_faculty_list field_faculty_list ON field_faculty_list.entity_type = 'node' AND field_faculty_list.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_hotel_link field_hotel_link ON field_hotel_link.entity_type = 'node' AND field_hotel_link.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_hotel_photo field_hotel_photo ON field_hotel_photo.entity_type = 'node' AND field_hotel_photo.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_venue_phone field_venue_phone ON field_venue_phone.entity_type = 'node' AND field_venue_phone.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_course_category field_course_category ON field_course_category.entity_type = 'node' AND field_course_category.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_taxonomy_term_data field_course_category_tax ON field_course_category_tid = field_course_category_tax.tid LEFT JOIN developlocal.drupal_field_data_field_related_courses_view field_related_courses_view ON field_related_courses_view.entity_type = 'node' AND field_related_courses_view.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_field_data_field_show_on_calendar field_show_on_calendar ON field_show_on_calendar.entity_type = 'node' AND field_show_on_calendar.entity_id = dn_course.nid LEFT JOIN developlocal.drupal_course_node cn ON cn.nid = dn_course.nid WHERE (dn_course.type IN ('course', 'group_event_series_event', 'course_imported')) GROUP BY `dn_course`.nid;

Querying field data

SLIDE 29 dw_mysiteprod.dw_user user_id fullname province country employer changed 1 Barry Cuda PA US A, LLC 2018-01-01 2 Abbey Normal NJ US B, Inc. 2018-05-25 Denormalizer will build a denormalized query and dump that data into a separate database. On subsequent runs, it will only insert or update new and changed records based

n the ID and

"changed key".

SLIDE 30 d_chinchilla d_user d_external_table drupal_user drupal_node drupal_profile drupal_field_data drupal_field_data drupal_field_data secret_table external_table Prod DB Data DB

Only the data you want is exposed in the database containing the denormalized data. Third party tools can be configured to connect as a user that only has read access to the data DB. A read-only replica can be used for increased performance.

SLIDE 31 d_user d_chinchilla external_table sendgrid_opens g_ad Data...lake? (denormalizer)

????

“The contents of the data lake stream in from a source to fill the lake, and various users of the lake can come to examine, dive in, or take samples.”

James Dixon, Pentaho

SLIDE 32

Tricks

uid colors 1 [blue, green] 2 [blue, green, red] uid color 1 blue 1 green 2 blue 2 green 2 red We can do some things that should not be done in an

perational database, like

combining multiple values into an array column, to be "unnested" later in a reporting database. item_id p_id 1 [6,7,8] 6 [7,8]

SLIDE 33

What’s the Difference?

Data lake

You don't know what you're

using this data for.

Data can be structured or

unstructured.

Retain all data. Avoids creating

data silos.

Data warehouse

You know what you're using

the data for.

Data typically structured or

processed.

Data is modeled to make

logical sense to the user, or to create “information”.

SLIDE 34

BLT ETL, ELT?

E = Extract T = Transform L = Load B = Bacon

SLIDE 35

Singer

The open-source standard for writing scripts that move data. https://www.singer.io

SLIDE 36

Singer

Taps extract data from any source and write it to a standard stream in a JSON-based format. Targets consume data from taps and do something with it, like load it into a file, API or database.

SLIDE 37

Singer cycle

Tap Target State

1. The tap extracts information from the source
2. The target

takes in data from the tap and transforms it to what the target needs. It outputs the state that the tap also sent

ver.
3. State is

then passed back to the tap, and the process continues at the last replication point. # tap-mysql -c catalog.json -s state.json | target-postgres > state.json

The catalog defines how to replicate the data. We use Drupal to generate these "streams".

# drush singer-json > catalog.json

SLIDE 38

Singer

d_user d_chinchilla external_table sendgrid_opens g_ad Data lake

Athena BigQuery PostgreSQL Redshift

??? Singer

(denormalized)

SLIDE 39

Our solution

Drupal and Singer being used to populate the

data lake

Production database on AWS Aurora provides a

read-only replica of the lake

~15 minutes, Singer extracts and loads new

data from lake of Drupal + other data in MySQL to PostgreSQL

Looker transforms and reports on data
Customer modeling generated from Drupal
100M+ rows being processed

Drupal Singer PostgreSQL

SLIDE 40

Rollout & Results

Customer interviews, mockups, beta

tests for feature design

Pre-built embedded dashboards in all

customer sites

Self-service reporting as an add-on
No price increase
Data warehouse became a

competitive advantage

SLIDE 41

Data Can Be Beautiful

SLIDE 42

Some Section header Second Line Support Desk Heros

Custom reports are now built by non-developers. Often for free! Sometimes in minutes!

SLIDE 43

Have we arrived?

Customers appreciate all the work
Still some things to work out on both ends

SLIDE 44

Join us! Join us!

SLIDE 45

Resources

Singer ETL: https://www.singer.io/
Denormalizer: https://www.drupal.org/project/denormalizer
Drupal Singer: https://www.drupal.org/sandbox/devin/3006817
MySQL tap: https://github.com/singer-io/tap-mysql
PostgreSQL tap:

https://github.com/singer-io/tap-postgres/tree/master/tap_postgres

PostgreSQL target: https://github.com/statsbotco/target-postgres

Some project are reaching maturity. Stay tuned! https://looker.com/blog/introducing-singer
